Steering Column (Service Information): Removal & Installation Lexus GX J150

REMOVAL

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

1. PLACE FRONT WHEELS FACING STRAIGHT AHEAD
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL Disable the auto tilt away function by changing the customize parameter. Refer to «CUSTOMIZE PARAMETERS»(ref-524111-S29830906752013012800000) . NOTE: Record the current customize parameter setting (whether the auto tilt away function is enabled or disabled) in order to restore the current setting after finishing the operation. HINT: Performing the above operation causes the auto tilt away function to be disabled when the engine switch is turned off. Turn the engine switch on (IG). Operate the tilt and telescopic switch to fully extend and lower the steering column assembly. Turn the engine switch off and disconnect the cable from the negative (-) battery terminal. WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. NOTE: w/ Navigation System for HDD: After the ignition switch is turned off, the HDD navigation system requires approximately a minute to record various types of memory and settings. As a result, after turning the ignition switch off, wait a minute or more before disconnecting the cable from the negative (-) battery terminal. When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-524109-S13936590332013012800000) .
3. REMOVE FRONT WHEEL LH
4. REMOVE STEERING WHEEL ASSEMBLY Remove the steering wheel assembly. Refer to «REMOVAL»(ref-524294-S18345652952013012800000) .
5. REMOVE STEERING COLUMN LOWER COVER Remove the 3 screws. Detach the 2 claws and remove the steering column lower cover. NOTE: Do not damage the tilt and telescopic switch.
6. REMOVE STEERING COLUMN UPPER COVER (w/o Driver Monitor Camera) Detach the 4 clips. Detach the claw and remove the steering column upper cover.
7. REMOVE STEERING COLUMN UPPER COVER (w/ Driver Monitor Camera) Detach the 4 clips. Detach the claw and connector, and disconnect remove the steering column upper cover.
8. REMOVE COMBINATION SWITCH ASSEMBLY WITH SPIRAL CABLE SUB-ASSEMBLY Disconnect the connectors from the combination switch with spiral cable. Use pliers to hold the clamp and raise the claw with a screwdriver. Then remove the combination switch assembly with spiral cable sub-assembly from the steering column assembly.
9. REMOVE NO. 1 INSTRUMENT LOWER PANEL AIRBAG ASSEMBLY Remove the instrument lower panel airbag assembly. Refer to «REMOVAL»(ref-524291-S06200618752013012800000) .
10. REMOVE STEERING COLUMN ASSEMBLY Detach the claws and remove the wire harness protector and wire harness. Put matchmarks on the steering actuator and steering column. TEXT IN ILLUSTRATION *1 Matchmark Remove the bolt. Remove the 4 nuts, steering column and steering shaft stopper.
11. REMOVE FRONT NO. 1 FENDER APRON TO FRAME SEAL LH . Refer to «REMOVAL - Step 12»(ref-524246-S36416482222013012800000)
12. DISCONNECT STEERING INTERMEDIATE SHAFT ASSEMBLY Put matchmarks on the steering intermediate shaft and No. 2 steering intermediate shaft. TEXT IN ILLUSTRATION *1 Matchmark
13. REMOVE NO. 1 STEERING COLUMN HOLE COVER SUB-ASSEMBLY Remove the 4 bolts and steering column hole cover from the vehicle.
14. DISCONNECT NO. 2 STEERING INTERMEDIATE SHAFT SUB-ASSEMBLY Put matchmarks on the No. 2 steering intermediate shaft and power steering gear. TEXT IN ILLUSTRATION *1 Matchmark Remove the bolt and No. 2 steering intermediate shaft from the power steering gear.

Scheme 23

Scheme 24

1. REMOVE STEERING LOCK ACTUATOR ASSEMBLY Using a center punch, mark the center of the 2 tapered-head bolts. Using a 3 to 4 mm (0.118 to 0.157 in.) drill, drill a hole in the 2 bolts. Using a screw extractor, remove the 2 bolts and steering lock actuator assembly from the steering column assembly.
2. REMOVE MULTIPLEX TILT AND TELESCOPIC ECU Disconnect the connector. Remove the bolt and ECU.

Scheme 25

1. INSTALL MULTIPLEX TILT AND TELESCOPIC ECU Install the ECU with the bolt. Torque: 2.8 N*m (28 kgf*cm, 24 in.*lbf) Connect the connector. NOTE: The connectors on both ends of the wire harness between the telescopic motor and ECU are the same shape. When installing them, connect the connectors of the same color.
2. INSTALL STEERING LOCK ACTUATOR ASSEMBLY Temporarily install the steering lock actuator assembly with 2 new tapered-head bolts. Tighten the 2 tapered-head bolt until the bolt heads breaks off.

