Cellular Communication System (Service Information): Overview Lexus ES XV60

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

1. REMOVE FRONT SEAT ASSEMBLY RH Refer to «REMOVAL [06/2012 - ]»(ref-598624-S12707437232014021400000)
2. REMOVE AUDIO AMPLIFIER COVER Using a clip remover, remove the 2 clips and audio amplifier cover.
3. REMOVE DCM (TELEMATICS TRANSCEIVER) WITH BACK-UP BATTERY Remove the bolt and disengage the 2 guides. Pull out the DCM (telematics transceiver) with back-up battery in the direction indicated by the arrow shown in the illustration. Disconnect each connector.
4. REMOVE DCM (TELEMATICS TRANSCEIVER) WITH BRACKET Remove the 3 screws and DCM (telematics transceiver) with bracket.
5. REMOVE NO. 2 DCM (TELEMATICS TRANSCEIVER) BRACKET Remove the 2 screws and No. 2 DCM (telematics transceiver) bracket.
6. REMOVE DCM (TELEMATICS TRANSCEIVER) ASSEMBLY

See also:
• REMOVAL [06/2012 - ] - Step 1
• REMOVAL [06/2012 - ]
