Windshield/windowglass: Removal & Installation

REMOVAL

REMOVE FRONT DOOR ARMREST BASE PANEL ASSEMBLY (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )

INSTALLATION

INSTALL POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INSTALL FRONT DOOR ARMREST BASE PANEL ASSEMBLY (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INITIALIZE POWER WINDOW CONTROL SYSTEM (See «INITIALIZATION»(ref-283132-S02546007652008041700000) )

Scheme 46

Scheme 46: COMPONENTS

REMOVE FRONT DOOR ARMREST BASE PANEL ASSEMBLY (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
REMOVE POWER WINDOW REGULATOR SWITCH ASSEMBLY (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )

REMOVE POWER WINDOW REGULATOR SWITCH ASSEMBLY (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INSTALL FRONT DOOR ARMREST BASE PANEL ASSEMBLY (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INITIALIZE POWER WINDOW CONTROL SYSTEM (See «INITIALIZATION»(ref-283132-S02546007652008041700000) )

Scheme 47

Scheme 47: COMPONENTS

REMOVE REAR DOOR ARMREST BASE PANEL ASSEMBLY (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )
REMOVE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )

INSTALL REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INSTALL REAR DOOR ARMREST BASE PANEL ASSEMBLY (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INITIALIZATION POWER WINDOW CONTROL SYSTEM (See «INITIALIZATION»(ref-283132-S02546007652008041700000) )

Scheme 48

Scheme 48: COMPONENTS

Scheme 49

REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG (See «ON-VEHICLE INSPECTION»(ref-283122-S12886884592008041700000) )
REMOVE FRONT DOOR ARMREST BASE PANEL ASSEMBLY (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
REMOVE COURTESY LIGHT ASSEMBLY (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
REMOVE DOOR ARMREST COVER (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
REMOVE FRONT DOOR INNER GLASS WEATHERSTRIP (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
REMOVE DOOR FRAME GARNISH (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
REMOVE OUTER MIRROR PROTECTOR (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
REMOVE FRONT NO. 1 SPEAKER ASSEMBLY (See «REMOVAL»(ref-283118-S31252883322008041700000) )
REMOVE FRONT NO. 1 DOOR TRIM BRACKET (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
REMOVE FRONT DOOR SERVICE HOLE COVER (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
REMOVE FRONT DOOR GLASS SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
REMOVE FRONT DOOR WINDOW REGULATOR SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
REMOVE FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
REMOVE REAR DOOR INSIDE HANDLE BEZEL PLUG (See «ON-VEHICLE INSPECTION»(ref-283122-S36206450302008041700000) )
REMOVE REAR DOOR ARMREST BASE PANEL ASSEMBLY (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )
REMOVE COURTESY LIGHT ASSEMBLY (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )
REMOVE REAR DOOR ARMREST COVER (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )
REMOVE REAR DOOR TRIM BOARD SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )
REMOVE REAR DOOR INNER GLASS WEATHERSTRIP (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )
REMOVE REAR DOOR FRAME GARNISH (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )
REMOVE REAR DOOR SERVICE HOLE COVER (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )
REMOVE REAR DOOR TRIM BRACKET (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )
REMOVE REAR DOOR GLASS RUN (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )
REMOVE REAR DOOR WINDOW DIVISION BAR SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )
REMOVE REAR DOOR QUARTER WINDOW GLASS (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )
REMOVE REAR DOOR GLASS SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )
REMOVE REAR DOOR WINDOW REGULATOR SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )
REMOVE REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY (See «DISASSEMBLY»(ref-283122-S00132948812008041700000) )

Scheme 50

Scheme 50: INSPECTION

Scheme 51

INSPECT POWER WINDOW REGULATOR MOTOR FRONT RH Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery voltage to any terminals except terminals 1, 2, 4, 7 and 10. Standard SPECIFIED CONDITION CHART Switch Condition Measurement Condition Specified Condition Manual Operation Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal 1 (E), 7 (DWN1) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal 1 (E), 10 (UP1) Motor gear rotates clockwise Auto Operation Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal 1 (E), 4 (AUTO), 7 (DWN1) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal 1 (E), 4 (AUTO) 10 (UP1) Motor gear rotates clockwise
INSPECT POWER WINDOW REGULATOR MOTOR FRONT LH Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery voltage to any terminals except terminals 1, 2, 4, 7 and 10. Standard SPECIFIED CONDITION CHART Switch Condition Measurement Condition Specified Condition Manual Operation Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal 1 (E), 7 (DWN1) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal (E), 10 (UP1) Motor gear rotates clockwise Auto Operation Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal 1 (E), 4 (AUTO), 7 (DWN1) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal 1 (E), 4 (AUTO) 10 (UP1) Motor gear rotates clockwise
INSPECT POWER WINDOW REGULATOR MOTOR REAR RH Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery voltage to any terminals except terminals 1, 2, 4, 7 and 10. Standard SPECIFIED CONDITION CHART Switch Condition Measurement Condition Specified Condition Manual Operation Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal 1 (E), 7 (DWN1) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal 1 (E), 10 (UP1) Motor gear rotates clockwise Auto Operation Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal 1 (E), 4 (AUTO), 7 (DWN1) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal 1 (E), 4 (AUTO) 10 (UP1) Motor gear rotates clockwise
INSPECT POWER WINDOW REGULATOR MOTOR REAR LH Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery voltage to any terminals except terminals 1, 2, 4, 7 and 10. Standard SPECIFIED CONDITION CHART Switch Condition Measurement Condition Specified Condition Manual Operation Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal 1 (E), 7 (DWN1) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal 1 (E), 10 (UP1) Motor gear rotates clockwise Auto Operation Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal 1 (E), 4 (AUTO), 7 (DWN1) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 2 (B) Battery negative (-) --> Terminal 1 (E), 4 (AUTO) 10 (UP1) Motor gear rotates clockwise

