Engine Control System (Diagnostic Codes (P0010 - P0159)): Diagnosis Lexus GS IV

Testing & Diagnostics 11 illustrations ~8361 words

INSPECTION PROCEDURE

HINT

  1. If DTC P0010 is displayed, check the intake camshaft circuit for the right bank VVT system (bank 1).
  2. If DTC P0020 is displayed, check the intake camshaft circuit for the left bank VVT system (bank 2).
  3. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from transmission.
  4. Bank 2 refers to the bank that does not include the No. 1 cylinder.
  5. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

HINT

Abnormal BankTiming Over Advanced (Valve timing is out of specified range)Timing Over Retarded (Valve timing is out of specified range)
Bank 1P0011P0012
Bank 2P0021P0022
  1. If DTC P0011 or P0012 is displayed, check the intake camshaft circuit for the right bank VVT system (bank 1).
  2. If DTC P0021 or P0022 is displayed, check the intake camshaft circuit for the left bank VVT system (bank 2).
  3. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from transmission.
  4. Bank 2 refers to the bank that does not include the No. 1 cylinder.
  5. DTC P0011, P0012, P0021 or P0022 may be set when foreign objects in the engine oil are caught in some parts of the system. The DTC will remain set even if the system returns to normal after a short time. Foreign objects are filtered out by the oil filter.
  6. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 100

Scheme 100: PROCEDURE
Scheme 100: PROCEDURE
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0011, P0012, P0021 OR P0022) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0011, P0012, P0021 or P0022 is output A DTC P0011, P0012, P0021 or P0022 and other DTCs are output B HINT: If any DTCs other than P0011, P0012, P0021 or P0022 are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
  2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR (BANK 1 OR 2)) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [03/2012 - ]»(ref-600412-S34816019962014022400000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Linear (Bank 2). Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. OK Techstream Operation Engine Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1, VVT Change Angle #1, VVT OCV Duty #2 and VVT Change Angle #2]. Refer to «DATA LIST / ACTIVE TEST [03/2012 - ]»(ref-600436-S18321174072014022400000) . Test not possible with the shift lever in P during charge control. Move the shift lever to N to perform test. NG --> See step 4 OK: Go to next step
  3. CHECK WHETHER DTC OUTPUT RECURS (DTC P0011, P0012, P0021 OR P0022) Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the tester on. Clear DTCs. Refer to «DTC CHECK / CLEAR [03/2012 - ]»(ref-600436-S38423165432014022400000) . HINT: P0011, P0021 is output: Clear the DTC without using the Techstream. P0012, P0022 is output: Clear the DTC with using the Techstream. Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [03/2012 - ]»(ref-600412-S34816019962014022400000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0011, P0012, P0021 or P0022 is output B HINT: DTC P0011, P0012, P0021 or P0022 may be stored when foreign objects in the engine oil are caught in some parts of the system. The DTC will remain set even if the system returns to normal after a short time. Those foreign objects may then be captured by the oil filter. B --> See step 4 A --> See step 9
  4. CHECK VALVE TIMING (CHECK FOR LOOSE OR JUMPED TEETH ON TIMING CHAIN) Remove the cylinder head cover sub-assemblies RH and LH. Turn the crankshaft to align the timing marks of the crankshaft. Align the notch of the crankshaft pulley to the "0" position. Check if the timing marks of the camshaft pulley and camshaft bearing cap align. TEXT IN ILLUSTRATION *1 Timing Mark Turn the crankshaft clockwise 360° if the timing marks do not align. Check if they align once again. OK The timing marks of the camshaft pulley and the camshaft bearing cap align when the notch of the crankshaft pulley is in the "0" position. Reinstall the cylinder head cover sub-assemblies RH and LH. NG --> See step 11 OK: Go to next step
  5. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) Inspect the camshaft timing oil control valve assembly for intake camshaft. Refer to «INSPECTION [03/2012 - ]»(ref-600565-S18041605372014022400000) . NG --> See step 12 OK: Go to next step
  6. INSPECT OIL CONTROL VALVE FILTER AND OIL PIPE Remove the No. 1 oil pipe or No. 2 oil pipe. Remove the oil control valve filter RH or oil control valve filter LH. Check that the oil control valve filter and oil pipe are not clogged. OK The oil control valve filter and oil pipe are not clogged. TEXT IN ILLUSTRATION *1 Bank 1 *2 Bank 2 Reinstall the oil control valve filter RH or oil control valve filter LH. Reinstall the No. 1 oil pipe or No. 2 oil pipe. NG --> See step 13 OK: Go to next step
  7. REPLACE CAMSHAFT TIMING GEAR ASSEMBLY Replace the camshaft timing gear assembly (bank 1 or bank 2). Refer to «REMOVAL [03/2012 - ]»(ref-600560-S27631210732014022400000) . HINT: Perform "Inspection After Repair" after replacing the camshaft timing gear assembly. Refer to «INITIALIZATION [03/2012 - ]»(ref-600436-S34722863312014022400000) . NEXT: Go to next step
  8. CHECK WHETHER DTC OUTPUT RECURS (DTC P0011, P0012, P0021 OR P0022) Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the tester on. Clear DTCs. Refer to «DTC CHECK / CLEAR [03/2012 - ]»(ref-600436-S38423165432014022400000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [03/2012 - ]»(ref-600412-S34816019962014022400000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Check the pending DTCs. Result Result Proceed to DTC is not output A DTC P0011, P0012, P0021 or P0022 is output B B --> See step 14 A --> END
  9. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [03/2012 - ]»(ref-600436-S08790525922014022400000)
  10. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [03/2012 - ]»(ref-600436-S04366444592014022400000)
  11. ADJUST VALVE TIMING. Refer to «REASSEMBLY [03/2012 - ]»(ref-600560-S36734244042014022400000)
  12. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT). Refer to «REMOVAL [03/2012 - ]»(ref-600565-S25065442872014022400000)
  13. REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE. Refer to «DISASSEMBLY [03/2012 - ]»(ref-600560-S23552623182014022400000)
  14. REPLACE ECM. Refer to «REMOVAL [03/2012 - ]»(ref-600565-S01816401622014022400000)