INSTALLATION

1. CONNECT NO. 2 STEERING INTERMEDIATE SHAFT SUB-ASSEMBLY Align the matchmarks on the No. 2 steering intermediate shaft and power steering gear. Install the bolt. Torque: 36 N*m (367 kgf*cm, 27 ft.*lbf)
2. INSTALL NO. 1 STEERING COLUMN HOLE COVER SUB-ASSEMBLY Install the hole cover with the 4 bolts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) NOTE: Do not fold back the boot part of the steering hole cover or extend it excessively. If it is extended excessively, return it to its original position.
3. CONNECT STEERING INTERMEDIATE SHAFT ASSEMBLY Align the matchmarks on the No. 2 steering intermediate shaft assembly and steering intermediate shaft assembly. HINT: Install the steering intermediate shaft to the inside of the vehicle. Install the bolt. Torque: 36 N*m (367 kgf*cm, 27 ft.*lbf)
4. INSTALL FRONT NO. 1 FENDER APRON TO FRAME SEAL LH . Refer to «INSTALLATION - Step 83»(ref-524246-S15625075792013012800000)
5. INSTALL STEERING COLUMN ASSEMBLY Align the matchmarks on the steering intermediate shaft, steering shaft stopper and steering column. Install the steering column with the 4 nuts. Torque: 26 N*m (265 kgf*cm, 19 ft.*lbf) Install the bolts. Torque: 36 N*m (367 kgf*cm, 27 ft.*lbf) Attach the claws to install the wire harness protector and wire harness.
6. INSTALL NO. 1 INSTRUMENT LOWER PANEL AIRBAG ASSEMBLY Install the instrument lower panel airbag assembly. Refer to «INSTALLATION»(ref-524291-S04752285732013012800000) .
7. INSTALL COMBINATION SWITCH ASSEMBLY WITH SPIRAL CABLE SUB-ASSEMBLY Using pliers, grip the claws of the clamp and install the combination switch assembly with spiral cable sub-assembly to the steering column assembly with the clamp. Connect the connectors to the combination switch with spiral cable.
8. INSTALL STEERING COLUMN UPPER COVER (w/ Driver Monitor Camera) Connect the connector and attach the claw to install the steering column upper cover. Attach the 4 clips to install the steering column upper cover to the instrument cluster finish panel.
9. INSTALL STEERING COLUMN UPPER COVER (w/o Driver Monitor Camera) Attach the claw to install the steering column upper cover. Attach the 4 clips to install the steering column upper cover to the instrument cluster finish panel.
10. INSTALL STEERING COLUMN LOWER COVER Attach the 2 claws to install the steering column lower cover. NOTE: Do not damage the tilt and telescopic switch. Install the 3 screws.
11. INSTALL STEERING WHEEL ASSEMBLY Install the steering wheel assembly. Refer to «INSTALLATION»(ref-524294-S24069381492013012800000) .
12. INSTALL FRONT WHEEL LH
13. CHECK FRONT WHEELS FACING STRAIGHT AHEAD
14. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: Reset the auto tilt away function setting to the previous condition by changing the customize parameter. Refer to «CUSTOMIZE PARAMETERS»(ref-524111-S29830906752013012800000) . When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-524109-S13936590332013012800000) .
15. INSPECT SRS WARNING LIGHT Inspect the SRS warning light. Refer to «DIAGNOSIS SYSTEM»(ref-524298-S05940239272013012800000) .

Scheme 26

Scheme 27

Scheme 28

1. PLACE FRONT WHEELS FACING STRAIGHT AHEAD
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. NOTE: w/ Navigation System for HDD: After the ignition switch is turned off, the HDD navigation system requires approximately a minute to record various types of memory and settings. As a result, after turning the ignition switch off, wait a minute or more before disconnecting the cable from the negative (-) battery terminal. When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-524109-S13936590332013012800000) .
3. REMOVE NO. 3 STEERING WHEEL LOWER COVER . Refer to «REMOVAL - Step 2»(ref-524291-S18570803972013012800000)
4. REMOVE NO. 2 STEERING WHEEL LOWER COVER . Refer to «REMOVAL - Step 3»(ref-524291-S18570803972013012800000)
5. REMOVE STEERING PAD ASSEMBLY . Refer to «REMOVAL - Step 4»(ref-524291-S18570803972013012800000)
6. REMOVE STEERING PAD SWITCH ASSEMBLY Disconnect the connector. Remove the 4 bolts. Detach the 2 claws and remove the steering pad switch assembly.
7. REMOVE CRUISE CONTROL MAIN SWITCH . Refer to «REMOVAL - Step 5»(ref-524127-S38197799722013012800000)
8. REMOVE STEERING WHEEL HEATER CONTROL ASSEMBLY See step 5
9. REMOVE STEERING WHEEL ASSEMBLY Remove the steering wheel set nut. Put matchmarks on the steering wheel and main shaft. TEXT IN ILLUSTRATION *a Matchmark *b Hold *c Turn Using SST, remove the steering wheel assembly. SST: 09950-50013 09951-05010 09952-05010 09953-05020 09954-05011