INSTALL REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INSTALL REAR DOOR WINDOW REGULATOR SUB-ASSEMBLY (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INSTALL REAR DOOR GLASS RUN (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INSTALL REAR DOOR GLASS SUB-ASSEMBLY (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INSTALL REAR DOOR QUARTER WINDOW GLASS (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INSTALL REAR DOOR WINDOW DIVISION BAR SUB-ASSEMBLY (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INSTALL REAR DOOR TRIM BRACKET (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INSTALL REAR DOOR SERVICE HOLE COVER (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INSTALL REAR DOOR FRAME GARNISH (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INSTALL REAR DOOR INNER GLASS WEATHERSTRIP (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INSTALL REAR DOOR TRIM BOARD SUB-ASSEMBLY (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INSTALL REAR DOOR ARMREST COVER (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INSTALL COURTESY LIGHT ASSEMBLY (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INSTALL REAR DOOR ARMREST BASE PANEL ASSEMBLY (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INSTALL REAR DOOR INSIDE HANDLE BEZEL PLUG (See «REASSEMBLY»(ref-283122-S10912800222008041700000) )
INITIALIZATION POWER WINDOW CONTROL SYSTEM (See «INITIALIZATION»(ref-283132-S02546007652008041700000) )
INSTALL FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INSTALL FRONT DOOR WINDOW REGULATOR SUB-ASSEMBLY (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INSTALL FRONT DOOR GLASS SUB-ASSEMBLY (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INSTALL FRONT DOOR SERVICE HOLE COVER (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INSTALL FRONT NO. 1 DOOR TRIM BRACKET (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INSTALL FRONT NO. 1 SPEAKER ASSEMBLY (See «INSTALLATION»(ref-283118-S04410051032008041700000) )
INSTALL OUTER MIRROR PROTECTOR (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INSTALL DOOR FRAME GARNISH (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INSTALL FRONT DOOR INNER GLASS WEATHERSTRIP (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INSTALL DOOR ARMREST COVER (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INSTALL COURTESY LIGHT ASSEMBLY (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INSTALL FRONT DOOR ARMREST BASE PANEL ASSEMBLY (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INSTALL FRONT DOOR INSIDE HANDLE BEZEL PLUG (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
INITIALIZE POWER WINDOW CONTROL SYSTEM (See «INITIALIZATION»(ref-283132-S02546007652008041700000) )