HINT

  1. If DTC P0013 is displayed, check the exhaust camshaft circuit for the right bank VVT system (bank 1).
  2. If DTC P0023 is displayed, check the exhaust camshaft circuit for the left bank VVT system (bank 2).
  3. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from transmission.
  4. Bank 2 refers to the bank that does not include the No. 1 cylinder.
  5. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

HINT

Abnormal BankTiming Over Advanced (Valve timing is out of specified range)Timing Over Retarded (Valve timing is out of specified range)
Bank 1P0014P0015
Bank 2P0024P0025
  1. If DTC P0014 or P0015 is displayed, check the exhaust camshaft circuit for the right bank VVT system (bank 1).
  2. If DTC P0024 or P0025 is displayed, check the exhaust camshaft circuit for the left bank VVT system (bank 2).
  3. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from transmission.
  4. Bank 2 refers to the bank that does not include the No. 1 cylinder.
  5. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

HINT

  1. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from transmission.
  2. Bank 2 refers to the bank that does not include the No. 1 cylinder.
  3. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

HINT

  1. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from transmission.
  2. Bank 2 refers to the bank that does not include the No. 1 cylinder.
  3. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

  1. Refer to "Data List / Active Test" [A/F Heater Duty #1 and A/F Heater Duty #2]. Refer to «DATA LIST / ACTIVE TEST [03/2012 - ]»(ref-600436-S18321174072014022400000) .
  2. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from the transmission.
  3. Bank 2 refers to the bank that does not include the No. 1 cylinder.
  4. Sensor 1 refers to the sensor closest to the engine assembly.
  5. Sensor 2 refers to the sensor farthest away from the engine assembly.
  6. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.
  7. Change the fuel injection volume using the Control the Injection Volume for A/F Sensor function provided in the Active Test and monitor the air fuel ratio sensor output voltage. Refer to «INSPECTION PROCEDURE»(ref-600581-S08081601452014022400000) . If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning.

