Audio / Visual (W/o Navigation) (Diagnostic Codes & Symptom Tests): Overview Lexus ES XV40 facelift

Entertainment Systems 46 illustrations ~7920 words

DESCRIPTION

DTC No.DTC Detection ConditionTrouble Area
01-21A ROM malfunction exists.Radio receiver assembly
01-22A RAM malfunction exists.
01-2EA checksum malfunction exists.
DTC No.DTC Detection ConditionTrouble Area
01-D5 *1, *3A device indicated by the sub-code is (was) disconnected from the system with the engine switch on (IG) or (ACC). The communication condition with the device that the DTC shows cannot be obtained when the engine starts.Power source circuit of the component shown by the sub-code AVC-LAN circuit between the radio receiver assembly and component shown by the sub-code Component shown by the sub-code
01-D8 *2, *3The device indicated by the sub-code is (was) disconnected from the system after the engine starts.
01-D9 *1, *3The device that had functioned before the engine stopped is (was) disconnected from the system with the engine switch on (IG) or (ACC).
01-DA *3No response is identified when changing mode. Sound and image do not change by switch operation.
01-DB *1, *3A dual alarm is detected.
01-DE *3A slave device has been disconnected after the engine starts.

HINT

  1. *1: Even if no fault is present, this DTC may be stored depending on the battery condition or engine start voltage.
  2. *2: If the power connector is disconnected after the engine starts, this DTC is stored after 180 seconds.
  3. *3: If the device is reported as not existing during verification, check the power source circuit and AVC-LAN circuit for the device.

Note. Before starting troubleshooting, be sure to clear the DTCs stored due to the reasons described in the HINT above. Then, check for DTCs and troubleshoot according to the output DTCs. The radio receiver assembly is the master unit. Be sure to clear and recheck for DTCs after the inspection is completed to confirm that no DTCs are output.

DTC No.DTC Detection ConditionTrouble Area
01-D6*1Either condition is met: The device that stores (stored) the DTC has (had) been disconnected with the engine switch on (IG) or (ACC). The master device has (had) been disconnected when this DTC is (was) stored.Radio receiver assembly power source circuit Power source circuit of the component which has stored this code AVC-LAN circuit between the radio receiver assembly and component which has stored this code Component which has stored this code Radio receiver assembly
01-D7*2Either condition is met: The device that stored the code has (had) been disconnected after the engine starts (started). The master device has (had) been disconnected when this DTC is (was) stored.

HINT

  1. *1: Even if no fault is present, this DTC may be stored depending on the battery condition or engine start voltage.
  2. *2: When 210 seconds have elapsed after disconnecting the power supply connector of the master component with the engine switch on (IG) or (ACC), this DTC is stored.

Note. Before starting troubleshooting, be sure to clear the DTCs stored due to the reasons described in the HINT above. Then, check for DTCs and troubleshoot according to the output DTCs. The radio receiver assembly is the master unit. Be sure to clear and recheck for DTCs after the inspection is completed to confirm that no DTCs are output.

DTC No.DTC Detection ConditionTrouble Area
01-DC *1Transmission to component shown by sub-code failed (Detecting this DTC does not always mean actual failure).If the same sub-code is stored in other components, check power source circuit and communication system of all components shown by sub-code

HINT

*1: If the engine switch is turned off after idling for 60 seconds, this DTC may be stored when the engine is started again.

Note. Before starting troubleshooting, be sure to clear the DTCs stored due to the reason described in the HINT above. Then, check for DTCs and troubleshoot according to the output DTCs. The radio receiver assembly is the master unit. Be sure to clear and recheck for the DTCs after the inspection is completed to confirm that no DTCs are output.

DTC No.DTC Detection ConditionTrouble Area
01-DD *1The device that should be the master has been disconnected after the engine starts.Radio receiver assembly power source circuit AVC-LAN circuit between the radio receiver assembly and component which has stored this code Radio receiver assembly Component which has stored this code
01-E1 *2The AMP device stores that the AMP output does not function even while the source device operates.

HINT

  1. *1: If the engine switch is turned off after idling for 60 seconds, this DTC may be stored when the engine is started again.
  1. *2: Even if no fault is present, this DTC may be stored depending on the battery condition or engine start voltage.

Note. Before starting troubleshooting, be sure to clear the DTCs stored due to the reasons described in the HINT above. Then, check for DTCs and troubleshoot according to the output DTCs. The radio receiver assembly is the master unit. Be sure to clear and recheck for the DTCs after the inspection is completed to confirm that no DTCs are output.

DTC No.DTC Detection ConditionTrouble Area
01-DF *1The device with a display fails and the master unit is switched to the audio device. Also when a communication error between the sub-master unit (audio) and master unit occurs, this DTC is stored.Radio receiver assembly power source circuit AVC-LAN circuit between the radio receiver assembly and component which has stored this code Radio receiver assembly Component which has stored this code

HINT

*1: When 210 seconds have elapsed after disconnecting the power supply connector of the master component with the engine switch on (IG) or (ACC), this DTC is stored.

Note. Before starting troubleshooting, be sure to clear the DTCs stored due to the reason described in the HINT above. Then, check for DTCs and troubleshoot according to the output DTCs. The radio receiver assembly is the master unit. Be sure to clear and recheck for the DTCs after the inspection is completed to confirm that no DTCs are output.

DTC No.DTC Detection ConditionTrouble Area
01-E0"Registration complete" signal from the master device cannot be received.
01-E3Either condition is met: The registration demand signal from the slave device is output. The registration demand signal is output by receiving connection confirmation signal from the sub-master device.
01-E4The multiple frame transmission is incomplete.

HINT

Even if no fault is present, these DTCs may be stored depending on the battery condition or engine start voltage.