Scheme 52

Scheme 52: COMPONENTS

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 57: REMOVAL

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

REMOVE COOL AIR INTAKE DUCT SEAL (See «REMOVAL»(ref-283116-S42135128222008041700000) )
REMOVE HOOD HINGE COVER (for LH Side) (See «REMOVAL»(ref-283123-S18755761682008041700000) )
REMOVE HOOD HINGE COVER (for RH Side) (See «REMOVAL»(ref-283123-S18755761682008041700000) )
REMOVE ENGINE ROOM SIDE COVER LH (See «REMOVAL»(ref-283123-S18755761682008041700000) )
REMOVE ENGINE ROOM SIDE COVER RH (See «REMOVAL»(ref-283123-S18755761682008041700000) )
REMOVE FRONT WIPER ARM AND BLADE ASSEMBLY LH (See «REMOVAL»(ref-283123-S18755761682008041700000) )
REMOVE FRONT WIPER ARM AND BLADE ASSEMBLY RH (See «REMOVAL»(ref-283123-S18755761682008041700000) )
REMOVE COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY NOTE: When removing the cowl top ventilator louver sub-assembly, hold the front fender to cowl side seals by hand to prevent them from coming off the windshield. The front fender to cowl side seals are attached to the windshield with double-sided tape. Once the front fender to cowl side seals come off, the adhesion of the tape is reduced. The double-sided tape is not available as a supply part. If the tape loses its adhesion, it is necessary to apply new high-heat resistant double-sided tape and install the front fender to cowl side seals to the windshield (See «REMOVAL»(ref-283123-S18755761682008041700000) ).
REMOVE SLIDING ROOF SIDE GARNISH LH (for Glass Roof) (See «REMOVAL»(ref-283133-S13077288662008041700000) )
REMOVE SLIDING ROOF SIDE GARNISH RH (for Glass Roof) (See «REMOVAL»(ref-283133-S13077288662008041700000) )
REMOVE NO. 1 SLIDING ROOF GLASS SUB-ASSEMBLY (for Glass Roof) (See «REMOVAL»(ref-283133-S13077288662008041700000) )
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
REMOVE INNER REAR VIEW MIRROR STAY HOLDER COVER (See «REMOVAL»(ref-283127-S11090645222008041700000) )
REMOVE INNER REAR VIEW MIRROR ASSEMBLY (See «REMOVAL»(ref-283127-S11090645222008041700000) )
REMOVE RAIN SENSOR COVER (w/ Rain Sensor) (See «REMOVAL»(ref-283123-S00938566512008041700000) )
REMOVE RAIN SENSOR (w/ Rain Sensor) (See «REMOVAL»(ref-283123-S00938566512008041700000) )
REMOVE RAIN SENSOR TAPE (w/ Rain Sensor) HINT: This step should be performed only when the rain sensor tape needs to be replaced (see «REMOVAL»(ref-283123-S00938566512008041700000) ).
REMOVE FRONT DOOR SCUFF PLATE LH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE FRONT DOOR OPENING TRIM COVER LH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE SIDE INSTRUMENT PANEL LH (See «REMOVAL»(ref-283109-S39106719462008041700000) )
REMOVE FRONT PILLAR GARNISH LH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE FRONT DOOR SCUFF PLATE RH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE FRONT DOOR OPENING TRIM COVER RH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE SIDE INSTRUMENT PANEL RH (See «REMOVAL»(ref-283109-S39106719462008041700000) )
REMOVE FRONT PILLAR GARNISH RH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE ROOF CONSOLE BOX ASSEMBLY (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE VISOR BRACKET COVER (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE VISOR ASSEMBLY LH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE VISOR ASSEMBLY RH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE VISOR HOLDER (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE ASSIST GRIP SUB-ASSEMBLY (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE ROOF HEADLINING ASSEMBLY (for Standard) It is not necessary to completely remove the roof headlining assembly. Slightly lower the front section of the roof headlining assembly so that the windshield glass can be removed (See «REMOVAL»(ref-283110-S29464350012008041700000) ).
REMOVE ROOF HEADLINING ASSEMBLY (for Glass Roof) It is not necessary to completely remove the roof headlining assembly. Slightly lower the front section of the roof headlining assembly so that the windshield glass can be removed (See «REMOVAL»(ref-283110-S29464350012008041700000) ).
REMOVE WINDSHIELD MOLDING OUTSIDE (for Standard) Using a knife, cut off the molding, as shown in the illustration. NOTE: Do not damage the vehicle body with the knife. If the vehicle body is damaged, repair the damaged portion by applying an anti-rust coating after removing the windshield glass. Remove the remaining molding from the windshield glass. HINT: When removing the molding, make a partial cut, then pull and remove it by hand.