Scheme 29

1. INSPECT STEERING PAD SWITCH ASSEMBLY Inspect the pad switch. TEXT IN ILLUSTRATION *1 Volume+ Switch *2 Volume- Switch *3 Seek+ Switch *4 Seek- Switch *5 MODE Switch *6 Off Hook Switch *7 Voice Switch *8 On Hook Switch *9 Menu Switch *10 ENTER Switch *11 UP/DOWN Up Switch *12 UP/DOWN Down Switch *13 Wide View Front and Side Monitor Switch *14 Distance Control Switch *15 Lane Departure Alert Main Switch - - Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 10 (AU1) - 8 (EAU) No switch pushed 95 to 105 kohms Seek+ switch pushed Below 2.5 ohms Seek- switch pushed 313 to 345 ohms Volume+ switch pushed 950 to 1050 ohms Volume- switch pushed 2955 to 3266 ohms 9 (AU2) - 8 (EAU) No switch pushed 95 to 105 kohms MODE switch pushed Below 2.5 ohms On hook switch pushed 313 to 345 ohms Off hook switch pushed 950 to 1050 ohms Voice switch pushed 2955 to 3266 ohms 2 (DISP) - 3 (GND1) Menu switch pushed Below 2.5 ohms ENTER switch pushed 313 to 345 ohms UP/DOWN Up switch pushed 2955 to 3266 ohms UP/DOWN Down switch pushed 950 to 1050 ohms 7 (+DP) - 3 (GND1) Wide View Front and Side Monitor switch pushed Below 2.5 ohms 4 (DIST) - 6 (ECC) Distance Control switch pushed Below 2.5 ohms Lane Departure Alert Main switch pushed 228 to 252 ohms If the result is not as specified, replace the steering pad switch assembly. Check the illumination. Connect the battery positive (+) lead to terminals IL+2 and the negative (-) lead to terminals EAU and GND1 of the steering pad switch assembly connector. Check that the switch illumination comes on. OK Steering pad switch illumination comes on. If the result is not as specified, replace the steering pad switch assembly.

1. INSTALL STEERING WHEEL ASSEMBLY Align the matchmarks on the steering wheel assembly and steering main shaft assembly. Install the steering wheel assembly set nut. Torque: 50 N*m (510 kgf*cm, 37 ft.*lbf)
2. INSTALL STEERING WHEEL HEATER CONTROL ASSEMBLY See step 1
3. INSTALL CRUISE CONTROL MAIN SWITCH . Refer to «INSTALLATION - Step 1»(ref-524127-S09128958822013012800000)
4. INSTALL STEERING PAD SWITCH ASSEMBLY Attach the 2 claws to install the steering pad switch assembly. Install the 4 screws. Connect the connector.
5. INSTALL STEERING PAD ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-524291-S40537879882013012800000)
6. INSTALL NO. 2 STEERING WHEEL LOWER COVER . Refer to «INSTALLATION - Step 3»(ref-524291-S40537879882013012800000)
7. INSTALL NO. 3 STEERING WHEEL LOWER COVER . Refer to «INSTALLATION - Step 2»(ref-524291-S40537879882013012800000)
8. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-524109-S13936590332013012800000) .
9. INSPECT SRS WARNING LIGHT Inspect the SRS warning light. Refer to «DIAGNOSIS SYSTEM»(ref-524298-S05940239272013012800000) .

