Wiring diagram: Air conditioning — Air conditioning circuits Lexus GS II facelift

Components on these wiring diagrams

Click a component to highlight it on every diagram it appears on.

• 1 2 M+ M
• 3.0L
• 4.3L
• 4.3L 3.0L
• A/C Ambient Temperature Sensor
• A/C Comp Relay
• A/C Condenser Fan Motor
• A/C Control Assembly
• A/C Magnetic Clutch, Lock Sensor
• A/C Room Temperature Sensor
• A/C Solar Sensor
• A/C Thermistor
• Air Inlet Control Servo Motor
• Air Mix Control Servo Motor2
• Air Vent Mode Control Servo Motor
• Blower Motor
• Blower Motor Controller
• Body ECU 1
• Combination Switch
• Dash Harn, Behind Combination Meter2
• Dgs Blw Mpx+ Tpi
• Driver Side J/B
• Driver Side J/B Ign Fuse
• Ed Ed
• Engine Control Module
• Engine Room R/B 1
• Engine Room R/B 3
• Exhaust Gas Sensor
• Fan 2 Relay
• Fan 3 Relay
• Gateway ECU
• Gnd Si B+ 2 3
• Heater Fuse
• Ill Tr Sg-1 Mpx- Tel In Sg-4 Sg-3 Ill Air Gnd
• Instrument Panel J/B
• J/C 13
• J/C 14
• J/C 172
• J/C 18
• J/C 2
• J/C 26
• Passenger Side J/B2
• Passenger Side R/B
• Radiator Fan Motor
• Sg-5 Aod Amcdr Amcpa
• Steering Pad Switch
• Telephone Transceiver, Speaker Relay
• Tilt, Telescopic ECU
• Tpi Mrec Sg
• Tspa Te Tpo