DTC No.DTC Detection ConditionTrouble Area
01-E2The command for ON/OFF control from the master device has a problem.Radio receiver assembly
DTC No.DTC Detection ConditionTrouble Area
01-F2Any reply to a system inspection instruction, system inspection result request or diagnosis memory request could not be completed within a designated time.Stereo component amplifier assembly
01-FFNo response to a diagnosis request
DTC No.DTC Detection ConditionTrouble Area
57-10"Bluetooh" module malfunctionRadio receiver assembly
57-47"Bluetooth" module is not installed. Problem with "Bluetooth" module Problem in communication line to "Bluetooth" module
DTC No.DTC Detection ConditionTrouble Area
60-10The AM tuner PLL (Phase Locked Loop) synchronization is impossible.Radio receiver assembly
60-11The FM tuner PLL (Phase Locked Loop) synchronization is impossible.
DTC No.DTC Detection ConditionTrouble Area
60-42The power source of the tuner is abnormal.Radio receiver assembly
60-43The AM tuner is abnormal.
60-44The FM tuner is abnormal.
60-50A problem occurs in the IC inside the tuner unit and radio reception is not normal.
DTC No.DTC Detection ConditionTrouble Area
63-10A mechanical error in the CD changer is detected while the CD is not being inserted or ejected.Radio receiver assembly
63-11CDs cannot be inserted or ejected.
63-12CD read problem occurs.
DTC No.DTC Detection ConditionTrouble Area
63-41An unsuitable disc is inserted.CD Radio receiver assembly
63-42The disc cannot be read.
DTC No.DTC Detection ConditionTrouble Area
63-43CD-ROM operation is abnormal.CD Radio receiver assembly
DTC No.DTC Detection ConditionTrouble Area
63-44Operation error in the CD mechanismRadio receiver assembly
63-48Excess current is present in the CD changer.
63-50Malfunction in insertion/ejection system
DTC No.DTC Detection ConditionTrouble Area
63-45CD cannot be ejected.Radio receiver assembly
63-51Mechanical error occurs during elevator operation.
63-52Error occurs in CD changer clamp.
DTC No.DTC Detection ConditionTrouble Area
63-46Scratches or dirt is found on CD surface or CD is inserted upside down.CD Radio receiver assembly
DTC No.DTC Detection ConditionTrouble Area
63-47Sensor detects that CD unit temperature is high (Over 80°C (176°F)).Radio receiver assembly
DTC No.DTC Detection ConditionTrouble Area
63-78An error occurs during the decode process (MP3/WMA).
DTC No.DTC Detection ConditionTrouble Area
63-7DAn incompatible MP3/WMA file is used. Although the file has an extension of ".mp3" or ".wma", the header information cannot be read.CD Radio receiver assembly
63-7EA disc with no music data is used. Playable files are not on the disc (MP3/WMA).
63-7FCopyright protection exists and playback is not possible.

This DTC is stored when a malfunction occurs in the speakers.

DTC No.DTC Detection ConditionTrouble Area
74-40A short is detected in the speaker output circuit.Wire harness or connector Speaker DCM (Telematics transceiver)*1 Stereo component amplifier assembly
  1. *1: w/ Manual (SOS) Switch