REMOVE WINDSHIELD MOLDING OUTSIDE UPPER (for Glass Roof) Using a knife, cut off the molding, as shown in the illustration. NOTE: Do not damage the vehicle body with the knife. If the vehicle body is damaged, repair the damaged portion by applying an anti-rust coating after removing the windshield glass. Remove the remaining molding from the windshield glass. HINT: When removing the molding, make a partial cut, then pull and remove it by hand.
REMOVE WINDSHIELD MOLDING OUTSIDE LH (for Glass Roof) Using a knife, cut off the molding, as shown in the illustration. NOTE: Do not damage the vehicle body with the knife. If the vehicle body is damaged, repair the damaged portion by applying an anti-rust coating after removing the windshield glass. Remove the remaining molding from the windshield glass. HINT: When removing the molding, make a partial cut, then pull and remove it by hand.
REMOVE WINDSHIELD MOLDING OUTSIDE RH (for Glass Roof) Using a knife, cut off the molding, as shown in the illustration. NOTE: Do not damage the vehicle body with the knife. If the vehicle body is damaged, repair the damaged portion by applying an anti-rust coating after removing the windshield glass. Remove the remaining molding from the windshield glass. HINT: When removing the molding, make a partial cut, then pull and remove it by hand.
REMOVE WINDSHIELD GLASS ASSEMBLY NOTE: There are No. 1 and No. 2 stoppers on the windshield glass as shown in the illustration. Be careful not to damage the windshield glass when cutting off the adhesive. To prevent the windshield glass from dropping when performing this operation, be sure to hold the windshield glass using suction cups. HINT: Depending on vehicles, a 1-piece or 2-piece type stopper is used. Apply protective tape to the installation position of the windshield glass assembly on the vehicle body. HINT: Apply protective tape to the installation surface to prevent it from being scratched. Pass a piano wire between the vehicle body and glass from the interior. Tie both wire ends to wooden blocks or similar objects. Cut off the adhesive by pulling the piano wire around the windshield glass. NOTE: When separating the windshield glass, take care not to damage the paint or the interior and exterior ornaments. To prevent the safety pad from being scratched when removing the windshield glass, place a plastic sheet between the piano wire and safety pad. Place matchmarks on the windshield glass and vehicle body on the locations indicated in the illustration. HINT: Matchmarks do not need to be placed if the windshield glass is not going to be reused. Using a suction cup, remove the windshield glass assembly. NOTE: Be careful not to drop the windshield glass. Leave as much adhesive on the vehicle body as possible when removing the windshield glass.
REMOVE WINDOW GLASS ADHESIVE DAM Using a scraper, remove the adhesive dam. NOTE: Be careful not to damage the windshield glass. Be sure to replace the adhesive dam with a new one.
REMOVE NO. 2 WINDSHIELD GLASS STOPPER Using a scraper, remove the 2 No. 2 stoppers. NOTE: Be careful not to damage the windshield glass. Be sure to replace the No. 2 stoppers with new ones.
REMOVE WINDSHIELD GLASS RETAINER Using a scraper, remove the 2 retainers. NOTE: Be careful not to damage the windshield glass. Be sure to replace the retainers with new ones.
REMOVE NO. 1 WINDSHIELD GLASS STOPPER (for 2-piece Type) Remove the 2 No. 1 stoppers. NOTE: Be sure to replace the No. 1 stoppers with new ones.
CLEAN WINDSHIELD GLASS Using a scraper, remove the adhesive tape and adhesive sticking to the windshield glass. NOTE: Be careful not to damage the windshield glass. Clean the outer circumference of the windshield glass with a non-residue solvent. NOTE: Do not touch the windshield glass surface after cleaning it. Even if using a new windshield glass, clean the windshield glass with a non-residue solvent.
CLEAN VEHICLE BODY Clean and shape the contact surface of the vehicle body. Using a knife, cut away any rough adhesive on the contact surface of the vehicle body to ensure the appropriate surface shape. NOTE: Be careful not to damage the vehicle body. HINT: Leave as much adhesive on the vehicle body as possible. Clean the contact surface of the vehicle body with a piece of cloth saturated with cleaner. HINT: Even if all the adhesive has been removed, clean the vehicle body.