Scheme 101

Scheme 101: PROCEDURE
Scheme 101: PROCEDURE
  1. INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) Inspect the air fuel ratio sensor. Refer to «INSPECTION [03/2012 - ]»(ref-600565-S29917695762014022400000) . HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [03/2012 - ]»(ref-600436-S34722863312014022400000) . NG --> See step 7 OK: Go to next step
  2. CHECK TERMINAL VOLTAGE (+B OF AIR FUEL RATIO SENSOR) Disconnect the air fuel ratio sensor connector. Turn the power switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition F62-2 (+B) - Body ground Power switch on (IG) 11 to 14 V F46-2 (+B) - Body ground Power switch on (IG) 11 to 14 V TEXT IN ILLUSTRATION *1 Bank 1 *2 Bank 2 *a Front view of wire harness connector (to Air Fuel Ratio Sensor) Reconnect the air fuel ratio sensor connector. NG --> See step 5 OK: Go to next step
  3. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F62-1 (HA1A) - F5-26 (HA1A) Always Below 1 ohms F46-1 (HA2A) - F5-20 (HA2A) Always Below 1 ohms F62-1 (HA1A) or F5-26 (HA1A) - Body ground Always 10 kohms or higher F46-1 (HA2A) or F5-20 (HA2A) - Body ground Always 10 kohms or higher Reconnect the air fuel ratio sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (AIR FUEL RATIO SENSOR - ECM) OK: Go to next step
  4. CHECK WHETHER DTC OUTPUT RECURS (DTC P0031, P0032, P0051, P0052, P101D OR P103D) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [03/2012 - ]»(ref-600436-S38423165432014022400000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Read the output pending DTCs using the Techstream. Result Result Proceed to Pending DTC is not output A Pending DTC P0031, P0032, P0051, P0052, P101D or P103D is output B B --> See step 8 A --> See step 9
  5. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - NO. 1 INTEGRATION RELAY) Disconnect the air fuel ratio sensor connector. Remove the No. 1 integration relay from the No. 1 engine room relay block and junction block assembly. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F62-2 (+B) - 1F-4 Always Below 1 ohms F46-2 (+B) - 1F-4 Always Below 1 ohms F62-2 (+B) or 1F-4 - Body ground Always 10 kohms or higher F46-2 (+B) or 1F-4 - Body ground Always 10 kohms or higher Reinstall the No. 1 integration relay. Reconnect the air fuel ratio sensor connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (AIR FUEL RATIO SENSOR - NO. 1 INTEGRATION RELAY) OK: Go to next step
  6. CHECK TERMINAL VOLTAGE (NO. 1 INTEGRATION RELAY) Remove the No. 1 integration relay from the No. 1 engine room relay block and junction block assembly. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition 1D-1 - Body ground Always 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to No. 1 Integration Relay) Reinstall the No. 1 integration relay. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (AUXILIARY BATTERY - NO. 1 INTEGRATION RELAY) OK --> REPLACE NO. 1 INTEGRATION RELAY
  7. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [03/2012 - ]»(ref-600565-S34342609552014022400000)
  8. REPLACE ECM. Refer to «REMOVAL [03/2012 - ]»(ref-600565-S01816401622014022400000)
  9. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [03/2012 - ]»(ref-600436-S08790525922014022400000)

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

  1. Refer to "Data List / Active Test" [O2 Heater B1S2, O2 Heater B2S2, O2 Heater Curr Val B1S2 and O2 Heater Curr Val B2S2]. Refer to «DATA LIST / ACTIVE TEST [03/2012 - ]»(ref-600436-S18321174072014022400000) .
  2. When the values for the Data List items O2 Heater Curr Val B1S2 and O2 Heater Curr Val B2S2 are not 0 A, the heaters are on.
  3. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from the transmission.
  4. Bank 2 refers to the bank that does not include the No. 1 cylinder.
  5. Sensor 1 refers to the sensor closest to the engine assembly.
  6. Sensor 2 refers to the sensor farthest away from the engine assembly.
  7. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.
  8. Change the fuel injection volume using the Control the Injection Volume for A/F Sensor function provided in the Active Test and monitor the heated oxygen sensor output voltage. Refer to «INSPECTION PROCEDURE»(ref-600581-S08081601452014022400000) . If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was moving or stationary, whether the engine was warmed up or not, whether the air fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was moving or stationary, whether the engine was warmed up or not, whether the air fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 102