Scheme 191

Scheme 191: WIRING DIAGRAM
Scheme 191: WIRING DIAGRAM

Scheme 192

Scheme 192
Scheme 192

Scheme 193

Scheme 193: PROCEDURE
Scheme 193: PROCEDURE

Scheme 194

Scheme 194
Scheme 194

Scheme 195

Scheme 195
Scheme 195

Scheme 196

Scheme 196
Scheme 196

Scheme 197

Scheme 197
Scheme 197

Scheme 198

Scheme 198
Scheme 198
  1. INSPECT STEREO COMPONENT AMPLIFIER ASSEMBLY Disconnect stereo component amplifier assembly connectors M35 and M32. Clear the DTCs and recheck for DTCs. Check if DTC 74-40 is output. OK DTC 74-40 is not output. NG --> See step 16 OK: Go to next step
  2. CHECK OPERATION Reconnect stereo component amplifier assembly connector M32. Check if DTC 74-40 is output. OK DTC 74-40 is not output. NG --> See step 9 OK: Go to next step
  3. CHECK HARNESS AND CONNECTOR Disconnect stereo component amplifier assembly connector M35, DCM (telematics transceiver) connector E97 (w/ Manual (SOS) Switch) and speaker connectors H8, E87, I7, E86, J5 and K5. Measure the resistance between the stereo component amplifier assembly and body ground to check for a short circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M35-10 (FR+) - Body ground Always 10 kohms or higher M35-9 (FR-) - Body ground Always 10 kohms or higher M35-3 (FL+) - Body ground Always 10 kohms or higher M35-8 (FL-) - Body ground Always 10 kohms or higher M35-5 (RR+) - Body ground Always 10 kohms or higher M35-12 (RR-) - Body ground Always 10 kohms or higher M35-4 (RL+) - Body ground Always 10 kohms or higher M35-11 (RL-) - Body ground Always 10 kohms or higher Measure the resistance between the front No. 1 speakers and body ground to check for a short circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition H8-1 - Body ground Always 10 kohms or higher H8-2 - Body ground Always 10 kohms or higher I7-1 - Body ground Always 10 kohms or higher I7-2 - Body ground Always 10 kohms or higher w/ Manual (SOS) Switch: Measure the resistance between the front No. 2 speaker RH and body ground to check for a short circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition E87-1 (TWR+) - Body ground Always 10 kohms or higher E87-2 (TWR-) - Body ground Always 10 kohms or higher Measure the resistance between the front No. 2 speaker LH and the stereo component amplifier assembly to check for an open circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M35-3 (FL+) - E86-1 (TWL+) Always Below 1 ohms M35-8 (FL-) - E86-2 (TWL-) Always Below 1 ohms w/o Manual (SOS) Switch: Measure the resistance between the front No. 2 speaker RH and the stereo component amplifier assembly to check for an open circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M35-10 (FR+) - E87-1 (TWR+) Always Below 1 ohms M35-9 (FR-) - E87-2 (TWR-) Always Below 1 ohms w/ Manual (SOS) Switch: Measure the resistance between the stereo component amplifier assembly and the DCM (telematics transceiver) to check for an open circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M35-10 (FR+) - E97-2 (SPI+) Always Below 1 ohms M35-9 (FR-) - E97-3 (SPI-) Always Below 1 ohms w/ Manual (SOS) Switch: Measure the resistance between the front No. 2 speaker RH and the DCM (telematics transceiver) to check for an open circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition E97-5 (SPO+) - E87-1 (TWR+) Always Below 1 ohms E97-6 (SPO-) - E87-2 (TWR-) Always Below 1 ohms Measure the resistance between each of the rear speakers and the stereo component amplifier assembly to check for an open circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M35-5 (RR+) - J5-1 Always Below 1 ohms M35-12 (RR-) - J5-2 Always Below 1 ohms M35-4 (RL+) - K5-1 Always Below 1 ohms M35-11 (RL-) - K5-2 Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  4. INSPECT FRONT NO. 1 SPEAKER Resistance check Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition H8-1 - H8-2 Always 3.2 to 4.8 ohms I7-1 - I7-2 Always 3.2 to 4.8 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Front No. 1 Speaker) NG --> See step 12 OK: Go to next step
  5. INSPECT FRONT NO. 2 SPEAKER Resistance check Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E87-1 (TWR+) - E87-2 (TWR-) Always 10 kohms or higher E86-1 (TWL+) - E86-2 (TWL-) Always 10 kohms or higher TEXT IN ILLUSTRATION *A for RH *B for LH *1 Component without harness connected (Front No. 2 Speaker) NG --> See step 17 OK: Go to next step
  6. INSPECT REAR SPEAKER Resistance check Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition J5-1 - J5-2 Always 3.2 to 4.8 ohms K5-1 - K5-2 Always 3.2 to 4.8 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Rear Speaker) Proceed to the next step based on the inspection result. Result Condition Proceed to OK (w/ Manual (SOS) Switch) A OK (w/o Manual (SOS) Switch) B NG C C --> See step 13 B --> See step 16 A: Go to next step
  7. INSPECT DCM (TELEMATICS TRANSCEIVER) Resistance check Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E97-2 (SPI+) - E97-5 (SPO+) Always Below 1 ohms E97-3 (SPI-) - E97-6 (SPO-) Always Below 1 ohms E97-2 (SPI+) - E97-3 (SPI-) Always 10 kohms or higher E97-5 (SPO+) - E97-6 (SPO-) Always 10 kohms or higher E97-3 (SPI-) - Body ground Always 10 kohms or higher E97-6 (SPO-) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *1 Component without harness connected (DCM (Telematics Transceiver)) NG --> See step 8 OK --> See step 16
  8. REPLACE DCM (TELEMATICS TRANSCEIVER). Refer to «REMOVAL»(ref-396740-S39942374592011050900000)
  9. CHECK HARNESS AND CONNECTOR Disconnect stereo component amplifier assembly connector M32 and speaker connectors M28, and G2. Measure the resistance between the stereo component amplifier assembly and body ground to check for a short circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M32-8 (CTR+) - Body ground Always 10 kohms or higher M32-7 (CTR-) - Body ground Always 10 kohms or higher M32-1 (WF1+) - Body ground Always 10 kohms or higher M32-5 (WF1-) - Body ground Always 10 kohms or higher M32-2 (WF2+) - Body ground Always 10 kohms or higher M32-6 (WF2-) - Body ground Always 10 kohms or higher Measure the resistance between the front stereo component speaker and the stereo component amplifier assembly to check for an open circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M32-8 (CTR+) - G2-1 Always Below 1 ohms M32-7 (CTR-) - G2-2 Always Below 1 ohms Measure the resistance between the stereo component speaker and the stereo component amplifier assembly to check for an open circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M32-1 (WF1+) - M28-4 (WF1+) Always Below 1 ohms M32-5 (WF1-) - M28-3 (WF1-) Always Below 1 ohms M32-2 (WF2+) - M28-2 (WF2+) Always Below 1 ohms M32-6 (WF2-) - M28-1 (WF2-) Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  10. INSPECT FRONT STEREO COMPONENT SPEAKER Resistance check Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition G2-1 - G2-2 Always 8 to 12 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Front Stereo Component Speaker) NG --> See step 14 OK: Go to next step
  11. INSPECT STEREO COMPONENT SPEAKER Resistance check Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition M28-4 (WF1+) - M28-3 (WF1-) Always 2 to 3 ohms M28-2 (WF2+) - M28-1 (WF2-) Always 2 to 3 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Stereo Component Speaker) NG --> See step 15 OK --> See step 16
  12. REPLACE FRONT NO. 1 SPEAKER. Refer to «REMOVAL»(ref-396678-S19670409452011050900000)
  13. REPLACE REAR SPEAKER. Refer to «REMOVAL»(ref-396678-S36636587502011050900000)
  14. REPLACE FRONT STEREO COMPONENT SPEAKER. Refer to «REMOVAL»(ref-396678-S16200948222011050900000)
  15. REPLACE STEREO COMPONENT SPEAKER. Refer to «REMOVAL»(ref-396678-S42189017472011050900000)
  16. REPLACE STEREO COMPONENT AMPLIFIER ASSEMBLY. Refer to «REMOVAL»(ref-396678-S22179403352011050900000)
  17. REPLACE FRONT NO. 2 SPEAKER. Refer to «REMOVAL»(ref-396678-S19670409452011050900000)
DTC No.DTC Detection ConditionTrouble Area
C0-11Tuner PLL synchronization is impossible.Radio receiver assembly
C0-12A communication error occurred in CDED.
C0-13A communication error occurred in SSDEC.
C0-14No response received from SSDEC.
C0-15An error occurred in CAP internal NVM.
C0-16An error occurred in CAP.
DTC No.DTC Detection ConditionTrouble Area
C0-40Antenna is not connected.Antenna cord Satellite radio antenna Radio receiver assembly
C0-41Short in antenna circuit
DTC No.DTC Detection ConditionTrouble Area
CB-10System microcomputer malfunctionMulti-media interface ECU "iPod" or USB device
CB-11Media interface microcomputer malfunction
CB-12CD-LSI (Large Scale Integration) malfunction
DTC No.DTC Detection ConditionTrouble Area
CB-13"iPod" or USB device overcurrent malfunction"iPod" or USB device No. 1 stereo jack adapter assembly Wire harness or connector Multi-media interface ECU

Scheme 199

Scheme 199: WIRING DIAGRAM
Scheme 199: WIRING DIAGRAM

Scheme 200

Scheme 200: PROCEDURE
Scheme 200: PROCEDURE

Scheme 201

Scheme 201
Scheme 201
  1. REPLACE USB DEVICE OR "iPod" Disconnect the USB device or "iPod" from the No. 1 stereo jack adapter assembly. Turn the engine switch off. HINT: When this DTC has been stored, it is necessary to turn off the engine switch to make it possible for the vehicle to recognize a new device when it is connected. Turn the engine switch on (ACC). Connect a known good USB device or "iPod" to the No. 1 stereo jack adapter assembly. NEXT: Go to next step
  2. CLEAR DTC Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-396741-S39865480252011050900000) . NEXT: Go to next step
  3. RECHECK FOR DTC Recheck for DTCs and check if the same DTC is output again. HINT: If DTCs are detected frequently, replace the multi-media interface ECU. OK No DTCs are output. NG --> See step 4 OK --> USB DEVICE OR "iPod" WAS DEFECTIVE
  4. INSPECT MULTI-MEDIA INTERFACE ECU Disconnect the No. 1 stereo jack adapter assembly connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition z1-1 (UPI) - z1-4 (UJSG) Always 5 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to No. 1 Stereo Jack Adapter Assembly) NG --> See step 6 OK --> See step 5
  5. REPLACE NO. 1 STEREO JACK ADAPTER ASSEMBLY. Refer to «REMOVAL»(ref-396678-S02275346842011050900000)
  6. CHECK WIRE HARNESS AND CONNECTOR Disconnect the multi-media interface ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E113-4 (UPO) - z1-1 (UPI) Always Below 1 ohms E113-1 (UESG) - z1-4 (UJSG) Always Below 1 ohms z1-1 (UPI) - Body ground Always 10 kohms or higher z1-4 (UJSG) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to No. 1 Stereo Jack Adapter Assembly) *2 Front view of wire harness connector (to Multi-media Interface ECU) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 7
  7. REPLACE MULTI-MEDIA INTERFACE ECU. Refer to «REMOVAL»(ref-396678-S07558536532011050900000)
DTC No.DTC Detection ConditionTrouble Area
CB-43When a non mass-storage class or in compatible protocol USB device is connected.Multi-media interface ECU USB device
CB-44When a USB device with an incompatible file system, corrupted or incompatible File Allocation Table (FAT) is connected.
CB-50"iPod" malfunctionMulti-media interface ECU "iPod"
CB-51When an "iPod" with an unsupported firmware is connected.
CB-7DWhen an unsupported model of "iPod" is connected.
DTC No.DTC Detection ConditionTrouble Area
CB-45Communication error with USB deviceMulti-media interface ECU USB device
CB-46"iPod" control software malfunctionMulti-media interface ECU "iPod"
CB-47Communication error with "iPod"
DTC No.DTC Detection ConditionTrouble Area
CB-52No playable files on the "iPod""iPod"
CB-7ENo playable files on the USB deviceUSB device

Speed signals are received from the combination meter assembly and used to cancel "Bluetooth" function operation.

