Automatic Transmission (Service Information): Overview Lexus ES XV60

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

1. REPLACE AUTOMATIC TRANSAXLE FLUID Lift the vehicle. [*1] NOTE: Set the vehicle on a lift so that the vehicle is kept level when it is lifted up (make sure that the tilt angle from the front to rear of the vehicle is within +/- 1°). Remove the front wheel opening extension pad LH, engine under cover LH and front fender apron seal LH. Remove the refill plug and gasket from the automatic transaxle assembly. [*2] Using a 6 mm hexagon socket wrench, remove the overflow plug and gasket from the automatic transaxle assembly. [*3] Using a 6 mm hexagon socket wrench, remove the No. 1 transmission oil filler tube from the automatic transaxle oil pan sub-assembly and drain the automatic transaxle fluid. [*4] TEXT IN ILLUSTRATION *1 No. 1 Transmission Oil Filler Tube *2 Hexagon Socket Wrench *a Overflow Plug Hole Measure the amount of fluid drained. [*5] HINT: Add the same amount of fluid in step [*8]. Using a 6 mm hexagon socket wrench, install the No. 1 transmission oil filler tube to the automatic transaxle oil pan sub-assembly. [*6] Torque: 1.7 N*m (17 kgf*cm, 15 in.*lbf) Temporarily install the gasket and the overflow plug. [*7] HINT: Reuse the old gasket as the plug will be removed again to adjust the fluid level. Add fluid to the refill hole using the same amount of fluid drained in step [*5]. [*8] NOTE: Use Toyota Genuine ATF WS. Temporarily install the gasket and refill plug to avoid fluid spillage. [*9] HINT: Reuse the old gasket as the plug will be removed again to adjust the fluid level. Lower the vehicle. [*10] Start the engine. [*11] Slowly move the shift lever from P to D, and then back to P. [*12] Allow the engine to idle for 30 seconds to warm it up. [*13] Turn the engine switch off. [*14] Repeat steps [*1] to [*14]. Repeat steps [*1] to [*10].
2. ADJUST FLUID TEMPERATURE See step 6
3. ADJUST FLUID LEVEL See step 7
4. REBUILD WORK See step 8