Scheme 102: PROCEDURE
Scheme 102: PROCEDURE
  1. READ DTC OUTPUT Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0102 is output A DTC P0103 is output B B --> See step 5 A: Go to next step
  2. CHECK HARNESS AND CONNECTOR (POWER SOURCE VOLTAGE) Disconnect the mass air flow meter connector. Turn the power switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition F39-3 (+B) - Body ground Power switch on (IG) 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Mass Air Flow Meter) Reconnect the mass air flow meter connector. NG --> See step 7 OK: Go to next step
  3. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F39-5 (VG) - F5-98 (VG) Always Below 1 ohms F39-4 (E2G) - F5-130 (E2G) Always Below 1 ohms F39-5 (VG) or F5-98 (VG) - Body ground Always 10 kohms or higher Reconnect the mass air flow meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (MASS AIR FLOW METER - ECM) OK: Go to next step
  4. INSPECT MASS AIR FLOW METER Perform On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [03/2012 - ]»(ref-600565-S22448133902014022400000) . Perform Inspection. Refer to «INSPECTION [03/2012 - ]»(ref-600565-S11343572192014022400000) . Inspect the function of the mass air flow meter. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [03/2012 - ]»(ref-600412-S34816019962014022400000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Data List / MAF. Check that the reading of the MAF value changes when the engine is raced. OK The reading changes. HINT: Perform "Inspection After Repair" after replacing the mass air flow meter. Refer to «INITIALIZATION [03/2012 - ]»(ref-600436-S34722863312014022400000) . NG --> See step 8 OK --> See step 9
  5. CHECK HARNESS AND CONNECTOR (SENSOR GROUND) Disconnect the mass air flow meter connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F39-4 (E2G) - Body ground Always Below 1 ohms Reconnect the mass air flow meter connector. NG --> See step 6 OK --> See step 8
  6. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F39-4 (E2G) - F5-130 (E2G) Always Below 1 ohms Reconnect the mass air flow meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (MASS AIR FLOW METER - ECM) OK --> See step 9
  7. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - NO. 1 INTEGRATION RELAY) Disconnect the mass air flow meter connector. Remove the No. 1 integration relay from the No. 1 engine room relay block and junction block assembly. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F39-3 (+B) - 1E-15 Always Below 1 ohms F39-3 (+B) or 1E-15 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (MASS AIR FLOW METER - NO. 1 INTEGRATION RELAY) OK --> REPLACE NO. 1 INTEGRATION RELAY
  8. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [03/2012 - ]»(ref-600565-S07874133562014022400000)
  9. REPLACE ECM. Refer to «REMOVAL [03/2012 - ]»(ref-600565-S01816401622014022400000)

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 103

Scheme 103: PROCEDURE
Scheme 103: PROCEDURE
  1. READ VALUE USING TECHSTREAM (INTAKE AIR) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Intake Air. Read the value displayed on the Techstream. Standard Same as actual intake air temperature. Result Result Proceed to Displayed temperature is -40°C (-40°F) A Displayed temperature is higher than 128°C (262°F) B Same as actual intake air temperature C HINT: If there is an open circuit, the Techstream indicates -40°C (-40°F). If there is a short circuit, the Techstream indicates higher than 128°C (262°F). B --> See step 4 C --> See step 6 A: Go to next step
  2. READ VALUE USING TECHSTREAM (CHECK FOR OPEN IN WIRE HARNESS) Confirm good connection at the mass air flow meter. TEXT IN ILLUSTRATION *1 Mass Air Flow Meter *2 ECM *a Front view of wire harness connector (to Mass Air Flow Meter) - - Disconnect the mass air flow meter connector. Connect terminals THA and E2 of the mass air flow meter connector on the wire harness side. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Intake Air. Read the value displayed on the Techstream. Standard Higher than 128°C (262°F) Reconnect the mass air flow meter connector. NG --> See step 3 OK --> See step 7
  3. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F39-1 (THA) - F5-96 (THA) Always Below 1 ohms F39-2 (E2) - F5-129 (ETHA) Always Below 1 ohms Reconnect the mass air flow meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (MASS AIR FLOW METER - ECM) OK --> See step 8
  4. READ VALUE USING TECHSTREAM (CHECK FOR SHORT IN WIRE HARNESS) Disconnect the mass air flow meter connector. TEXT IN ILLUSTRATION *1 Mass Air Flow Meter *2 ECM Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Intake Air. Read the value displayed on the Techstream. Standard -40°C (-40°F) Reconnect the mass air flow meter connector. NG --> See step 5 OK --> See step 7
  5. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F39-1 (THA) or F5-96 (THA) - Body ground Always 10 kohms or higher Reconnect the mass air flow meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (MASS AIR FLOW METER - ECM) OK --> See step 8
  6. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [03/2012 - ]»(ref-600436-S08790525922014022400000)
  7. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [03/2012 - ]»(ref-600565-S07874133562014022400000)
  8. REPLACE ECM. Refer to «REMOVAL [03/2012 - ]»(ref-600565-S01816401622014022400000)