The radio receiver assembly recognizes that the vehicle is being to driven and makes it impossible to connect or register a "Bluetooth" device while driving.

HINT

  1. A voltage of 12 V or 5 V is output from each ECU and then input to the combination meter assembly. The signal is changed to a pulse signal at the transistor in the combination meter assembly. Each ECU controls the respective system based on the pulse signal.
  2. If a short occurs in any of the ECUs or in the wire harness connected to an ECU, all systems in the following diagram will not operate normally.

Scheme 202

Scheme 202: WIRING DIAGRAM
Scheme 202: WIRING DIAGRAM

Scheme 203

Scheme 203: PROCEDURE
Scheme 203: PROCEDURE
  1. INSPECT COMBINATION METER ASSEMBLY (OUTPUT WAVEFORM) Check the output waveform. Remove the combination meter assembly with the connector still connected. Connect an oscilloscope to terminal E20-12 (+S) and body ground. Turn the engine switch on (IG). Turn a wheel slowly. Check the signal waveform according to the condition(s) in the table below. Item Condition Tool setting 5 V/DIV., 20 ms./DIV. Vehicle condition Wheel being rotated OK The waveform is similar to that shown in the illustration. HINT: When the system is functioning normally, one wheel revolution generates 4 pulses. As the vehicle speed increases, the width indicated by (A) in the illustration narrows. TEXT IN ILLUSTRATION *1 Component with harness connected (Combination Meter Assembly) NG --> See step 8 OK: Go to next step
  2. CHECK HARNESS AND CONNECTOR (RADIO RECEIVER ASSEMBLY - COMBINATION METER ASSEMBLY) Disconnect the radio receiver assembly and combination meter assembly connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E70-3 (SPD) - E20-12 (+S) Always Below 1 ohms NG --> See step 3 OK --> See step 7
  3. CHECK HARNESS AND CONNECTOR (RADIO RECEIVER ASSEMBLY - NO. 4 JUNCTION BLOCK) Disconnect the radio receiver assembly and No. 4 junction block. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E70-3 - 4K-7 Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  4. CHECK HARNESS AND CONNECTOR (NO. 4 JUNCTION BLOCK - NO. 3 JUNCTION BLOCK) Disconnect the No. 3 junction block and No. 4 junction block. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 4M-8 - 3F-5 Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  5. INSPECT NO. 4 JUNCTION BLOCK Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 4K-7 - 4M-8 Always Below 1 ohms NG --> REPLACE NO. 4 JUNCTION BLOCK OK: Go to next step
  6. INSPECT NO. 3 JUNCTION BLOCK Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3F-5 - 3P-6 Always Below 1 ohms NG --> REPLACE NO. 3 JUNCTION BLOCK OK --> See step 7
  7. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-396678-S10849609972011050900000)
  8. GO TO METER / GAUGE SYSTEM. Refer to «Speed Signal Circuit»(ref-396647-S25441360352011050900000)

This circuit sends an operation signal from the steering pad switch assembly to the radio receiver assembly.

If there is an open in the circuit, the audio system cannot be operated using the steering pad switch assembly.

If there is a short in the circuit, the same condition as to when a switch is continuously depressed occurs.

Therefore, the radio receiver assembly cannot be operated using the steering pad switch assembly, and also the radio receiver assembly itself cannot function.

Scheme 204

Scheme 204: WIRING DIAGRAM
Scheme 204: WIRING DIAGRAM

Power is supplied to the radio receiver assembly and steering pad switch assembly illumination when the light control switch is in the tail or head position.

Scheme 205

Scheme 205: WIRING DIAGRAM
Scheme 205: WIRING DIAGRAM

If there is a short in a speaker circuit, the stereo component amplifier assembly detects the short and stops output to the speakers.

Thus sound cannot be heard from the speakers even if there is no malfunction in the stereo component amplifier assembly, DCM (telematics transceiver)*1 or speakers.