Scheme 68

Scheme 68: INSTALLATION

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

INSTALL NO. 2 WINDSHIELD GLASS STOPPER Using a brush or sponge, coat the application area of the No. 2 stoppers with Primer G. NOTE: Do not apply too much primer. Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer G for later use. HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean piece of cloth before it dries. Install 2 new No. 2 stoppers onto the windshield glass, as shown in the illustration. HINT: Only 2-piece type No. 2 stoppers are supplied. Use the 2-piece type stoppers even if a 1-piece type was used. Standard dimension AREA DIMENSION Area Dimension A 40 mm (1.574 in.) B 20.9 mm (0.822 in.) C 10.2 mm (0.401 in.) D 23.5 mm (0.925 in.) E 12.8 mm (0.503 in.) F 10.9 mm (0.429 in.) G 19.3 mm (0.759 in.) H 47.3 mm (1.862 in.) I 17.0 mm (0.669 in.) J 42.6 mm (1.677 in.) K 12.3 mm (0.484 in.)
INSTALL WINDSHIELD GLASS RETAINER Using a brush or sponge, coat the application area of the retainers with Primer G. NOTE: Do not apply too much primer. Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer G for later use. HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean piece of cloth before it dries. Install 2 new retainers onto the windshield glass, as shown in the illustration.
INSTALL NO. 1 WINDSHIELD GLASS STOPPER Install 2 new No. 1 stoppers to the vehicle body, as shown in the illustration. HINT: Only 2-piece type No. 1 stoppers are supplied. Use the 2-piece type stoppers even if a 1 -piece type was used.
INSTALL WINDSHIELD MOLDING OUTSIDE (for Standard) Using a brush or sponge, coat the application area of molding with Primer G. NOTE: Do not apply too much primer. Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer G for later use. HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean piece of cloth before it dries. Install a new molding onto the windshield glass, as shown in the illustration. Standard dimension AREA DIMENSION Area Dimension A 6.4 mm (0.252 in.)
INSTALL WINDSHIELD MOLDING OUTSIDE UPPER (for Glass Roof) Using a brush or sponge, coat the application area of molding with Primer G. NOTE: Do not apply too much primer. Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer G for later use. HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean piece of cloth before it dries. Install a new molding onto the windshield glass, as shown in the illustration. Standard dimension AREA DIMENSION Area Dimension A 25.9 mm (1.019 in.)
INSTALL WINDSHIELD MOLDING OUTSIDE LH (for Glass Roof) Using a brush or sponge, coat the application area of molding with Primer G. NOTE: Do not apply too much primer. Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer G for later use. HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean piece of cloth before it dries. Install a new molding onto the windshield glass, as shown in the illustration. Standard dimension AREA DIMENSION Area Dimension A 6.4 mm (0.252 in.)
INSTALL WINDSHIELD MOLDING OUTSIDE RH (for Glass Roof) HINT: Use the same procedures for the RH side and LH side.
INSTALL WINDOW GLASS ADHESIVE DAM Using a brush or sponge, coat the application area of adhesive dam with Primer G. NOTE: Do not apply too much primer. Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer G for later use. HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean piece of cloth before it dries. Install a new adhesive dam onto the windshield glass, as shown in the illustration.
INSTALL WINDSHIELD GLASS ASSEMBLY Position the windshield glass assembly. Using a suction cup, place the windshield glass assembly in the correct position. Check that the whole contact surface of the windshield glass rim is perfectly even. Align the matchmarks on the windshield glass and vehicle body. NOTE: Check that the windshield glass stoppers are attached to the vehicle body correctly. Remove the windshield glass assembly. Using a brush, coat the installation surface on the vehicle body with Primer M. NOTE: Do not coat the adhesive with Primer M. Do not apply too much primer. Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer M for later use. HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean piece of cloth before it dries. Standard dimension AREA DIMENSION Area Dimension A 20.0 mm (0.787 in.) B 43.7 mm (1.720 in.) C 70.2 mm (2.763 in.) Using a brush or sponge, coat the application area of adhesive with Primer G. NOTE: Do not apply too much primer. Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer G for later use. HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean piece of cloth before it dries. Standard dimension AREA DIMENSION Area Dimension a 8.7 mm (0.342 in.) b 12.0 mm (0.472 in.) c 28.6 mm (1.126 in.) d 12.0 mm (0.472 in.) e 8.7 mm (0.342 in.) f 12.0 mm (0.472 in.) g 12.0 mm (0.472 in.) h 6.4 mm (0.252 in.) Apply adhesive (Adhesive: TOYOTA genuine windshield glass adhesive or equivalent). Cut off the tip of the cartridge nozzle, as shown in the illustration. HINT: After cutting off the tip, use all adhesive within the time described in the table below. Usage time frame TACK-FREE TIME CHART Temperature Tack-free Time 35°C (95°F) 15 minutes 20°C (68°F) 1 hour and 40 minutes 5°C (41°F) 8 hours Load the sealer gun with cartridge. Apply adhesive to the windshield glass, as shown in the illustration. Standard dimension AREA DIMENSION Area Dimension a 8.7 mm (0.342 in.) b 28.6 mm (1.126 in.) c 8.7 mm (0.342 in.) d 6.4 mm (0.252 in.) e 12.0 mm (0.472 in.) f 8.0 mm (0.315 in.) Install the windshield glass assembly. Using a suction cup, position the windshield glass so that the matchmarks are aligned, and press it in gently along the rim. NOTE: Check that the windshield glass stoppers are attached to the vehicle body correctly. Check the clearance between the vehicle body and windshield glass. Lightly press the front surface of the windshield glass to ensure a close fit. HINT: Press the glass with force of 98 N (10 kgf, 22 lb) or more. If necessary, use a scraper to correct the level or position of adhesive that has been applied. HINT: Apply adhesive onto the windshield glass rim. Hold the windshield glass using protective tape until applied adhesive becomes hard. NOTE: Do not drive the vehicle for the time described in the table below. Minimum time TEMPERATURE CHART Temperature Minimum time prior to driving vehicle 35°C (95°F) 1 hour and 30 minutes 20°C (68°F) 5 hours 5°C (41°F) 24 hours
