Audio / Visual (Service Information): Overview Lexus ES XV40 facelift

Entertainment Systems 10 illustrations ~405 words

Scheme 5

Scheme 5: ILLUSTRATION
Scheme 5: ILLUSTRATION

Scheme 6

Scheme 6: ILLUSTRATION
Scheme 6: ILLUSTRATION

Scheme 7

Scheme 7: REMOVAL
Scheme 7: REMOVAL

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14
  1. PRECAUTION NOTE: After the engine switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL (w/ Navigation System for HDD) NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-396530-S14462624912011050900000).
  3. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY . Refer to «REMOVAL - Step 26»(/lexus/es/xv40-facelift-2009-2012/remont/gauges-instrument-panels/#instrument-panel-safety-pad-service-information)
  4. REMOVE UPPER CONSOLE PANEL ASSEMBLY WITH FRONT ASH RECEPTACLE . Refer to «REMOVAL - Step 27»(/lexus/es/xv40-facelift-2009-2012/remont/gauges-instrument-panels/#instrument-panel-safety-pad-service-information)
  5. REMOVE INSTRUMENT PANEL FINISH PANEL END LH . Refer to «REMOVAL - Step 11»(/lexus/es/xv40-facelift-2009-2012/remont/gauges-instrument-panels/#instrument-panel-safety-pad-service-information)
  6. REMOVE INSTRUMENT PANEL FINISH PANEL END RH . Refer to «REMOVAL - Step 19»(/lexus/es/xv40-facelift-2009-2012/remont/gauges-instrument-panels/#instrument-panel-safety-pad-service-information)
  7. REMOVE NO. 2 INSTRUMENT PANEL REGISTER ASSEMBLY . Refer to «REMOVAL - Step 28»(/lexus/es/xv40-facelift-2009-2012/remont/gauges-instrument-panels/#instrument-panel-safety-pad-service-information)
  8. REMOVE INTEGRATION CONTROL PANEL WITH RADIO RECEIVER ASSEMBLY (w/o Navigation System) Remove the 4 bolts. Pull the integration control panel with radio receiver assembly toward the rear of the vehicle and disengage the 2 clips. Disconnect each connector and remove the integration control panel with radio receiver assembly.
  9. REMOVE NO. 1 RADIO BRACKET (w/o Navigation System) Remove the 4 bolts, screw, and No. 1 radio bracket.
  10. REMOVE NO. 2 RADIO BRACKET (w/o Navigation System) Remove the 4 bolts, screw, and No. 2 radio bracket.
  11. REMOVE RADIO RECEIVER ASSEMBLY (w/o Navigation System) Disengage the 2 claws and 6 clips. Remove the radio receiver assembly.
  12. REMOVE DISPLAY AND NAVIGATION MODULE DISPLAY WITH RADIO RECEIVER ASSEMBLY (w/ Navigation System) Remove the 4 bolts. Pull the display and navigation module display with radio receiver assembly toward the rear of the vehicle and disengage the 2 clips. Disconnect each connector and remove the display and navigation module display with radio receiver assembly.
  13. REMOVE NO. 1 RADIO BRACKET (w/ Navigation System) Remove the 6 bolts and No. 1 radio bracket.
  14. REMOVE NO. 2 RADIO BRACKET (w/ Navigation System) Remove the 6 bolts and No. 2 radio bracket.
  15. REMOVE RADIO RECEIVER ASSEMBLY (w/ Navigation System) Disengage the 2 claws and 4 clips. Remove the radio receiver assembly.