  1. *1: w/ Manual (SOS) Switch

Scheme 206

Scheme 206
Scheme 206
  1. CHECK HARNESS AND CONNECTOR Disconnect the connectors from the stereo component amplifier assembly, DCM (telematics transceiver) (w/ Manual (SOS) Switch) and speakers. Measure the resistance between the front No. 2 speaker LH and the stereo component amplifier assembly to check for an open circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M35-3 (FL+) - E86-1 (TWL+) Always Below 1 ohms M35-8 (FL-) - E86-2 (TWL-) Always Below 1 ohms w/o Manual (SOS) Switch: Measure the resistance between the front No. 2 speaker RH and the stereo component amplifier assembly to check for an open circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M35-10 (FR+) - E87-1 (TWR+) Always Below 1 ohms M35-9 (FR-) - E87-2 (TWR-) Always Below 1 ohms w/ Manual (SOS) Switch: Measure the resistance between the stereo component amplifier assembly and the DCM (telematics transceiver) to check for an open circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M35-10 (FR+) - E97-2 (SPI+) Always Below 1 ohms M35-9 (FR-) - E97-3 (SPI-) Always Below 1 ohms w/ Manual (SOS) Switch: Measure the resistance between the front No. 2 speaker RH and the DCM (telematics transceiver) to check for an open circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition E97-5 (SPO+) - E87-1 (TWR+) Always Below 1 ohms E97-6 (SPO-) - E87-2 (TWR-) Always Below 1 ohms Measure the resistance between each of the front No. 2 speakers and the front No. 1 speakers to check for an open circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition E87-3 (+) - H8-1 Always Below 1 ohms E87-4 (-) - H8-2 Always Below 1 ohms E86-3 (+) - I7-1 Always Below 1 ohms E86-4 (-) - I7-2 Always Below 1 ohms Measure the resistance between each of the rear speakers and the stereo component amplifier assembly to check for an open circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M35-5 (RR+) - J5-1 Always Below 1 ohms M35-12 (RR-) - J5-2 Always Below 1 ohms M35-4 (RL+) - K5-1 Always Below 1 ohms M35-11 (RL-) - K5-2 Always Below 1 ohms Measure the resistance between the front stereo component speaker and the stereo component amplifier assembly to check for an open circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M32-8 (CTR+) - G2-1 Always Below 1 ohms M32-7 (CTR-) - G2-2 Always Below 1 ohms Measure the resistance between the stereo component speaker and the stereo component amplifier assembly to check for an open circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M32-1 (WF1+) - M28-4 (WF1+) Always Below 1 ohms M32-5 (WF1-) - M28-3 (WF1-) Always Below 1 ohms M32-2 (WF2+) - M28-2 (WF2+) Always Below 1 ohms M32-6 (WF2-) - M28-1 (WF2-) Always Below 1 ohms Measure the resistance between the stereo component amplifier assembly and body ground to check for a short circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M35-10 (FR+) - Body ground Always 10 kohms or higher M35-9 (FR-) - Body ground Always 10 kohms or higher M35-3 (FL+) - Body ground Always 10 kohms or higher M35-8 (FL-) - Body ground Always 10 kohms or higher M35-5 (RR+) - Body ground Always 10 kohms or higher M35-12 (RR-) - Body ground Always 10 kohms or higher M35-4 (RL+) - Body ground Always 10 kohms or higher M35-11 (RL-) - Body ground Always 10 kohms or higher M32-8 (CTR+) - Body ground Always 10 kohms or higher M32-7 (CTR-) - Body ground Always 10 kohms or higher M32-1 (WF1+) - Body ground Always 10 kohms or higher M32-5 (WF1-) - Body ground Always 10 kohms or higher M32-2 (WF2+) - Body ground Always 10 kohms or higher M32-6 (WF2-) - Body ground Always 10 kohms or higher w/ Manual (SOS) Switch: Measure the resistance between the front No. 2 speaker RH and body ground to check for a short circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition M87-1 (TWR+) - Body ground Always 10 kohms or higher M87-2 (TWR-) - Body ground Always 10 kohms or higher Measure the resistance between the front No. 1 speakers and body ground to check for a short circuit in the wire harness. Standard Resistance Tester Connection Condition Specified Condition H8-1 - Body ground Always 10 kohms or higher H8-2 - Body ground Always 10 kohms or higher I7-1 - Body ground Always 10 kohms or higher I7-2 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  2. INSPECT FRONT NO. 1 SPEAKER Resistance check Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition H8-1 - H8-2 Always 3.2 to 4.8 ohms I7-1 - I7-2 Always 3.2 to 4.8 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Front No. 1 Speaker) NG --> See step 9 OK: Go to next step
  3. INSPECT FRONT NO. 2 SPEAKER Resistance check Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E87-1 (TWR+) - E87-3 (+) Always Below 1 ohms E87-2 (TWR-) - E87-4 (-) Always Below 1 ohms E87-1 (TWR+) - E87-2 (TWR-) Always 10 kohms or higher E86-1 (TWL+) - E86-3 (+) Always Below 1 ohms E86-2 (TWL-) - E86-4 (-) Always Below 1 ohms E86-1 (TWL+) - E86-2 (TWL-) Always 10 kohms or higher TEXT IN ILLUSTRATION *A for RH *B for LH *1 Component without harness connected (Front No. 2 Speaker) NG --> See step 14 OK: Go to next step
  4. REPLACE FRONT NO. 2 SPEAKER Check that the malfunction disappears when a known good speaker is installed. Refer to «REMOVAL»(ref-396678-S19670409452011050900000) . OK Malfunction disappears. HINT: Connect all the connectors to the front No. 2 speakers that were disconnected. When there is a possibility that either the right or left front speaker is defective, inspect by interchanging the right one with the left one. Perform the above inspection on both LH and RH sides. NG --> See step 5 OK --> END (FRONT NO. 2 SPEAKER WAS DEFECTIVE)
  5. INSPECT REAR SPEAKER Resistance check Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition J5-1 - J5-2 Always 3.2 to 4.8 ohms K5-1 - K5-2 Always 3.2 to 4.8 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Rear Speaker) NG --> See step 10 OK: Go to next step
  6. INSPECT FRONT STEREO COMPONENT SPEAKER Resistance check Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition G2-1 - G2-2 Always 1.6 to 2.4 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Front Stereo Component Speaker) NG --> See step 11 OK: Go to next step
  7. INSPECT STEREO COMPONENT SPEAKER Resistance check Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition M28-4 (WF1+) - M28-3 (WF1-) Always 1.6 to 2.4 ohms M28-2 (WF2+) - M28-1 (WF2-) Always 1.6 to 2.4 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Stereo Component Speaker) Proceed to the next step based on the inspection result. Result Condition Proceed to OK (w/ Manual (SOS) Switch) A OK (w/o Manual (SOS) Switch) B NG C C --> See step 12 B --> PROCEED TO NEXT SUSPECTED AREA SHOWN IN «PROBLEM SYMPTOMS TABLE»(ref-396741-S05259221712011050900000) PROBLEM SYMPTOMS TABLE A: Go to next step
  8. INSPECT DCM (TELEMATICS TRANSCEIVER) Resistance check Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E97-2 (SPI+) - E97-5 (SPO+) Always Below 1 ohms E97-3 (SPI-) - E97-6 (SPO-) Always Below 1 ohms E97-2 (SPI+) - E97-3 (SPI-) Always 10 kohms or higher E97-5 (SPO+) - E97-6 (SPO-) Always 10 kohms or higher E97-3 (SPI-) - Body ground Always 10 kohms or higher E97-6 (SPO-) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *1 Component without harness connected (DCM (Telematics Transceiver)) NG --> See step 13 OK --> PROCEED TO NEXT SUSPECTED AREA SHOWN IN «PROBLEM SYMPTOMS TABLE»(ref-396741-S05259221712011050900000) PROBLEM SYMPTOMS TABLE
  9. REPLACE FRONT NO. 1 SPEAKER. Refer to «REMOVAL»(ref-396678-S19670409452011050900000)
  10. REPLACE REAR SPEAKER. Refer to «REMOVAL»(ref-396678-S36636587502011050900000)
  11. REPLACE FRONT STEREO COMPONENT SPEAKER. Refer to «REMOVAL»(ref-396678-S16200948222011050900000)
  12. REPLACE STEREO COMPONENT SPEAKER. Refer to «REMOVAL»(ref-396678-S42189017472011050900000)
  13. REPLACE DCM (TELEMATICS TRANSCEIVER). Refer to «REMOVAL»(ref-396740-S39942374592011050900000)
  14. REPLACE FRONT NO. 2 SPEAKER. Refer to «REMOVAL»(ref-396678-S19670409452011050900000)

The radio receiver assembly sends sounds signal to the stereo component amplifier assembly through this circuit.

The sound signal that has been sent is amplified by the stereo component amplifier assembly, and then is sent to the speakers.

If there is an open or short in the circuit, sound cannot be heard from the speakers even if there is no malfunction in the stereo component amplifier assembly, radio receiver assembly, DCM (telematics transceiver)*1 or speakers.

