HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - ]
HINT
- Use the following procedure to troubleshoot the lighting system.
- *: Use the Techstream.
- VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
- INSPECT AUXILIARY BATTERY VOLTAGE Standard voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the auxiliary battery before proceeding. NEXT: Go to next step
- CHECK COMMUNICATION FUNCTION OF CAN COMMUNICATION SYSTEM* Use the Techstream to check if the CAN communication system is functioning normally. Refer to «PRECAUTION [03/2012 - ]»(ref-600588-S03798215262014022400000) . RESULT Result Proceed to CAN DTC is not output A CAN DTC is output B B --> Go to CAN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - ]»(ref-600588-S38298476802014022400000) A: Go to next step
- PROBLEM SYMPTOMS TABLE Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE [03/2012 - ]»(ref-600423-S18953902322014022400000) . RESULT Result Proceed to Fault is not listed in Problem Symptoms Table A Fault is listed in Problem Symptoms Table B B --> ADJUST, REPAIR OR REPLACE IN ACCORDANCE WITH PROBLEM SYMPTOMS TABLE A: Go to next step
- OVERALL ANALYSIS AND TROUBLESHOOTING* Operation Check. Refer to «OPERATION CHECK [03/2012 - ]»(ref-600423-S09518322902014022400000) Terminals of ECU. Refer to «TERMINALS OF ECU [03/2012 - ]»(ref-600423-S04291532562014022400000) Data List / Active Test. Refer to «DATA LIST / ACTIVE TEST [03/2012 - ]»(ref-600423-S11851139912014022400000) NEXT: Go to next step
- ADJUST, REPAIR OR REPLACE NEXT: Go to next step
- CONFIRMATION TEST NEXT --> END
PROBLEM SYMPTOMS TABLE [03/2012 - ]
HINT
Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
| Symptom | Suspected Area | See |
|---|---|---|
| Illuminated entry system does not operate. | CAN communication system | Refer to HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - ] |
| Smart access system with push-button start (for Entry Function) | Refer to HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - ] | |
| Luggage compartment door closer system (w/ Power Trunk Lid System) | Refer to HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - ] | |
| Lighting system (EXT) | Refer to HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - ] | |
| DOME fuse | ||
| Interior light circuit | Refer to Interior Light Circuit | |
| Door unlock detection switch circuit | Refer to Door Unlock Detection Switch Circuit | |
| Door courtesy switch circuit | Refer to Door Courtesy Switch Circuit | |
| Luggage compartment door courtesy switch circuit | Refer to Luggage Compartment Door Courtesy Switch Circuit | |
| IG signal circuit | Refer to IG Signal Circuit | |
| ACC signal circuit | Refer to ACC Signal Circuit | |
| Interior light auto cut circuit | Refer to Interior Light Auto Cut Circuit | |
| Harness or connector | ||
| Main body ECU (Multiplex network body ECU) | Refer to REMOVAL [03/2012 - ] |
ILLUMINATED ENTRY SYSTEM
| Symptom | Suspected Area | See |
|---|---|---|
| Map light assembly does not illuminate. | Map light assembly | Refer to INSPECTION [03/2012 - ] |
| Harness or connector |
MAP LIGHT ASSEMBLY
| Symptom | Suspected Area | See |
|---|---|---|
| Spot light assembly does not illuminate. | Spot light assembly | Refer to INSPECTION [03/2012 - ] |
| Harness or connector |
SPOT LIGHT ASSEMBLY
| Symptom | Suspected Area | See |
|---|---|---|
| No. 1 luggage compartment light assembly does not illuminate. | No. 1 luggage compartment light bulb | Refer to REMOVAL [03/2012 - ] |
| No. 1 luggage compartment light assembly | Refer to REMOVAL [03/2012 - ] | |
| Luggage compartment door closer system | Refer to HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - ] | |
| Harness or connector |
NO. 1 LUGGAGE COMPARTMENT LIGHT ASSEMBLY (W/ POWER TRUNK LID SYSTEM)
| Symptom | Suspected Area | See |
|---|---|---|
| No. 1 luggage compartment light assembly does not illuminate. | No. 1 luggage compartment light bulb | Refer to REMOVAL [03/2012 - ] |
| No. 1 luggage compartment light assembly | Refer to REMOVAL [03/2012 - ] | |
| Luggage compartment door courtesy switch circuit | Refer to Luggage Compartment Door Courtesy Switch Circuit | |
| Harness or connector | ||
| Main body ECU (Multiplex network body ECU) | Refer to REMOVAL [03/2012 - ] |
NO. 1 LUGGAGE COMPARTMENT LIGHT ASSEMBLY (W/O POWER TRUNK LID SYSTEM)
| Symptom | Suspected Area | See |
|---|---|---|
| Vanity light assembly does not illuminate. | Vanity light bulb | Refer to REMOVAL [03/2012 - ] |
| Visor assembly | Refer to REMOVAL [03/2012 - ] | |
| Harness or connector |
VANITY LIGHT ASSEMBLY