CHECK FOR LEAKS AND REPAIR After the adhesive has hardened, apply water from the outside of the vehicle. Check that no water leaks into the cabin. If water leaks into the cabin, allow the water to dry and add adhesive. Remove the protective tape.
INSTALL ROOF HEADLINING ASSEMBLY (for Standard) Return the front section of the roof headlining assembly to the original position (See «INSTALLATION»(ref-283110-S31613301962008041700000) ).
INSTALL ROOF HEADLINING ASSEMBLY (for Glass Roof) Return the front section of the roof headlining assembly to the original position (See «INSTALLATION»(ref-283110-S31613301962008041700000) ).
INSTALL ASSIST GRIP SUB-ASSEMBLY (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL VISOR HOLDER (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL VISOR ASSEMBLY LH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL VISOR ASSEMBLY RH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL VISOR BRACKET COVER (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL ROOF CONSOLE BOX ASSEMBLY (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL FRONT PILLAR GARNISH LH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL SIDE INSTRUMENT PANEL LH (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
INSTALL FRONT DOOR OPENING TRIM COVER LH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL FRONT DOOR SCUFF PLATE LH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL FRONT PILLAR GARNISH RH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL SIDE INSTRUMENT PANEL RH (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
INSTALL FRONT DOOR OPENING TRIM COVER RH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL FRONT DOOR SCUFF PLATE RH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL RAIN SENSOR TAPE (w/ Rain Sensor) HINT: This step should be performed only when the rain sensor tape needs to be replaced (see «INSTALLATION»(ref-283123-S18058778842008041700000) ).
INSTALL RAIN SENSOR (w/ Rain Sensor) (See «INSTALLATION»(ref-283123-S18058778842008041700000) )
INSTALL RAIN SENSOR COVER (w/ Rain Sensor) (See «INSTALLATION»(ref-283123-S18058778842008041700000) )
INSTALL INNER REAR VIEW MIRROR ASSEMBLY (See «INSTALLATION»(ref-283127-S02177136522008041700000) )
INSTALL INNER REAR VIEW MIRROR STAY HOLDER COVER (See «INSTALLATION»(ref-283127-S02177136522008041700000) )
TEMPORARILY TIGHTEN NO. 1 SLIDING ROOF GLASS SUB-ASSEMBLY (for Glass Roof) (See «INSTALLATION»(ref-283133-S02476562472008041700000) )
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
ADJUST NO. 1 SLIDING ROOF GLASS SUB-ASSEMBLY (for Glass Roof) (See «INSTALLATION»(ref-283133-S02476562472008041700000) )
INSTALL SLIDING ROOF SIDE GARNISH LH (for Glass Roof) (See «INSTALLATION»(ref-283133-S02476562472008041700000) )
INSTALL SLIDING ROOF SIDE GARNISH RH (for Glass Roof) (See «INSTALLATION»(ref-283133-S02476562472008041700000) )
CHECK FOR WATER LEAKS (for Glass Roof) (See «INSTALLATION»(ref-283133-S02476562472008041700000) )
INSTALL FRONT FENDER TO COWL SIDE SEAL RH HINT: In cases where double-sided tape cannot be reused (See «INSTALLATION»(ref-283123-S10239775612008041700000) ).
INSTALL FRONT FENDER TO COWL SIDE SEAL LH HINT: In cases where double-sided tape cannot be reused (See «INSTALLATION»(ref-283123-S10239775612008041700000) ).
INSTALL COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY NOTE: When installing the cowl top ventilator louver sub-assembly, hold the front fender to cowl side seals by hand to prevent them from coming off the windshield. The front fender to cowl side seals are attached to the windshield with double-sided tape. Once the front fender to cowl side seals come off, the adhesion of the tape is reduced. The double-sided tape is not available as a supply part. If the tape loses its adhesion, it is necessary to apply new high-heat resistant double-sided tape and install the front fender to cowl side seals to the windshield (See «INSTALLATION»(ref-283123-S10239775612008041700000) ).
INSTALL FRONT WIPER ARM AND BLADE ASSEMBLY LH (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
INSTALL FRONT WIPER ARM AND BLADE ASSEMBLY RH (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
INSTALL ENGINE ROOM SIDE COVER RH (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
INSTALL ENGINE ROOM SIDE COVER LH (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
INSTALL HOOD HINGE COVER (for RH Side) (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
INSTALL HOOD HINGE COVER (for LH Side) (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
INSTALL COOL AIR INTAKE DUCT SEAL (See «INSTALLATION»(ref-283116-S26519527622008041700000) )
PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the cable to the negative battery terminal (See «INITIALIZATION»(ref-283083-S29543038892008041700000) ).
CHECK SLIDING ROOF SYSTEM (for Glass Roof) (See «DATA LIST / ACTIVE TEST»(ref-283133-S15498297642008041700000) )
INSPECT SRS WARNING LIGHT (See «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) )