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

1. PRECAUTIONS AND WORK DESCRIPTION The U660E automatic transaxle assembly does not have an oil filler tube and oil level gauge. When adding fluid, add fluid through the refill hole on the rear transaxle cover sub-assembly. The fluid level can be adjusted by draining excess fluid (allowing excess fluid to overflow) through the No. 1 transmission oil filler tube of the automatic transaxle oil pan sub-assembly. HINT: "Overflow" indicates the condition under which fluid comes out of the overflow plug hole. Before adjusting the fluid level, add the specified amount of fluid when the engine is cold and warm up the engine to circulate the fluid in the transaxle. Ensure that the fluid temperature is as specified and the engine is idling. The U660E automatic transaxle assembly requires Toyota Genuine ATF WS. The adjustment should be performed according to the procedures and notes.
2. WORK FLOW The adjustment should be performed according to the procedure referenced in the work flow below.
3. PREPARATION WORK Lift the vehicle. NOTE: Set the vehicle on a lift so that the vehicle is kept level when it is lifted up (make sure that the tilt angle from the front to rear of the vehicle is within +/- 1°). Remove the 2 bolts, clip and front fender apron seal LH.
4. PERFORM INITIAL FILLING NOTE: If the transaxle is hot (ATF temperature is high), wait until the fluid temperature becomes the same as the ambient temperature before starting the following procedure. (Recommended ATF temperature: around 20°C [68°F]) Remove the refill plug and gasket from the automatic transaxle assembly. NOTE: After performing any of the following operations, it is not necessary to perform the initial filling procedure. Proceed to the Add Specified Amount of Fluid procedure. Operations that do not require initial filling Disconnection of the oil cooler tube or oil cooler hose Repair of fluid leak due to a loose case plug, or a faulty plug gasket or O-ring Installation of a new automatic transaxle assembly with torque converter assembly (filled fluid parts) Using a 6 mm hexagon socket wrench, remove the overflow plug and gasket from the automatic transaxle assembly. NOTE: If ATF comes out after removing the overflow plug, wait until the fluid flow slows and only drips come out. If ATF comes out, it is not necessary to perform the initial filling procedure. After checking the tightening torque of the No. 1 transmission oil filler tube, temporarily tighten the overflow plug. Using a 6 mm hexagon socket wrench, check that the No. 1 transmission oil filler tube is tightened to the specified torque. Torque: 1.7 N*m (17 kgf*cm, 15 in.*lbf) NOTE: If the No. 1 transmission oil filler tube is not tightened to the specified torque, the amount of fluid cannot be precisely adjusted. HINT: To check the torque of the No. 1 transmission oil filler tube, insert the hexagon socket wrench into the overflow plug hole. TEXT IN ILLUSTRATION *1 No. 1 Transmission Oil Filler Tube *2 Hexagon Socket Wrench *a Overflow Plug Hole Perform initial filling. Fill the transaxle through the refill hole until fluid begins to come out of the overflow plug hole. NOTE: Use Toyota Genuine ATF WS. Wait until the fluid flow slows and only drips come out. Temporarily install the gasket and the overflow plug to the automatic transaxle assembly. HINT: Reuse the old gasket as the plug will be removed again to adjust the fluid level.
5. ADD SPECIFIED AMOUNT OF FLUID Fill the transaxle with the correct amount of fluid as listed in the table below. NOTE: Refill amount differs depending on the operation that was performed. Standard Capacity Performed Repair Fill Amount Disconnection of the oil cooler tube or oil cooler hose Repair of fluid leak due to a loose case plug, or a faulty plug gasket or O-ring Installation of a new automatic transaxle assembly with torque converter assembly (filled fluid parts) 0.5 liters (0.5 US qts., 0.4 Imp. qts.) Removal and installation of the drive shaft Removal and installation of the transaxle case oil seal Removal and installation of the automatic transaxle oil pan sub-assembly 2.8 liters (3.0 US qts., 2.5 Imp. qts.) Removal and installation of the transmission valve body assembly 3.2 liters (3.4 US qts., 2.8 Imp. qts.) Removal and installation of the automatic transaxle assembly (not including removal of the torque converter assembly) 3.4 liters (3.6 US qts., 3.0 Imp. qts.) Removal and installation of the torque converter assembly (torque converter assembly reused) 4.8 liters (5.1 US qts., 4.2 Imp. qts.) Installation of a new torque converter assembly 5.3 liters (5.6 US qts., 4.7 Imp. qts.) Temporarily install the gasket and refill plug to avoid fluid spillage. HINT: Reuse the old gasket as the plug will be removed again to adjust the fluid level. Lower the vehicle.
6. ADJUST FLUID TEMPERATURE When using the Techstream: HINT: The actual ATF temperature can be checked on the Data List using the Techstream. Connect the Techstream to the DLC3 with the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. NOTE: To reduce load, make sure that all electrical systems, such as the air conditioning, lighting system, electric fan and audio system are off. Enter the following menus: Powertrain / ECT / Active Test / Connect the TC and TE1. Select the Active Test menu: Connect the TC and TE1 / ON. Select the Data List item: A/T Oil Temperature 1. Check the ATF temperature. NOTE: If the fluid temperature is below 45°C (113°F), proceed to the next step. (Recommended ATF temperature: 40°C [104°F] or less) If the fluid temperature is 45°C (113°F) or more, turn the engine switch off and wait until the fluid temperature drops below 45°C (113°F). Depress and hold the brake pedal. Start the engine. Slowly move the shift lever from P to D, and then back to P. HINT: Slowly move the shift lever to circulate the fluid through each part of the transaxle. While observing the D shift indicator on the combination meter, move the shift lever back and forth between N and D at an interval of less than 1.5 seconds for 6 seconds or more. NOTE: Do not pause for more than 1.5 seconds. HINT: Performing this operation will cause the vehicle to enter fluid temperature detection mode. Check that the D shift indicator comes on for 2 seconds. HINT: When fluid temperature detection mode is activated, the D shift indicator on the combination meter comes on for 2 seconds. If the D shift indicator does not come on for 2 seconds, return to the first step and perform the procedure again. Move the shift lever from N to P. Release the brake pedal. Select the Active Test item: Connect the TC and TE1 / OFF. NOTE: Be sure that