  1. *1: w/ Manual (SOS) Switch

Scheme 207

Scheme 207: WIRING DIAGRAM
Scheme 207: WIRING DIAGRAM

The multi-media interface ECU sends sound signals to the radio receiver assembly through this circuit.

If there is an open or short in the circuit, sound cannot be heard from the speakers even if there is no malfunction in the stereo component amplifier assembly, radio receiver assembly, DCM (telematics transceiver)*1 or speakers.

  1. *1: w/ Manual (SOS) Switch

Scheme 208

Scheme 208: WIRING DIAGRAM
Scheme 208: WIRING DIAGRAM

The No. 1 stereo jack adapter assembly sends sound signal from an external device to the radio receiver assembly through this circuit.

The sound signal that has been sent is amplified by the stereo component amplifier assembly or radio receiver assembly, and then is sent to the speakers.

If there is an open or short in the circuit, sound cannot be heard from the speakers even if there is no malfunction in the stereo component amplifier assembly, radio receiver assembly, DCM (telematics transceiver)*1 or speakers.

  1. *1: w/ Manual (SOS) Switch

Scheme 209

Scheme 209: WIRING DIAGRAM
Scheme 209: WIRING DIAGRAM

Scheme 210

Scheme 210: PROCEDURE
Scheme 210: PROCEDURE
  1. CHECK HARNESS AND CONNECTOR (RADIO RECEIVER ASSEMBLY - NO. 1 STEREO JACK ADAPTER ASSEMBLY) Disconnect the No. 1 stereo jack adapter assembly and radio receiver assembly connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance W/O USB AUDIO SYSTEM Tester Connection Condition Specified Condition F5-4 (AUXO) - E70-19 (AUXI) Always Below 1 ohms F5-2 (ARO) - E70-15 (ARI) Always Below 1 ohms F5-1 (ALO) - E70-17 (ALI) Always Below 1 ohms F5-5 (AGND) - E70-18 (AGND) Always Below 1 ohms F5-3 (ASGN) - E70-16 (ASGN) Always Below 1 ohms F5-3 (ASGN) - Body ground Always Below 1 ohms F5-4 (AUXO) - Body ground Always 10 kohms or higher F5-2 (ARO) - Body ground Always 10 kohms or higher F5-1 (ALO) - Body ground Always 10 kohms or higher F5-5 (AGND) - Body ground Always 10 kohms or higher W/ USB AUDIO SYSTEM Tester Connection Condition Specified Condition z1-9 (AUXO) - E70-19 (AUXI) Always Below 1 ohms z1-8 (ASGN) - E70-16 (ASGN) Always Below 1 ohms z1-6 (ARO) - E70-15 (ARI) Always Below 1 ohms z1-7 (ALO) - E70-17 (ALI) Always Below 1 ohms z1-10 (AGND) - E70-18 (AGND) Always Below 1 ohms z1-9 (AUXO) - Body ground Always 10 kohms or higher z1-8 (ASGN) - Body ground Always 10 kohms or higher z1-6 (ARO) - Body ground Always 10 kohms or higher z1-7 (ALO) - Body ground Always 10 kohms or higher z1-10 (AGND) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *A w/o USB Audio System *B w/ USB Audio System *1 Front view of wire harness connector (to Radio Receiver Assembly) *2 Front view of wire harness connector (to No. 1 Stereo Jack Adapter Assembly) *3 Front view of wire harness connector (to No. 1 Stereo Jack Adapter Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 2
  2. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-396741-S05259221712011050900000)

The No. 1 stereo jack adapter assembly sends the sound data signal of an external device to the multi-media interface ECU through this circuit.

Scheme 211

Scheme 211: WIRING DIAGRAM
Scheme 211: WIRING DIAGRAM

Scheme 212

Scheme 212: PROCEDURE
Scheme 212: PROCEDURE

Scheme 213

Scheme 213
Scheme 213
  1. CHECK HARNESS AND CONNECTOR Disconnect the multi-media interface ECU connector. Disconnect the No. 1 stereo jack adapter assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition z1-3 (UDO+) - E113-2 (UDI+) Always Below 1 ohms z1-2 (UDO-) - E113-3 (UDI-) Always Below 1 ohms z1-5 (UJSS) - E113-5 (UESS) Always Below 1 ohms z1-3 (UDO+) - Body ground Always 10 kohms or higher z1-2 (UDO-) - Body ground Always 10 kohms or higher z1-5 (UJSS) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Multi-media Interface ECU) *2 Front view of wire harness connector (to No. 1 Stereo Jack Adapter Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 2
  2. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-396741-S05259221712011050900000)

This circuit sends a signal to the stereo component amplifier assembly to mute noise. Because of that, the noise produced by changing the sound source ceases.

If there is an open in the circuit, noise can be heard from the speakers when changing the sound source.

If there is a short in the circuit, even though the stereo component amplifier assembly is functioning, no sound, or only an extremely faint sound, can be heard.

Scheme 214

Scheme 214: WIRING DIAGRAM
Scheme 214: WIRING DIAGRAM

Scheme 215

Scheme 215: PROCEDURE
Scheme 215: PROCEDURE

Scheme 216

Scheme 216
Scheme 216
  1. INSPECT STEREO COMPONENT AMPLIFIER ASSEMBLY Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition M30-1 (MUTE) - Body ground Engine switch on (ACC), audio system is playing --> Changing sources Above 2.5 V --> Below 0.5 V TEXT IN ILLUSTRATION *1 Component with harness connected (Stereo Component Amplifier Assembly) NG --> See step 2 OK --> See step 5
  2. CHECK HARNESS AND CONNECTOR Disconnect the radio receiver assembly and stereo component amplifier assembly connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E69-7 (MUTE) - M30-1 (MUTE) Always Below 1 ohms E69-7 (MUTE) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  3. INSPECT STEREO COMPONENT AMPLIFIER ASSEMBLY (OUTPUT SIGNAL) Reconnect the stereo component amplifier assembly connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition E69-7 (MUTE) - Body ground Engine switch on (ACC), audio system is playing Above 2.5 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Radio Receiver Assembly) NG --> See step 6 OK --> See step 4
  4. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-396678-S10849609972011050900000)
  5. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-396741-S05259221712011050900000)
  6. REPLACE STEREO COMPONENT AMPLIFIER ASSEMBLY. Refer to «REMOVAL»(ref-396678-S22179403352011050900000)

The multi-media interface ECU sends a mute signal to the radio receiver assembly.

The radio receiver assembly controls the volume according to the mute signal from the multi-media interface ECU.

The mute signal is sent to reduce noise and popping sounds generated when switching modes.

If there is an open in the circuit, noise can be heard from the speakers when changing the sound source.

If there is a short in the circuit, even though the radio receiver assembly is functioning, no sound, or only an extremely faint sound, can be heard.