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 104

Scheme 104: PROCEDURE
Scheme 104: PROCEDURE

Scheme 105

Scheme 105
Scheme 105
  1. READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Read the value displayed on the Techstream. Standard Between 75 and 100°C (167 and 212°F) with warm engine. Result Result Proceed to Displayed temperature is -40°C (-40°F) A Displayed temperature is higher than 135°C (275°F) B Between 75 to 100°C (167 and 212°F) C HINT: If there is an open circuit, the Techstream indicates -40°C (-40°F). If there is a short circuit, the Techstream indicates higher than 135°C (275°F). B --> See step 4 C --> See step 6 A: Go to next step
  2. READ VALUE USING TECHSTREAM (CHECK FOR OPEN IN WIRE HARNESS) Confirm good connection at the engine coolant temperature sensor connector. TEXT IN ILLUSTRATION *1 Engine Coolant Temperature Sensor *2 ECM *a Front view of wire harness connector (to Engine Coolant Temperature Sensor) - - Disconnect the engine coolant temperature sensor connector. Connect terminals 1 and 2 of the engine coolant temperature sensor connector on the wire harness side. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Read the value displayed on the Techstream. Standard Higher than 135°C (275°F) Reconnect the engine coolant temperature sensor connector. HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [03/2012 - ]»(ref-600436-S34722863312014022400000) . NG --> See step 3 OK --> See step 7
  3. CHECK HARNESS AND CONNECTOR (ENGINE COOLANT TEMPERATURE SENSOR - ECM) Disconnect the engine coolant temperature sensor connector. Disconnect the ECM connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F59-2- F5-114 (THW) Always Below 1 ohms F59-1 - F5-122 (ETHW) Always Below 1 ohms Reconnect the engine coolant temperature sensor connector. Reconnect the ECM connectors. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ENGINE COOLANT TEMPERATURE SENSOR - ECM) OK --> See step 8
  4. READ VALUE USING TECHSTREAM (CHECK FOR SHORT IN WIRE HARNESS) Disconnect the engine coolant temperature sensor connector. TEXT IN ILLUSTRATION *1 Engine Coolant Temperature Sensor *2 ECM Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Read the value displayed on the Techstream. Standard -40°C (-40°F) Reconnect the engine coolant temperature sensor connector. HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [03/2012 - ]»(ref-600436-S34722863312014022400000) . NG --> See step 5 OK --> See step 7
  5. CHECK HARNESS AND CONNECTOR (ENGINE COOLANT TEMPERATURE SENSOR - ECM) Disconnect the engine coolant temperature sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F59-2 or F5-114 (THW) - Body ground Always 10 kohms or higher Reconnect the engine coolant temperature sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ENGINE COOLANT TEMPERATURE SENSOR - ECM) OK --> See step 8
  6. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [03/2012 - ]»(ref-600436-S08790525922014022400000)
  7. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [03/2012 - ]»(ref-600565-S11893316872014022400000)
  8. REPLACE ECM. Refer to «REMOVAL [03/2012 - ]»(ref-600565-S01816401622014022400000)

HINT

  1. If any of DTCs P0115, P0117 and P0118 are set simultaneously with DTC P0116, the engine coolant temperature sensor may have an open or a short circuit. Troubleshoot those DTCs first.
  2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

HINT

  1. If any of DTCs P0115, P0117 or P0118 are set simultaneously with DTC P0125, the engine coolant temperature sensor may have an open or a short circuit. Troubleshoot those DTCs first.
  2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

HINT

  1. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.
  2. When the DTC is output, check the engine coolant temperature using the Techstream. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. If the Coolant Temp value is lower than the actual engine coolant temperature, the engine coolant temperature sensor circuit may be malfunctioning. In this case, check the wire harnesses and connectors (and those connections) between the ECM and the engine coolant temperature sensor first.

