Mirror (Service Information): Removal & Installation Lexus GS III рестайлинг

INSTALLATION

1. INSTALL INNER REAR VIEW MIRROR ASSEMBLY Connect the connector. Install the mirror with the screw.
2. INSTALL PERSONAL LIGHT ASSEMBLY . Refer to «INSTALLATION - Step 12»(ref-387112-S34119271062011022400000)
3. INSTALL FRONT ROOFTOP GARNISH . Refer to «INSTALLATION - Step 13»(ref-387112-S34119271062011022400000)
4. INSTALL INNER REAR VIEW MIRROR COVER

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. CHECK POWER RETRACTABLE MIRROR Turn the power switch ON (ACC). At each position of the outer mirror body, check the retractable mirror's operation when operating the retract switch of the outer mirror. Move the mirrors to the driving position. Press the retract switch. Check that the right and left mirrors move from the driving position to the retracted position. Move the mirrors to the driving position. Move one of the mirrors to the forward position by hand. Press the retract switch. Check that the mirror moves from the forward position to the retracted position. Check that the other mirror moves from the driving position to the retracted position. Move the mirrors to the driving position. Move one of the mirrors to the retracted position by hand. Press the retract switch. Check that the outer mirror moves from the driving position to the retracted position. Move the mirrors to the retracted position. Press the retract switch. Check that the right and left mirrors move from the retracted position to the driving position. Move the mirrors to the retracted position. Move one of the mirrors to the driving position by hand. Press the retract switch. Check that the outer mirror moves from the retracted position to the driving position. Check the operation of the outer mirror in relation to retract switch operations and power switch operations. When the mirror is operating, turn the power switch OFF. Check that the mirror operation does not stop and continues until the operation has finished. Repeat the step above. This time, before the mirror operation completes, turn the power switch ON (ACC) and press the retract switch. Check that the mirror operates in the opposite direction. Check the operation of the outer mirror when it is restrained by an obstacle. When the mirror is moving to the retracted or driving position, restrain the mirror by hand. Check that the mirror stops moving. With the mirror stopped partway, push the retract switch. Check that the mirror moves in the opposite direction it was moving when it was restrained.
2. CHECK REVERSE-SHIFT LINKED OPERATION OF MIRRORS Turn the power switch ON (IG). Set the mirror switch to L or R. Check that the mirror faces downward when the shift lever is moved to R. When the shift lever is not on P, or the mirror switch is in the neutral position (OFF), check that the outer rear view mirror returns to the driving position.
3. CHECK MIRROR HEATER Turn the power switch ON (IG). Check that pressing the rear defogger switch illuminates the indicator and warms the mirror surface. Check that after approximately 15 minutes, the indicator light turns off and the mirror heater deactivates.

REMOVAL

HINT

1. Use the same procedures for the LH side and RH side.

1. The procedures listed below are for the LH side.

Scheme 17

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG LH . Refer to «REMOVAL - Step 1»(ref-387104-S13389567862011022400000)
3. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH . Refer to «REMOVAL - Step 2»(ref-387104-S13389567862011022400000)
4. REMOVE FRONT DOOR TRIM COVER LH . Refer to «REMOVAL - Step 8»(ref-387104-S13389567862011022400000)
5. REMOVE FRONT DOOR GLASS WEATHERSTRIP INNER LH . Refer to «REMOVAL - Step 12»(ref-387104-S13389567862011022400000)
6. REMOVE DOOR FRAME GARNISH LH . Refer to «REMOVAL - Step 10»(ref-387104-S13389567862011022400000)
7. REMOVE OUTER REAR VIEW MIRROR ASSEMBLY Disconnect the connector. Disengage the clip. Remove the 3 bolts and the outer rear view mirror assembly.

Scheme 18

Scheme 19

1. REMOVE OUTER MIRROR Using a molding remover, disengage the 4 claws and remove the outer mirror. HINT: Apply protective tape to the mirror body. Using a screwdriver, disconnect each connector.
2. REMOVE OUTER MIRROR LIGHT ASSEMBLY . Refer to «REMOVAL - Step 2»(ref-387111-S36391645482011022400000)
3. REMOVE SIDE TURN SIGNAL LIGHT ASSEMBLY . Refer to «REMOVAL - Step 3»(ref-387111-S36391645482011022400000)