Scheme 30

Scheme 31

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. NOTE: w/ Navigation System for HDD: After the ignition switch is turned off, the HDD navigation system requires approximately a minute to record various types of memory and settings. As a result, after turning the ignition switch off, wait a minute or more before disconnecting the cable from the negative (-) battery terminal. When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-524109-S13936590332013012800000) .
2. REMOVE DOOR SCUFF PLATE ASSEMBLY RH . Refer to «REMOVAL - Step 6»(ref-524278-S01507908182013012800000)
3. REMOVE COWL SIDE TRIM BOARD RH . Refer to «REMOVAL - Step 8»(ref-524278-S01507908182013012800000)
4. REMOVE INSTRUMENT PANEL FINISH PANEL END RH . Refer to «REMOVAL - Step 6»(ref-524278-S34350614792013012800000)
5. REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 2»(ref-524278-S34350614792013012800000)
6. REMOVE INSTRUMENT LOWER COVER LH . Refer to «REMOVAL - Step 28»(ref-524278-S01507908182013012800000)
7. REMOVE NO. 2 INSTRUMENT LOWER PANEL AIRBAG ASSEMBLY . Refer to «REMOVAL - Step 7»(ref-524291-S31279910242013012800000)
8. REMOVE INSTRUMENT SIDE PANEL RH . Refer to «REMOVAL - Step 25»(ref-524278-S01507908182013012800000)
9. REMOVE CENTER INSTRUMENT CLUSTER FINISH PANEL GARNISH . Refer to «REMOVAL - Step 26»(ref-524278-S01507908182013012800000)
10. REMOVE NO. 2 INSTRUMENT PANEL REGISTER ASSEMBLY . Refer to «REMOVAL - Step 27»(ref-524278-S01507908182013012800000)
11. REMOVE INSTRUMENT PANEL BOX DOOR COVER . Refer to «REMOVAL - Step 30»(ref-524278-S01507908182013012800000)
12. REMOVE INSTRUMENT PANEL BOX ASSEMBLY . Refer to «REMOVAL - Step 31»(ref-524278-S01507908182013012800000)
13. REMOVE DRIVING SUPPORT SWITCH CONTROL ECU Disconnect the connector. Remove the bolt and driving support switch control ECU.

1. INSTALL DRIVING SUPPORT SWITCH CONTROL ECU Install the driving support switch control ECU with the bolt. Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf) Connect the connector.
2. INSTALL INSTRUMENT PANEL BOX ASSEMBLY . Refer to «INSTALLATION - Step 18»(ref-524278-S42190031612013012800000)
3. INSTALL INSTRUMENT PANEL BOX DOOR COVER . Refer to «INSTALLATION - Step 19»(ref-524278-S42190031612013012800000)
4. INSTALL NO. 2 INSTRUMENT PANEL REGISTER ASSEMBLY . Refer to «INSTALLATION - Step 22»(ref-524278-S42190031612013012800000)
5. INSTALL CENTER INSTRUMENT CLUSTER FINISH PANEL GARNISH . Refer to «INSTALLATION - Step 23»(ref-524278-S42190031612013012800000)
6. INSTALL INSTRUMENT SIDE PANEL RH . Refer to «INSTALLATION - Step 24»(ref-524278-S42190031612013012800000)
7. INSTALL NO. 2 INSTRUMENT LOWER PANEL AIRBAG ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-524291-S37343841702013012800000)
8. INSTALL INSTRUMENT LOWER COVER LH . Refer to «INSTALLATION - Step 21»(ref-524278-S42190031612013012800000)
9. INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 12»(ref-524278-S04260668782013012800000)
10. INSTALL INSTRUMENT PANEL FINISH PANEL END RH . Refer to «INSTALLATION - Step 8»(ref-524278-S04260668782013012800000)
11. INSTALL COWL SIDE TRIM BOARD RH . Refer to «INSTALLATION - Step 12»(ref-524303-S05234985092013012800000)
12. INSTALL DOOR SCUFF PLATE ASSEMBLY RH . Refer to «INSTALLATION - Step 13»(ref-524303-S05234985092013012800000)
13. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-524109-S13936590332013012800000) .
14. CHECK SRS WARNING LIGHT Check the SRS warning light. Refer to «SYSTEM DESCRIPTION»(ref-524298-S38840199062013012800000) .

Scheme 32

Scheme 33

1. REMOVE NO. 1 INSTRUMENT LOWER PANEL AIRBAG ASSEMBLY Remove the instrument lower panel airbag assembly. Refer to «REMOVAL»(ref-524291-S06200618752013012800000) .
2. REMOVE MULTIPLEX TILT AND TELESCOPIC ECU Detach the wire harness clamp. Disconnect the 2 connectors. Remove the bolt and ECU.

1. INSTALL MULTIPLEX TILT AND TELESCOPIC ECU Install the ECU with the bolt. Torque: 2.8 N*m (28 kgf*cm, 24 in.*lbf) Connect the 2 connectors. NOTE: The connectors on both ends of the wire harness between the telescopic motor and ECU are the same shape. When installing them, connect the connectors of the same color. Attach the wire harness clamp.
2. INSTALL NO. 1 INSTRUMENT LOWER PANEL AIRBAG ASSEMBLY Install the instrument lower panel airbag assembly. Refer to «INSTALLATION»(ref-524291-S06241926782013012800000) .
3. INSPECT SRS WARNING LIGHT Inspect the SRS warning light. Refer to «DIAGNOSIS SYSTEM»(ref-524298-S05940239272013012800000) .