terminals TC and TE1 are not connected. If the terminals are connected, the fluid level cannot be precisely adjusted due to fluctuations in engine speed. HINT: Disconnecting terminals TC and TE1 activates engine idle speed control mode. In engine idle speed control mode, engine idle speed control starts when the fluid temperature becomes 35°C (95°F) or more and the engine speed is maintained at approximately 800 rpm. Even after terminals TC and TE1 are disconnected, fluid temperature detection mode is active until the engine switch is turned off. Warm up the engine with the engine idling until the fluid temperature reaches the fluid level adjustment temperature (40 to 45°C [104 to 113°F]). Below Fluid Level Adjustment Temperature Fluid Level Adjustment Temperature Above Fluid Level Adjustment Temperature 40°C or less (104°F or less) 40 to 45°C (104 to 113°F) 45°C or more (113°F or more) NOTE: If the fluid temperature is within the fluid level adjustment temperature range, immediately proceed to the Adjust Fluid Level procedure. If the fluid temperature is 45°C (113°F) or more, stop the engine and wait until the fluid temperature drops to 40°C (104°F) or less. Then perform the Adjust Fluid Temperature procedure again from the beginning. HINT: In fluid temperature detection mode, the D shift indicator comes on, goes off, or blinks depending on the fluid temperature. D SHIFT INDICATOR Below Fluid Level Adjustment Temperature (40°C or less) (104°F or less) Fluid Level Adjustment Temperature (40 to 45°C) (104 to 113°F) Above Fluid Level Adjustment Temperature (45°C or more) (113°F or more) OFF ON Blinks TEXT IN ILLUSTRATION *a Turned Off *b Turned On *c Blinking When not using the Techstream: Using SST, connect terminals 13 (TC) and 4 (CG) of the DLC3 with the engine switch off. SST: 09843-18040 TEXT IN ILLUSTRATION *1 DLC3 Depress and hold the brake pedal. Start the engine. NOTE: To reduce load, make sure that all electrical systems, such as the air conditioning, lighting system, electric fan and audio system, are off. HINT: The indicator lights on the combination meter blink to indicate the DTC output when terminals TC and CG are connected. Slowly move the shift lever from P to D, and then back to P. HINT: Slowly move the shift lever to circulate the fluid through each part of the transaxle. While observing the D shift indicator on the combination meter, move the shift lever back and forth between N and D at an interval of less than 1.5 seconds for 6 seconds or more. NOTE: Do not pause for more than 1.5 seconds. HINT: Performing this operation will cause the vehicle to enter fluid temperature detection mode. Check that the D shift indicator comes on for 2 seconds. HINT: When fluid temperature detection mode is activated, the D shift indicator on the combination meter comes on for 2 seconds. If the D shift indicator does not come on for 2 seconds, return to the first step and perform the procedure again. Move the shift lever from N to P. Release the brake pedal. Remove SST from terminals 13 (TC) and 4 (CG). SST: 09843-18040 NOTE: Be sure that terminals TC and CG are not connected. If the terminals are connected, the fluid level cannot be precisely adjusted due to fluctuations in engine speed. HINT: Disconnecting terminals TC and CG activates the engine idle speed control mode. In engine idle speed control mode, engine idle speed control starts when the fluid temperature becomes 35°C (95°F) or more and the engine speed is maintained at approximately 800 rpm. Even after terminals TC and CG are disconnected, fluid temperature detection mode is active until the engine switch is turned off. TEXT IN ILLUSTRATION *1 DLC3 Allow the engine to idle until the D shift indicator comes on again. D SHIFT INDICATOR Below Fluid Level Adjustment Temperature (40°C or less) (104°F or less) Fluid Level Adjustment Temperature (40 to 45°C) (104 to 113°F) Above Fluid Level Adjustment Temperature (45°C or more) (113°F or more) OFF ON Blinks NOTE: If the D shift indicator is on, immediately proceed to the Adjust Fluid Level procedure. If the D shift indicator blinks, stop the engine and wait until the fluid temperature drops to 40°C (104°F) or less (the indicator goes off). Then perform the Adjust Fluid Temperature procedure again from the beginning. HINT: In fluid temperature detection mode, the D shift indicator comes on, goes off, or blinks depending on the fluid temperature. Fluid filling procedure should be performed when the D shift indicator is on (the fluid temperature is within the fluid level adjustment temperature range). TEXT IN ILLUSTRATION *a Turned Off *b Turned On *c Blinking
7. ADJUST FLUID LEVEL WARNING: Use caution while the engine is idling and the radiator fan is operating. Lift the vehicle. NOTE: Set the vehicle on a lift so that the vehicle is kept level when it is lifted up (make sure that the tilt angle from the front to rear of the vehicle is within +/- 1°). Adjust the fluid level. Using a 6 mm hexagon socket wrench, remove the overflow plug and gasket from the automatic transaxle assembly. WARNING: Be careful as the fluid coming out of the overflow plug hole is hot. Check the amount of fluid that comes out of the overflow plug hole. NOTE: If only a small amount of fluid (approximately 1 cc) comes out of the overflow plug hole, then only fluid remaining in the No. 1 transmission oil filler tube has come out. This condition is not considered as overflow, so it is necessary to add fluid. If the amount of fluid that comes out of the overflow plug hole is large, wait until the fluid flow slows and only drips come out. If no fluid comes out of the overflow plug hole, remove the refill plug and gasket. Then add transaxle fluid through the refill hole until fluid comes out of the overflow plug hole. Wait until the fluid flow slows and only drips come out. NOTE: Use Toyota Genuine ATF WS. Check that the fluid flow has slowed and only drips come out. HINT: The fluid flow will not completely stop because the fluid continues to expand as its temperature increases. Install the overflow plug to the automatic transaxle assembly with a new gasket. Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) Install the refill plug to the automatic transaxle assembly with a new gasket. Torque: 49 N*m (500 kgf*cm, 36 ft.*lbf) Lower the vehicle. Turn the engine switch off. HINT: Turning the engine switch off exits fluid temperature detection mode. Remove the Techstream from the DLC3 (when using the Techstream).
8. REBUILD WORK Lift the vehicle. Clean each part. Check for fluid leaks. Install the front wheel opening extension pad LH, engine under cover LH and front fender apron seal LH. Lower the vehicle.

