Automatic Transmission (Diagnostic Codes & Circuit Tests): Diagnosis Lexus ES XV60

Automatic Trans 8 illustrations ~4739 words

INSPECTION PROCEDURE

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

Scheme 403

Scheme 403: PROCEDURE
Scheme 403: PROCEDURE
  1. READ VALUE USING TECHSTREAM (VEHICLE SPEED) Drive the vehicle and check whether the operation of the speedometer in the combination meter assembly is normal. HINT: The vehicle speed sensor is operating normally if the speedometer reading is normal. If the speedometer does not operate, check it by following the procedure described for a speedometer malfunction. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Data List / Vehicle Speed. Drive the vehicle. Read the value displayed on the Techstream. OK Vehicle speeds displayed on tester and speedometer display are equal. NG --> See step 2 OK --> See step 6
  2. CHECK COMBINATION METER ASSEMBLY (SPD SIGNAL WAVEFORM) Inspect the combination meter assembly using an oscilloscope. Move the shift lever to N. Jack up the vehicle. Turn the engine switch on (IG). Measure the voltage between the terminal of the combination meter assembly and the body ground while the wheel is turned slowly. Standard Voltage Tester Connection Condition Specified Condition H14-19 (+S) - Body ground Engine switch on (IG) Voltage generated intermittently TEXT IN ILLUSTRATION *a Component with harness connected (Combination Meter Assembly) HINT: The output voltage should fluctuate up and down, similarly to the diagram, when the wheel is turned slowly. As the vehicle speed increases, the width indicated by (A) in the illustration narrows. NG --> See step 5 OK: Go to next step
  3. CHECK HARNESS AND CONNECTOR (COMBINATION METER ASSEMBLY - TCM) Disconnect the combination meter assembly connector. Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition H14-9 (+S) - D6-3 (SPD) Always Below 1 ohms Reconnect the combination meter assembly connector. Reconnect the TCM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (COMBINATION METER ASSEMBLY - TCM) OK --> See step 4
  4. REPLACE TCM. Refer to «COMPONENTS [06/2012 - ]»(ref-598611-S34944164312014021400000)
  5. GO TO METER / GAUGE SYSTEM (SPEED SIGNAL CIRCUIT). Refer to «Speed Signal Circuit»(ref-598609-S29310982022014021400000)
  6. SYMPTOM SIMULATION AND DTC CHECK. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [06/2012 - ]»(ref-598449-S34618498472014021400000)

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

HINT

  1. The following troubleshooting flowchart is based on the premise that the engine is cranked normally. If the engine does not crank, proceed to the problem symptoms table.Refer to «PROBLEM SYMPTOMS TABLE [06/2012 - ]»(ref-598472-S12013296402014021400000) .
  2. Read freeze frame data using the Techstream. The TCM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was running or stopped, whether the engine was warmed up or not, whether the air-fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction.Refer to «FREEZE FRAME DATA [06/2012 - ]»(ref-598472-S37095654262014021400000) .