| Symptom | Suspected Area | See |
|---|---|---|
| Front courtesy light assembly does not illuminate. | CAN communication system | Refer to HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - ] |
| Front courtesy light bulb | Refer to REMOVAL [03/2012 - ] | |
| Front courtesy light assembly | Refer to REMOVAL [03/2012 - ] | |
| Door courtesy switch circuit | Refer to Door Courtesy Switch Circuit | |
| Door courtesy light Circuit | Refer to Door Courtesy Light Circuit | |
| Harness or connector | ||
| Front multiplex network door ECU LH | Refer to DISASSEMBLY [03/2012 - ] | |
| Front multiplex network door ECU RH | Refer to DISASSEMBLY [03/2012 - ] | |
| Main body ECU (Multiplex network body ECU) | Refer to REMOVAL [03/2012 - ] |
FRONT COURTESY LIGHT ASSEMBLY
| Symptom | Suspected Area | See. |
|---|---|---|
| Rear courtesy light assembly does not illuminate. | Rear courtesy light bulb | Refer to REMOVAL [03/2012 - ] |
| Door courtesy switch circuit | Refer to Door Courtesy Switch Circuit | |
| Rear courtesy light assembly | Refer to REMOVAL [03/2012 - ] | |
| Harness or connector | ||
| Main body ECU (Multiplex network body ECU) | Refer to REMOVAL [03/2012 - ] |
REAR COURTESY LIGHT ASSEMBLY
| Symptom | Suspected Area | See |
|---|---|---|
| Glove box light does not illuminate. | Harness or connector |
GLOVE BOX LIGHT
| Symptom | Suspected Area | See |
|---|---|---|
| Console box illumination light assembly does not illuminate. | Console box illumination light assembly | Refer to INSPECTION [03/2012 - ] |
| Harness or connector |
CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
| Symptom | Suspected Area | See |
|---|---|---|
| Front door inside handle illumination light assembly and No. 1 interior illumination light assembly (front door ambient light) do not illuminate. | Illumination circuit | Refer to Illumination Circuit |
| Front multiplex network door ECU LH | Refer to DISASSEMBLY [03/2012 - ] | |
| Front multiplex network door ECU RH | Refer to DISASSEMBLY [03/2012 - ] | |
| Main body ECU (Multiplex network body ECU) | Refer to REMOVAL [03/2012 - ] | |
| Rear door inside handle illumination light assembly, No. 1 interior illumination light assembly (rear door ambient light), front interior foot lights and No. 1 interior illumination light assembly (rear interior foot light) do not illuminate. | Illumination circuit | Refer to Illumination Circuit |
| Main body ECU (Multiplex network body ECU) | Refer to REMOVAL [03/2012 - ] | |
| Rear door inside handle illumination light assembly does not illuminate. | Rear door inside handle illumination light assembly | Refer to INSPECTION [03/2012 - ] |
| Harness or connector | ||
| No. 1 interior illumination light assembly (rear door ambient light) does not illuminate. | No. 1 interior illumination light assembly (rear door ambient light) | Refer to INSPECTION [03/2012 - ] |
| Harness or connector | ||
| No. 1 interior illumination light assembly (rear interior foot light) does not illuminate. | No. 1 interior illumination light assembly (rear interior foot light) | Refer to INSPECTION [03/2012 - ] |
| Harness or connector | ||
| Front interior foot lights do not illuminate. | Harness or connector |
INTERIOR FOOT LIGHT AND DOOR ILLUMINATION
| Symptom | Suspected Area | See |
|---|---|---|
| Door mirror foot light does not illuminate. | CAN communication system | Refer to HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - ] |
| Door mirror foot light circuit | Refer to Door Mirror Foot Light Circuit | |
| Front multiplex network door ECU LH | Refer to DISASSEMBLY [03/2012 - ] | |
| Front multiplex network door ECU RH | Refer to DISASSEMBLY [03/2012 - ] | |
| Main body ECU (Multiplex network body ECU) | Refer to REMOVAL [03/2012 - ] |
OUTER REAR VIEW MIRROR ASSEMBLY (DOOR MIRROR FOOT LIGHT)
| Symptom | Suspected Area | See |
|---|---|---|
| Clock assembly does not illuminate. | Meter/gauge system | Refer to HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - ] |
| Clock assembly | Refer to INSPECTION [03/2012 - ] | |
| Harness or connector |
CLOCK ASSEMBLY
| Symptom | Suspected Area | See |
|---|---|---|
| Battery saving function does not operate. | Door courtesy switch circuit | Refer to Door Courtesy Switch Circuit |
| Luggage compartment door courtesy switch circuit | Refer to Luggage Compartment Door Courtesy Switch Circuit | |
| IG signal circuit | Refer to IG Signal Circuit | |
| Interior light auto cut circuit | Refer to Interior Light Auto Cut Circuit | |
| Harness or connector | ||
| Main body ECU (Multiplex network body ECU) | Refer to REMOVAL [03/2012 - ] |
