A/C-HEATER SYSTEMS SPECIFICATIONS
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in appropriate AIR BAG RESTRAINT SYSTEM article in ACCESSORIES/SAFETY EQUIPMENT SECTION. |
Note. When battery is disconnected, radio will go into anti-theft protection mode. Obtain radio anti-theft protection code from owner prior to servicing vehicle.
| Application | Specifications |
|---|
| Compressor Type | Nippondenso 10PA20 10-Cyl. |
| Compressor Belt Tension (1) |
| Compressor Oil Capacity | (2) 4.1 ozs. |
| Refrigerant (R-134a) Capacity | 28.2-31.7 ozs. |
| System Operating Pressures (3) |
| High Side | 199-228 psi (14-16 kg/cm 2 ) |
| Low Side | 21-36 psi (1.5-2.5 kg/cm 2 ) |
| (1) Belt tension is maintained automatically. (2) Use Denso/ND-OIL 8 refrigerant. (3) Specification is with ambient temperature at 86-95°F (30-35°C) and engine speed at 1500 RPM. |
| (1) | Belt tension is maintained automatically. |
| (2) | Use Denso/ND-OIL 8 refrigerant. |
| (3) | Specification is with ambient temperature at 86-95°F (30-35°C) and engine speed at 1500 RPM. |
A/C-HEATER SYSTEMS SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor |
| Stud Bolt | 19 (26) |
| Bolts | 38 (52) |
| Power Steering Pump Bolts | 43 (58) |
| Steering Wheel Hub Nut | 26 (35) |
| INCH Lbs. (N.m) |
| Compressor Hoses | 88 (10) |
| Steering Wheel Pad Torx Screw | 78 (9) |
Automatic A/C-Heater System Wiring Diagram (1 Of 2). Scheme 1
Scheme 1: Automatic A/C-Heater System Wiring Diagram (1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2 Of 2). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (2 Of 2)
