Lighting System (Interior) (Diagnostics & Circuit Tests): Overview Lexus GS IV

Interior/illumination Lights 20 illustrations ~1552 words

Scheme 1

Scheme 1: ILLUSTRATION

Scheme 2

Scheme 2: ILLUSTRATION

Scheme 3

Scheme 3: ILLUSTRATION

Scheme 4

Scheme 4: ILLUSTRATION

Scheme 5

Scheme 5: ILLUSTRATION

Scheme 6

Scheme 6: SYSTEM DIAGRAM [03/2012 - ]

Scheme 7

Scheme 7
TransmitterReceiverSignalCommunication Line
Main Body ECUFront Multiplex Network Door ECUFront door inside handle illumination light request signalCAN
No. 1 interior illumination light (front door ambient light) request signalCAN
Front door courtesy light request signalCAN
Door mirror foot light request signalCAN
Certification ECUPower switch illumination signalCAN
Luggage Closer MotorMain Body ECULuggage door courtesy light switch signalCAN

COMMUNICATION TABLE

SYSTEM DESCRIPTION [03/2012 - ]

  1. ILLUMINATION CONTROL SYSTEM (Illuminated Entry System) HINT: When inspecting the following functions, make sure that the map light door switch is on. The illuminated entry system has the following control functions: Control Outline Lighting Actuation Area-linked When a registered key is brought within any vehicle exterior detection area around the doors, the items listed to the right turn on. Map light assembly (dome light) Spot light assembly Power switch illumination Door mirror foot lights Door Lock/Unlock-linked When any door is unlocked, the items listed to the right turn on. Map light assembly (dome light) Spot light assembly Power switch illumination Door mirror foot lights Front interior foot lights No. 1 interior illumination light assembly (rear interior foot light) Front door inside handle illumination light assembly Rear door inside handle illumination light assembly No. 1 interior illumination light assembly (front door ambient light) No. 1 interior illumination light assembly (rear door ambient light) Side marker lights (headlight dimmer switch in AUTO position) Clearance lights (headlight dimmer switch in AUTO position) Taillights (headlight dimmer switch in AUTO position) License plate lights (headlight dimmer switch in AUTO position) Clock assembly When all doors are locked, the items listed to the right turn off. Map light assembly (dome light) Spot light assembly Power switch illumination Door mirror foot lights Front interior foot lights No. 1 interior illumination light assembly (rear interior foot light) Front door inside handle illumination light assembly Rear door inside handle illumination light assembly No. 1 interior illumination light assembly (front door ambient light) No. 1 interior illumination light assembly (rear door ambient light) Clock assembly Door Open/Close-linked When any door is opened, the items listed to the right turn on. Map light assembly (dome light) Spot light assembly Power switch illumination Front interior foot lights No. 1 interior illumination light assembly (rear interior foot light) Front door inside handle illumination light assembly Rear door inside handle illumination light assembly No. 1 interior illumination light assembly (front door ambient light) No. 1 interior illumination light assembly (rear door ambient light) When all doors are closed, the items listed to the right turn off. Power Switch-linked When the power switch is turned from on (ACC) or on (IG) to off, the items listed to the right turn on. Map light assembly (dome light) Spot light assembly Power switch illumination Front interior foot lights No. 1 interior illumination light assembly (rear interior foot light) Front door inside handle illumination light assembly Rear door inside handle illumination light assembly No. 1 interior illumination light assembly (front door ambient light) No. 1 interior illumination light assembly (rear door ambient light) When the power switch is turned from off to on (ACC) or on (IG) the items listed to the right turn on. Front interior foot lights No. 1 interior illumination light assembly (rear interior foot light) Front door inside handle illumination light assembly Rear door inside handle illumination light assembly No. 1 interior illumination light assembly (front door ambient light) No. 1 interior illumination light assembly (rear door ambient light)
  2. BATTERY SAVING CONTROL SYSTEM When the interior lights have been illuminated for approximately 20 minutes with any of the doors ajar and the power switch off, this function turns off all of the interior lights in order to prevent the auxiliary battery from being depleted. HINT: When the light control operation conditions are met, battery saving control is canceled.