BATTERY SAVING CONTROL SYSTEM
| Symptom | Suspected Area | See |
|---|---|---|
| Power switch illumination does not illuminate. | CAN communication system | Refer to HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - ] |
| Headlight dimmer switch circuit | Refer to Headlight Dimmer Switch Circuit | |
| Power switch illumination circuit | Refer to Power Switch Illumination Circuit | |
| Certification ECU (Smart key ECU assembly) | Refer to REMOVAL [03/2012 - ] | |
| Main body ECU (Multiplex network body ECU) | Refer to REMOVAL [03/2012 - ] |
POWER SWITCH ILLUMINATION SYSTEM
| Symptom | Suspected Area | See |
|---|---|---|
| No instrument panel illumination lights come on (taillights operate normally). | Instrument panel illumination circuit | Refer to Instrument Panel Illumination Circuit |
| Harness or connector | ||
| No. 2 integration relay | Refer to ON-VEHICLE INSPECTION [03/2012 - ] | |
| Main body ECU (Multiplex network body ECU) | Refer to REMOVAL [03/2012 - ] |
INSTRUMENT PANEL ILLUMINATION SYSTEM
Scheme 21
![Scheme 21: TERMINALS OF ECU [03/2012 - ]](https://i.diagnostdata.com/repair/f9/f94afedf876a811cfc2b311ec7a46bbca23e1ed78fac9310c4da18e752ddc2b6.webp)
Scheme 22
Scheme 23
Scheme 24
- CHECK COWL SIDE JUNCTION BLOCK LH, MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) TEXT IN ILLUSTRATION *1 Main Body ECU (Multiplex Network Body ECU) - - Remove the main body ECU (multiplex network body ECU) from the cowl side junction block LH. Refer to «REMOVAL [03/2012 - ]»(ref-600595-S12145438012014022400000) . Connect the cowl side junction block LH connectors. Measure the voltage and resistance according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A-32 (IG) - Body ground - Ignition power supply Power switch on (IG) 11 to 14 V A-30 (BECU) - Body ground - Battery power supply Always 11 to 14 V A-29 (ACC) - Body ground - ACC power supply Power switch on (ACC) 11 to 14 V A-11 (GND1) - Body ground - Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction in the wire harness or passenger side junction block. Install the main body ECU (multiplex network body ECU). Refer to «INSTALLATION [03/2012 - ]»(ref-600595-S31982790842014022400000) . Measure the voltage and pulse according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition N13-1 (RCYL) - Body ground GR - Body ground Rear courtesy light RH signal Rear courtesy light RH off 11 to 14 V Rear courtesy light RH on Below 1 V N13-2 (LSWR) - Body ground B - Body ground Rear door unlock detection switch RH signal Front door RH unlocked Below 1 V Power switch off, all doors closed and rear door RH locked 11 to 14 V N13-20 (FSPT) - Body ground R - Body ground Interior foot light and door illumination signal Rear door inside handle illumination light, No. 1 interior illumination light (rear door ambient light), front interior foot lights and No. 1 interior illumination light (rear interior foot light) off 11 to 14 V Rear door inside handle illumination light, No. 1 interior illumination light (rear door ambient light), front interior foot lights and No. 1 interior illumination light (rear interior foot light) on Below 1 V N12-6 (RCTY) - Body ground G - Body ground Rear door courtesy light switch RH signal Rear door RH open Below 1 V Rear door RH closed Pulse generation N12-7 (LSFL) - Body ground SB - Body ground Front door unlock detection switch LH signal Front door LH unlocked Below 1 V Power switch off, all doors closed and front door LH locked Pulse generation N12-18 (LSFR) - Body ground SB - Body ground Front door unlock detection switch RH signal Front door RH unlocked Below 1 V Power switch off, all doors closed and front door RH locked Pulse generation N12-19 (LGCY) - Body ground P - Body ground Luggage door courtesy light switch signal Luggage compartment door open Below 1 V Luggage compartment door closed 11 to 14 V N11-2 (DOMR) - Body ground Y - Body ground Battery saving control signal Battery saving control for map light, spot light and vanity light operating 11 to 14 V Battery saving control for map light, spot light and vanity light not operating Below 1 V N11-3 (LCTY) - Body ground G - Body ground Rear door courtesy light switch LH signal Rear door LH open Below 1 V Rear door LH closed Pulse generation N11-4 (LCYL) - Body ground GR - Body ground Rear courtesy light LH signal Rear courtesy light LH off 11 to 14 V Rear courtesy light LH on Below 1 V N11-5 (PANL) - Body ground V - Body ground Instrument panel illumination signal Headlight dimmer switch in TAIL Below 1 V Headlight dimmer switch off 11 to 14 V