Scheme 404

Scheme 404: PROCEDURE
Scheme 404: PROCEDURE
  1. READ VALUE USING TECHSTREAM (STARTER SIGNAL) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Data List. Tester Display Measurement Item/Range Normal Condition Diagnostic Note Starter Signal Starter signal/ ON or OFF ON: Starter operating OFF: Starter not operating - Crank the engine. Read the value displayed on the Techstream. OK Tester Display Condition Specified Condition Starter Signal Engine switch on (IG) OFF Starter Signal Engine is cranking ON NG --> See step 2 OK --> See step 7
  2. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Disconnect the park/neutral position switch connector. Measure the resistance according to the value(s) in the table below when the shift lever is moved to each position. Standard Resistance Tester Connection Condition Specified Condition D5-4 (B) - D5-9 (L) P Below 1 ohms N Below 1 ohms Except P and N 10 kohms or higher D5-1 (RB) - D5-9 (L) P 10 kohms or higher R 10 kohms or higher N 10 kohms or higher D 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Park/Neutral Position Switch) NG --> See step 6 OK: Go to next step
  3. CHECK HARNESS AND CONNECTOR (TCM - PARK/NEUTRAL POSITION SWITCH) Disconnect the TCM connector. Remove the ST relay from the engine room relay block and junction block assembly. Disconnect the park/neutral position switch connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition D6-10 (STA) - Body ground Engine switch on (IG) Below 1 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  4. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs.Refer to «DTC CHECK / CLEAR [06/2012 - ]»(ref-598475-S37876009632014021400000) . Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / ECT/ Trouble Codes. Read the DTCs. RESULT: Result Proceed to DTC is not output OK DTC P0617 is output NG NG --> See step 5 OK --> END
  5. REPLACE TCM. Refer to «COMPONENTS [06/2012 - ]»(ref-598611-S34944164312014021400000)
  6. REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «COMPONENTS [06/2012 - ]»(ref-598611-S30122884242014021400000)
  7. CHECK FOR INTERMITTENT PROBLEMS. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [06/2012 - ]»(ref-598449-S04910338212014021400000)

Note. After turning engine switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work.Refer to PRECAUTION [06/2012 - ] . Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

HINT

Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time.

Note. In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not.

  1. Warm up the engine.
  2. Turn the engine switch off.
  3. Connect the Techstream to the DLC3.
  4. Turn the engine switch on (IG).
  5. Turn the Techstream on.
  6. Enter the following menus: Powertrain / ECT / Data List.
  7. According to the display on the Techstream, read the Data List. Tester Display Measurement Item / Range Normal Condition Diagnostic Note Neutral Position SW Signal PNP switch status / ON or OFF ON: Shift lever is in P or N OFF: Shift lever is not in P or N When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. Shift SW Status (R Range) PNP switch status / ON or OFF ON: Shift lever is in R OFF: Shift lever is not in R When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. Shift SW Status (D Range) PNP switch status / ON or OFF ON: Shift lever is in D or S OFF: Shift lever is not in D or S When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect.

Scheme 405

Scheme 405: PROCEDURE
Scheme 405: PROCEDURE

Scheme 406

Scheme 406
Scheme 406

Scheme 407

Scheme 407
Scheme 407
  1. CHECK HARNESS AND CONNECTOR (BATTERY - PARK/NEUTRAL POSITION SWITCH) Disconnect the park/neutral position switch assembly connector. Turn the engine switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition D5-1 (RB) - Body ground Engine switch on (IG) 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Park/Neutral Position Switch Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  2. CHECK HARNESS AND CONNECTOR (OUTPUT SIGNAL) Turn the engine switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition D5-4 (B) - Body ground Engine switch on (IG) 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Park/Neutral Position Switch Assembly) NG --> See step 5 OK: Go to next step
  3. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Disconnect the park/neutral position switch assembly connector. Measure the resistance according to the value(s) in the table below when the shift lever is moved to each position. Standard Resistance Tester Connection Shift Lever Position Specified Condition D5-4 (B) - D5-9 (L) P or N Below 1 ohms Except P and N 10 kohms or higher D5-1 (RB) - D5-2 (RL) R Below 1 ohms Except R 10 kohms or higher D5-1 (RB) - D5-7 (DL) D, S, "+" or "-" Below 1 ohms Except D, S, "+" and "-" 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Park/Neutral Position Switch Assembly) NG --> See step 7 OK: Go to next step
  4. CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - TCM) Connect the park/neutral position switch Assembly connector. Disconnect the TCM connectors. Turn the engine switch on (IG), and measure the voltage according to the value(s) in the table below when the shift lever is moved to each position. Standard Voltage Tester Connection Shift Lever Position Specified Condition D6-15 (R) - Body ground R 11 to 14 V* Except R Below 1 V D6-16 (D) - Body ground D, S, "+" or "-" 11 to 14 V Except D, S, "+" and "-" Below 1 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) HINT: *: The voltage will drop slightly due to lighting up of the back up light. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
  5. CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - TCM) Turn the engine switch off. Disconnect the TCM connector. Disconnect the park/neutral position switch Assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition D5-4 (B) - D6-11 (NSW) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition D5-4 (B) or D6-11 (NSW) - Body ground and other terminals Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
  6. REPLACE TCM. Refer to «COMPONENTS [06/2012 - ]»(ref-598611-S34944164312014021400000)
  7. REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «COMPONENTS [06/2012 - ]»(ref-598611-S30122884242014021400000)