Scheme 67

Scheme 68

1. REMOVE TRANSMISSION VALVE BODY ASSEMBLY Refer to «REMOVAL [06/2012 - ]»(ref-598611-S39251553132014021400000)
2. REMOVE TRANSMISSION REVOLUTION SENSOR Disconnect the connector. Remove the 2 bolts and transmission revolution sensor from the transmission valve body assembly.

Scheme 69

1. INSTALL TRANSMISSION REVOLUTION SENSOR Coat the 2 bolts with ATF. Install the transmission revolution sensor to the transmission valve body assembly with the 2 bolts. Torque: 11 N*m (110 kgf*cm, 8 ft.*lbf) Connect the connector.
2. INSTALL TRANSMISSION VALVE BODY ASSEMBLY Refer to «INSTALLATION [06/2012 - ]»(ref-598611-S31984482712014021400000)

Scheme 70

Scheme 71

Scheme 72

1. REMOVE VALVE BODY OIL STRAINER ASSEMBLY See step 4
2. REMOVE ATF TEMPERATURE SENSOR ASSEMBLY Disconnect the connector. Remove the 4 bolts, ATF temperature sensor assembly and clamp from the transmission valve body assembly. TEXT IN ILLUSTRATION *1 Clamp Remove the O-ring from the ATF temperature sensor assembly. TEXT IN ILLUSTRATION *1 O-ring

Scheme 73

1. INSPECT ATF TEMPERATURE SENSOR ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition THO1 - E2 10°C (50°F) 5 to 8 kohms THO1 - E2 25°C (77°F) 2.5 to 4.5 kohms THO1 - E2 110°C (230°F) 0.22 to 0.28 kohms THO1 - Body ground Always 10 kohms or higher If the resistance is out of the specified range with the ATF temperature shown in the preceding table, replace the ATF temperature sensor assembly. Otherwise, the driveability of the vehicle may decrease.