N11-12 (TCYL) - Body ground* B - Body ground No. 1 luggage compartment light signal No. 1 luggage compartment light off 11 to 14 V No. 1 luggage compartment light on Below 1 V 5A-27 (ILE) - Body ground SB - Body ground Map light and spot light signal Map light and spot light on using illuminated entry system Below 1 V Map light and spot light off using illuminated entry system 11 to 14 V 5A-33 (FRCY) - Body ground R - Body ground Front door courtesy light switch RH signal Front door RH open Below 1 V Front door RH closed Pulse generation 5A-4 - Body ground L - Body ground Battery saving control signal Battery saving control operating Below 1 V Battery saving control not operating 11 to 14 V 5A-8 - Body ground L - Body ground Battery saving control signal Battery saving control operating Below 1 V Battery saving control not operating 11 to 14 V 5A-9 - Body ground L - Body ground Battery saving control signal Battery saving control operating Below 1 V Battery saving control not operating 11 to 14 V 5A-22 - Body ground L - Body ground Battery saving control signal Battery saving control operating Below 1 V Battery saving control not operating 11 to 14 V 5A-30 - Body ground L - Body ground Battery saving control signal Battery saving control operating Below 1 V Battery saving control not operating 11 to 14 V 5C-30 (LSWL) - Body ground B - Body ground Rear door unlock detection switch LH signal Rear door LH unlocked Below 1 V Power switch off, all doors closed and rear door LH locked Pulse generation 5C-44 (FLCY) - Body ground R - Body ground Front door courtesy light switch LH signal Front door LH open Below 1 V Front door LH closed Pulse generation 5C-38 - Body ground Y - Body ground Battery saving control signal Battery saving control operating Below 1 V Battery saving control not operating 11 to 14 V 5C-39 - Body ground L - Body ground Battery saving control signal Battery saving control operating Below 1 V Battery saving control not operating 11 to 14 V 5C-42 - Body ground L - Body ground Battery saving control signal Battery saving control operating Below 1 V Battery saving control not operating 11 to 14 V *: w/o Power Trunk Lid System
- CHECK FRONT MULTIPLEX NETWORK DOOR ECU RH Disconnect the Q4 front multiplex network door ECU RH connector. Measure the resistance and voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition Q4-6 (BDR) - Body ground V - Body ground Battery power supply Always 11 to 14 V Q4-4 (CPUB) - Body ground P - Body ground Battery power supply Always 11 to 14 V Q4-3 (SIG) - Body ground B - Body ground Ignition power supply Power switch on (IG) 11 to 14 V Q4-1 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the Q4 front multiplex network door ECU RH connector. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition Q4-10 (LED+) - Q4-11 (LED-) Y - W Front door inside handle illumination light RH signal Front door inside handle illumination light RH on 11 to 14 V Front door inside handle illumination light RH off Below 1 V Q4-12 (IL1+) - Q3-21 (Il1-) P - SB No. 1 interior illumination light RH (front door ambient light) signal No. 1 interior illumination light RH (front door ambient light) on 11 to 14 V No. 1 interior illumination light RH (front door ambient light) off Below 1 V Q4-13 (CYL) - Body ground GR - Body ground Front courtesy light RH signal Front courtesy light RH on Below 1 V Front courtesy light RH off 11 to 14 V z11-2 (MLP) - z11-12 (-) Y - B-R Door mirror foot light RH signal Door mirror foot light RH on 11 to 14 V Door mirror foot light RH off Below 1 V
- CHECK FRONT MULTIPLEX NETWORK DOOR ECU LH Disconnect the Q19 front multiplex network door ECU LH connector. Measure the resistance and voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition Q19-6 (BDR) - Body ground V - Body ground Battery power supply Always 11 to 14 V Q19-4 (CPUB) - Body ground P - Body ground Battery power supply Always 11 to 14 V Q19-16 (BCUT) - Body ground W - Body ground Battery power supply Always 11 to 14 V Q19-3 (SIG) - Body ground B - Body ground Ignition power supply Power switch on (IG) 11 to 14 V Q19-1 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the Q19 front multiplex network door ECU LH connector. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition Q19-10 (LED+) - Q19-11 (LED-) Y - W Front door inside handle illumination light LH signal Front door inside handle illumination light LH on 11 to 14 V Front door inside handle illumination light LH off Below 1 V Q19-12 (IL1+) - Q18-21 (Il1-) P - SB No. 1 interior illumination light LH (front door ambient light) signal No. 1 interior illumination light LH (front door ambient light) on 11 to 14 V No. 1 interior illumination light LH (front door ambient light) off Below 1 V Q19-13 (CYL) - Body ground GR - Body ground Front courtesy light LH signal Front courtesy light LH on Below 1 V Front courtesy light LH off 11 to 14 V z10-2 (MLP) - z10-12 (-) Y - B-R Door mirror foot light LH signal Door mirror foot light LH on 11 to 14 V Door mirror foot light LH off Below 1 V