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] . If DTCs P0711 and P2610 are output simultaneously, confirm that the ATF temperature is as specified in "Normal Condition" using the Techstream first. When the ATF temperature is as specified in "Normal Condition", perform troubleshooting for DTC P2610.Refer to DIAGNOSTIC TROUBLE CODE CHART [06/2012 - ] . In the table below, the value listed under "Normal Condition" are reference values.

HINT

Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time.

  1. Warm up the engine.
  2. Turn the engine switch off.
  3. Connect the Techstream to the DLC3.
  4. Turn the engine switch on (IG).
  5. Turn the Techstream on.
  6. Enter the following menus: Powertrain / ECT / Data List.
  7. According to the display on the Techstream, read the Data List. TCM Tester Display Measurement Item/Range Normal Condition Diagnostic Note A/T Oil Temperature 1 ATF temperature sensor value/ Min.: -40°C (-40°F) Max.: 215°C (419°F) After stall speed test: Approximately 80°C (176°F) While engine is cold: Equal to ambient temperature If value is -40°C (-40°F) or 150°C (302°F), ATF temperature sensor circuit is open or short circuited HINT: When DTC P0712 is output and the Techstream indicates 150°C (302°F) or more, there is a short circuit. When DTC P0713 is output and the Techstream indicates -40°C (-40°F), there is an open circuit. Measure the resistance between terminal THO1 (OT) and body ground. Temperature Displayed Malfunction -40°C (-40°F) Open circuit 150°C (302°F) or more Short circuit HINT: If a circuit related to the ATF temperature sensor becomes open, P0713 is immediately set (in 0.5 seconds). When P0713 is set, P0711 cannot be detected. It is not necessary to inspect the circuit when P0711 is set.

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

HINT

Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time.

Note. In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not.

  1. Warm up the engine.
  2. Turn the engine switch off.
  3. Connect the Techstream to the DLC3.
  4. Turn the engine switch on (IG).
  5. Turn the Techstream on.
  6. Enter the following menus: Powertrain / ECT / Data List.
  7. According to the display on the Techstream, read the Data List. TCM Tester Display Measurement Item/Range Normal Condition Diagnostic Note A/T Oil Temperature 1 ATF temperature sensor value/ Min.: -40°C (-40°F) Max.: 215°C (419°F) After stall speed test: Approximately 80°C (176°F) While engine is cold: Equal to ambient temperature If value is -40°C (-40°F) or 150°C (302°F), ATF temperature sensor circuit is open or short circuited HINT: When DTC P0712 is output and the Techstream indicates 150°C (302°F) or more, there is a short circuit. When DTC P0713 is output and the Techstream indicates -40°C (-40°F), there is an open circuit. Measure the resistance between terminal THO1 (OT) and body ground. Temperature Displayed Malfunction -40°C (-40°F) Open circuit 150°C (302°F) or more Short circuit HINT: If the circuit related to the ATF temperature sensor becomes open, P0713 is immediately set (in 0.5 seconds). When P0713 is set, P0711 cannot be detected. It is not necessary to inspect the circuit when P0711 is set.

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

HINT

Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time.

Note. In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not.