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. INSPECT OUTER MIRROR ACTUATOR ASSEMBLY LH Apply battery voltage and check the operation of the mirror. OK Measurement Condition Specified Condition Battery positive (+) - Terminal 1 (MV) Battery negative (-) - Terminal 10 (M+) Turns upward A Battery positive (+) - Terminal 10 (M+) Battery negative (-) - Terminal 1 (MV) Turns downward B Battery positive (+) - Terminal 9 (MH) Battery negative (-) - Terminal 10 (M+) Turns right C Battery positive (+) - Terminal 10 (M+) Battery negative (-) - Terminal 9 (MH) Turns left D If the result is not as specified, replace the outer mirror actuator assembly LH. For each position: Disconnect the battery, set the mirror position by hand, connect the battery, and check the retractable mirror's movement. OK Measurement Condition Mirror Position Specified Condition Battery positive (+) - Terminal 3 (MR) Battery negative (-) - Terminal 11 (MF) Forward position A Moves from A to retracted position E Battery positive (+) - Terminal 11 (MF) Battery negative (-) - Terminal 3 (MR) Forward position A Does not move Battery positive (+) - Terminal 3 (MR) Battery negative (-) - Terminal 11 (MF) Position between forward position A and driving position C Moves from B to retracted position E Battery positive (+) - Terminal 11 (MF) Battery negative (-) - Terminal 3 (MR) Position between forward position A and driving position C Moves from B to forward position A Battery positive (+) - Terminal 3 (MR) Battery negative (-) - Terminal 11 (MF) Driving position C Moves from C to retracted position E Battery positive (+) - Terminal 11 (MF) Battery negative (-) - Terminal 3 (MR) Driving position C Does not move Battery positive (+) - Terminal 3 (MR) Battery negative (-) - Terminal 11 (MF) Position between driving position C and retracted position E Moves from D to retracted position E Battery positive (+) - Terminal 11 (MF) Battery negative (-) - Terminal 3 (MR) Position between driving position C and retracted position E Moves from D to driving position C Battery positive (+) - Terminal 3 (MR) Battery negative (-) - Terminal 11 (MF) Retracted position E Does not move Battery positive (+) - Terminal 11 (MF) Battery negative (-) - Terminal 3 (MR) Retracted position E Moves from E to driving position C NOTE: The mirror position cannot be changed manually when the battery is connected. To change the mirror position manually, the battery must be disconnected first. If the result is not as specified, replace the outer mirror actuator assembly LH. Check the mirror position sensor. Apply battery and dry cell battery voltage to the terminals as shown in the table below. Measure the voltage when the mirror is in the fully downward and fully upward positions. Standard voltage Measurement Condition (Battery) Measurement Condition (Dry Cell Battery) Voltmeter Condition Mirror Condition Specified Condition Battery positive (+) - Terminal 10 (M+) Battery negative (-) - Terminal 1 (MV) Battery positive (+) - Terminal 5 (VC) Battery negative (-) - Terminal 14 (E1) Positive (+) lead -Terminal 6 (VSSL) Negative (-) lead - Terminal 14 (E1) Turns fully downward 0 to 1.0 V Battery positive (+) - Terminal 1 (MV) Battery negative (-) - Terminal 10 (M+) Battery positive (+) - Terminal 5 (VC) Battery negative (-) - Terminal 14 (E1) Positive (+) lead -Terminal 6 (VSSL) Negative (-) lead - Terminal 14 (E1) Turns fully upward 2.8 to 5.0 V If the result is not as specified, replace the outer mirror actuator assembly LH. Measure the voltage when the mirror is in the fully turned to the left and fully turned to the right positions Standard voltage Measurement Condition (Battery) Measurement Condition (Dry Cell Battery) Voltmeter Condition Mirror Condition Specified Condition Battery positive (+) - Terminal 9 (MH) Battery negative (-) - Terminal 10 (M+) Battery positive (+) - Terminal 5 (VC) Battery negative (-) - Terminal 14 (E1) Positive (+) lead -Terminal 13 (HSSL) Negative (-) lead - Terminal 14 (E1) Turns to left fully 2.8 to 5.0 V Battery positive (+) - Terminal 10 (M+) Battery negative (-) - Terminal 9 (MH) Battery positive (+) - Terminal 5 (VC) Battery negative (-) - Terminal 14 (E1) Positive (+) lead -Terminal 13 (HSSL) Negative (-) lead - Terminal 14 (E1) Turns to right fully 0 to 1.0 V If the result is not as specified, replace the outer mirror actuator assembly LH. Check the mirror heater. Measure the resistance between terminals 4 and 12 of the connector. Standard resistance 3.6 to 4.8 ohms at 25°C (75°F) Apply battery voltage and check the operation of the mirror heater. OK Measurement Condition Specified Condition Battery positive (+) - Terminal 4 (+) Battery negative (-) - Terminal 12 (-) Mirror becomes warm HINT: It will take a short time for the mirror to become warm. If the result is not as specified, replace the mirror assembly. Check operation of the electrochromatic outer mirror LH. Disconnect the mirror connector. Apply dry cell battery voltage (1.3 V) to the mirror and check operation of the mirror face. OK Condition Specified Condition Battery positive (+) - 7 (EC+) Battery negative (-) - 15 (EC-) Mirror face darkens If the result is not as specified, replace the mirror assembly.