- CHECK CERTIFICATION ECU (SMART KEY ECU ASSEMBLY) Disconnect the N94 and N95 certification ECU connectors. Measure the resistance and voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition N95-5 (+B) - Body ground GR - Body ground Battery power supply Always 11 to 14 V N95-4 (CUTB) - Body ground P - Body ground Battery power supply Always 11 to 14 V N93-16 (IG) - Body ground B - Body ground Ignition power supply Power switch on (IG) 11 to 14 V N94-1 (E) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the N94 and N95 certification ECU connectors. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition N95-6 (SWIL) - Body ground B - Body ground Power switch illumination operation signal Power switch illumination on 11 to 14 V Power switch illumination off Below 1 V
DATA LIST / ACTIVE TEST [03/2012 - ]
- DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body / (desired system) / Data List / All Data. According to the display on the Techstream, read the Data List. MAIN BODY Tester Display Measurement Item/Range Normal Condition Diagnostic Note ACC SW Power switch on (ACC) signal / ON or OFF ON: Power switch on (ACC) OFF: Power switch off "ON" is also displayed for this item when the power switch is on (IG). IG SW Power switch on (IG) signal / ON or OFF ON: Power switch on (IG) OFF: Power switch off "OFF" is also displayed for this item when the power switch is on (ACC). RR Door Courtesy SW Rear door courtesy light switch RH signal / ON or OFF ON: Rear door RH open OFF: Rear door RH closed - RL Door Courtesy SW Rear door courtesy light switch LH signal / ON or OFF ON: Rear door LH open OFF: Rear door LH closed - FR Door Lock Pos Front door unlock detection switch RH signal / LOCK or UNLOCK LOCK: Front door RH locked UNLOCK: Front door RH unlocked - FR Door Courtesy Front door courtesy light switch RH signal / ON or OFF ON: Front door RH closed OFF: Front door RH open - FL Door Lock Pos Front door unlock detection switch LH signal / LOCK or UNLOCK LOCK: Front door LH locked UNLOCK: Front door LH unlocked - FL Door Courtesy Front door courtesy light switch LH signal / ON or OFF ON: Front door LH closed OFF: Front door LH open - RR-Door Lock Pos SW Rear door unlock detection switch RH signal / ON or OFF ON: Rear door RH unlocked OFF: Rear door RH locked - RL-Door Lock Pos SW Rear door unlock detection switch LH signal / ON or OFF ON: Rear door LH unlocked OFF: Rear door LH locked - Luggage Courtesy SW Luggage door courtesy light switch signal / ON or OFF ON: Luggage compartment door open OFF: Luggage compartment door closed For vehicles with power trunk lid system, this item is not related luggage compartment door condition. Mirr-Foot-Lgt Approached Function to light up door mirror foot lights when key is brought within vehicle exterior detection area / ON or OFF Customized setting displayed - Mirr-Foot-Lgt Unlocked Function to light up door mirror foot lights when doors are unlocked using mechanical key or door control transmitter / ON or OFF Customized setting displayed - Mirror Foot Light Time Function to change lighting time of door mirror foot lights / 7.5 s, 15 s or 30 s Customized setting displayed - Interior Light Control Function which controls interior lights / ON or OFF Customized setting displayed - Exterior Light Control Function which controls door mirror foot lights / ON or OFF Customized setting displayed - I/L ON W/Door Key Unlock Function which turns on interior lights when door is unlocked / ON or OFF Customized setting displayed - Lighting Time Lighting time after closing all doors / 7.5 s, 15 s or 30 s Customized setting displayed - Room Light when Aprchd Function which turns on room lights when key is brought within vehicle exterior detection area / ON or OFF Customized setting displayed - Inside Foot Light Function which controls interior foot lights / ON or OFF Customized setting displayed - I/L when ACC OFF Function which turns on lights when power switch is turned from on (IG) or on (ACC) to off / ON or OFF Customized setting displayed - Light Control Function which controls interior foot lights, inside handle illumination and door ambient light / ON or OFF Customized setting displayed - Light up Clearance Lights at Door Unlock Function Function which turns on clearance lights, taillights, side marker lights and license plate lights for 15 seconds when doors are unlocked by an entry unlock operation or wireless unlock operation / ON or OFF Customized setting displayed
- ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body / (desired system) / Active Test. According to the display on the Techstream, perform the Active Test. MAIN BODY Tester Display Test Part Control Range Diagnostic Note Illuminated Entry System Map light and spot light ON/OFF - Fr Foot Light Rear door inside handle illumination light, rear door ambient light, rear interior foot light and front interior foot light ON/OFF - Interior Panel Relay Interior panel relay ON/OFF - Relay for Interior Light Auto Cut Function DOME CUT relay ON/OFF - Dimmer Signal Illumination dimming ON/OFF - FRONT LEFT DOOR Tester Display Test Part Control Range Diagnostic Note Foot Light Door mirror foot light LH ON/OFF - Courtesy Light Front door courtesy light LH ON/OFF - Inside Handle Light Front door inside handle illumination light LH ON/OFF - Interior Illumination Light Front door ambient light LH ON/OFF - FRONT RIGHT DOOR Tester Display Test Part Control Range Diagnostic Note Foot Light Door mirror foot light RH ON/OFF - Courtesy Light Front door courtesy light RH ON/OFF - Inside Handle Light Front door inside handle illumination light RH ON/OFF - Interior Illumination Light Front door ambient light RH ON/OFF - SMART ACCESS Tester Display Test Part Control Range Diagnostic Note Power/Engine SW Light Power switch illumination ON/OFF
INSPECTION PROCEDURE
Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure. Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] .
Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure. Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] .
Note. Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] .
Scheme 25
- READ VALUE USING TECHSTREAM (DOOR COURTESY LIGHT SWITCH) Using the Techstream, read the Data List. Refer to «DATA LIST / ACTIVE TEST [03/2012 - ]»(ref-600423-S11851139912014022400000) . MAIN BODY Tester Display Measurement Item/Range Normal Condition Diagnostic Note RR Door Courtesy SW Rear door courtesy light switch RH signal / ON or OFF ON: Rear door RH open OFF: Rear door RH closed - RL Door Courtesy SW Rear door courtesy light switch LH signal / ON or OFF ON: Rear door LH open OFF: Rear door LH closed - FR Door Courtesy Front door courtesy light switch RH signal / ON or OFF ON: Front door RH closed OFF: Front door RH open - FL Door Courtesy Front door courtesy light switch LH signal / ON or OFF ON: Front door LH closed OFF: Front door LH open - OK Normal conditions listed above are displayed. RESULT Result Proceed to OK A NG (Front door courtesy light switch RH does not operate) B NG (Front door courtesy light switch LH does not operate) C NG (Rear door courtesy light switch RH does not operate) D NG (Rear door courtesy light switch LH does not operate) E B --> See step 2 C --> See step 5 D --> See step 8 E --> See step 10 A --> See step 13
- INSPECT FRONT DOOR COURTESY LIGHT SWITCH RH Remove the front door courtesy light switch RH. Refer to «REMOVAL [03/2012 - ]»(ref-600610-S01057216312014022400000) . Inspect the front door courtesy light switch RH. Refer to «INSPECTION [03/2012 - ]»(ref-600610-S22852545972014022400000) . NG --> See step 12 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (FRONT DOOR COURTESY LIGHT SWITCH RH - COWL SIDE JUNCTION BLOCK LH) Disconnect the T6 front door courtesy light switch RH connector. Disconnect the 5A cowl side junction block LH connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition T6-1 - 5A-33 Always Below 1 ohms T6-1 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT COWL SIDE JUNCTION BLOCK LH Remove the cowl side junction block LH. Refer to «REMOVAL [03/2012 - ]»(ref-600595-S12145438012014022400000) . Remove the main body ECU from the cowl side junction block LH. Refer to «REMOVAL [03/2012 - ]»(ref-600595-S12145438012014022400000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A-4 (FRCY) - 5A-33 Always Below 1 ohms NG --> See step 18 OK --> See step 14