Scheme 34

Scheme 35

Scheme 36

1. ALIGN FRONT WHEELS FACING STRAIGHT AHEAD
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL Disable the auto tilt away function by changing the customize parameter. Refer to «CUSTOMIZE PARAMETERS»(ref-524111-S29830906752013012800000) . NOTE: Record the current customize parameter setting (whether the auto tilt away function is enabled or disabled) in order to restore the current setting after finishing the operation. HINT: Performing the above operation causes the auto tilt away function to be disabled when the engine switch is turned off. Turn the engine switch on (IG). Operate the tilt and telescopic switch to fully extend and lower the steering column assembly. Turn the engine switch off and disconnect the cable from the negative (-) battery terminal. WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. NOTE: w/ Navigation System for HDD: After the ignition switch is turned off, the HDD navigation system requires approximately a minute to record various types of memory and settings. As a result, after turning the ignition switch off, wait a minute or more before disconnecting the cable from the negative (-) battery terminal. When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-524109-S13936590332013012800000) .
3. REMOVE STEERING COLUMN LOWER COVER Remove the 3 screws. Detach the 2 claws and remove the steering column lower cover. NOTE: Do not damage the tilt and telescopic switch.
4. REMOVE TILT AND TELESCOPIC SWITCH Disconnect the connector. Detach the claw and pull out the tilt and telescopic switch. NOTE: Pushing on the claw too hard will break the claw.

Scheme 37

1. INSPECT TILT AND TELESCOPIC SWITCH Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 1 (VC) - 3 (MSW) Tilt up 342 to 378 ohms Tilt down 1890.5 to 2089.5 ohms Telescopic contract 750.5 to 829.5 ohms Telescopic extend 152 to 168 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Tilt and Telescopic Manual Switch) If the result is not as specified, replace the tilt and telescopic manual switch.

1. INSTALL TILT AND TELESCOPIC SWITCH Attach the claw to install the tilt and telescopic switch. Connect the connector.
2. INSTALL STEERING COLUMN LOWER COVER Install the 3 screws. Attach the 2 claws to install the steering column lower cover. NOTE: Do not damage the tilt and telescopic switch.
3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: Reset the auto tilt away function setting to the previous condition by changing the customize parameter. Refer to «CUSTOMIZE PARAMETERS»(ref-524111-S29830906752013012800000) . When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-524109-S13936590332013012800000) .
4. INSPECT SRS WARNING LIGHT Inspect the SRS warning light. Refer to «DIAGNOSIS SYSTEM»(ref-524298-S05940239272013012800000) .

Scheme 38

Scheme 39

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. NOTE: w/ Navigation System for HDD: After the ignition switch is turned off, the HDD navigation system requires approximately a minute to record various types of memory and settings. As a result, after turning the ignition switch off, wait a minute or more before disconnecting the cable from the negative (-) battery terminal. When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-524109-S13936590332013012800000) .
2. REMOVE NO. 3 STEERING WHEEL LOWER COVER . Refer to «REMOVAL - Step 2»(ref-524291-S18570803972013012800000)
3. REMOVE NO. 2 STEERING WHEEL LOWER COVER . Refer to «REMOVAL - Step 3»(ref-524291-S18570803972013012800000)
4. REMOVE STEERING PAD ASSEMBLY . Refer to «REMOVAL - Step 4»(ref-524291-S18570803972013012800000)
5. REMOVE STEERING WHEEL HEATER CONTROL ASSEMBLY Disconnect the 2 connectors. Remove the 2 screws and controller.

1. INSTALL STEERING WHEEL HEATER CONTROL ASSEMBLY Install the controller with the 2 screws. Connect the 2 connectors.
2. INSTALL STEERING PAD ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-524291-S40537879882013012800000)
3. INSTALL NO. 2 STEERING WHEEL LOWER COVER . Refer to «INSTALLATION - Step 3»(ref-524291-S40537879882013012800000)
4. INSTALL NO. 3 STEERING WHEEL LOWER COVER . Refer to «INSTALLATION - Step 2»(ref-524291-S40537879882013012800000)
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-524109-S13936590332013012800000) .
6. CHECK SRS WARNING LIGHT Inspect the SRS warning light. Refer to «DIAGNOSIS SYSTEM»(ref-524298-S05940239272013012800000) .