Scheme 217

Scheme 217: WIRING DIAGRAM
Scheme 217: WIRING DIAGRAM

Scheme 218

Scheme 218: PROCEDURE
Scheme 218: PROCEDURE

Scheme 219

Scheme 219
Scheme 219
  1. INSPECT RADIO RECEIVER ASSEMBLY Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition E110-6 (MUTE) - Body ground Engine switch on (ACC), USB audio system is playing --> Mode is changing Above 2.5 V --> Below 0.5 V TEXT IN ILLUSTRATION *1 Component with harness connected (Radio Receiver Assembly) NG --> See step 2 OK --> See step 4
  2. CHECK HARNESS AND CONNECTOR (RADIO RECEIVER ASSEMBLY - MULTI-MEDIA INTERFACE ECU) Disconnect the radio receiver assembly and multi-media interface ECU connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E110-6 (MUTE) - E102-6 (MUT1) Always Below 1 ohms E110-6 (MUTE) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  3. INSPECT MULTI-MEDIA INTERFACE ECU Reconnect the multi-media interface ECU connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition E102-6 (MUT1) - Body ground Engine switch on (ACC) Above 2.5 V TEXT IN ILLUSTRATION *1 Component with harness connected (Multi-media Interface ECU) NG --> See step 5 OK --> See step 6
  4. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-396741-S05259221712011050900000)
  5. REPLACE MULTI-MEDIA INTERFACE ECU. Refer to «REMOVAL»(ref-396678-S07558536532011050900000)
  6. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-396678-S10849609972011050900000)

The DCM (telematics transceiver) sends a mute signal to the stereo component amplifier assembly.

The stereo component amplifier assembly controls the volume according to the mute signal from the DCM (telematics transceiver).

Scheme 220

Scheme 220: WIRING DIAGRAM
Scheme 220: WIRING DIAGRAM

Scheme 221

Scheme 221: PROCEDURE
Scheme 221: PROCEDURE

Scheme 222

Scheme 222
Scheme 222
  1. INSPECT DCM (TELEMATICS TRANSCEIVER) Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition E97-17 (MUTE) - Body ground Engine switch on (ACC), audio system is playing --> Emergency call mode Above 3.5 V --> Below 1 V TEXT IN ILLUSTRATION *1 Component with harness connected (to DCM (Telematics Transceiver)) NG --> See step 2 OK --> See step 4
  2. CHECK HARNESS AND CONNECTOR Disconnect the stereo component amplifier assembly connector and DCM (telematics transceiver) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition M30-24 (TMUT) - E97-17 (MUTE) Always Below 1 ohms M30-24 (TMUT) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  3. INSPECT STEREO COMPONENT AMPLIFIER ASSEMBLY Reconnect the stereo component amplifier assembly connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition E97-17 (MUTE) - Body ground Engine switch on (ACC) Above 3.5 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (DCM (Telematics Transceiver)) NG --> See step 6 OK --> See step 5
  4. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-396741-S05259221712011050900000)
  5. REPLACE DCM (TELEMATICS TRANSCEIVER). Refer to «REMOVAL»(ref-396740-S39942374592011050900000)
  6. REPLACE STEREO COMPONENT AMPLIFIER ASSEMBLY. Refer to «REMOVAL»(ref-396678-S22179403352011050900000)

Each audio system component connected to the AVC-LAN (communication bus) transfers the switch signals by the audio visual communication local area network.

If a short to +B or short to ground occurs in this AVC-LAN, the audio system will not function normally as communication is stopped.

The circuit is necessary for the Automatic Sound Levelizer (ASL) built into the stereo component amplifier assembly.

Speed signals are received from the combination meter assembly and used for the ASL.

The Automatic Sound Levelizer (ASL) function automatically adjusts the audio system volume level in order to compensate for increased vehicle noise (vehicle noise tends to increase as vehicle speed increases). The ASL adjusts the volume level based upon vehicle speed signals that it receives from the combination meter.

HINT

  1. A voltage of 12 V or 5 V is output from each ECU and then input to the combination meter assembly. The signal is changed to a pulse signal at the transistor in the combination meter assembly. Each ECU controls the respective system based on the pulse signal.
  2. If a short occurs in any of the ECUs or in the wire harness connected to an ECU, all systems in the following diagram will not operate normally.

This circuit is used when an incoming cellular phone voice in the "Bluetooth" hands-free system is received.

Scheme 223

Scheme 223: WIRING DIAGRAM
Scheme 223: WIRING DIAGRAM
  1. w/o Manual (SOS) Switch Using this circuit, the radio receiver assembly sends power to the map light assembly (telephone microphone assembly), and the roof console box assembly sends microphone signals to the radio receiver assembly.
  2. w/ Manual (SOS) Switch Using this circuit, the DCM (telematics transceiver) sends power to the roof console box assembly (telephone microphone assembly), and the roof console box assembly (telephone microphone assembly) sends microphone signals to the radio receiver assembly via the DCM (telematics transceiver). The radio receiver assembly and roof console box assembly (telephone microphone assembly) are connected to each other using the microphone connection detection signal lines.

