PRECAUTION
Note. Perform the RESET MEMORY (AT initialization) when replacing the automatic transmission assy, engine assy or ECM (See INITIALIZATION ).
HINT
RESET MEMORY can not be completed by only disconnecting the battery terminal.
DEFINITION OF TERMS
| Term | Definition |
|---|---|
| Monitor description | Description of what the ECM monitors and how it detects malfunctions (monitoring purpose and its details). |
| Related DTCs | A group of diagnostic trouble codes that are output by the ECM based on the same malfunction detection logic. |
| Typical enabling condition | Preconditions that allow the ECM to detect malfunctions. |
| Typical enabling condition | With all preconditions satisfied, the ECM sets the DTC when the monitored value(s) exceeds the malfunction threshold(s). |
| Sequence of operation | The priority order that is applied to monitoring, if multiple sensors and components are used to detect the malfunction. |
| Sequence of operation | While a sensor is being monitored, a sensor or component will not be monitored until the previous monitoring has concluded. |
| Required sensor/components | The sensors and components that are used by the ECM to detect malfunctions. |
| Frequency of operation | The number of times that the ECM checks for malfunctions per driving cycle. |
| Frequency of operation | "Once per driving cycle" means that the ECM detects a malfunction only one time during a single driving cycle. |
| Frequency of operation | "Continuous" means that the ECM a detects malfunction every time when the enabling condition is met. |
| Duration | The minimum time that the ECM must sense a continuous deviation in the monitored value(s) before setting a DTC. This timing begins after the "typical enabling conditions" are met. |
| Malfunction thresholds | Beyond this value, the ECM will conclude that there is a malfunction and set a DTC. |
| MIL operation | MIL illumination timing after a defect is detected. |
| MIL operation | "Immediately" means that the ECM illuminates the MIL the instant the ECM determines that there is a malfunction. |
| MIL operation | "2 driving cycle" means that the ECM illuminates the MIL if the same malfunction is detected again in the 2nd driving cycle. |
| Component operating range | Normal operation range of sensors and solenoids under normal driving conditions. |
| Component operating range | Use these ranges as a reference. |
| Component operating range | They cannot be used to judge if a sensor or solenoid is defective or not. |
DEFINITION TERMS REFERENCE
PART AND SYSTEM NAME LIST
This PART AND SYSTEM NAME LIST REFERENCE TABLE indicates the part names used in this article along with their definitions.
| Part and system name | Definition |
|---|---|
| Toyota HCAC system, Hydrocarbon adsorptive Catalyst (HCAC) system, HC adsorptive three-way catalyst | HC adsorptive three-way catalytic converter |
| Variable Valve Timing sensor, VVT sensor | Camshaft position sensor |
| Variable valve timing system, VVT system | Camshaft timing control system |
| Camshaft timing oil control valve, Oil control valve OCV, VVT, VSV | Camshaft timing oil control valve |
| Variable timing and lift, VVTL | Camshaft timing and lift control |
| Crankshaft position sensor "A" | Crankshaft position sensor |
| Engine speed sensor | Crankshaft position sensor |
| THA | Intake air temperature |
| Knock control module | Engine knock control module |
| Knock sensor | Engine knock sensor |
| Mass or volume air flow circuit | Mass air flow sensor circuit |
| Vacuum sensor | Manifold air pressure sensor |
| Internal control module, Control module, Engine control ECU, PCM | Power train control module |
| FC idle | Deceleration fuel cut |
| Idle air control valve | Idle speed control |
| VSV for CCV, Canister close valve VSV for canister control | Evaporative emissions canister vent valve |
| VSV for EVAP, Vacuum switching valve assembly No.1, EVAP VAV, Purge VSV | Evaporative emissions canister purge valve |
| VSV for pressure switching valve, Bypass VSV | Evaporative emission pressure switching valve |
| Vapor pressure sensor, EVAP pressure sensor, Evaporative emission control system pressure sensor | Fuel tank pressure sensor |
| Charcoal canister | Evaporative emissions canister |
| ORVR system | On-board refueling vapor recovery system |
| Intake manifold runner control | Intake manifold tuning system |
| Intake manifold runner valve, IMRV, IACV (runner valve) | Intake manifold tuning valve |
| Intake control VSV | Intake manifold tuning solenoid valve |
| AFS | Air fuel ratio sensor |
| O2 sensor | Heater oxygen sensor |
| Oxygen sensor pumping current circuit | Oxygen sensor output signal |
| Oxygen sensor reference ground circuit | Oxygen sensor signal ground |
| Accel position sensor | Accelerator pedal position sensor |
| Throttle actuator control motor, Actuator control motor, Electronic throttle motor, Throttle control motor | Electronic throttle actuator |
| Electronic throttle control system, Throttle actuator control system | Electronic throttle control system |
| Throttle/pedal position sensor, Throttle/pedal position switch, Throttle position sensor/switch | Throttle position sensor |
| Turbo press sensor | Turbocharger pressure sensor |
| Turbo VSV | Turbocharger pressure control solenoid valve |
| P/S pressure switch | Power-steering pressure switch |
| VSV for ACM | Active control engine mount |
| Speed sensor, Vehicle speed sensor "A", Speed sensor for skid control ECU | Vehicle speed sensor |
| ATF temperature sensor, Trans, fluid temp, sensor, ATF temperature sensor "A" | Transmission fluid temperature sensor |
| Electronic controlled automatic transmission, ECT | Electronically controlled automatic |
| Intermediate shaft speed sensor "A" | Counter gear speed sensor |
| Output speed sensor | Output shaft speed sensor |
| Input speed sensor, Input turbine speed sensor "A", Speed sensor (NT), Turbine speed sensor | Input turbine speed sensor |
| PNP switch, NSW | Park/neutral position switch |
| Pressure control solenoid | Transmission pressure control solenoid |
| Shift solenoid | Transmission shift solenoid valve |
| Transmission control switch, Shift lock control unit | Shift lock control module |
| Engine immobilizer system, Immobilizer system | Vehicle anti-theft system |
PART AND SYSTEM NAME LIST REFERENCE TABLE
Scheme 221
SYSTEM DIAGRAM
The configuration of the electronic control system in the A750F automatic transmission is (Scheme 222)
Scheme 222
LIST OF DISABLE A MONITOR
HINT
This (Scheme 223) indicates ECM monitoring status for the items in the upper columns if the DTCs in each line on the left are being set.
As for the "X" mark, when the DTC on the left is stored, detection of the DTC in the upper column is not performed.
Scheme 223
Scheme 224
Scheme 225
Scheme 226
Scheme 227
Scheme 228
Scheme 229
- MONITOR DRIVE PATTERN FOR ECT TEST Perform this drive pattern as one method to simulate the detection conditions of the ECT malfunctions. (The DTCs may not be detected due to the actual driving conditions. And some codes may not be detected through this drive pattern.) HINT: Preparation for driving Warm up the engine sufficiently. (Engine coolant temperature is 60°C (140°F) or higher). Drive the vehicle when the atmospheric temperature is -10°C (14°F) or higher. (Malfunction is not detected when the atmospheric temperature is less than -10°C (14°F)). Notice in driving Drive the vehicle through all gears. Stop -> 1st -> 2nd -> 3rd -> 4th -> 5th -> 5th (lock-up ON). Repeat the above driving pattern three times or more. NOTE: The monitor status can be checked using the OBD II scan tool. When using the hand-held tester, monitor status can be found in the "ENHANCED OBD II/DATA LIST" or under "CARB OBD II". In the event that the drive pattern must be interrupted (possibly due to traffic conditions or other factors), the drive pattern can be resumed and, in most cases, the monitor can be completed. Perform this drive pattern on a level road as much as possible and strictly observe the posted speed limits and traffic laws while driving. HINT: *1: Drive at such a speed in the uppermost gear, to engage lock-up. The vehicle can be driven at a speed lower than that in (Scheme 229) under the lock-up condition. NOTE: It is necessary to drive the vehicle for approximately 30 minutes to detect DTC P0711 (ATF temperature sensor malfunction).
NORMAL MODE AND CHECK MODE
The diagnosis system operates in "normal mode" during normal vehicle use. In normal mode, "2-trip detection logic" is used to ensure accurate detection of malfunctions. "Check mode" is also available to technicians as an option. In check mode, "1-trip detection logic" is used for simulating malfunction symptoms and increasing the system's ability to detect malfunctions, including intermittent malfunctions.
