PRECAUTION
- NOTICE FOR INITIALIZATION: NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected. System Name See procedure Variable Gear Ratio Steering System Refer to «INITIALIZATION»(ref-386951-S21829001392011022400000) Theft Deterrent System Intuitive Parking Assist System
- PRECAUTIONS WHEN WORKING ON ELECTRIC STEERING LOCK After replacing the steering lock actuator, perform the code registration. Refer to «REGISTRATION»(ref-387084-S31120496972011022400000) . If the steering lock actuator is replaced, open and close the driver's door. The engine may not start until either operation is performed. HINT: Performing the above operation causes the steering lock actuator to memorize the correct steering lock bar position. If checking for push button start function DTCs or checking the DATA LIST with the power switch OFF, make sure that the driver's door is open. HINT: When the power switch is OFF, the main body ECU RH to which the Techstream is to be connected may not be working. Communication with the Techstream is impossible if the main body ECU RH is not working.
Scheme 9
Scheme 10
| Transmitting ECU (transmitter) | Receiving ECU | Signals | Communication Method |
|---|---|---|---|
| Power Source Control ECU | Steering Lock ECU | Power supply status (to steering lock motor) | LIN |
| Steering Lock ECU | Certification ECU Power source control ECU ID code box | Sleep available status | LIN |
| Steering Lock ECU | Certification ECU Power source control ECU ID code box | Lock/Unlock sensor status | LIN |
| Steering Lock ECU | Certification ECU Power source control ECU ID code box | Steering lock status | LIN |
| Steering Lock ECU | Certification ECU Power source control ECU ID code box | Motor control status | LIN |
| Steering Lock ECU | Certification ECU Power source control ECU ID code box | Diagnostic response status | LIN |
| Steering Lock ECU | Certification ECU Power source control ECU ID code box | Lock/Unlock sensor malfunction | LIN |
| Steering Lock ECU | Certification ECU Power source control ECU ID code box | Power supply malfunction (to steering lock motor) | LIN |
| Steering Lock ECU | Certification ECU Power source control ECU ID code box | Motor driver malfunction | LIN |
| Steering Lock ECU | Certification ECU Power source control ECU ID code box | Lock bar (stuck) status | LIN |
| Steering Lock ECU | Certification ECU Power source control ECU ID code box | Push start status | LIN |
| Steering Lock ECU | Certification ECU Power source control ECU ID code box | Lock/Unlock relay drive status | LIN |
| Steering Lock ECU | Certification ECU Power source control ECU ID code box | Engine start control status | LIN |
INPUT AND OUTPUT SIGNALS OF EACH ECU