Scheme 224

Scheme 224: WIRING DIAGRAM
Scheme 224: WIRING DIAGRAM

Scheme 225

Scheme 225: PROCEDURE
Scheme 225: PROCEDURE

Scheme 226

Scheme 226
Scheme 226

Scheme 227

Scheme 227
Scheme 227

Scheme 228

Scheme 228
Scheme 228

Scheme 229

Scheme 229
Scheme 229
  1. CONFIRM MODEL Choose the model to be inspected. Result Model Proceed to w/o Manual (SOS) Switch A w/ Manual (SOS) Switch B B --> See step 5 A: Go to next step
  2. CHECK HARNESS AND CONNECTOR Disconnect the radio receiver assembly and roof console box assembly connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E103-1 (SNS2) - Q2-28 (SNS2) Always Below 1 ohms E103-3 (MACC) - Q2-12 (MACC) Always Below 1 ohms E103-2 (MIC+) - Q2-13 (MCO+) Always Below 1 ohms E103-5 (MIC-) - Q2-14 (MCO-) Always Below 1 ohms E103-1 (SNS2) - Body ground Always 10 kohms or higher E103-3 (MACC) - Body ground Always 10 kohms or higher E103-2 (MIC+) - Body ground Always 10 kohms or higher E103-5 (MIC-) - Body ground Always 10 kohms or higher E103-6 (SGND) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  3. INSPECT RADIO RECEIVER ASSEMBLY Disconnect the radio receiver assembly connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition E103-3 (MACC) - Body ground Engine switch on (ACC) 4 to 6 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E103-6 (SGND) - Body ground Always Below 1 ohms E103-5 (MIC-) - Body ground Always Below 1 ohms Proceed to the next step based on the inspection result. Result Result Proceed to NG A OK B TEXT IN ILLUSTRATION *1 Component without harness connected (Radio Receiver Assembly) B --> See step 10 A --> See step 4
  4. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-396678-S10849609972011050900000)
  5. CHECK HARNESS AND CONNECTOR Disconnect the radio receiver assembly and roof console box assembly connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E103-1 (SNS2) - Q2-28 (SNS2) Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  6. CHECK HARNESS AND CONNECTOR Disconnect the radio receiver assembly and DCM (telematics transceiver) connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E103-2 (MIC+) - E97-18 (MCO+) Always Below 1 ohms E103-5 (MIC-) - E97-19 (MCO-) Always Below 1 ohms E103-2 (MIC+) - Body ground Always 10 kohms or higher E103-5 (MIC-) - Body ground Always 10 kohms or higher E103-6 (SGND) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  7. CHECK HARNESS AND CONNECTOR Disconnect the DCM (telematics transceiver) and roof console box assembly connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E97-33 (MCVD) - Q2-12 (MACC) Always Below 1 ohms E97-34 (MCI+) - Q2-13 (MCO+) Always Below 1 ohms E97-35 (MCI-) - Q2-14 (MCO-) Always Below 1 ohms E97-33 (MCVD) - Body ground Always 10 kohms or higher E97-34 (MCI+) - Body ground Always 10 kohms or higher E97-35 (MCI-) - Body ground Always 10 kohms or higher E97-32 (SGND) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  8. INSPECT RADIO RECEIVER ASSEMBLY Disconnect the radio receiver assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E103-6 (SGND) - Body ground Always Below 1 ohms E103-5 (MIC-) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Radio Receiver Assembly) NG --> See step 14 OK: Go to next step
  9. INSPECT DCM (TELEMATICS TRANSCEIVER) Reconnect the DCM (telematics transceiver) connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition E97-33 (MCVD) - Body ground Engine switch on (ACC) 4 to 6 V TEXT IN ILLUSTRATION *1 Component with harness connected (DCM (Telematics Transceiver)) NG --> See step 16 OK: Go to next step
  10. INSPECT ROOF CONSOLE BOX ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Q2-14 (MCO-) - Q2-28 (SNS2) Always Below 1 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Roof Console Box Assembly) NG --> See step 13 OK: Go to next step
  11. INSPECT ROOF CONSOLE BOX ASSEMBLY Reconnect the radio receiver assembly connector. Reconnect the DCM (telematics transceiver) connector (w/ Manual (SOS) Switch). Reconnect the roof console box assembly connector. Turn the engine switch on (ACC). Connect an oscilloscope to terminals 13 (MCO+) and 14 (MCO-) of the Q2 roof console box assembly connector. Check the waveform of the telephone microphone assembly using the oscilloscope. Result Result Proceed to A waveform synchronized with the voice input to the roof console box assembly is output A A waveform synchronized with the voice input to the roof console box assembly is not output B TEXT IN ILLUSTRATION *1 Component with harness connected (Roof Console Box Assembly) B --> See step 13 A --> See step 12
  12. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-396741-S05259221712011050900000)
  13. REPLACE TELEPHONE MICROPHONE ASSEMBLY Replace the telephone microphone assembly. Refer to «REMOVAL»(ref-396678-S32374695332011050900000) . Check if the same malfunction recurs. Result Result Proceed to Malfunction does not recur (returns to normal) A Malfunction recurs B B --> See step 15 A --> END
  14. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-396678-S10849609972011050900000)
  15. REPLACE ROOF CONSOLE BOX ASSEMBLY. Refer to «REMOVAL»(ref-396648-S35632314242011050900000)
  16. REPLACE DCM (TELEMATICS TRANSCEIVER). Refer to «REMOVAL»(ref-396740-S39942374592011050900000)

The radio receiver assembly uses this circuit to communicate with the main body ECU (multiplex network body ECU) via a direct line. The main body ECU (multiplex network body ECU) uses this circuit to send an auto dimmer signal to the radio receiver assembly. The main body ECU (multiplex network body ECU) detects the position of the light control switch according to the resistance. When the light control switch is set to the head or tail position, the resistance between the head or tail terminal and body ground is below 1 ohms. When the light control switch is set to the head or tail position, the main body ECU (multiplex network body ECU) sends an auto dimmer signal to the radio receiver assembly. When the radio receiver assembly receives an auto dimmer signal from the main body ECU (multiplex network body ECU), the radio receiver assembly causes instrument panel illumination to be dimmed.

Scheme 230

Scheme 230: WIRING DIAGRAM
Scheme 230: WIRING DIAGRAM

Scheme 231

Scheme 231: PROCEDURE
Scheme 231: PROCEDURE

Scheme 232

Scheme 232
Scheme 232
  1. INSPECT MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) Disconnect the radio receiver assembly connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition E70-20 (ADIM) - Body ground Engine switch on (IG), automatic light control sensor covered by hand, and light control switch tail or head position 11 to 14 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Radio Receiver Assembly) NG --> See step 3 OK: Go to next step
  2. INSPECT RADIO RECEIVER ASSEMBLY Disconnect the radio receiver assembly connector. Measure the resistance according to the value(s) in the table below Standard Resistance Tester Connection Condition Specified Condition E69-20 (GND) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Radio Receiver Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
  3. CHECK HARNESS AND CONNECTOR Disconnect the radio receiver assembly and main body ECU (multiplex network body ECU) connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E60-16 (ACAN) - E70-20 (ADIM) Always Below 1 ohms E70-20 (ADIM) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) (Instrument panel J/B)
  4. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-396678-S10849609972011050900000)

This circuit provides power to the radio receiver assembly.

Scheme 233

Scheme 233: WIRING DIAGRAM
Scheme 233: WIRING DIAGRAM

This circuit provides power to the stereo component amplifier assembly.

Scheme 234

Scheme 234: WIRING DIAGRAM
Scheme 234: WIRING DIAGRAM

This circuit provides power to the multi-media interface ECU.

Scheme 235

Scheme 235: WIRING DIAGRAM
Scheme 235: WIRING DIAGRAM

Scheme 236

Scheme 236: PROCEDURE
Scheme 236: PROCEDURE
  1. INSPECT MULTI-MEDIA INTERFACE ECU Disconnect the multi-media interface ECU connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition E102-12 (+B) - E102-7 (GND) Always 11 to 14 V E102-11 (ACC) - E102-7 (GND) Engine switch on (ACC) 11 to 14 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Multi-media Interface ECU) NG --> See step 3 OK --> See step 2
  2. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-396741-S05259221712011050900000)
  3. CHECK HARNESS AND CONNECTOR Disconnect the radio receiver assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E102-11 (ACC) - E110-11 (ACC) Always Below 1 ohms E102-12 (+B) - E110-12 (+B) Always Below 1 ohms E102-7 (GND) - E110-7 (GND) Always Below 1 ohms E102-11 (ACC) - Body ground Always 10 kohms or higher E102-12 (B+) - Body ground Always 10 kohms or higher E102-7 (GND) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 2

More articles — Audio / Visual (W/o Navigation) (Diagnostic Codes & Symptom Tests)