Scheme 230
2-TRIP DETECTION LOGIC
When a malfunction is first detected, the malfunction is temporarily stored in the ECM memory (1st trip). If the ignition switch is turned OFF and then ON again, and the same malfunction is detected again, the MIL will illuminate.
FREEZE FRAME DATA
Freeze frame data records the engine conditions (fuel system, calculated load, engine coolant temperature, fuel trim, engine speed, vehicle speed, etc.) when a malfunction is detected. When troubleshooting, freeze frame data can help determine if the vehicle was running or stopped, if the engine was warmed up or not, if the air/fuel ratio was Lean or Rich, and other data from the time the malfunction occurred.
The hand-held tester records freeze frame data in five different instances: 1) 3 times before the DTC is set, 2) once when the DTC is set, and 3) once after the DTC is set. These data can be used to simulate the vehicle's condition around the time when the malfunction occurred. The data may help find the cause of the malfunction, or judge if the DTC is being caused by a temporary malfunction or not.
Scheme 231
DLC3 (Data Link Connector 3)
The vehicle's ECM uses the ISO 15765-4 for communication protocol. The terminal arrangement of the DLC3 complies with SAE J1962 and matches the ISO 15765-4 format.
HINT
Connect the cable of the hand-held tester to the DLC3, turn the ignition switch ON and attempt to use the hand-held tester. If the screen displays UNABLE TO CONNECT TO VEHICLE, a problem exists in the vehicle side or the tester side.
If the communication is normal when the tool is connected to another vehicle, inspect the DLC3 on the original vehicle.
If the communication is still impossible when the tool is connected to another vehicle, the problem is probably in the tool itself. Consult the Service Department listed in the tool's instruction manual.
Scheme 232
| Symbol | Terminal No. | Name | Reference terminal | Result | Condition |
|---|---|---|---|---|---|
| SIL | 7 | Bus "+" line | 5 - Signal ground | Pulse generation | During transmission |
| CG | 4 | Chassis ground | Body ground | Below 1.0 ohms | Always |
| SG | 5 | Signal ground | Body ground | Below 1.0 ohms | Always |
| BAT | 16 | Battery positive | Body ground | 11 to 14 V | Always |
| CANH | 6 | HIGH-level CAN bus line | CANL | 54 to 69 ohms | IG switch OFF |
| CANH | 6 | HIGH-level CAN bus line | Battery positive | 1 M ohms or higher | IG switch OFF |
| CANH | 6 | HIGH-level CAN bus line | CG | 1 k ohms or higher | IG switch OFF |
| CANL | 14 | LOW-level CAN bus line | Battery positive | 1 M ohms or higher | IG switch OFF |
| CANL | 14 | LOW-level CAN bus line | CG | 1 k ohms or higher | IG switch OFF |
SYMBOL TERMINAL SPECIFICATION
CHECK BATTERY VOLTAGE
Battery voltage: 11 to 14 V
If voltage is below 11 V, replace the battery before proceeding.
CHECK MIL
- Check that the MIL illuminates when turning the ignition switch ON. If the MIL does not illuminate, there is a problem in the MIL circuit (refer to «MIL CIRCUIT»(ref-228749-S04697796732007052500000) )
- When the engine is started, the MIL should turn off.
ALL READINESS
For this vehicle, using the hand-held tester allows readiness codes corresponding to all DTCs to be read. When diagnosis (normal or malfunctioning) has been complete, readiness codes are set. Enter the following menus: ENHANCED OBD II/MONITOR STATUS on the hand-held tester.
Scheme 233
- CHECK DTC DTCs which are stored in the ECM can be displayed with the hand-held tester or generic OBD II scan tool. These scan tools can display pending DTCs and current DTCs. Some DTC aren't stored if the ECM doesn't detect a malfunction during consecutive driving. However, the detected malfunction during once driving is stored as pending DTC. Connect the hand-held tester to the Controller Area Network Vehicle Interface Module (CAN VIM). Then connect the CAN VIM to the Data Link Connector 3 (DLC3). Turn the ignition switch ON. Enter the following menus: DIAGNOSIS / ENHANCED OBD II / DTC INFO / CURRENT CODES (or PENDING CODE). Confirm the DTCs and freeze frame data and then write them down. See «DIAGNOSTIC TROUBLE CODE TABLE»(ref-228754-S20843591202006041100000) to confirm the details of the DTCs. NOTE: When simulating a symptom with the scan tool to check for DTCs, use normal mode. For codes on DIAGNOSTIC TROUBLE CODE TABLE subject to "2-trip detection logic", perform the following actions. Turn the ignition switch OFF after the symptom is simulated once. Then repeat the simulation process again. When the problem has been simulated twice, the MIL illuminates and the DTCs are recorded in the ECM.
- CLEAR DTC Connect the hand-held tester to the CAN VIM. Then connect the CAN VIM to the DLC3. Turn the ignition switch ON. Enter the following menus: DIAGNOSIS / ENHANCED OBD II / DTC INFO / CLEAR CODES and press YES.
TYPICAL ENABLING CONDITIONS
ALL
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Ignition switch | ON |
| Battery voltage | 10.5 V or more |
TYPICAL ENABLING CONDITIONS - ALL
TYPICAL MALFUNCTION THRESHOLDS
One of the following conditions is met: Condition (A) or (B)
Condition (A)
| Number of the following signal input at the same time | 2 or more |
|---|---|
| NSW switch | ON |
| R switch | ON |
| D switch | ON |
| 3 switch | ON |
| 2 switch | ON |
TYPICAL ENABLING CONDITIONS - A
Condition (B)
| All of the following conditions are met | |
|---|---|
| NSW switch | OFF |
| R switch | OFF |
| D switch | OFF |
| 3 switch | OFF |
| 2 switch | OFF |
TYPICAL ENABLING CONDITIONS - B
Condition (C)
Both of the following conditions is met: Condition 1 or 2
| 1. One of the following conditions is met | |
|---|---|
| NSW switch | ON |
| R switch | ON |
| 2. One of the following conditions is met | |
| 4 shift position switch | ON |
| L shift position switch | ON |
TYPICAL ENABLING CONDITIONS - C
COMPONENT OPERATING RANGE
| Park/neutral Position switch | The park/neutral position switch sends only one signal to the ECM. |
COMPONENT OPERATING RANGE
Scheme 234
Scheme 235
- DATA LIST HINT: According to the DATA LIST displayed by the hand-held tester, you can read the value of the switch, sensor, actuator and so on without parts removal. Reading the DATA LIST as the first step of troubleshooting is one method to shorten labor time. NOTE: In (Scheme 235), the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the hand-held tester together with the CAN VIM (controller area network vehicle interface module) to the DLC3. Turn the ignition switch to the ON position. Turn on the tester. Select the item "DIAGNOSIS / ENHANCED OBD II / DATA LIST". According to the display on the tester, read the "DATA LIST".
Scheme 236
Scheme 237
Scheme 238
Scheme 239
- INSPECT PARK/NEUTRAL POSITION SWITCH ASSY Jack up the vehicle. Disconnect the park/neutral position switch connector. Measure the resistance according to the value(s) in «PARK/NEUTRAL POSITION SWITCH ASSY»(ref-228754-S42524693232006041100000) when the shift lever is moved to each position. Standard: PARK/NEUTRAL POSITION SWITCH ASSY Shift Position Tester Connection Specified Condition P 2 - 6 and 4 - 5 Below 1.0 ohms Except P 10 k ohms or higher R 2 - 1 Below 1.0 ohms Except R 10 k ohms or higher N 2 - 9 and 4 - 5 Below 1.0 ohms Except N 10 k ohms or higher D and 4 2 - 7 Below 1.0 ohms Except D and 4 10 k ohms or higher 3 2 - 3 Below 1.0 ohms Except 3 10 k ohms or higher 2 and L 2 - 8 Below 1.0 ohms Except 2 and L 10 k ohms or higher NG: REPLACE PARK/NEUTRAL POSITION SWITCH ASSY (SEE «PARK/NEUTRAL POSITION SWITCH ASSY»(ref-228796-S24860972642006041100000) ) OK: Go to next step.