OPERATION CHECK [03/2012 - ]

  1. INSPECT INTERIOR LIGHT CONTROL OPERATION NOTE: Perform this inspection with the customizable parameters set to the initial settings. HINT: When inspecting the following functions, make sure that the map light door switch is on. The interior light control illuminates the lights below. Map light assembly (dome light) Spot light assembly Power switch illumination The operation and operating condition of this control are described below. Operation Condition Lights fade in and illuminate constantly Any door is opened when all the doors are closed. Lights illuminate for 15 seconds, and then fade out When any of the following conditions is met: The key is brought within any vehicle exterior detection area when the power switch is off and all the doors are closed.* Any door is unlocked when the power switch is off and all the doors are closed and locked. The power switch is turned from on (ACC) to off when all doors are closed. All the doors are closed when any door is opened and the power switch is off. Lights fade out immediately When either of the following conditions is met: The power switch is turned from off to on (ACC) when all the doors are closed. All the doors are locked when the power switch is off, all the doors are closed and any door is unlocked. *: When the lights are on, if the key leaves all of actuation areas around the doors, after approximately 3 seconds, the lights fade out.
  2. INSPECT INTERIOR FOOT LIGHT AND DOOR ILLUMINATION CONTROL OPERATION NOTE: Perform this inspection with the customizable parameters set to the initial settings. The interior foot light and door illumination control illuminates the lights below. Front interior foot lights No. 1 interior illumination light assembly (rear interior foot light) Front door inside handle illumination light assembly Rear door inside handle illumination light assembly No. 1 interior illumination light assembly (front door ambient light) No. 1 interior illumination light assembly (rear door ambient light) The operation and operating condition of this control are described below. Operation Condition Lights fade in and illuminate constantly Any door is opened when all the doors are closed. The power switch is turned from off to on (IG). Lights illuminate for 15 seconds, and then fade out When any of the following conditions is met: Any door is unlocked when the power switch is off and all the doors are closed and locked. The power switch is turned from on (ACC) to off when all doors are closed. All the doors are closed when any door is opened and the power switch is off. Lights fade out immediately All the doors are locked when the power switch is off, all the doors are closed and any door is unlocked.
  3. INSPECT DOOR MIRROR FOOT LIGHT CONTROL OPERATION NOTE: Perform this inspection with the customizable parameters set to the initial settings. The door mirror foot light control illuminates the door mirror foot lights. The operation and operating condition of this control are described below. Operation Condition Lights illuminate for 15 seconds, and then fade out When any of the following conditions is met: The key is brought within any vehicle exterior detection area when the power switch is off and all the doors are closed.* Any door is unlocked when the power switch is off and all the doors are closed and locked. Lights fade out immediately All the doors are locked when the power switch is off, all the doors are closed and any door is unlocked. *: When the lights are on, if the key leaves all of actuation areas around the doors, after approximately 3 seconds, the lights fade out.
  4. INSPECT EXTERIOR LIGHT CONTROL OPERATION NOTE: Perform this inspection with the customizable parameters set to the initial settings. The exterior light control illuminates the lights below. Side marker lights Clearance lights Taillights License plate lights The operation and operating condition of this control are described below. Operation Condition Lights illuminate for 15 seconds, and then fade out When either of the following conditions is met: Headlight dimmer switch is in the AUTO position and the doors are unlocked by a wireless unlock operation Headlight dimmer switch is in the AUTO position and the doors are unlocked by an entry unlock operation
  5. BATTERY SAVING CONTROL SYSTEM OPERATION Check that when any of the doors is ajar and the power switch is off, all of the interior lights turn off within approximately 20 minutes. HINT: When the light control operation conditions are met, battery saving control is canceled.

DESCRIPTION

This circuit detects whether the power switch is on (IG) or off, and sends this information to the main body ECU.

Scheme 8

Scheme 8: WIRING DIAGRAM

This circuit detects whether the power switch is on (ACC) or off, and sends this information to the main body ECU.

Scheme 9

Scheme 9: WIRING DIAGRAM

The main body ECU receives a door open or closed signal from each door courtesy light switch.

Scheme 10

Scheme 10: WIRING DIAGRAM

The main body ECU controls the front courtesy lights.

Scheme 11

Scheme 11: WIRING DIAGRAM

The main body ECU controls the map light and spot light.

Scheme 12

Scheme 12: WIRING DIAGRAM

The main body ECU controls the DOME CUT relay.

Scheme 13

Scheme 13: WIRING DIAGRAM

The main body ECU controls the instrument panel illumination lights.

Scheme 14

Scheme 14: WIRING DIAGRAM

The illuminated entry system controls the power switch illumination.

Scheme 15

Scheme 15: WIRING DIAGRAM

The front multiplex network door ECU controls the door mirror foot lights.

Scheme 16

Scheme 16: WIRING DIAGRAM

The main body ECU and front multiplex network door ECU controls the interior illumination lights.

Scheme 17

Scheme 17: WIRING DIAGRAM

Scheme 18

Scheme 18

The main body ECU detects the condition of each door unlock detection switch.

Scheme 19

Scheme 19: WIRING DIAGRAM

The main body ECU receives a luggage compartment door open or closed signal from luggage door courtesy light switch.

Scheme 20

Scheme 20: WIRING DIAGRAM