Scheme 74

1. INSTALL ATF TEMPERATURE SENSOR ASSEMBLY Coat a new O-ring with ATF and install it to the ATF temperature sensor assembly. Coat the 4 bolts with ATF. Install the ATF temperature sensor assembly and clamp to the transmission valve body assembly with the 4 bolts. TEXT IN ILLUSTRATION *1 Clamp Torque: 11 N*m (110 kgf*cm, 8 ft.*lbf) Bolt length Bolt A 25 mm (0.984 in.) Bolt B 85 mm (3.35 in.) Connect the connector.
2. INSTALL VALVE BODY OIL STRAINER ASSEMBLY See step 3

Scheme 75

Scheme 76

Scheme 77

1. REMOVE TRANSMISSION VALVE BODY ASSEMBLY Refer to «REMOVAL [06/2012 - ]»(ref-598611-S39251553132014021400000)
2. REMOVE TRANSMISSION WIRE Disconnect the 9 connectors. Remove the transmission wire from the clamp. Remove the bolt, lock plate and transmission wire from the transmission valve body assembly.

Scheme 78

1. INSTALL TRANSMISSION WIRE Coat the O-ring with ATF. TEXT IN ILLUSTRATION *1 O-ring Coat the bolt with ATF. Install the transmission wire and lock plate to the transmission valve body assembly with the bolt. Torque: 11 N*m (110 kgf*cm, 8 ft.*lbf) Install the transmission wire to the clamp. Connect the 9 connectors.
2. INSTALL TRANSMISSION VALVE BODY ASSEMBLY Refer to «INSTALLATION [06/2012 - ]»(ref-598611-S31984482712014021400000)

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

1. REMOVE AUTOMATIC TRANSAXLE ASSEMBLY Refer to «REMOVAL [06/2012 - ]»(ref-598611-S38337276292014021400000)
2. REMOVE TORQUE CONVERTER ASSEMBLY See step 13
3. REMOVE AUTOMATIC TRANSAXLE OIL PAN SUB-ASSEMBLY Remove the 18 bolts and automatic transaxle oil pan sub-assembly from the transaxle case. NOTE: Some fluid will remain in the automatic transaxle oil pan sub-assembly. Remove all the automatic transaxle oil pan sub-assembly bolts and carefully remove the automatic transaxle oil pan sub-assembly. Remove the automatic transaxle oil pan gasket from the automatic transaxle oil pan sub-assembly. Remove the 2 transmission oil cleaner magnets from the automatic transaxle oil pan sub-assembly. TEXT IN ILLUSTRATION *1 Transmission Oil Cleaner Magnet Examine the particles in the automatic transaxle oil pan sub-assembly. Collect any steel chips with the removed magnets. Look carefully at the chips and particles in the automatic transaxle oil pan sub-assembly and on the transmission oil cleaner magnets to see the type of wear which might be found in the transaxle. Result Steel (magnetic) Bearing, gear and plate wear Brass (non-magnetic) Bushing wear
4. REMOVE VALVE BODY OIL STRAINER ASSEMBLY Remove the 2 bolts and valve body oil strainer assembly from the transmission valve body assembly. Remove the O-ring from the valve body oil strainer assembly. TEXT IN ILLUSTRATION *1 O-ring
5. REMOVE TRANSMISSION VALVE BODY ASSEMBLY Remove the 11 bolts and transmission valve body assembly from the transaxle case. NOTE: When removing the transmission valve body assembly, be careful not to allow the transmission revolution sensor and the transaxle case to interfere with each other.
6. REMOVE MANUAL VALVE Remove the manual valve from the transmission valve body assembly.