- INSPECT SHIFT LOCK CONTROL ECU SUB-ASSY (TRANSMISSION CONTROL SWITCH) Connect the park/neutral position switch connector. Disconnect the shift lock control ECU connector. Measure the resistance according to the value(s) in (Scheme 237) when the shift lever is moved to each position. Standard: NG: REPLACE SHIFT LOCK CONTROL ECU SUB-ASSY (SEE «FLOOR SHIFT ASSY»(ref-228796-S22743998842006041100000) ) OK: Go to next step.
- CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - ECM) Connect the shift lock control ECU connector. Turn the ignition switch to the ON position, and measure the voltage according to the value(s) in «TESTER CONNECTION SPECIFIED CONDITION TABLE»(ref-228754-S33146097032006041100000) when the shift lever is moved to each position. Standard: PARK/NEUTRAL POSITION SWITCH - ECM Shift Position Tester connection Specified condition P and N E6 - 8 (STAR/NSW) - Body ground Below 2 V Except P and N 10 to 14 V R E8 - 11 (R) - Body ground 10 to 14 V (1) Except R Below 1 V D and 4 E8 - 21 (D) - Body ground 10 to 14 V Except D and 4 Below 1 V 4 E8 - 20 (4) - Body ground 10 to 14 V Except 4 Below 1 V 3 E8 - 19 (3) - Body ground 10 to 14 V Except 3 Below 1 V 2 and L E8 - 10 (2) - Body ground 10 to 14 V Except 2 and L Below 1 V L E8 - 9 (L) - Body ground 10 to 14 V Except L Below 1 V (1) The voltage will drop slightly due to the turning on of the back up light. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-228746-S10052866652006041000000) ) OK: REPLACE ECM (SEE «ECM (2UZ-FE)»(ref-228777-S42069210522006041100000) ).
MONITOR STRATEGY
| Related DTCs | P0710: ATF temperature sensor/Range check (Fluttering) P0712: ATF temperature sensor/Range check (Low resistance) P0713: ATF temperature sensor/Range check (High resistance) |
|---|---|
| Required sensors/Components | ATF temperature sensor (TFT sensor) |
| Frequency of operation | Continuous |
| Duration | 0.5 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
P0710: Range check (Fluttering)
P0712: Range check (Low resistance)
| The monitor will run whenever these DTCs are not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| The typical enabling condition is not available. |
TYPICAL ENABLING CONDITIONS - P0710/P0712
P0713: Range check (High resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Time after engine start | 15 min. or more |
TYPICAL ENABLING CONDITIONS - P0713
P0710: Range check (Fluttering)
| TFT (Transmission fluid temperature) sensor resistance | Less than 79 ohms or More than 156 k ohms |
TYPICAL MALFUNCTION THRESHOLDS - P0710
P0712: Range check (Low resistance)
| TFT (Transmission fluid temperature) sensor resistance | Less than 79 ohms |
TYPICAL MALFUNCTION THRESHOLDS - P0712
P0713: Range check (High resistance)
| TFT (Transmission fluid temperature) sensor resistance | More than 156 k ohms |
TYPICAL MALFUNCTION THRESHOLDS - P0713
| TFT (Transmission fluid temperature) sensor | Atmospheric temperature - approx. 130°C (266°F) |
COMPONENT OPERATING RANGE
Scheme 240
| Related DTCs | P0711: ATF temperature sensor/Rationality check |
|---|---|
| Required sensors/Components | ATF temperature sensor (TFT sensor) |
| Frequency of operation | Continuous |
| Duration | 3 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| TFT (Transmission fluid temperature) sensor circuit | Not circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | Not circuit malfunction |
| IAT (Intake air temperature) sensor circuit | Not circuit malfunction |
| Time after engine start | 21 min. and 40 sec. |
| Driving distance after engine start | 9 km (5.6 mile) or more |
| IAT (12 sec. after starting engine) | 10°C (14°F) or more |
| ECT (12 sec. after starting engine) | 10°C (14°F) or more |
TYPICAL ENABLING CONDITIONS
| TFT (Transmission fluid temperature) | Less than 10°C (50°F) (varies with TFT (Transmission fluid temperature) at engine start) |
TYPICAL MALFUNCTION THRESHOLDS
| Related DTCs | P0717: Speed sensor (NT)/ Verify pulse input |
|---|---|
| Required sensors/Components | Speed sensor (NT), Speed sensor (NO) |
| Frequency of operation | Continuous |
| Duration | 5 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift change | Shift change is completed and before starting next shift change operation |
| ECM selected gear | 4th or 5th |
| Output shaft rpm | 1,000 rpm or more |
| NSW switch | OFF |
| R switch | OFF |
| L switch | OFF |
| Engine | Running |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS
| Sensor signal rpm | Less than 300 rpm |
TYPICAL MALFUNCTION THRESHOLDS
| Speed sensor (NT) | Turbine speed is equal to engine speed when lock-up ON |
COMPONENT OPERATING RANGE
Scheme 241
| Related DTCs | P0722: Speed sensor SP2/Verify pulse input |
|---|---|
| Required sensors/Components | Speed sensor SP2 |
| Frequency of operation | Continuous |
| Duration | 500 output shaft revolution |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Vehicle speed sensor pulse input | 4 |
| Vehicle speed range (4 sec. or more) | 9 km/h (5.59 mph) or more |
| NSW switch | OFF |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS
| Output speed sensor pulse input | No input |
TYPICAL MALFUNCTION THRESHOLDS
Scheme 242
| Related DTCs | P0724: Stop light switch/Rationality |
|---|---|
| Required sensors/Components | Stop light switch, Vehicle speed sensor |
| Frequency of operation | Continuous |
| Duration | GO and STOP 5 times |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
| GO (Vehicle speed is 30 km/h (18.63 mph) or more) | Once |
| STOP (Vehicle speed is less than 3 km/h (1.86 mph)) | Once |
TYPICAL ENABLING CONDITIONS
| Brake switch | Remain ON during GO and STOP 5 times |
TYPICAL MALFUNCTION THRESHOLDS
| Related DTCs | P0748: Shift solenoid valve SL1/Range check |
|---|---|
| Required sensors/Components | Shift solenoid valve SL1 |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Battery voltage | 10 V or more |
| CPU commanded duty | Less than 75% |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS
| Output signal duty | 100% |
TYPICAL MALFUNCTION THRESHOLDS
| Output signal duty | Less than 100% |
COMPONENT OPERATING RANGE
Scheme 243
ALL
| Turbine speed sensor circuit | Not circuit malfunction |
|---|---|
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve S1 circuit | Not circuit malfunction |
| Shift solenoid valve S2 circuit | Not circuit malfunction |
| Shift solenoid valve SR circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | Not circuit malfunction |
| KCS sensor circuit | Not circuit malfunction |
| ETCS (Electric throttle control system) | Not system down |
| Transmission range | "D" |
| ECT | 40°C (104°F) or more |
| Spark advance from Max. retard timing by KCS control | 0°CA or more |
| Engine | Starting |
| Transfer range | "HIGH"*1 |
TYPICAL ENABLING CONDITIONS - ALL
*1: Transfer range "HIGH" (This condition is applied only 4WD)
| Following conditions met*1 | |
|---|---|
| Vehicle speed sensor circuit | Not circuit malfunction |
| Output shaft speed sensor circuit | Not circuit malfunction |
| Transfer output speed | 143 rpm or more |
| NO/NOtf (Transfer input speed/Transfer output speed) | 0.9 to 1.1 |
TYPICAL ENABLING CONDITIONS - TRANSFER RANGE HIGH
OFF malfunction (A)
| ECM selected gear | 1st |
|---|---|
| Vehicle speed | 2 to 40 km/h (1.2 to 24.9 mph) |
| Throttle valve opening angle | 8% or more and 7.0% or more at 2,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - OFF MALFUNCTION (A)
OFF malfunction (B)
| Current ECM selected gear | 5th |
|---|---|
| Last ECM selected gear | 4th |
| Continuous time for ECM selecting 4th gear | 2 sec. or more |
| Actual gear when ECM selected 4th gear | 4th |
TYPICAL ENABLING CONDITIONS - OFF MALFUNCTION (B)
OFF malfunction (C)
| Current ECM selected gear | 5th |
|---|---|
| Last ECM selected gear | 4th |
TYPICAL ENABLING CONDITIONS - OFF MALFUNCTION (C)
ON malfunction (A)
| ECM selected gear | 1st |
|---|---|
| Vehicle speed | 2 to 40 km/h (1.2 to 24.9 mph) |
| Throttle valve opening angle | 7.0% or more at 2,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (A)
ON malfunction (B)
| ECM selected gear | 4th |
|---|---|
| Vehicle speed | 2 km/h (1.2 mph) or more |