  1. Warm up the engine.
  2. Turn the engine switch off.
  3. Connect the Techstream to the DLC3.
  4. Turn the engine switch on (IG).
  5. Turn the Techstream on.
  6. Enter the following menus: Powertrain / ECT / Data List.
  7. According to the display on the Techstream, read the Data List. TCM Tester Display Measurement Item/Range Normal Condition Diagnostic Note SPD (NT) Input shaft speed/ Min.: 0 rpm Max.: 12750 rpm Lock-up is ON (after warming up engine): Input turbine speed (NT) is equal to engine speed OFF (idling with shift lever in N): Input turbine speed (NT) is nearly equal to engine speed Data is displayed in increments of 50 rpm HINT: SPD (NT) is always 0 while driving: Open or short in the sensor or circuit. SPD (NT) is always more than 0 and less than 300 rpm while driving the vehicle at 50 km/h (31 mph) or more: Sensor trouble, improper installation, or intermittent connection trouble of the circuit.

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

Scheme 408

Scheme 408: PROCEDURE
Scheme 408: PROCEDURE
  1. READ VALUE USING DATA LIST (STP SIGNAL) HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Data List. According to the display on the Techstream, read the Data List. OK Tester Display Measurement Item/Range Normal Condition Diagnostic Note Stop Light Switch Stop light switch status/ ON or OFF Brake pedal is ON: Depressed OFF: Released - NOTE: In the table above, the conditions listed under "Normal Condition" are reference conditions. Do not depend solely on these reference conditions when deciding whether a part is faulty. NG --> See step 2 OK --> CHECK FOR INTERMITTENT PROBLEMS
  2. CHECK STOP LIGHT SWITCH ASSEMBLY INSTALLATION Check the stop light switch assembly installation.Refer to «INSTALLATION [06/2012 - ]»(ref-598610-S26765205372014021400000) . OK Stop light switch assembly is installed correctly. NG --> SECURELY REINSTALL STOP LIGHT SWITCH ASSEMBLY OK: Go to next step
  3. INSPECT STOP LIGHT SWITCH ASSEMBLY Inspect the stop light switch assembly.Refer to «ON-VEHICLE INSPECTION [06/2012 - ]»(ref-598610-S33221477832014021400000) . NG --> See step 6 OK: Go to next step
  4. CHECK HARNESS AND CONNECTOR (STOP LIGHT SWITCH ASSEMBLY - TCM) Install the stop light switch assembly. Connect the stop light switch connector. Disconnect the TCM connector. Measure the voltage according to the value(s) in the table below when the brake pedal is depressed and released. Standard Voltage Tester Connection Condition Specified Condition D6-12 (STP) - Body ground Brake pedal is depressed 7.5 to 14 V D6-12 (STP) - Body ground Brake pedal is released Below 1 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
  5. REPLACE TCM. Refer to «COMPONENTS [06/2012 - ]»(ref-598611-S34944164312014021400000)
  6. REPLACE STOP LIGHT SWITCH ASSEMBLY. Refer to «COMPONENTS [06/2012 - ]»(ref-598610-S01816437082014021400000)

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

HINT

Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests.

Scheme 409

Scheme 409: INSPECTION PROCEDURE
Scheme 409: INSPECTION PROCEDURE
  1. PERFORM ACTIVE TEST Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Active Test. According to the display on the Techstream, perform the Active Test. Tester Display Test Part Control Range Diagnostic Note Activate the Lock Up Controls the shift solenoid SLU and SL to set the automatic transaxle to the lock-up condition. ON/OFF Can be used to check SLU and SL solenoid operation. [Vehicle Condition] Throttle valve opening angle: Less than 20% Vehicle speed:60 km/h (37 mph) or more, and 6th gear HINT: This test can be conducted when the vehicle speed is 60 km/h (37 mph) or more. Lightly depress the accelerator pedal and check that the engine speed does not change abruptly. HINT: When changing the accelerator pedal opening angle while driving, if the engine speed does not change, lock-up is on. Slowly release, but not fully, the accelerator pedal in order to decelerate. (Fully releasing the pedal will close the throttle valve and lock-up may be turned off.)

