# Courtesy lamps circuit

# Courtesy lamps circuit (1 of 3)

Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (1 of 3). Lexus GS II facelift (2000-2004)
Components on the diagram

    # Courtesy lamps circuit (2 of 3)

    Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (2 of 3). Lexus GS II facelift (2000-2004)
    Components on the diagram

      # Courtesy lamps circuit (3 of 3)

      Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (3 of 3). Lexus GS II facelift (2000-2004)
      Components on the diagram