| Throttle valve opening angle | 7.0% or more at 2,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (B)
ON malfunction (C)
| ECM selected gear | 3rd |
|---|---|
| Vehicle speed | 2 km/h (1.2 mph) or more |
| Throttle valve opening angle | 7.0% or more at 2,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (C)
ON malfunction (D)
| Current ECM selected gear | 5th |
|---|---|
| Last ECM selected gear | 4th |
| Vehicle speed (During transition from 4th to 5th gear) | Less than 100 km/h (62.2 mph) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (D)
ON malfunction (E)
| ECM selected gear | 5th |
|---|---|
| Engine speed - Turbine speed (NE - NT) (After transition from 4th to 5th gear) | Less than 150 rpm |
| Vehicle speed (After transition from 4th to 5th gear) | Less than 100 km/h (62.2 mph) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (E)
OFF malfunction
All of the following conditions are met: Conditions (A), (B) and (C)
2 detections are necessary per driving cycle
1st detection; temporary flag ON
2nd detection; pending fault code ON
OFF malfunction (A)
| Turbine speed/Output speed | 0.93 to 1.07 |
TYPICAL MALFUNCTION THRESHOLDS - OFF MALFUNCTION (A)
OFF malfunction (B)
| Turbine speed/Output speed | 0.65 to 0.79 |
TYPICAL MALFUNCTION THRESHOLDS - OFF MALFUNCTION (B)
OFF malfunction (C)
| Output record from ECM for 4th -> 5th upshifting | Recorded |
TYPICAL MALFUNCTION THRESHOLDS - OFF MALFUNCTION (C)
ON malfunction
Either of the following conditions is met
- ON malfunction (A) and (B)
- ON malfunction (B) or (C), and ON malfunction (D) or (E)
ON malfunction (A) and (B)
| Turbine speed/Output speed | 3.30 to 7.50 |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION (A) AND (B)
ON malfunction (C)
| Turbine speed/Output speed | 1.91 to 2.35 |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION (C)
ON malfunction (D)
| Turbine speed - Output speed x 4th gear ratio (NT - NO x 4th gear ratio) | 1,000 rpm or more |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION (D)
ON malfunction (E)
| Turbine speed - Output speed x 5th gear ratio (NT - NO x 5th gear ratio) | 1,000 rpm or more |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION (E)
ALL
| Turbine speed sensor circuit | Not circuit malfunction |
|---|---|
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve S1 circuit | Not circuit malfunction |
| Shift solenoid valve S2 circuit | Not circuit malfunction |
| Shift solenoid valve SR circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | Not circuit malfunction |
| KCS sensor circuit | Not circuit malfunction |
| ETCS (Electric throttle control system) | Not system down |
| Transmission range | "D" |
| ECT | 40°C (104°F) or more |
| Spark advance from Max. retard timing by KCS control | 0°CA or more |
| Engine | Starting |
| Transfer range | "HIGH"*1 |
TYPICAL ENABLING CONDITIONS - ALL
*1: Transfer range "HIGH" *1 (This condition is applied only 4WD)
| Following conditions met*1 | |
|---|---|
| Vehicle speed sensor circuit | Not circuit malfunction |
| Output shaft speed sensor circuit | Not circuit malfunction |
| Transfer output speed | 143 rpm or more |
| NO/NOtf (Transfer input speed/Transfer output speed) | 0.9 to 1.1 |
TYPICAL ENABLING CONDITIONS - TRANSFER RANGE HIGH
OFF malfunction (A)
| ECM selected gear | 1st |
|---|---|
| Vehicle speed | 2 to 40 km/h (1.2 to 24.9 mph) |
| Throttle valve opening angle | 7.0% or more at 2,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - OFF MALFUNCTION (A)
OFF malfunction (B)
| ECM selected gear | 2nd |
|---|---|
| Vehicle speed | 2 km/h (1.2 mph) or more |
| Output speed | 2nd -> 1st down shift point or more |
| Throttle valve opening angle | 7.0% or more at 2,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - OFF MALFUNCTION (B)
OFF malfunction (C)
| Current ECM selected gear | 5th |
|---|---|
| Last ECM selected gear | 4th |
| Continuous time for ECM selecting 4th gear | 2 sec. or more |
| Actual gear when ECM selected 4th gear | 4th |
TYPICAL ENABLING CONDITIONS - OFF MALFUNCTION (C)
OFF malfunction (D)
| Current ECM selected gear | 5th |
|---|---|
| Last ECM selected gear | 4th |
TYPICAL ENABLING CONDITIONS - OFF MALFUNCTION (D)
ON malfunction (A)
| ECM selected gear | 1st |
|---|---|
| Vehicle speed | 2 to 40 km/h (1.2 to 24.9 mph) |
| Throttle valve opening angle | 7.0% or more at 2,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (A)
ON malfunction (B)
| ECM selected gear | 4th |
|---|---|
| Vehicle speed | 2 km/h (1.2 mph) or more |
| Throttle valve opening angle | 7.0% or more at 2,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (B)
ON malfunction (C)
| Current ECM selected gear | 5th |
|---|---|
| Last ECM selected gear | 4th |
| Vehicle speed (During transition from 4th to 5th gear) | Less than 100 km/h (62.2 mph) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (C)
ON malfunction (D)
| ECM selected gear | 5th |
|---|---|
| Engine speed - Turbine speed (NE - NT) (After transition from 4th to 5th gear) | Less than 150 rpm |
| Vehicle speed (After transition from 4th to 5th gear) | Less than 100 km/h (62.2 mph) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (D)
OFF malfunction
All of the following conditions are met: Conditions (A), (B), (C) and (D)
2 detections are necessary per driving cycle: 1st detection; temporary flag ON
2nd detection; pending fault code ON
OFF malfunction (A) and (B)
| Turbine speed/Output speed | 3.30 to 7.50 |
TYPICAL MALFUNCTION THRESHOLDS - OFF MALFUNCTION (A) AND (B)
OFF malfunction (C)
| Turbine speed/Output speed | 0.65 to 0.79 |
TYPICAL MALFUNCTION THRESHOLDS - OFF MALFUNCTION (C)
OFF malfunction (D)
| Output record from ECM for 4th -> 5th upshifting | Recorded |
TYPICAL MALFUNCTION THRESHOLDS - OFF MALFUNCTION (D)
ON malfunction
Both of the following conditions are met: ON malfunction (A) or (B), and ON malfunction (C) or (D)
ON malfunction (A)
| Turbine speed/Output speed | 1.91 to 2.35 |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION (A)
ON malfunction (B)
| Turbine speed/Output speed | 1.28 to 1.53 |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION (B)
ON malfunction (C)
| Turbine speed - Output speed x 4th gear ratio (NT - NO x 4th gear ratio) | 1,000 rpm or more |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION (C)
ON malfunction (D)
| Turbine speed - Output speed x 5th gear ratio (NT - NO x 5th gear ratio) | 1,000 rpm or more |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION (D)
ALL
| Turbine speed sensor circuit | Not circuit malfunction |
|---|---|
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve S1 circuit | Not circuit malfunction |
| Shift solenoid valve S2 circuit | Not circuit malfunction |
| Shift solenoid valve SR circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | Not circuit malfunction |
| KCS sensor circuit | Not circuit malfunction |
| ETCS (Electric throttle control system) | Not system down |
| Transmission range | "D" |
| ECT | 40°C (104°F) or more |
| Spark advance from Max. retard timing by KCS control | 0°CA or more |
| Engine | Starting |
| Transfer range | "HIGH"*1 |
TYPICAL ENABLING CONDITIONS - ALL
*1: Transfer range "HIGH" (This condition is applied only 4WD)
| Following conditions met*1 | |
|---|---|
| Vehicle speed sensor circuit | Not circuit malfunction |
| Output shaft speed sensor circuit | Not circuit malfunction |
| Transfer output speed | 143 rpm or more |
| NO/NOtf (Transfer input speed/Transfer output speed) | 0.9 to 1.1 |
TYPICAL ENABLING CONDITIONS - TRANSFER RANGE HIGH
OFF malfunction (A)
| ECM selected gear | 5th |
|---|---|
| Vehicle speed | 2 km/h (1.2 mph) or more |
| Throttle valve opening angle | 7.0% or more at 2,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - OFF MALFUNCTION (A)
OFF malfunction (B)
| Current ECM selected gear | 5th |
|---|---|
| Last ECM selected gear | 4th |
| Continuous time for ECM selecting 4th gear | 2 sec. or more |
TYPICAL ENABLING CONDITIONS - OFF MALFUNCTION (B)
OFF malfunction (C)
| Current ECM selected gear | 5th |
|---|---|
| Last ECM selected gear | 4th |
TYPICAL ENABLING CONDITIONS - OFF MALFUNCTION (C)
ON malfunction
| Current ECM selected gear | 2th |
|---|---|
| Last ECM selected gear | 1st |