HINT

Malfunctioning areas can be identified by performing the Control the Injection Volume for A/F Sensor function provided in the Active Test. The Control the Injection Volume for A/F Sensor function can help to determine whether the air fuel ratio sensor, heated oxygen sensor and other potential trouble areas are malfunctioning.

The following instructions describe how to conduct the Control the Injection Volume for A/F Sensor operation using the Techstream.

  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG).
  3. Turn the Techstream on.
  4. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [03/2012 - ]»(ref-600412-S34816019962014022400000) .
  5. Start the engine.
  6. After the engine is warmed up, idle the engine with a coolant temperature of 75°C (167°F) or higher for 5 minutes or more with the shift lever in P. HINT: In order to keep the idling stable, turn off the A/C and all other electric loads and do not perform any shift operations.
  7. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / Gas AF Control / AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2.
  8. Perform the Active Test operation with the engine idling (press the RIGHT or LEFT button to change the fuel injection volume).
  9. Monitor the output voltages of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream.

HINT

  1. Change the fuel injection volume within the range of -12.5% to +12.5%. The injection volume can be changed in fine gradations.
  2. Each sensor reacts in accordance with increases and decreases in the fuel injection volume.
Techstream Display (Sensor)Injection VolumeStatusVoltage
AFS Voltage B1S1 AFS Voltage B2S1 (Air fuel ratio)+12.5%RichBelow 3.1 V
12.5%LeanHigher than 3.4 V
O2S B1S2 O2S B2S2 (Heated oxygen)+12.5%RichHigher than 0.55 V
12.5%LeanBelow 0.4 V

Note. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds.

Case Air Fuel Ratio Sensor (Sensor 1) Output Voltage Heated Oxygen Sensor (Sensor 2) Output Voltage Main Suspected Trouble Area 1 - 2 Air fuel ratio sensor Air fuel ratio sensor heater Air fuel ratio sensor circuit 3 Heated oxygen sensor Heated oxygen sensor heater Heated oxygen sensor circuit 4 Fuel injector assembly Fuel pressure Gas leak from exhaust system (Air fuel ratio extremely rich or lean)

Scheme 106

Scheme 106
Scheme 106

Scheme 107

Scheme 107
Scheme 107

Scheme 108

Scheme 108
Scheme 108

Scheme 109

Scheme 109
Scheme 109
  1. Following the Control the Injection Volume for A/F Sensor procedure enables technicians to check and graph the voltage outputs of both the air fuel ratio and heated oxygen sensors.
  2. To display the graph, enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / Gas AF Control / AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2; and then press the graph button on the Data List view.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

  1. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from transmission.
  2. Bank 2 refers to the bank that does not include the No. 1 cylinder.
  3. Sensor 1 refers to the sensor closest to the engine assembly.
  4. Sensor 2 refers to the sensor farthest away from the engine assembly.
  5. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.
  6. If the OX1B wire from the ECM connector is short-circuited to the +B wire, DTC P0136 will be set.
  7. If the OX2B wire from the ECM connector is short-circuited to the +B wire, DTC P0156 will be set.