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

HINT

The following table shows normal operation of the shift solenoid valve SL1 when the shift lever is in D

TCM commanded gear1st2nd3rd4th5th6th
Shift solenoid valve SL1ONONONONOFFOFF

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

HINT

The following table shows normal operation of the shift solenoid valve SL2 when the shift lever is in D

TCM commanded gear1st2nd3rd4th5th6th
Shift solenoid valve SL2OFFOFFOFFONONON

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

  1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Data List. According to the display on the Techstream, read the Data List. Item Measurement Item/Range (display) Normal Condition Diagnostic Note SPD (NC) Counter gear speed/ Min.: 0 rpm, Max.: 12750 rpm - Data is displayed in increments of 50 rpm HINT: SPD (NC) is always 0 while driving: Open or short in the sensor or circuit. SPD (NC) is always more than 0 and less than 300 rpm while driving the vehicle at 50 km/h (31 mph) or more: Sensor trouble, improper installation, or intermittent connection trouble of the circuit.

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

HINT

Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests.

  1. ACTIVE TEST Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Active Test. According to the display on the Techstream, perform the Active Test. Tester Display Test Part Control Range Diagnostic Note Activate the Lock Up Control the shift solenoid SLU and SL to set the automatic transaxle to the lock-up condition. ON/OFF Can be used to check SLU and SL solenoid operation. [Vehicle Condition] Throttle valve opening angle: Less than 20% Vehicle speed:60 km/h (37 mph) or more, and 6th gear HINT: This test can be conducted when the vehicle speed is 60 km/h (37 mph) or more. Lightly depress the accelerator pedal and check that the engine speed does not change abruptly. HINT: When changing the accelerator pedal opening angle while driving, if the engine speed does not change, lock-up is on. Slowly release, but not fully, the accelerator pedal in order to decelerate. (Fully releasing the pedal will close the throttle valve and lock-up may be turned off.)

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs.Refer to DTC CHECK / CLEAR [06/2012 - ] .

HINT

  1. Refer to inspection procedure for CAN communication system.
  2. If the CAN communication malfunctions, the TCM cannot receive the current data from the ECM. In this case, the freeze frame data output from the TCM has not been updated, so the data will not be useful for the inspection. However, reading the Data List as the first step in troubleshooting is effective to find malfunctions.
  3. The malfunction area can be checked using the Bus Check function on the Techstream.Refer to «DIAGNOSIS SYSTEM [06/2012 - ]»(ref-598642-S28836115522014021400000) .

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

  1. Refer to inspection procedure for CAN communication system.
  2. If the CAN communication malfunctions, the TCM cannot receive the current data from the ECM. In this case, the freeze frame data output from the TCM has not been updated, so the data will not be useful for the inspection. However, reading the Data List as the first step in troubleshooting is effective to find malfunctions.
  3. The malfunction area can be checked using the Bus Check function on the Techstream.Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [06/2012 - ]»(ref-598635-S10414945732014021400000) .

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Scheme 410

Scheme 410: PROCEDURE
Scheme 410: PROCEDURE
  1. CHECK HARNESS AND CONNECTOR (TCM - BODY GROUND) Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D6-8 (E1) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  2. INSPECT ECU TERMINAL VOLTAGE (+B TERMINAL) Disconnect the TCM connector. Turn the engine switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition D6-18 (+B) - Body ground Engine switch on (IG) 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) NG --> See step 3 OK --> See step 4
  3. CHECK HARNESS AND CONNECTOR (TCM - INTEGRATION RELAY) Remove the integration relay from the engine room relay block and junction block assembly. Disconnect the integration relay connector. Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition D6-18 (+B) - 1A-4 (+B) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition D6-18 (+B) or 1A-4 (+B) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
  4. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE [06/2012 - ]»(ref-598475-S41601500052014021400000)
  5. GO TO ECM POWER SOURCE CIRCUIT (ENGINE CONTROL SYSTEM / SFI SYSTEM). Refer to «ECM Power Source Circuit»(ref-598599-S31649039382014021400000)