Scheme 81

Scheme 81: COMPONENTS

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 86: REMOVAL

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
REMOVE REAR SEAT CUSHION ASSEMBLY (See «REMOVAL»(ref-283115-S40416737822008041700000) )
REMOVE REAR SEAT HEADREST ASSEMBLY
REMOVE REAR CENTER SEAT HEADREST ASSEMBLY
REMOVE REAR SEATBACK ASSEMBLY (See «REMOVAL»(ref-283115-S40416737822008041700000) )
REMOVE REAR DOOR SCUFF PLATE LH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE REAR SEAT SIDE GARNISH LH (w/o Rear Seat Side Airbag) (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE REAR SEAT SIDE AIRBAG ASSEMBLY LH (w/ Rear Seat Side Airbag) (See «REMOVAL»(ref-283084-S37887340342008041700000) )
REMOVE ROOF SIDE INNER GARNISH ASSEMBLY LH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE REAR DOOR SCUFF PLATE RH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE REAR SEAT SIDE GARNISH RH (w/o Rear Seat Side Airbag) (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE REAR SEAT SIDE AIRBAG ASSEMBLY RH (w/ Rear Seat Side Airbag) (See «REMOVAL»(ref-283085-S26429593062008041700000) )
REMOVE ROOF SIDE INNER GARNISH ASSEMBLY RH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
DISCONNECT REAR SEAT 3 POINT TYPE BELT ASSEMBLY LH (See «REMOVAL»(ref-283085-S26429593062008041700000) )
DISCONNECT REAR SEAT 3 POINT TYPE BELT ASSEMBLY RH (See «REMOVAL»(ref-283085-S26429593062008041700000) )
DISCONNECT REAR SEAT INNER WITH CENTER BELT ASSEMBLY RH (See «REMOVAL»(ref-283085-S26429593062008041700000) )
REMOVE REAR SEAT SHOULDER BELT HOLE COVER (See «REMOVAL»(ref-283085-S26429593062008041700000) )
REMOVE PACKAGE TRAY TRIM PANEL ASSEMBLY (w/o Rear Sunshade) (See «REMOVAL»(ref-283085-S26429593062008041700000) )
REMOVE PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade) (See «REMOVAL»(ref-283110-S38740762922008041700000) )
REMOVE CENTER STOP LIGHT SET (See «REMOVAL»(ref-283105-S16785288212008041700000) )
REMOVE NO. 2 PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade) (See «REMOVAL»(ref-283110-S38740762922008041700000) )
REMOVE COAT HOOK (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE SPOT LIGHT ASSEMBLY (for Standard) (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE SPOT LIGHT ASSEMBLY (for Glass Roof) (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE ASSIST GRIP SUB-ASSEMBLY (See «REMOVAL»(ref-283110-S29464350012008041700000) )
REMOVE ROOF HEADLINING ASSEMBLY (for Standard) It is not necessary to completely remove the roof headlining. Slightly lower the rear section of the roof headlining so that the back window glass can be removed (See «REMOVAL»(ref-283110-S29464350012008041700000) ).
REMOVE ROOF HEADLINING ASSEMBLY (for Glass Roof) It is not necessary to completely remove the roof headlining. Slightly lower the rear section of the roof headlining so that the back window glass can be removed (See «REMOVAL»(ref-283110-S29464350012008041700000) ).
REMOVE BACK WINDOW MOLDING Using a knife, cut off the molding, as shown in the illustration. NOTE: Do not damage the vehicle body with the knife. If the vehicle body is damaged, repair the damaged portion by applying an anti-rust coating after removing the back window glass. Remove the remaining molding from the back window glass. HINT: When removing the molding, make a partial cut, then pull and remove it by hand.
REMOVE BACK WINDOW GLASS ASSEMBLY NOTE: There are No. 1 and No. 2 stoppers on the back window glass as shown in the illustration. Be careful not to damage the back window glass when cutting off the adhesive. To prevent the back window glass from dropping when performing this operation, be sure to hold the back window glass using suction cups. HINT: Depending on vehicles, a 1-piece or 2-piece type stopper is used. Disconnect the connector. Disconnect the connectors. Apply protective tape to the installation position of the back window glass assembly on the vehicle body. HINT: Apply protective tape to the installation surface to prevent it from being scratched. Pass a piano wire between the vehicle body and glass from the interior. Tie both wire ends to wooden blocks or similar objects. Cut off the adhesive by pulling the piano wire around the back window glass. NOTE: When separating the back window glass, take care not to damage the paint or the interior and exterior ornaments. To prevent the package tray from being scratched when removing the back window glass, place a plastic sheet between the piano wire and package tray. Place matchmarks on the back window glass and vehicle body on the locations indicated in the illustration. HINT: Matchmarks do not need to be placed if the back window glass is not going to be reused. Using a suction cup, remove the back window glass assembly. NOTE: Be careful not to drop the back window glass. Leave as much adhesive on the vehicle body as possible when removing the back window glass.
REMOVE WINDSHIELD GLASS ADHESIVE DAM Using a scraper, remove the adhesive dam. NOTE: Be careful not to damage the windshield glass. Be sure to replace the adhesive dam with a new one.
REMOVE NO. 2 BACK WINDOW GLASS STOPPER Using a scraper, remove the 2 No. 2 stoppers. NOTE: Be careful not to damage the back window glass. Be sure to replace the No. 2 stoppers with new ones.
REMOVE NO. 1 BACK WINDOW GLASS STOPPER (for 2-piece Type) Remove the 2 No. 1 stoppers. NOTE: Be sure to replace the No. 1 stoppers with new ones.
CLEAN BACK WINDOW GLASS Using a scraper, remove the adhesive tape and adhesive sticking to the back window glass. NOTE: Be careful not to damage the back window glass. Clean the outer circumference of the back window glass with a non-residue solvent. NOTE: Do not touch the back window glass surface after cleaning it. Even if using a new back window glass, clean the back window glass with a non-residue solvent.
CLEAN VEHICLE BODY Clean and shape the contact surface of the vehicle body. Using a knife, cut away any rough adhesive on the contact surface of the vehicle body to ensure the appropriate surface shape. NOTE: Be careful not to damage the vehicle body. HINT: Leave as much adhesive on the vehicle body as possible. Clean the contact surface of the vehicle body with a piece of cloth saturated with cleaner. HINT: Even if all the adhesive has been removed, clean the vehicle body.