| Throttle valve opening angle (During transition from 1st to 2nd gear) | 6.0% or more at 3,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION
OFF malfunction
All of the following conditions are met: Conditions (A), (B) and (C)
2 detections are necessary per driving cycle
- 1st detection; temporary flag ON
- 2nd detection; pending fault code ON
OFF malfunction (A)
| Turbine speed/Output speed | 0.93 to 1.07 |
TYPICAL MALFUNCTION THRESHOLDS - OFF MALFUNCTION (A)
OFF malfunction (B)
| Turbine speed/Output speed | Not change as follow |
|---|---|
| Turbine speed/Output speed | 0.93 to 1.07 |
| 0.65 to 0.79 |
TYPICAL MALFUNCTION THRESHOLDS - OFF MALFUNCTION (B)
OFF malfunction (C)
| Output record from ECM for 4th -> 5th upshifting | Recorded |
TYPICAL MALFUNCTION THRESHOLDS - OFF MALFUNCTION (C)
ON malfunction
2 detections are necessary per driving cycle
- 1st detection; temporary flag ON
- 2nd detection; pending fault code ON
| Turbine speed-Output speed x 1st gear ratio (NT-No x 1st gear ratio) | 150 rpm or more |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION
ALL
| Turbine speed sensor circuit | Not circuit malfunction |
|---|---|
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve S1 circuit | Not circuit malfunction |
| Shift solenoid valve S2 circuit | Not circuit malfunction |
| Shift solenoid valve SR circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | Not circuit malfunction |
| KCS sensor circuit | Not circuit malfunction |
| ETCS (Electric throttle control system) | Not system down |
| Transmission range | "D" |
| ECT | 40°C (104°F) or more |
| Spark advance from Max. retard timing by KCS control | 0°CA or more |
| Engine | Starting |
| Transfer range | "HIGH"*1 |
TYPICAL ENABLING CONDITIONS - ALL
*1: Transfer range "HIGH" (This condition is applied only 4WD)
| Following conditions met*1 | |
|---|---|
| Vehicle speed sensor circuit | Not circuit malfunction |
| Output shaft speed sensor circuit | Not circuit malfunction |
| Transfer output speed | 143 rpm or more |
| NO/NOtf (Transfer input speed/Transfer output speed) | 0.9 to 1.1 |
TYPICAL ENABLING CONDITIONS - TRANSFER RANGE HIGH
ON malfunction (A)
| ECM selected gear | 1st |
|---|---|
| Vehicle speed | 2 to 40 km/h (1.2 to 24.9 mph) |
| Throttle valve opening angle | 7.0% or more at 2,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (A)
ON malfunction (B)
| ECM selected gear | 3rd |
|---|---|
| Vehicle speed | 2 km/h (1.2 mph) or more |
| Throttle valve opening angle | 7.0% or more at 2,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (B)
ON malfunction (C)
| ECM selected gear | 4th |
|---|---|
| Vehicle speed | 2 km/h (1.2 mph) or more |
| Throttle valve opening angle | 7.0% or more at 2,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (C)
ON malfunction (D)
| Current ECM selected gear | 5th |
|---|---|
| Last ECM selected gear | 4th |
| Vehicle speed (During transition from 4th to 5th gear) | Less than 100 km/h (62.2 mph) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (D)
ON malfunction (E)
| ECM selected gear | 5th |
|---|---|
| Engine speed - Turbine speed (NE - NT) (After transition from 4th to 5th gear) | Less than 150 rpm |
| Vehicle speed (After transition from 4th to 5th gear) | Less than 100 km/h (62.2 mph) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (E)
ON malfunction
Both of the following conditions is met
- ON malfunction (A) and (B), or ON malfunction (C)
- ON malfunction (D) or (E)
ON malfunction (A)
| Turbine speed/Output speed | 3.30 to 7.50 |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION (A)
ON malfunction (B)
| Turbine speed/Output speed | 1.28 to 1.53 |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION (B)
ON malfunction (C)
| Turbine speed/Output speed | 0.93 to 1.07 |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION (C)
ON malfunction (D)
| Turbine speed - Output speed x 4th gear ratio (NT - NO x 4th gear ratio) | 1,000 rpm or more |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION (D)
ON malfunction (E)
| Turbine speed - Output speed x 5th gear ratio (NT - NO x 5th gear ratio) | 1,000 rpm or more |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION (E)
| Related DTCs | P0778: Shift solenoid valve SL2/Range check |
|---|---|
| Required sensors/Components | Shift solenoid valve SL2 |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
| The monitor will run whenever this DTC is not present | See LIST OF DISABLE A MONITOR |
|---|---|
| Battery voltage | 10 V or more |
| CPU commanded duty | Less than 75% |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS
| Output signal duty | 100% |
TYPICAL MALFUNCTION THRESHOLDS
| Output signal duty | Less than 100% |
COMPONENT OPERATING RANGE
Scheme 244
ALL
| Turbine speed sensor circuit | Not circuit malfunction |
|---|---|
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve S1 circuit | Not circuit malfunction |
| Shift solenoid valve S2 circuit | Not circuit malfunction |
| Shift solenoid valve SR circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | Not circuit malfunction |
| KCS sensor circuit | Not circuit malfunction |
| ETCS (Electric throttle control system) | Not system down |
| Transmission range | "D" |
| ECT | 40°C (104°F) or more |
| Spark advance from Max. retard timing by KCS control | 0°CA or more |
| Engine | Starting |
| Transfer range | "HIGH"*1 |
TYPICAL ENABLING CONDITIONS - ALL
*1: Transfer range "HIGH" (This condition is applied only 4WD)
| *1Following conditions met | |
|---|---|
| Vehicle speed sensor circuit | Not circuit malfunction |
| Output shaft speed sensor circuit | Not circuit malfunction |
| Transfer output speed | 143 rpm or more |
| NO/NOtf (Transfer input speed/Transfer output speed) | 0.9 to 1.1 |
TYPICAL ENABLING CONDITIONS - TRANSFER RANGE HIGH
Condition (A)
| ECM selected gear | 2nd |
|---|---|
| Vehicle speed | 2 km/h (1.2 mph) or more |
| Output speed | 2nd -> 1st down shift point or more |
| Throttle valve opening angle | 7.0% or more at 2,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - CONDITION (A)
Condition (B)
| ECM selected gear | 4th |
|---|---|
| Vehicle speed | 2 km/h (1.2 mph) or more |
| Throttle valve opening angle | 7.0% or more at 2,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - CONDITION (B)
Condition (C)
| Current ECM selected gear | 5th |
|---|---|
| Last ECM selected gear | 4th |
| Vehicle speed (During transition from 4th to 5th gear) | Less than 100 km/h (62.2 mph) |
TYPICAL ENABLING CONDITIONS - CONDITION (C)
Condition (D)
| ECM selected gear | 5th |
|---|---|
| Engine speed - Turbine speed (NE - NT) (After transition from 4th to 5th gear) | Less than 150 rpm |
| Vehicle speed (After transition from 4th to 5th gear) | Less than 100 km/h (62.2 mph) |
TYPICAL ENABLING CONDITIONS - CONDITION (D)
Both of the following conditions is met
Condition (A), and Condition (B), (C) or (D)
Condition (A)
| Turbine speed/Output speed | 3.30 to 7.50 |
TYPICAL MALFUNCTION THRESHOLDS - CONDITION (A)
Condition (B)
| Turbine speed/Output speed | 1.28 to 1.53 |
TYPICAL MALFUNCTION THRESHOLDS - CONDITION (B)
Condition (C)
| Turbine speed - Output speed x 4th gear ratio (NT - NO x 4th gear ratio) | 1,000 rpm or more |
TYPICAL MALFUNCTION THRESHOLDS - CONDITION (C)
Condition (D)
| Turbine speed - Output speed x 5th gear ratio (NT - NO x 5th gear ratio) | 1,000 rpm or more |
TYPICAL MALFUNCTION THRESHOLDS - CONDITION (D)
Scheme 245
- CHECK OTHER DTCS OUTPUT (IN ADDITION TO PTC P0781) Connect the OBD II scan tool or the hand-held tester to the DLC3. Turn the ignition switch to the ON position and push the OBD II scan tool or the hand-held tester main switch ON. When you use hand-held tester: Select the item "DIAGNOSIS / ENHANCED OBD II / DTC INFO / CURRENT CODES". Read the DTCs using the OBD II scan tool or the hand-held tester. Result: OTHER DTCS OUTPUT (IN ADDITION TO PTC P0781) Display (DTC output) Proceed to Only "P0781" is output A "P0781" and other DTCs B HINT: If any other codes besides "P0781" are output, perform troubleshooting for those DTCs first. B: GO TO «DIAGNOSTIC TROUBLE CODE TABLE»(ref-228754-S20843591202006041100000) A: Go to next step.