- INSPECT FRONT DOOR COURTESY LIGHT SWITCH LH Remove the front door courtesy light switch LH. Refer to «REMOVAL [03/2012 - ]»(ref-600610-S01057216312014022400000) . Inspect the front door courtesy light switch LH. Refer to «INSPECTION [03/2012 - ]»(ref-600610-S22852545972014022400000) . NG --> See step 16 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (FRONT DOOR COURTESY LIGHT SWITCH LH - COWL SIDE JUNCTION BLOCK LH) Disconnect the U8 front door courtesy light switch LH connector. Disconnect the 5C cowl side junction block LH connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition U8-1 - 5C-44 Always Below 1 ohms U8-1 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT COWL SIDE JUNCTION BLOCK LH Remove the cowl side junction block LH. Refer to «REMOVAL [03/2012 - ]»(ref-600595-S12145438012014022400000) . Remove the main body ECU from the cowl side junction block LH. Refer to «REMOVAL [03/2012 - ]»(ref-600595-S12145438012014022400000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A-2 (FLCY) - 5C-44 Always Below 1 ohms NG --> See step 18 OK --> See step 14
- INSPECT REAR DOOR COURTESY LIGHT SWITCH RH Remove the rear door courtesy light switch RH. Refer to «REMOVAL [03/2012 - ]»(ref-600610-S39591067642014022400000) . Inspect the rear door courtesy light switch RH. Refer to «INSPECTION [03/2012 - ]»(ref-600610-S18989971572014022400000) . NG --> See step 17 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (REAR DOOR COURTESY LIGHT SWITCH RH - MAIN BODY ECU) Disconnect the T21 rear door courtesy light switch RH connector. Disconnect the N12 main body ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition T21-1 - N12-6 (RCTY) Always Below 1 ohms T21-1 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 14
- INSPECT REAR DOOR COURTESY LIGHT SWITCH LH Remove the rear door courtesy light switch LH. Refer to «REMOVAL [03/2012 - ]»(ref-600610-S39591067642014022400000) . Inspect the rear door courtesy light switch LH. Refer to «INSPECTION [03/2012 - ]»(ref-600610-S18989971572014022400000) . NG --> See step 15 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (REAR DOOR COURTESY LIGHT SWITCH LH - MAIN BODY ECU) Disconnect the U18 rear door courtesy light switch LH connector. Disconnect the N11 main body ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition U18-1 - N11-3 (LCTY) Always Below 1 ohms U18-1 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 14
- REPLACE FRONT DOOR COURTESY LIGHT SWITCH RH. Refer to «REMOVAL [03/2012 - ]»(ref-600610-S01057216312014022400000)
- PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE [03/2012 - ]»(ref-600423-S18953902322014022400000)
- REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU). Refer to «REMOVAL [03/2012 - ]»(ref-600595-S12145438012014022400000)
- REPLACE REAR DOOR COURTESY LIGHT SWITCH LH. Refer to «REMOVAL [03/2012 - ]»(ref-600610-S39591067642014022400000)
- REPLACE FRONT DOOR COURTESY LIGHT SWITCH LH. Refer to «REMOVAL [03/2012 - ]»(ref-600610-S01057216312014022400000)
- REPLACE REAR DOOR COURTESY LIGHT SWITCH RH. Refer to «REMOVAL [03/2012 - ]»(ref-600610-S39591067642014022400000)
- REPLACE COWL SIDE JUNCTION BLOCK LH. Refer to «REMOVAL [03/2012 - ]»(ref-600595-S12145438012014022400000)
Note. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no CAN communication malfunctions before troubleshooting this symptom. Inspect the bulbs for circuits related to this system before performing the following inspection procedure.
Note. Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] .
Scheme 26
- PERFORM ACTIVE TEST USING TECHSTREAM (MAP LIGHT, SPOT LIGHT) Using the Techstream, perform the Active Test. Refer to «DATA LIST / ACTIVE TEST [03/2012 - ]»(ref-600423-S11851139912014022400000) . MAIN BODY Tester Display Test Part Control Range Diagnostic Note Illuminated Entry System Map light and spot light ON/OFF - OK Map light and spot light comes on. NG --> See step 2 OK --> See step 10
- INSPECT MAP LIGHT Remove the map light. Refer to «REMOVAL [03/2012 - ]»(ref-600610-S15814264062014022400000) . Turn the door position switch to door mode. Connect the positive (+) lead from the battery to terminal Y9-19 (+B1) and the negative (-) lead to terminal Y9-14 (DOOR), then check that the map light (dome light portion) illuminates. OK Map light (dome light portion) illuminates Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Y9-19 (+B1) - Y11-16 (RIFR) Always Below 1 ohms Y9-19 (+B1) - Y9-26 (RIFL) Y9-27 (RLSW) - Y9-14 (DOOR) Turn the door position switch to door mode Below 1 ohms Turn the door position switch off mode 10 kohms or higher Y11-14 (RRSW) - Y9-14 (DOOR) Turn the door position switch to door mode Below 1 ohms Turn the door position switch off mode 10 kohms or higher NG --> See step 11 OK: Go to next step