Scheme 95

Scheme 95: INSTALLATION

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

INSTALL NO. 2 BACK WINDOW GLASS STOPPER Using a brush or sponge, coat the application area of the No. 2 stoppers with Primer G. NOTE: Do not apply too much primer. Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer G for later use. HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean piece of cloth before it dries. Install 2 new No. 2 stoppers onto the back window glass, as shown in the illustration. HINT: Only 2-piece type No. 2 stoppers are supplied. Use the 2-piece type stoppers even if a 1 -piece type was used. Standard dimension AREA DIMENSION Area Dimension A 15.5 mm (0.610 in.)
INSTALL NO. 1 BACK WINDOW GLASS STOPPER Install 2 new No. 1 stoppers to the vehicle body, as shown in the illustration. HINT: Only 2-piece type No. 1 stoppers are supplied. Use the 2-piece type stoppers even if a 1-piece type was used.
INSTALL BACK WINDOW MOLDING Using a brush or sponge, coat the application area of molding with Primer G. NOTE: Do not apply too much primer. Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer G for later use. HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean piece of cloth before it dries. Install a new molding onto the back window glass, as shown in the illustration. Standard dimension AREA DIMENSION Area Dimension A 6.4 mm (0.252 in.)
INSTALL WINDSHIELD GLASS ADHESIVE DAM Using a brush or sponge, coat the application area of adhesive dam with Primer G. NOTE: Do not apply too much primer. Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer G for later use. HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean piece of cloth before it dries. Install a new adhesive dam onto the windshield glass, as shown in the illustration.
INSTALL BACK WINDOW GLASS ASSEMBLY Position the back window glass assembly. Using a suction cup, place the back window glass assembly in the correct position. Check that the whole contact surface of the back window glass rim is perfectly even. Align the matchmarks on the back window glass and vehicle body. NOTE: Check that the back window glass stoppers are attached to the vehicle body correctly. Remove the back window glass assembly. Using a brush, coat the installation surface on the vehicle body with Primer M. NOTE: Do not coat the adhesive with Primer M. Do not apply too much primer. Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer M for later use. HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean piece of cloth before it dries. Using a brush or sponge, coat the application area of adhesive with Primer G. NOTE: Do not apply too much primer. Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer G for later use. HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean piece of cloth before it dries. Standard dimension AREA DIMENSION Area Dimension a 9.6 mm (0.378 in.) b 15.5 mm (0.610 in.) c 10.1 mm (0.397 in.) d 10.0 mm (0.393 in.) e 6.5 mm (0.255 in.) f 10.0 mm (0.393 in.) Apply adhesive (Adhesive: TOYOTA genuine windshield glass adhesive or equivalent). Cut off the tip of the cartridge nozzle, as shown in the illustration. HINT: After cutting off the tip, use all adhesive within the time described in the table below. Usage time frame TACK-FREE TIME CHART Temperature Tack-free Time 3S°C (95°F) 15 minutes 20°C (68°F) 1 hour and 40 minutes 5°C (41°F) 8 hours Load the sealer gun with cartridge. Apply adhesive to the back window glass, as shown in the illustration. Standard dimension AREA DIMENSION Area Dimension a 9.6 mm (0.378 in.) b 10.1 mm (0.397 in.) c 6.5 mm (0.255 in.) d 12.0 mm (0.472 in.) e 8.0 mm (0.315 in.) Install the back window glass assembly. Using a suction cup, position the back window glass so that the matchmarks are aligned, and press it in gently along the rim. NOTE: Check that the back window glass stoppers are attached to the vehicle body correctly. Check the clearance between the vehicle body and back window glass. Lightly press the front surface of the back window glass to ensure a close fit. HINT: Press the glass with force of 98 N (10 kgf, 22 lb) or more. Hold the back window glass using protective tape until applied adhesive becomes hard. NOTE: Do not drive the vehicle for the time described in the table below. Minimum time TEMPERATURE CHART Temperature Minimum time prior to driving vehicle 35°C (95°F) 1 hour and 30 minutes 20°C (68°F) 5 hours 5°C (41°F) 24 hours Connect the connectors. Connect the connector.
CHECK FOR LEAKS AND REPAIR After the adhesive has hardened, apply water from the outside of the vehicle. Check that no water leaks into the cabin. If water leaks into the cabin, allow the water to dry and add adhesive. Remove the protective tape.
INSTALL ROOF HEADLINING ASSEMBLY (for Standard) Return the rear section of the roof headlining assembly to the original position (See «INSTALLATION»(ref-283110-S31613301962008041700000) ).
INSTALL ROOF HEADLINING ASSEMBLY (for Glass Roof) Return the rear section of the roof headlining assembly to the original position (See «INSTALLATION»(ref-283110-S31613301962008041700000) ).
INSTALL ASSIST GRIP SUB-ASSEMBLY (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL SPOT LIGHT ASSEMBLY (for Standard) (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL SPOT LIGHT ASSEMBLY (for Glass Roof) (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL COAT HOOK (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL NO. 2 PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade) (See «INSTALLATION»(ref-283110-S28849350622008041700000) )
INSTALL CENTER STOP LIGHT SET (See «INSTALLATION»(ref-283105-S36778177742008041700000) )
INSTALL PACKAGE TRAY TRIM PANEL ASSEMBLY (w/o Rear Sunshade) (See «INSTALLATION»(ref-283085-S35330709052008041700000) )
INSTALL PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade) (See «INSTALLATION»(ref-283110-S28849350622008041700000) )
INSTALL REAR SEAT SHOULDER BELT HOLE COVER (See «INSTALLATION»(ref-283085-S35330709052008041700000) )
INSTALL REAR SEAT INNER WITH CENTER BELT ASSEMBLY RH (See «INSTALLATION»(ref-283085-S35330709052008041700000) )
INSTALL REAR SEAT 3 POINT TYPE BELT ASSEMBLY LH (See «INSTALLATION»(ref-283085-S35330709052008041700000) )
INSTALL REAR SEAT 3 POINT TYPE BELT ASSEMBLY RH (See «INSTALLATION»(ref-283085-S35330709052008041700000) )
INSTALL ROOF SIDE INNER GARNISH ASSEMBLY LH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL ROOF SIDE INNER GARNISH ASSEMBLY RH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL REAR SEAT SIDE GARNISH LH (w/o Rear Seat Side Airbag) (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL REAR SEAT SIDE AIRBAG ASSEMBLY LH (w/ Rear Seat Side Airbag) (See «INSTALLATION»(ref-283084-S18648232732008041700000) )
INSTALL REAR SEAT SIDE GARNISH RH (w/o Rear Seat Side Airbag) (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL REAR SEAT SIDE AIRBAG ASSEMBLY RH (w/ Rear Seat Side Airbag) (See «INSTALLATION»(ref-283085-S35330709052008041700000) )
INSTALL REAR DOOR SCUFF PLATE LH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL REAR DOOR SCUFF PLATE RH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
INSTALL REAR SEATBACK ASSEMBLY (See «INSTALLATION»(ref-283115-S15106762642008041700000) )
INSTALL REAR CENTER SEAT HEADREST ASSEMBLY
INSTALL REAR SEAT HEADREST ASSEMBLY
INSTALL REAR SEAT CUSHION ASSEMBLY (See «INSTALLATION»(ref-283115-S15106762642008041700000) )
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the cable to the negative battery terminal (See «INITIALIZATION»(ref-283083-S29543038892008041700000) ).
INSPECT SRS WARNING LIGHT (See «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) )

Windshield/windowglass: Removal & Installation Lexus ES XV40