Scheme 110

Scheme 110: PROCEDURE
Scheme 110: PROCEDURE
  1. READ DTC OUTPUT (DTC P0136, P0137, P0138, P0139, P013A, P013C, P0156, P0157, P0158 OR P0159) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0138 or P0158 is output A DTC P0137 or P0157 is output B DTC P0136 or P0156 is output C DTC P0139, P013A, P013C or P0159 is output D P0136, P0137, P0138, P0156, P0157 or P0158 and other DTCs are output E HINT: If any DTCs other than P0136, P0137, P0138, P0139, P013A, P013C, P0156, P0157, P0158 and P0159 are output, troubleshoot those DTCs first. B --> See step 6 C --> See step 4 D --> See step 15 E --> See step 24 A: Go to next step
  2. INSPECT HEATED OXYGEN SENSOR (CHECK FOR SHORT) Turn the power switch off and wait for 5 minutes. Disconnect the heated oxygen sensor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2 (+B) - 4 (E2) Always 10 kohms or higher 2 (+B) - 3 (OX1B) Always 10 kohms or higher 2 (+B) - 4 (E2) Always 10 kohms or higher 2 (+B) - 3 (OX2B) Always 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Heated Oxygen Sensor for Bank 1) *b Component without harness connected (Heated Oxygen Sensor for Bank 2) Reconnect the heated oxygen sensor connector. HINT: Perform "Inspection After Repair" after replacing the heated oxygen sensor. Refer to «INITIALIZATION [03/2012 - ]»(ref-600436-S34722863312014022400000) . NG --> See step 22 OK: Go to next step
  3. CHECK HARNESS AND CONNECTOR (CHECK FOR SHORT) Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F5-28 (HT1B) - F5-101 (OX1B) Always 10 kohms or higher F5-22 (HT2B) - F5-133 (OX2B) Always 10 kohms or higher Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (HEATED OXYGEN SENSOR - ECM) OK --> See step 19
  4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [03/2012 - ]»(ref-600412-S34816019962014022400000) . Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with the shift lever in P. HINT: In order to keep the idling stable, turn off the A/C and all other electric loads and do not perform any shift operations. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / All Data / O2S B1S2 or O2S B2S2. Change the fuel injection volume using the Techstream, and monitoring the voltage output of heated oxygen sensor displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12.5% and +12.5%. The injection volume can be changed in fine graduations within the range. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. Standard Fluctuates between 0.4 V or less and 0.55 V or more. NG --> See step 6 OK: Go to next step
  5. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [03/2012 - ]»(ref-600412-S34816019962014022400000) . Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with the shift lever in P. HINT: In order to keep the idling stable, turn off the A/C and all other electric loads and do not perform any shift operations. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / AFS Voltage B1S1 or AFS Voltage B2S1. Change the fuel injection volume using the Techstream, and monitoring the voltage output of air fuel ratio and heated oxygen sensors displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12.5% and +12.5%. The injection volume can be changed in fine graduations within the range. The air fuel ratio sensor is displayed as AFS Voltage B1S1 or AFS Voltage B2S1, and the heated oxygen sensor is displayed as O2S B1S2 or O2S B2S2, on the Techstream. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Result Techstream Display (Sensor) Voltage Variation Proceed to AFS Voltage B1S1 AFS Voltage B2S1 (Air fuel ratio) Alternates between more and less than 3.3 V OK Remains at more than 3.3 V NG Remains at less than 3.3 V NG HINT: A normal heated oxygen sensor voltage (O2S B1S2 or O2S B2S2) reacts in accordance with increases and decreases in fuel injection volumes. When the air fuel ratio sensor voltage remains at either less or more than 3.3 V despite the heated oxygen sensor indicating a normal reaction, the air fuel ratio sensor is malfunctioning. NG --> See step 12 OK --> See step 20
  6. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [03/2012 - ]»(ref-600436-S34722863312014022400000) . NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK: Go to next step
  7. INSPECT HEATED OXYGEN SENSOR (CHECK FOR SHORT) Inspect the heated oxygen sensor. Refer to «INSPECTION [03/2012 - ]»(ref-600565-S24113812362014022400000) . NG --> See step 22 OK: Go to next step