- PERFORM ACTIVE TEST BY HAND-HELD TESTER HINT: Performing the ACTIVE TEST using the hand-held tester allows the relay, VSV, actuator and so on to operate without parts removal. Performing the ACTIVE TEST as the first step of troubleshooting is one method to shorten labor time. It is possible to display the DATA LIST during the ACTIVE TEST. Warm up the engine. Turn the ignition switch off. Connect the hand-held tester together with the CAN VIM (controller area network vehicle interface module) to the DLC3. Turn the ignition switch to the ON position. Turn on the tester. Select the item "DIAGNOSIS / ENHANCED OBD II / ACTIVE TEST / SHIFT". According to the display on the tester, perform the "ACTIVE TEST". HINT: While driving, the shift position can be forcibly changed with the hand-held tester. Comparing the shift position commanded by the ACTIVE TEST with the actual shift position enables you to confirm the problem (See «FAIL-SAFE TABLE»(ref-228754-S01632432172006041100000) ). HINT: This test can be conducted when the vehicle speed is 50 km/h (31 mph) or less. The 4th to 5th up-shiftings must be performed with the accelerator pedal released. The 5th to 4th down-shiftings must be performed with the accelerator pedal released. Do not operate the accelerator pedal for at least 2 seconds after shifting and do not shift successively. The shift position commanded by the ECM is shown in the DATA LIST (SHIFT) display on the hand-held tester. OK: Gear position changes in accordance with the tester command. NG: REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSY (SEE «TRANSMISSION VALVE BODY ASSY»(ref-228796-S05223383022006041100000) ) OK: Go to next step.
- CLEAR THE PTC AND RUNNING TEST Clear the DTC, and check DTC again after conducting the "MONITOR DRIVE PATTERN FOR ECT TEST" (See «MONITOR DRIVE PATTERN»(ref-228754-S00981861842006041100000) ). OK: No DTC code NG: REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSY (SEE «TRANSMISSION VALVE BODY ASSY»(ref-228796-S05223383022006041100000) ) OK: END
| Related DTCs | P0818: Transfer neutral position switch/Verify switch cycling |
|---|---|
| Required sensors/Components | Transfer neutral position switch, Vehicle speed sensor |
| Frequency of operation | Continuous |
| Duration | 30 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
TYPICAL ENABLING CONDITION
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Vehicle speed | 25 km/h (15.52 mph) or more |
| Transfer position | High |
| Ignition switch ON and time after OFF to ON | 0.5 sec. or more |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITION
| Transfer neutral switch signal | ON |
TYPICAL MALFUNCTION THRESHOLDS
Scheme 246
Scheme 247
Scheme 248
Scheme 249
Scheme 250
- CHECK HARNESS AND CONNECTOR (TRANSFER INDICATOR SWITCH - BODY GROUND) Disconnect the transfer indicator switch No. 2 connector. Measure the resistance according to the value(s) in «TRANSFER INDICATOR SWITCH - BODY GROUND»(ref-228754-S12844002542006041100000) . Standard: TRANSFER INDICATOR SWITCH - BODY GROUND Tester Connection Specified Condition 2 - Body ground Below 1.0 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-228746-S10052866652006041000000) ) OK: Go to next step.
- INSPECT TRANSFER INDICATOR SWITCH NO. 2 Remove the transfer indicator switch No. 2. Measure the resistance according to the value(s) in «TRANSFER INDICATOR SWITCH NO. 2»(ref-228754-S18577674972006041100000) . Standard: TRANSFER INDICATOR SWITCH NO. 2 Switch position Tester Connection Specified Condition Free 1 - 2 10 k ohms or higher Pushed in Below 1.0 ohms NG: REPLACE TRANSFER INDICATOR SWITCH NO. 2 (TRANSFER NEUTRAL POSITION SWITCH) OK: Go to next step.
- CHECK HARNESS AND CONNECTOR (TRANSFER INDICATOR SWITCH - ECM) Disconnect the connector from the ECM. Measure the resistance according to the value(s) in «TRANSFER INDICATOR SWITCH - ECM (CHECK FOR OPEN)»(ref-228754-S05491079082006041100000) . Standard (Check for open): TRANSFER INDICATOR SWITCH - ECM (CHECK FOR OPEN) Tester Connection Specified Condition E6 - 25 (TFN) - D2 - 1 (TFN) Below 1.0 ohms Measure the resistance according to the value(s) in «TRANSFER INDICATOR SWITCH - ECM (CHECK FOR SHORT)»(ref-228754-S00764571982006041100000) . Standard (Check for short): TRANSFER INDICATOR SWITCH - ECM (CHECK FOR SHORT) Tester Connection Specified Condition E6 - 25 (TFN) - Body ground 10 k ohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-228746-S10052866652006041000000) ) OK: REPLACE ECM (SEE «ECM (2UZ-FE)»(ref-228777-S42069210522006041100000) )
| Related DTCs | P0973: Shift solenoid valve S1/Range check (Low resistance) P0974: Shift solenoid valve S1/Range check (High resistance) |
|---|---|
| Required sensors/Components | Shift solenoid valve S1 |
| Frequency of operation | Continuous |
| Duration | 0.064 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
P0973: Range check (Low resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve S1 | ON |
TYPICAL ENABLING CONDITIONS - P0973
P0974: Range check (High resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve S1 | OFF |
TYPICAL ENABLING CONDITIONS - P0974
P0973: Range check (Low resistance)
| Shift solenoid valve S1 resistance | 8 ohms or less |
TYPICAL MALFUNCTION THRESHOLDS - P0973
P0974: Range check (High resistance)
| Shift solenoid valve S1 resistance | 100 k ohms or more |
TYPICAL MALFUNCTION THRESHOLDS - P0974
| Shift solenoid valve S1 | Resistance: 11 to 15 ohms at 20°C (68°F) |
COMPONENT OPERATING RANGE
Scheme 251
| Related DTCs | P0976: Shift solenoid valve S2/Range check (Low resistance) P0977: Shift solenoid valve S2/Range check (High resistance) |
|---|---|
| Required sensors/Components | Shift solenoid valve S2 |
| Frequency of operation | Continuous |
| Duration | 0.064 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
P0976: Range check (Low resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve S2 | ON |
TYPICAL ENABLING CONDITIONS - P0976
P0977: Range check (High resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve S2 | OFF |
TYPICAL ENABLING CONDITIONS - P0977
P0976: Range check (Low resistance)
| Shift solenoid valve S2 resistance | 8 ohms or less |
TYPICAL MALFUNCTION THRESHOLDS - P0976
P0977: Range check (High resistance)
| Shift solenoid valve S2 resistance | 100 k ohms or more |
TYPICAL MALFUNCTION THRESHOLDS - P0977
| Shift solenoid valve S2 | Resistance: 11 to 15 ohms at 20°C (68°F) |
COMPONENT OPERATING RANGE
Scheme 252
| Related DTCs | P0985: Shift solenoid valve SR/Range check (Low resistance) |
|---|---|
| Related DTCs | P0986: Shift solenoid valve SR/Range check (High resistance) |
| Required sensors/Components | Shift solenoid valve SR |
| Frequency of operation | Continuous |
| Duration | 0.064 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
P0985: Range check (Low resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve SR | ON |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS - P0985
P0986: Range check (High resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve SR | OFF |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS - P0986
P0985: Range check (Low resistance)
| Shift solenoid valve SR resistance | 8 ohms or less |
TYPICAL MALFUNCTION THRESHOLDS - P0985
P0986: Range check (High resistance)