- INSPECT SPOT LIGHT ASSEMBLY LH Remove the spot light LH. Refer to «REMOVAL [03/2012 - ]»(ref-600610-S14696422102014022400000) . Inspect the spot light LH. Refer to «INSPECTION [03/2012 - ]»(ref-600610-S32194759452014022400000) . NG --> See step 12 OK: Go to next step
- INSPECT SPOT LIGHT ASSEMBLY RH Remove the spot light RH. Refer to «REMOVAL [03/2012 - ]»(ref-600610-S14696422102014022400000) . Inspect the spot light RH. Refer to «INSPECTION [03/2012 - ]»(ref-600610-S32194759452014022400000) . NG --> See step 13 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (MAP LIGHT - SPOT LIGHT LH) Disconnect the Y9 map light connector. Disconnect the Y3*1 or Y16*2 spot light LH connector. *1: w/ Sliding Roof *2: w/o Sliding Roof Measure the resistance according to the value(s) in the table below. Standard Resistance w/ Sliding Roof w/o Sliding Roof Tester Connection Condition Specified Condition Y9-26 (RIFL) - Y3-3 (B) Always Below 1 ohms Y9-26 (RIFL) - Body ground 10 kohms or higher Y9-27 (RLSW) - Y3-1 (CTY) Always Below 1 ohms Y9-27 (RLSW) - Body ground Always 10 kohms or higher Tester Connection Condition Specified Condition Y9-26 (RIFL) - Y16-3 (B) Always Below 1 ohms Y9-26 (RIFL) - Body ground 10 kohms or higher Y9-27 (RLSW) - Y16-1 (CTY) Always Below 1 ohms Y9-27 (RLSW) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK HARNESS AND CONNECTOR (MAP LIGHT - SPOT LIGHT RH) Disconnect the Y11 map light connector. Disconnect the Y14*1 or Y15*2 spot light RH connector. *1: w/ Sliding Roof *2: w/o Sliding Roof Measure the resistance according to the value(s) in the table below. Standard Resistance w/ Sliding Roof w/o Sliding Roof Tester Connection Condition Specified Condition Y11-16 (RIFR) - Y14-3 (B) Always Below 1 ohms Y11-16 (RIFR) - Body ground 10 kohms or higher Y11-14 (RRSW) - Y14-1 (CTY) Always Below 1 ohms Y11-14 (RRSW) - Body ground 10 kohms or higher Tester Connection Condition Specified Condition Y11-16 (RIFR) - Y15-3 (B) Always Below 1 ohms Y11-16 (RIFR) - Body ground 10 kohms or higher Y11-14 (RRSW) - Y15-1 (CTY) Always Below 1 ohms Y11-14 (RRSW) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK HARNESS AND CONNECTOR (MAP LIGHT - COWL SIDE JUNCTION BLOCK LH AND BATTERY) Disconnect the Y9 map light connector. Disconnect the 5A cowl side junction block LH connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition Y9-19 (+B1) - Y11-16 (RIFR) Battery saving control not operating 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Y9-14 (DOOR) - 5A-27 Always Below 1 ohms Y9-14 (DOOR) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT COWL SIDE JUNCTION BLOCK LH Remove the cowl side junction block LH. Refer to «REMOVAL [03/2012 - ]»(ref-600595-S12145438012014022400000) . Remove the main body ECU from the cowl side junction block LH. Refer to «REMOVAL [03/2012 - ]»(ref-600595-S12145438012014022400000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A-1 (ILE) - 5A-27 Always Below 1 ohms NG --> See step 14 OK --> See step 9
- REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU). Refer to «REMOVAL [03/2012 - ]»(ref-600595-S12145438012014022400000)
- PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE [03/2012 - ]»(ref-600423-S18953902322014022400000)
- REPLACE MAP LIGHT ASSEMBLY. Refer to «REMOVAL [03/2012 - ]»(ref-600610-S15814264062014022400000)
- REPLACE SPOT LIGHT ASSEMBLY LH. Refer to «REMOVAL [03/2012 - ]»(ref-600610-S14696422102014022400000)
- REPLACE SPOT LIGHT ASSEMBLY RH. Refer to «REMOVAL [03/2012 - ]»(ref-600610-S14696422102014022400000)
- REPLACE COWL SIDE JUNCTION BLOCK LH. Refer to «REMOVAL [03/2012 - ]»(ref-600595-S12145438012014022400000)
Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure. Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] .
Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure. Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] .
Note. Before replacing the certification ECU (smart key ECU assembly), refer to the smart access system with push-button start (for Entry Function) precaution. Refer to PRECAUTION [03/2012 - ] .
Note. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no CAN communication malfunctions before troubleshooting this symptom. Inspect the bulbs for circuits related to this system before performing the following inspection procedure.
Note. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no CAN communication malfunctions before troubleshooting this DTC. Inspect the fuses for circuits related to this system before performing the following inspection procedure. Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] .
| WARNING | Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] . |
Note. Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] .