  8. CHECK HARNESS AND CONNECTOR (HEATED OXYGEN SENSOR - ECM) Disconnect the heated oxygen sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition N71-1 (HT1B) - F5-28 (HT1B) Always Below 1 ohms N71-3 (OX1B) - F5-101 (OX1B) Always Below 1 ohms N71-4 (E2) - F5-102 (EX1B) Always Below 1 ohms F53-1 (HT2B) - F5-22 (HT2B) Always Below 1 ohms F53-3 (OX2B) - F5-133 (OX2B) Always Below 1 ohms F53-4 (E2) - F5-134 (EX2B) Always Below 1 ohms N71-1 (HT1B) or F5-28 (HT1B) - Body ground Always 10 kohms or higher N71-3 (OX1B) or F5-101 (OX1B) - Body ground Always 10 kohms or higher F53-1 (HT2B) or F5-22 (HT2B) - Body ground Always 10 kohms or higher F53-3 (OX2B) or F5-133 (OX2B) - Body ground Always 10 kohms or higher Reconnect the heated oxygen sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (HEATED OXYGEN SENSOR - ECM) OK: Go to next step
  9. REPLACE HEATED OXYGEN SENSOR Replace the heated oxygen sensor. Refer to «REMOVAL [03/2012 - ]»(ref-600565-S26113396882014022400000) . HINT: Perform "Inspection After Repair" after replacing the heated oxygen sensor. Refer to «INITIALIZATION [03/2012 - ]»(ref-600436-S34722863312014022400000) . NEXT: Go to next step
  10. PERFORM CONFIRMATION DRIVING PATTERN Refer to the Confirmation Driving Pattern ( «CONFIRMATION DRIVING PATTERN»(ref-600581-S06715339842014022400000) in P0136, P0137, P0138, P0156, P0157 and P0158). NEXT: Go to next step
  11. CHECK WHETHER DTC OUTPUT RECURS (DTC P0136, P0137, P0138, P0156, P0157 OR P0158) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input DTC: P0136, P0137, P0138, P0156, P0157 or P0158. Check that the DTC monitor is NORMAL. If the DTC monitor is INCOMPLETE, perform the driving pattern again but increase the vehicle speed. Result Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0136, P00137, P0138, P0156, P0157 or P0158 is output) B B --> See step 21 A --> END
  12. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL [03/2012 - ]»(ref-600565-S34342609552014022400000) . HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [03/2012 - ]»(ref-600436-S34722863312014022400000) . NEXT: Go to next step
  13. PERFORM CONFIRMATION DRIVING PATTERN Refer to the Confirmation Driving Pattern ( «CONFIRMATION DRIVING PATTERN»(ref-600581-S06715339842014022400000) in P0136, P0137, P0138, P0156, P0157 and P0158). NEXT: Go to next step
  14. CHECK WHETHER DTC OUTPUT RECURS (DTC P0136, P0138, P0156 OR P0158) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input DTC: P0136, P0138, P0156 or P0158. Check that the DTC monitor is NORMAL. If the monitor is INCOMPLETE, perform the driving pattern again but increase the vehicle speed. Result Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0136, P0138, P0156 or P0158 is output) B B --> See step 22 A --> END
  15. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leak. OK No gas leakage. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [03/2012 - ]»(ref-600436-S34722863312014022400000) . NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK: Go to next step
  16. CHECK HARNESS AND CONNECTOR (CHECK FOR SHORT) Turn the power switch off and wait for 5 minutes. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition F5-28 (HT1B) - F5-101 (OX1B) Always 10 kohms or higher F5-22 (HT2B) - F5-133 (OX2B) Always 10 kohms or higher Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  17. PERFORM CONFIRMATION DRIVING PATTERN Perform Confirmation Driving Pattern (P0139, P013A, P013C and P0159). NEXT: Go to next step
  18. READ DTC OUTPUT (DTC P0139, P013A, P013C OR P0159 IS OUTPUT AGAIN) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input DTCs: P0139, P013A, P013C and P0159. Check that the DTC monitor is NORMAL. If the monitor is INCOMPLETE, perform the driving pattern and but increase vehicle speed. Result Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0139, P013A, P013C or P0159 is output) B B --> See step 22 A --> See step 23
  19. REPLACE ECM. Refer to «REMOVAL [03/2012 - ]»(ref-600565-S01816401622014022400000)
  20. CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO (FUEL INJECTOR, FUEL SYSTEM, INTAKE SYSTEM, ETC.). Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1); DTC P0174: System Too Lean (Bank 2); DTC P0175: System Too Rich (Bank 2); DTC P1170: Port Injector Fuel Performance; DTC P117B: Direct Injector Fuel Performance»(ref-600582-S18965104442014022400000)
  21. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [03/2012 - ]»(ref-600565-S34342609552014022400000)
  22. REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL [03/2012 - ]»(ref-600565-S26113396882014022400000)
  23. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [03/2012 - ]»(ref-600436-S08790525922014022400000)
  24. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [03/2012 - ]»(ref-600436-S04366444592014022400000)

More articles — Engine Control System (Diagnostic Codes (P0010 - P0159))
