PRECAUTION

  1. NOTICE FOR INITIALIZATION: NOTE: When disconnecting the cable from the negative battery terminal, initialize the following systems after the cable is reconnected. System Name See procedure Variable Gear Ratio Steering Refer to «INITIALIZATION»(ref-382578-S40254115562011012800000) Theft Deterrent System Refer to «INITIALIZATION»(ref-382578-S40254115562011012800000) Intuitive parking Assist System Refer to «INITIALIZATION»(ref-382578-S40254115562011012800000)
  2. PRECAUTIONS WHEN WORKING ON ELECTRIC STEERING LOCK After replacing the steering lock actuator assembly, perform the code registration Refer to «REGISTRATION»(ref-382739-S04074371812011012800000) . If the steering lock actuator assembly is replaced, open and close the driver's door. The engine may not start until either operation is performed. HINT: Performing the above operation causes the steering lock actuator assembly to memorize the correct steering lock bar position. If checking for push button start function DTCs or checking the data list with the engine switch off, make sure that the driver's door is open. HINT: When the engine switch is off, the body ECU to which the Techstream is to be connected may not be working. Communication with the Techstream is impossible if the body ECU is not working.

Scheme 107

Scheme 107: ILLUSTRATION

Scheme 108

Scheme 108: SYSTEM DIAGRAM
Transmitting ECU (transmitter)Receiving ECUSignalsCommunication Method
Power Source Control ECU assemblySteering Lock ECUPower supply status (to steering lock motor)LIN
Steering Lock ECUCertification ECU Power source control ECU assembly ID code boxSleep available statusLIN
Steering Lock ECUCertification ECU Power source control ECU assembly ID code boxLock/Unlock sensor statusLIN
Steering Lock ECUCertification ECU Power source control ECU assembly ID code boxSteering lock statusLIN
Steering Lock ECUCertification ECU Power source control ECU assembly ID code boxMotor control statusLIN
Steering Lock ECUCertification ECU Power source control ECU assembly ID code boxDiagnostic response statusLIN
Steering Lock ECUCertification ECU Power source control ECU assembly ID code boxLock/Unlock sensor malfunctionLIN
Steering Lock ECUCertification ECU Power source control ECU assembly ID code boxPower supply malfunction (to steering lock motor)LIN
Steering Lock ECUCertification ECU Power source control ECU assembly ID code boxMotor driver malfunctionLIN
Steering Lock ECUCertification ECU Power source control ECU assembly ID code boxLock bar (stuck) statusLIN
Steering Lock ECUCertification ECU Power source control ECU assembly ID code boxPush start statusLIN
Steering Lock ECUCertification ECU Power source control ECU assembly ID code boxLock/Unlock relay drive statusLIN
Steering Lock ECUCertification ECU Power source control ECU assembly ID code boxEngine start control statusLIN

INPUT AND OUTPUT SIGNALS OF EACH ECU

PROCEDURE

  1. REPLACE STEERING LOCK ACTUATOR ASSEMBLY HINT: The steering lock ECU and steering lock actuator assembly supplied as a unit. Replace the steering lock actuator assembly See step 1 under «DISASSEMBLY»(ref-382576-S16865108172011012800000) for 2GR-FSE, or see step 1 under «DISASSEMBLY»(ref-382576-S18616626182011012800000) for 1UR-FSE). NEXT --> PERFORM DTC
