Charging System (Diagnostics & Symptom Tests): Diagnosis Lexus ES XV60

PROBLEM SYMPTOMS TABLE [06/2012 - ]

1. Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. Inspect the fuses and relays related to this system before inspecting the suspected areas below.

CHARGING SYSTEM

Scheme 13

Scheme 14

Scheme 15

1. CHECK BATTERY CONDITION NOTE: If the battery is weak or if the engine is difficult to start, perform the following procedure. Check the battery for damage and deformation. If severe damage, deformation or leakage is found, replace the battery. Check the electrolyte quantity of each cell. For maintenance-free batteries: If the electrolyte quantity is below the lower line, replace the battery. If the electrolyte quantity is above the lower line, check the battery voltage when cranking the engine. If the voltage is less than 9.6 V, recharge or replace the battery. HINT: Before checking the battery voltage, turn off all the electrical systems (headlights, blower motor, rear defogger, etc.). For non-maintenance-free batteries: If the electrolyte quantity is below the lower line, add distilled water to each cell. Then, recharge the battery and check the electrolyte specific gravity. Standard specific gravity 1.25 to 1.29 at 20°C (68°F) If the electrolyte quantity is above the lower line, check the battery voltage when cranking the engine. If the voltage is less than 9.6 V, recharge or replace the battery. HINT: Before checking the battery voltage, turn off all the electrical systems (headlights, blower motor, rear defogger, etc.). Check the voltage. Turn the engine switch off and turn on the headlights for 20 to 30 seconds. This will remove the surface charge from the battery. Measure the battery voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition Positive (+) terminal - Negative (-) terminal 20°C (68°F) 12.5 to 12.9 V HINT: If the voltage is not as specified, charge the battery.
2. CHECK BATTERY TERMINAL Check that the battery terminals are not loose or corroded. If the voltage is not as specified, recharge or replace the battery.
3. CHECK FUSES Measure the resistance of each fuse for the charging system. HINT: The fuses shown in System Diagram are related to the charging system. Standard resistance Below 1 ohms If any of the results is not as specified, replace the fuse(s) as necessary.
4. INSPECT V-RIBBED BELT . Refer to «ON-VEHICLE INSPECTION [06/2012 - ] - Step 1»(ref-598588-S11761345822014021400000)
5. INSPECT GENERATOR WIRING Visually check the generator wiring. Check that the wiring is in good condition.
6. CHECK FOR ABNORMAL NOISE Check for abnormal noises from the generator assembly. Check that no abnormal noises are heard from the generator assembly while the engine is running.
7. INSPECT CHARGE WARNING LIGHT CIRCUIT Turn the engine switch on (IG). Check that the charge warning light comes on. Start the engine and check that the light goes off. If the light does not operate as specified, troubleshoot the charge warning light circuit.
8. INSPECT CHARGING CIRCUIT WITHOUT LOAD Connect a voltmeter and an ammeter to the charging circuit as follows. TEXT IN ILLUSTRATION *1 Ammeter *2 Terminal B *3 Generator Assembly *4 Voltmeter *5 Battery Disconnect the wire from terminal B of the generator assembly and connect it to the negative (-) lead of the ammeter. Connect the ammeter positive (+) lead to terminal B of the generator assembly. Connect the voltmeter positive (+) lead to the positive (+) terminal of the battery. Ground the voltmeter negative (-) lead. Check the charging circuit. Keep the engine speed at 2000 rpm and check the readings on the ammeter and voltmeter. Standard current 14 A or less Standard voltage 13.2 to 14.8 V If the result is not as specified, repair or replace the generator assembly. HINT: If the battery is not fully charged, the ammeter reading will sometimes be more than the standard amperage.
9. INSPECT CHARGING CIRCUIT WITH LOAD With the engine running at 2000 rpm, turn the high beam headlights on and turn the heater blower switch to the "HI" position. Check the reading on the ammeter. Standard current 30 A or more If the result is not as specified, repair or replace the generator assembly. HINT: If the battery is fully charged, the reading will sometimes be less than the standard amperage. If this is the case, add more electrical load (operate the wipers, rear window defogger, etc.) and check the reading on the ammeter again.

Scheme 16

1. CHECK LOCK FUNCTION OF GENERATOR PULLEY WITH CLUTCH Check the lock function with the generator pulley with clutch installed in the vehicle. Visually check that the rotor in the generator assembly operates with the engine running. Check the lock function with the generator pulley with clutch removed from the vehicle. Remove the generator pulley cap. Hold the center of the generator pulley with clutch, and confirm that the outer ring turns counterclockwise and does not turn clockwise. Refer to «INSPECTION [06/2012 - ] - Step 1»(/lexus/es/xv60-2012-2015/remont/charging-system/#charging-system-service-information) . TEXT IN ILLUSTRATION *a Free *b Lock OK The outer ring turns counterclockwise and does not turn clockwise. SST: 09820-63021 NG --> See step 3 OK: Go to next step
2. CHECK INSTALLATION OF GENERATOR PULLEY WITH CLUTCH Start the engine and visually check the generator pulley with clutch for looseness. OK The generator pulley with clutch is not loose. NG --> TIGHTEN GENERATOR PULLEY WITH CLUTCH TO THE SPECIFIED TORQUE OK --> See step 4
3. REPLACE GENERATOR PULLEY WITH CLUTCH. Refer to «COMPONENTS [06/2012 - ]»(/lexus/es/xv60-2012-2015/remont/charging-system/#charging-system-service-information)
4. REPLACE GENERATOR ASSEMBLY. Refer to «COMPONENTS [06/2012 - ]»(/lexus/es/xv60-2012-2015/remont/charging-system/#charging-system-service-information)