2. INSPECT OUTER MIRROR ACTUATOR ASSEMBLY RH Apply battery voltage and check the operation of the mirror. OK Measurement Condition Specified Condition Battery positive (+) - Terminal 1 (MV) Battery negative (-) - Terminal 10 (M+) Turns upward A Battery positive (+) - Terminal 10 (M+) Battery negative (-) - Terminal 1 (MV) Turns downward B Battery positive (+) - Terminal 9 (MH) Battery negative (-) - Terminal 10 (M+) Turns left C Battery positive (+) - Terminal 10 (M+) Battery negative (-) - Terminal 9 (MH) Turns right D If the result is not as specified, replace the outer mirror actuator assembly RH. For each position: Disconnect the battery, set the mirror position by hand, connect the battery, and check the retractable mirror's movement. OK Measurement Condition Mirror Position Specified Condition Battery positive (+) - Terminal 3 (MR) Battery negative (-) - Terminal 11 (MF) Forward position A Moves from A to retracted position E Battery positive (+) - Terminal 11 (MF) Battery negative (-) - Terminal 3 (MR) Forward position A Does not move Battery positive (+) - Terminal 3 (MR) Battery negative (-) - Terminal 11 (MF) Position between forward position A and driving position C Moves from B to retracted position E Battery positive (+) - Terminal 11 (MF) Battery negative (-) - Terminal 3 (MR) Position between forward position A and driving position C Moves from B to forward position A Battery positive (+) - Terminal 3 (MR) Battery negative (-) - Terminal 11 (MF) Driving position C Moves from C to retracted position E Battery positive (+) - Terminal 11 (MF) Battery negative (-) - Terminal 3 (MR) Driving position C Does not move Battery positive (+) - Terminal 3 (MR) Battery negative (-) - Terminal 11 (MF) Position between driving position C and retracted position E Moves from D to retracted position E Battery positive (+) - Terminal 11 (MF) Battery negative (-) - Terminal 3 (MR) Position between driving position C and retracted position E Moves from D to driving position C Battery positive (+) - Terminal 3 (MR) Battery negative (-) - Terminal 11 (MF) Retracted position E Does not move Battery positive (+) - Terminal 11 (MF) Battery negative (-) - Terminal 3 (MR) Retracted position E Moves from E to driving position C NOTE: Disconnect and reconnect the battery between each mirror position check. The mirror position cannot be changed manually when the battery is connected. To change the mirror position manually, the battery must be disconnected first. If the result is not as specified, replace the outer mirror actuator assembly RH. Check the mirror position sensor. Apply battery and dry cell battery voltage to the terminals as shown in the table below. Measure the voltage when the mirror is in the fully downward and fully upward positions. Standard voltage Measurement Condition (Battery) Measurement Condition (Dry Cell Battery) Voltmeter Condition Mirror Condition Specified Condition Battery positive (+) - Terminal 10 (M+) Battery negative (-) - Terminal 1 (MV) Battery positive (+) - Terminal 5 (VC) Battery negative (-) - Terminal 14 (E1) Positive lead (+) - Terminal 6 (VSSL) Negative lead (-) - Terminal 14 (E1) Turns fully downward 0 to 1.0 V Battery positive (+) - Terminal 1 (MV) Battery negative (-) - Terminal 10 (M+) Battery positive (+) - Terminal 5 (VC) Battery negative (-) - Terminal 14 (E1) Positive lead (+) - Terminal 6 (VSSL) Negative lead (-) - Terminal 14 (E1) Turns fully upward 2.8 to 5.0 V If the result is not as specified, replace the outer mirror actuator assembly RH. Measure the voltage when the mirror is in the fully turned to the left and fully turned to the right positions Standard voltage Measurement Condition (Battery) Measurement Condition (Dry Cell Battery) Voltmeter Condition Mirror Condition Specified Condition Battery positive (+) - Terminal 9 (MH) Battery negative (-) - Terminal 10 (M+) Battery positive (+) - Terminal 5 (VC) Battery negative (-) - Terminal 14 (E1) Positive lead (+) - Terminal 13 (HSSL) Negative lead (-) - Terminal 14 (E1) Turns to left fully 0 to 1.0 V Battery positive (+) - Terminal 10 (M+) Battery negative (-) - Terminal 9 (MH) Battery positive (+) - Terminal 5 (VC) Battery negative (-) - Terminal 14 (E1) Positive lead (+) - Terminal 13 (HSSL) Negative lead (-) - Terminal 14 (E1) Turns to right fully 2.8 to 5.0 V If the result is not as specified, replace the outer mirror actuator assembly RH. Check the mirror heater. Measure the resistance between terminals 4 and 12 of the connector. Standard resistance 3.6 to 4.8 ohms at 25°C (75°F) Apply battery voltage and check the operation of the mirror heater. OK Measurement Condition Specified Condition Battery positive (+) - Terminal 4 (+) Battery negative (-) - Terminal 12 (-) Mirror becomes warm HINT: It will take a short time for the mirror to become warm. If the result is not as specified, replace the mirror assembly. Check operation of the electrochromatic outer mirror RH. Disconnect the mirror connector. Apply dry cell battery voltage (1.3 V) to the mirror and check operation of the mirror face. OK Condition Specified Condition Battery positive (+) - 7 (EC+) Battery negative (-) - 15 (EC-) Mirror face darkens If the result is not as specified, replace the mirror assembly.