| Shift solenoid valve SR resistance | 100 k ohms or more |
TYPICAL MALFUNCTION THRESHOLDS - P0986
| Shift solenoid valve SR | Resistance: 11 to 15 ohms at 20°C (68°F) |
COMPONENT OPERATING RANGE
Scheme 253
| Related DTCs | P2714: Shift solenoid valve SLT/ON malfunction |
|---|---|
| Required sensors/Components | Shift solenoid valve SLT, Valve body, ATF temperature sensor, Speed sensor (NT), Speed sensor (NO) |
| Frequency of operation | Continuous |
| Duration | Immediate |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
| Turbine speed sensor circuit | Not circuit malfunction |
|---|---|
| Output speed sensor circuit | Not circuit malfunction |
| Transmission Fluid Temperature Sensor circuit | Not circuit malfunction |
| Shift solenoid valve S1 circuit | Not circuit malfunction |
| Shift solenoid valve S2 circuit | Not circuit malfunction |
| Shift solenoid valve SR circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| Shift solenoid valve SLT circuit | Not circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | Not circuit malfunction |
| KCS sensor circuit | Not circuit malfunction |
| ETCS (Electric throttle control system) | Not system down |
| Transmission range | "D" |
| ECT | 40°C (104°F) or more |
| Spark advance from Max. retard timing by KCS control | 0°CA or more |
| Engine | Starting |
| TFT (transmission fluid temperature) | 10°C or more |
| Transfer range | "HIGH"*1 |
TYPICAL ENABLING CONDITIONS
Transfer range "HIGH" (This condition is applied only 4WD)
| *1Following conditions met | |
|---|---|
| Vehicle speed sensor circuit | Not circuit malfunction |
| Output shaft speed sensor circuit | Not circuit malfunction |
| Transfer output speed | 143 rpm or more |
| NO/NOtf (Transfer input speed/Transfer output speed) | 0.9 to 1.1 |
TYPICAL ENABLING CONDITIONS - TRANSFER RANGE HIGH
| Summation of C1 clutch heat generations = sigma (Turbine speed - Output speed x Temporary ratio) | Specified value |
TYPICAL MALFUNCTION THRESHOLDS
Scheme 254
| Related DTCs | P2716: Shift solenoid valve SLT/Range check |
|---|---|
| Required sensors/Components | Shift solenoid valve SLT |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Solenoid current cut status | Not cut |
| Battery voltage | 11 V or more |
| CPU commanded duty ratio to SLT | 19% or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS
| Solenoid status from IC | Fail (Open or short) |
TYPICAL MALFUNCTION THRESHOLDS
Scheme 255
Scheme 256
Scheme 257
- INSPECT TRANSMISSION WIRE (SLT) Disconnect the transmission wire connector from the transmission. Measure the resistance according to the value(s) in «TRANSMISSION WIRE (SLT)»(ref-228754-S29890899722006041100000) . Standard: TRANSMISSION WIRE (SLT) Tester Connection Specified Condition 20°C (68°F) 14 (SLT+) - 6 (SLT-) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in «TRANSMISSION WIRE (SLT) (CHECK FOR SHORT)»(ref-228754-S31669980102006041100000) . Standard (Check for short): TRANSMISSION WIRE (SLT) (CHECK FOR SHORT) Tester Connection Specified Condition 14 (SLT+) - Body ground 10 k ohms or higher 6 (SLT-) - Body ground ohms NG: Go to step 3 . OK: Go to next step.
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transmission. Disconnect the ECM connector. Measure the resistance according to the value(s) in «TRANSMISSION WIRE - ECM»(ref-228754-S28719519912006041100000) . Standard: TRANSMISSION WIRE - ECM Tester Connection Specified Condition 20°C (68°F) E6 - 13 (SLT+) - E6 - 12 (SLT-) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in «TRANSMISSION WIRE - ECM (CHECK FOR SHORT)»(ref-228754-S33760246582006041100000) . Standard (Check for short): TRANSMISSION WIRE - ECM (CHECK FOR SHORT) Tester Connection Specified Condition E6 - 13 (SLT+) - Body ground 10 k ohms or higher E6 - 12 (SLT-) - Body ground NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-228746-S10052866652006041000000) ) OK: REPLACE ECM (SEE «ECM (2UZ-FE)»(ref-228777-S42069210522006041100000) )
- INSPECT SHIFT SOLENOID VALVE (SLT)
Scheme 258
- Remove the shift solenoid valve (SLT).
- Measure the resistance according to the value(s) in «SHIFT SOLENOID VALVE (SLT)»(ref-228754-S17879909012006041100000) . Standard: SHIFT SOLENOID VALVE (SLT) Tester Connection Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6 ohms
- Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK: The solenoid makes an operating sound. NG: REPLACE SHIFT SOLENOID VALVE (SLT) (SEE «TRANSMISSION VALVE BODY ASSY»(ref-228796-S05223383022006041100000) ) OK: REPAIR OR REPLACE TRANSMISSION WIRE (SEE «TRANSMISSION WIRE»(ref-228796-S11517454892006041100000) )
| Related DTCs | P2740: ATF temperature sensor/Range check (Fluttering) |
|---|---|
| Related DTCs | P2742: ATF temperature sensor/Range check (Low resistance) |
| Related DTCs | P2743: ATF temperature sensor/Range check (High resistance) |
| Required sensors/Components | ATF temperature sensor (TFT sensor) |
| Frequency of operation | Continuous |
| Duration | 0.5 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
P2740: Range check (Fluttering)
P2742: Range check (Low resistance)
| The monitor will run whenever these DTCs are not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| The typical enabling condition is not available. |
TYPICAL ENABLING CONDITIONS - P2740
P2743: Range check (High resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Time after engine start | 15 min. or more |
TYPICAL ENABLING CONDITIONS - P2743
P0710: Range check (Fluttering)
| TFT (Transmission fluid temperature) sensor voltage | Less than 0.046 V or More than 4.915 V |
TYPICAL MALFUNCTION THRESHOLDS - P0710
P0712: Range check (Low resistance)
| TFT (Transmission fluid temperature) sensor voltage | Less than 0.046 V |
TYPICAL MALFUNCTION THRESHOLDS - P0712
P0713: Range check (High resistance)
| TFT (Transmission fluid temperature) sensor voltage | More than 4.915 V |
TYPICAL MALFUNCTION THRESHOLDS - P0713
| TFT (Transmission fluid temperature) sensor | Atmospheric temperature - approx. 130°C (266°F) |
COMPONENT OPERATING RANGE
Scheme 259
ALL
| Turbine speed sensor circuit | Not circuit malfunction |
|---|---|
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve S1 circuit | Not circuit malfunction |
| Shift solenoid valve S2 circuit | Not circuit malfunction |
| Shift solenoid valve SR circuit | Not circuit malfunction |
| Torque converter clutch pressure control solenoid circuit | Not circuit malfunction |
| KCS sensor circuit | Not circuit malfunction |
| ETCS (Electric throttle control system) | Not system down |
| Transmission range | "D" |
| ECT (Engine coolant temperature) | 40°C (104°F) or more |
| Spark advance from Max. retard timing by KCS control | 0°CA or more |
| Engine | Starting |
| ECM selected gear | 4th or 5th |
| Vehicle speed | 25 km/h (15.5 mph) or more |
| Shift solenoid valve S1 circuit | Not on malfunction |
| Shift solenoid valve S2 circuit | Not on malfunction |
| Shift solenoid valve SL2 circuit | Not on malfunction |
| 1-2 Shift valve | Not on malfunction |
| Transfer neutral position switch | OFF |
| Transfer range | "HIGH"*1 |
TYPICAL ENABLING CONDITIONS - ALL
*1: Transfer range "HIGH" (This condition is applied only 4WD)
| *1Following conditions met | |
|---|---|
| Vehicle speed sensor circuit | Not circuit malfunction |