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

1. REMOVE TRANSMISSION WIRE See step 2
2. REMOVE ATF TEMPERATURE SENSOR ASSEMBLY Remove the 4 bolts, ATF temperature sensor assembly and clamp from the transmission valve body assembly. TEXT IN ILLUSTRATION *1 Clamp Remove the O-ring from the ATF temperature sensor assembly. TEXT IN ILLUSTRATION *1 O-ring
3. REMOVE SHIFT SOLENOID VALVE SL Remove the shift solenoid valve SL from the transmission valve body assembly.
4. REMOVE SHIFT SOLENOID VALVE SLT Remove the solenoid lock plate and shift solenoid valve SLT from the transmission valve body assembly. TEXT IN ILLUSTRATION *1 Solenoid Lock Plate *2 Shift Solenoid Valve SLT *3 Shift Solenoid Valve SLU
5. REMOVE SHIFT SOLENOID VALVE SLU Remove the shift solenoid valve SLU from the transmission valve body assembly.
6. REMOVE SHIFT SOLENOID VALVE SL2 Remove the bolt, solenoid lock plate and shift solenoid valve SL2 from the transmission valve body assembly. TEXT IN ILLUSTRATION *1 Solenoid Lock Plate *2 Shift Solenoid Valve SL2 *3 Shift Solenoid Valve SL1
7. REMOVE SHIFT SOLENOID VALVE SL1 Remove the shift solenoid valve SL1 from the transmission valve body assembly.
8. REMOVE SHIFT SOLENOID VALVE SL3 Remove the bolt, solenoid lock plate and shift solenoid valve SL3 from the transmission valve body assembly. TEXT IN ILLUSTRATION *1 Solenoid Lock Plate *2 Shift Solenoid Valve SL3
9. REMOVE SHIFT SOLENOID VALVE SL4 Remove the bolt, solenoid lock plate and shift solenoid valve SL4 from the transmission valve body assembly. TEXT IN ILLUSTRATION *1 Solenoid Lock Plate *2 Shift Solenoid Valve SL4

Scheme 95

Scheme 96

1. INSPECT SHIFT SOLENOID VALVE SL Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Solenoid Connector (SL) - Solenoid Body (SL) 20°C (68°F) 11 to 15 ohms TEXT IN ILLUSTRATION *a Shift Solenoid Valve SL If the value is not as specified, replace the shift solenoid valve. Connect a positive (+) lead from the battery to the terminal of the solenoid connector and a negative (-) lead to the solenoid body, and check the operation of the valve. NOTE: When using battery voltage during the inspection, do not bring the positive (+) and negative (-) tester probes too close to each other as a short circuit may occur. OK The valve moves and makes an operating sound. If the operation cannot be done as specified, replace the shift solenoid valve.
2. INSPECT SHIFT SOLENOID VALVE (SLT, SLU, SL1, SL2, SL3, SL4) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve SLT, SLU, SL1, SL2, SL3, SL4) If the value is not as specified, replace the shift solenoid valve. Connect a positive (+) lead from the battery with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, and check the operation of the valve. NOTE: When using battery voltage during the inspection, do not bring the positive (+) and negative (-) tester probes too close to each other as a short circuit may occur. OK The valve moves and makes an operating sound. If the operation cannot be done as specified, replace the shift solenoid valve.

Scheme 97

1. INSTALL SHIFT SOLENOID VALVE SL4 Coat the shift solenoid valve SL4 and bolt with ATF. TEXT IN ILLUSTRATION *1 Solenoid Lock Plate *2 Shift Solenoid Valve SL4 Install the shift solenoid valve SL4 and solenoid lock plate to the transmission valve body assembly with the bolt. Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf)
2. INSTALL SHIFT SOLENOID VALVE SL3 Coat the shift solenoid valve SL3 and bolt with ATF. TEXT IN ILLUSTRATION *1 Solenoid Lock Plate *2 Shift Solenoid Valve SL3 Install the shift solenoid valve SL3 and solenoid lock plate to the transmission valve body assembly with the bolt. Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf)
3. INSTALL SHIFT SOLENOID VALVE SL1 Coat the shift solenoid valve SL1 with ATF. TEXT IN ILLUSTRATION *1 Solenoid Lock Plate *2 Shift Solenoid Valve SL2 *3 Shift Solenoid Valve SL1 Install the shift solenoid valve SL1 to the transmission valve body assembly.
4. INSTALL SHIFT SOLENOID VALVE SL2 Coat the shift solenoid valve SL2 and bolt with ATF. Install the shift solenoid valve SL2 and solenoid lock plate to the transmission valve body assembly with the bolt. Torque: 11 N*m (110 kgf*cm, 8 ft.*lbf)
5. INSTALL SHIFT SOLENOID VALVE SLU Coat the shift solenoid valve SLU with ATF. TEXT IN ILLUSTRATION *1 Solenoid Lock Plate *2 Shift Solenoid Valve SLT *3 Shift Solenoid Valve SLU Install the shift solenoid valve SLU to the transmission valve body assembly.
6. INSTALL SHIFT SOLENOID VALVE SLT Coat the shift solenoid valve SLT with ATF. Install the shift solenoid valve SLT and solenoid lock plate to the transmission valve body assembly.
7. INSTALL SHIFT SOLENOID VALVE SL Coat the shift solenoid valve SL with ATF. Install the shift solenoid valve SL to the transmission valve body assembly.
8. INSTALL ATF TEMPERATURE SENSOR ASSEMBLY Coat a new O-ring with ATF and install it to the ATF temperature sensor assembly. TEXT IN ILLUSTRATION *1 O-ring Coat the 4 bolts with ATF. TEXT IN ILLUSTRATION *1 Clamp Install the ATF temperature sensor assembly and clamp to the transmission valve body assembly with the 4 bolts. Torque: 11 N*m (110 kgf*cm, 8 ft.*lbf) Bolt length Bolt A 25 mm (0.984 in.) Bolt B 85 mm (3.35 in.)
9. INSTALL TRANSMISSION WIRE See step 1