Scheme 32

1. INSTALL SIDE TURN SIGNAL LIGHT ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-387111-S29634496802011022400000)
2. INSTALL OUTER MIRROR LIGHT ASSEMBLY . Refer to «INSTALLATION - Step 2»(ref-387111-S29634496802011022400000)
3. INSTALL OUTER MIRROR Connect each connector. Engage the 4 claws and install the outer mirror.

HINT

1. Use the same procedures for the LH side and RH side.

1. The procedures listed below are for the LH side.

1. INSTALL OUTER REAR VIEW MIRROR ASSEMBLY Install the outer rear view mirror assembly with the 3 bolts. Torque: 8.0 N*m ( 82 kgf*cm, 71 in.*lbf) Engage the clip. Connect the connector.
2. INSTALL DOOR FRAME GARNISH LH . Refer to «INSTALLATION - Step 22»(ref-387104-S05304920912011022400000)
3. INSTALL FRONT DOOR TRIM COVER LH . Refer to «INSTALLATION - Step 24»(ref-387104-S05304920912011022400000)
4. INSTALL FRONT DOOR GLASS WEATHERSTRIP INNER LH . Refer to «INSTALLATION - Step 20»(ref-387104-S05304920912011022400000)
5. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH . Refer to «INSTALLATION - Step 30»(ref-387104-S05304920912011022400000)
6. INSTALL FRONT DOOR INSIDE HANDLE BEZEL PLUG LH . Refer to «INSTALLATION - Step 31»(ref-387104-S05304920912011022400000)
7. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
8. PERFORM INITIALIZATION Perform initialization. Refer to «INITIALIZATION»(ref-386951-S21829001392011022400000) . NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 33

1. INSTALL INTEGRATION CONTROL AND PANEL ASSEMBLY Connect each connector. Attach the 2 claws to install the control panel. Install the 2 screws.
2. INSTALL NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 11»(ref-387101-S06767646592011022400000)
3. INSTALL NO. 1 INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY . Refer to «INSTALLATION - Step 10»(ref-387101-S06767646592011022400000)
4. INSTALL INSTRUMENT SIDE PANEL LH . Refer to «INSTALLATION - Step 12»(ref-387101-S06767646592011022400000)
5. INSTALL FRONT DOOR OPENING TRIM COVER LH Attach the 3 claws to install the trim cover. Pull out the folded lip of the weatherstrip.
6. INSTALL FRONT DOOR SCUFF PLATE LH . Refer to «INSTALLATION - Step 29»(ref-387112-S34119271062011022400000)
7. INSTALL INSTRUMENT PANEL FINISH PANEL END LH . Refer to «INSTALLATION - Step 19»(ref-387101-S06767646592011022400000)
8. INSTALL CONSOLE UPPER PANEL ASSEMBLY . Refer to «INSTALLATION - Step 21»(ref-387101-S06767646592011022400000)
9. INSTALL FRONT CONSOLE UPPER PANEL GARNISH . Refer to «INSTALLATION - Step 22»(ref-387101-S06767646592011022400000)
10. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
11. PERFORM INITIALIZATION Perform initialization. Refer to «INITIALIZATION»(ref-386951-S21829001392011022400000) . NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
12. CHECK SRS WARNING LIGHT Check the SRS warning light. Refer to «DTC CHECK / CLEAR»(ref-387113-S10657878242011022400000) .