| Output shaft speed sensor circuit | Not circuit malfunction |
| Transfer output speed | 143 rpm or more |
| NO/NOtf (Transfer input speed/Transfer output speed) | 0.9 to 1.1 |
TYPICAL ENABLING CONDITIONS - TRANSFER RANGE HIGH
OFF malfunction (A)
| ECM lock-up command | ON (SLU pressure: 513 kpa or more) |
|---|---|
| Vehicle speed | Less than 100 km/h (62.2 mph) |
TYPICAL ENABLING CONDITIONS - OFF MALFUNCTION (A)
OFF malfunction (B)
| ECM selected gear | 2nd |
|---|---|
| Vehicle speed | 2 km/h (1.2 mph) or more |
| Output speed | 2nd -> 1st down shift point or more |
| Throttle valve opening angle | 7.0% or more at 2,000 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS - OFF MALFUNCTION (B)
ON malfunction
| ECM lock-up command | OFF (SLU pressure: less than 4 kpa) |
|---|---|
| Throttle valve opening angle | 9% or more |
| Vehicle speed | Less than 60 km/h (37.3 mph) |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION
OFF malfunction
Both of the following conditions is met: OFF malfunctions (A) and (B)
OFF malfunction (A)
| Engine speed - Turbine speed | 70 rpm or more |
TYPICAL ENABLING CONDITIONS - OFF MALFUNCTION (A)
OFF malfunction (B)
| Turbine speed/Output speed | Not 3.30 to 7.50 |
TYPICAL ENABLING CONDITIONS - OFF MALFUNCTION (B)
ON malfunction
2 detections are necessary per driving cycle
- 1st detection; temporary flag ON
- 2nd detection; pending fault code ON
| Vehicle speed must be under 10 km/h (6.2 mph) once before 2nd detection | |
|---|---|
| Difference between engine speed and turbine speed | Less then 35 rpm |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION
| Related DTCs | P2759: Shift solenoid valve SLU/Range check |
|---|---|
| Required sensors/Components | Shift solenoid valve SLU |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Solenoid current cut status | Not cut |
| Battery voltage | 11 V or more |
| CPU commanded duty ratio to SLU | 19% or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS
| Solenoid status from IC | Fail (Open or short) |
TYPICAL MALFUNCTION THRESHOLDS
Scheme 260
Scheme 261
Scheme 262
Scheme 263
- INSPECT TRANSMISSION WIRE (SLU) Disconnect the transmission wire connector from the transmission. Measure the resistance according to the value(s) in «TRANSMISSION WIRE (SLU)»(ref-228754-S42849443172006041100000) . Standard: TRANSMISSION WIRE (SLU) Tester Connection Specified Condition 20°C (68°F) 13 (SLU+) - 5 (SLU-) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in «TRANSMISSION WIRE (SLU) (CHECK FOR SHORT)»(ref-228754-S27059666872006041100000) . Standard (Check for short): TRANSMISSION WIRE (SLU) (CHECK FOR SHORT) Tester Connection Specified Condition 13 (SLU+) - Body ground 10 k ohms or higher 5 (SLU-) - Body ground NG: Go to step 3 OK: Go to next step.
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transmission. Disconnect the ECM connector. Measure the resistance according to the value(s) in «TRANSMISSION WIRE - ECM»(ref-228754-S33204489972006041100000) . Standard: TRANSMISSION WIRE - ECM Tester Connection Specified Condition 20°C (68°F) E6 - 15 (SLU+) - E6 - 14 (SLU-) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in «TRANSMISSION WIRE - ECM (CHECK FOR SHORT)»(ref-228754-S02957515022006041100000) . Standard (Check for short): TRANSMISSION WIRE - ECM (CHECK FOR SHORT) Tester Connection Specified Condition E6 - 15 (SLU+) - Body ground 10 k ohms or higher E6 - 14 (SLU-) - Body ground ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-228746-S10052866652006041000000) ) OK: REPLACE ECM (SEE «ECM (2UZ-FE)»(ref-228777-S42069210522006041100000) )
- INSPECT SHIFT SOLENOID VALVE (SLU) Remove the shift solenoid valve SLU. Measure the resistance according to the value(s) in «SHIFT SOLENOID VALVE (SLU)»(ref-228754-S36881231322006041100000) . Standard: SHIFT SOLENOID VALVE (SLU) Tester Connection Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6 ohms Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK: The solenoid makes an operating sound. NG: REPLACE SHIFT SOLENOID VALVE (SLU) (SEE «TRANSMISSION VALVE BODY ASSY»(ref-228796-S05223383022006041100000) ) OK: REPAIR OR REPLACE TRANSMISSION WIRE (SEE «TRANSMISSION WIRE»(ref-228796-S11517454892006041100000) )
| Related DTCs | P2772: Transfer L4 position switch/ON malfunction |
|---|---|
| Required sensors/Components | Transfer L4 position switch |
| Frequency of operation | Continuous |
| Duration | ON malfunction (A): 1.8 sec. |
| Duration | ON malfunction (B): 0.5 sec. |
| MIL operation | 1 driving cycle |
| Sequence of operation | None |
MONITOR STRATEGY
ALL
| Output speed sensor circuit | Not circuit malfunction |
|---|---|
| Vehicle speed sensor circuit | Not circuit malfunction |
| Transfer neutral position switch | OFF |
TYPICAL ENABLING CONDITIONS - ALL
ON malfunction (A)
| Output speed (Transfer output speed) | 1,000 to 3,000 rpm |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (A)
ON malfunction (B)
| Output speed (Transfer output speed) | 143 rpm or more |
TYPICAL ENABLING CONDITIONS - ON MALFUNCTION (B)
Both of the following conditions is met: ON malfunctions (A) and (B)
ON malfunction (A)
| L4 switch | ON |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION (A)
ON malfunction (B)
| Actual Transfer gear ratio Transfer input speed/Transfer output speed | 0.9 to 1.1 |
TYPICAL MALFUNCTION THRESHOLDS - ON MALFUNCTION (B)
Scheme 264
Scheme 265
Scheme 266
Scheme 267
Scheme 268
- CHECK HARNESS AND CONNECTOR (TRANSFER INDICATOR SWITCH - BODY GROUND) Disconnect the transfer indicator switch No. 1 connector. Measure the resistance according to the value(s) in «TESTER CONNECTION SPECIFIED CONDITION TABLE»(ref-228754-S30885137792006041100000) . Standard: TRANSFER INDICATOR SWITCH - BODY GROUND Tester Connection Specified Condition 2 - Body ground Below 1.0 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-228746-S10052866652006041000000) ) OK: Go to next step.
- INSPECT TRANSFER INDICATOR SWITCH NO. 1 (L4 POSITION SWITCH) Remove the transfer indicator switch No. 1. Measure the resistance according to the value(s) in «TRANSFER INDICATOR SWITCH NO. 1 (L4 POSITION SWITCH)»(ref-228754-S32455000292006041100000) . Standard: TRANSFER INDICATOR SWITCH NO. 1 (L4 POSITION SWITCH) Switch position Tester Connection Specified Condition Free 1 - 2 10 k ohms or higher Pushed in Below 1.0 ohms NG: REPLACE TRANSFER INDICATOR SWITCH NO. 1 OK: Go to next step.
- CHECK HARNESS AND CONNECTOR (TRANSFER INDICATOR SWITCH - ECM) Disconnect the connector from the ECM. Measure the resistance according to the value(s) in «TRANSFER INDICATOR SWITCH - ECM (CHECK FOR OPEN)»(ref-228754-S27135139292006041100000) . Standard (Check for open): TRANSFER INDICATOR SWITCH - ECM (CHECK FOR OPEN) Tester Connection Specified Condition E7 - 13 (L4) - D2 - 1 (L4) Below 1.0 ohms Measure the resistance according to the value(s) in «TRANSFER INDICATOR SWITCH - ECM (CHECK FOR SHORT)»(ref-228754-S30336117342006041100000) . Standard (Check for short): TRANSFER INDICATOR SWITCH - ECM (CHECK FOR SHORT) Tester Connection Specified Condition E7 - 13 (L4) - Body ground 10 k ohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-228746-S10052866652006041000000) ) OK: REPLACE ECM (SEE «ECM (2UZ-FE)»(ref-228777-S42069210522006041100000) )