Scheme 98

Scheme 99

Scheme 100

1. INSTALL MANUAL VALVE Coat the manual valve with ATF and install it to the transmission valve body assembly.
2. INSTALL TRANSMISSION VALVE BODY ASSEMBLY Coat the O-ring of the transmission wire with ATF. Confirm that the manual valve lever sub-assembly is positioned as shown in the illustration and install the transmission valve body assembly to the transaxle case with the 11 bolts. Torque: 11 N*m (110 kgf*cm, 8 ft.*lbf) Bolt length Bolt A 25 mm (0.984 in.) Bolt B 30 mm (1.18 in.) Bolt C 35 mm (1.38 in.) Bolt D 45 mm (1.77 in.) Bolt E 55 mm (2.17 in.) NOTE: When installing the transmission valve body assembly, be careful not to allow the transmission revolution sensor and transaxle case to interfere with each other. Be sure to insert the pin of the manual valve lever sub-assembly into the groove on the end of the manual valve. First, temporarily tighten the bolts marked *a in the illustration because they are positioning bolts. TEXT IN ILLUSTRATION *a Positioning Bolt
3. INSTALL VALVE BODY OIL STRAINER ASSEMBLY Coat a new O-ring with ATF and install it to the valve body oil strainer assembly. NOTE: Ensure that the O-ring is not twisted or pinched. Install the valve body oil strainer assembly to the transmission valve body assembly with the 2 bolts. Torque: 11 N*m (110 kgf*cm, 8 ft.*lbf)
4. INSTALL AUTOMATIC TRANSAXLE OIL PAN SUB-ASSEMBLY Install the 2 transmission oil cleaner magnets onto the automatic transaxle oil pan sub-assembly as shown in the illustration. TEXT IN ILLUSTRATION *1 Transmission Oil Cleaner Magnet Install a new automatic transaxle oil pan gasket to the automatic transaxle oil pan sub-assembly. Install the automatic transaxle oil pan sub-assembly to the transaxle case with the 17 bolts. Torque: 7.5 N*m (76 kgf*cm, 66 in.*lbf) Clean and degrease the bolt and the installation hole in the transaxle case. Apply adhesive to the bolt. Adhesive Toyota Genuine Adhesive 1344, Three Bond 1344 or equivalent Install the bolt. Torque: 7.0 N*m (71 kgf*cm, 62 in.*lbf) NOTE: In order to ensure proper sealing of the automatic transaxle oil pan sub-assembly bolts, apply adhesive to the bolts and install them within 10 minutes of adhesive application. Completely remove any oil or grease from the contact surface of the transaxle case and automatic transaxle oil pan sub-assembly with the gasket before installation.
5. INSTALL TORQUE CONVERTER ASSEMBLY See step 1
6. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY Refer to «INSTALLATION [06/2012 - ]»(ref-598611-S29268603132014021400000)

Scheme 101
