Seat: Removal & Installation Lexus ES XV40

INSTALLATION

1. INSTALL FRONT SEAT ASSEMBLY Place the seat in the cabin. Connect the connectors under the seat. Connect the negative (-) battery terminal. Move the front seat assembly fully forward by operating the slide and vertical power seat switch knob. NOTE: Check that the seat is locked. Temporarily install the front side of the front seat assembly with the 2 bolts. Move the front seat assembly fully forward by operating the slide and vertical power seat switch knob. NOTE: Check that the seat is locked. Temporarily install the rear side of the front seat assembly with the 2 bolts. Move the front seat assembly to the rearmost position by operating the slide and vertical power seat switch knob. NOTE: Check that the seat is locked. Fully tighten the 2 bolts on the front side of the front seat assembly in the order of the inner side bolt and then the outer side bolt. Torque: 37 N*m (377 kgf*cm, 27 ft.*lbf) Move the front seat assembly fully forward by operating the slide and vertical power seat switch knob. NOTE: Check that the seat is locked. Fully tighten the 2 bolts on the rear side of the front seat assembly in the order of the inner side bolt and then the outer side bolt. Torque: 37 N*m (377 kgf*cm, 27 ft.*lbf)
2. INSTALL FRONT SEAT REAR OUTER TRACK BRACKET COVER Engage the 4 claws and install the front seat rear outer track cover.
3. INSTALL FRONT SEAT REAR INNER TRACK BRACKET COVER Engage the 4 claws and install the inner seat track bracket cover.
4. INSTALL FRONT SEAT OUTER TRACK BRACKET COVER Move the front seat assembly to the rearmost position by operating the slide and vertical power seat switch knob. Engage the 2 claws and install the front seat outer track bracket cover.
5. INSTALL FRONT SEAT INNER TRACK BRACKET COVER Engage the 2 claws and install the front seat inner track bracket cover.
6. INSTALL FRONT SEAT HEADREST ASSEMBLY
7. CONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «DISPOSAL»(ref-283085-S21440971552008041700000) )
8. INSTALL SEAT BELT ANCHOR COVER CAP (See «DISPOSAL»(ref-283085-S21440971552008041700000) )
9. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the negative battery cable (See «INITIALIZATION»(ref-283083-S29543038892008041700000) ).
10. INSPECT FRONT SEAT ASSEMBLY Check the power seat operation. Check the seat heater operation (with seat heater system). Turn the engine switch on (IG). Turn the seat heater switch ON. Wait 5 minutes or more and confirm that the seat surface becomes warm.
11. INSPECT SRS WARNING LIGHT (See «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) )

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

1. REMOVE REAR SEAT CUSHION ASSEMBLY Detach the 2 front hooks of the rear seat cushion assembly from the vehicle body. NOTE: Follow the instructions below carefully as the cushion frame deforms easily. Choose a hook to detach first. Place your hands near the hook as shown in the illustration. Then lift the seat cushion to detach the hook. Repeat for the other hook. Detach the 2 rear hooks of the seat cushion from the seatback. Remove the seat cushion.
2. REMOVE REAR SEAT HEADREST ASSEMBLY
3. REMOVE REAR SEAT CENTER HEADREST ASSEMBLY
4. REMOVE REAR SEATBACK ASSEMBLY Using a screwdriver, detach the claws to open the caps of the rear seat shoulder belt guide RH. Remove the 3 screws and rear seat shoulder belt guide RH. HINT: Tape the screwdriver tip before use. Use the same procedure for the LH side and RH side Using a screwdriver, detach the claw to open the cap of the rear seat shoulder belt guide. HINT: Tape the screwdriver tip before use. Remove the 2 screws and rear seat shoulder belt guide. Remove the 4 bolts and rear seatback assembly. Detach the 3 upper hooks of the rear seatback assembly from the vehicle body.

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

1. REMOVE REAR BENCH TYPE SEAT CUSHION COVER Remove the 33 hog rings. Remove the 20 hog rings and seat cushion cover from the seat cushion frame (with pad).
2. REMOVE INNER CENTER SEAT ARMREST PLATE Disengage the 11 claws and remove the inner center seat armrest plate.
3. REMOVE REAR CENTER SEAT ARMREST ASSEMBLY Remove the 2 nuts. Disengage the 2 claws and remove the rear center seat armrest assembly.
4. REMOVE REAR SEAT HEADREST SUPPORT Disengage the 6 claws and remove the 3 rear seat headrest supports.
5. REMOVE REAR SEAT HEADREST SUPPORT
6. REMOVE REAR SEAT SHOULDER BELT GUIDE RH Remove the 3 screws and rear seat shoulder belt guide RH.
7. REMOVE REAR SEAT SHOULDER BELT GUIDE LH HINT: Use the same procedure for the RH side and LH side.
8. REMOVE REAR SEAT CENTER SHOULDER BELT GUIDE Remove the 2 screws and rear seat center shoulder belt guide.
9. REMOVE REAR BENCH TYPE SEATBACK COVER Remove the 55 hog rings. Remove the 20 hog rings and rear bench type seatback cover from the seatback frame (with pad).

Scheme 131

Scheme 132

Scheme 133

Scheme 134

1. INSTALL REAR BENCH TYPE SEATBACK COVER Using hog ring pliers, install 20 new hog rings. NOTE: Be careful not to damage the cover. When installing the hog rings, take care to minimize wrinkles as much as possible. Using hog ring pliers, install the rear bench type seatback cover to the seatback frame (with pad) with 55 new hog rings. NOTE: Be careful not to damage the cover. When installing the hog rings, take care to minimize wrinkles as much as possible.
2. INSTALL REAR SEAT CENTER SHOULDER BELT GUIDE Install the rear seat center shoulder belt guide with the 2 screws.
3. INSTALL REAR SEAT SHOULDER BELT GUIDE RH Install the rear seat shoulder belt guide RH with the 3 screws.
4. INSTALL REAR SEAT SHOULDER BELT GUIDE LH HINT: Use the same procedure for the RH and LH side.
5. INSTALL REAR SEAT HEADREST SUPPORT Engage the 6 claws and install the 3 rear seat headrest supports.
6. INSTALL REAR SEAT HEADREST SUPPORT
7. INSTALL REAR CENTER SEAT ARMREST ASSEMBLY Engage the 2 claws and install the rear center seat armrest assembly with the 2 nuts. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf)
8. INSTALL INNER CENTER SEAT ARMREST PLATE Engage the 11 claws and install the inner center seat armrest plate.
9. INSTALL REAR BENCH TYPE SEAT CUSHION COVER Using hog ring pliers, install the rear bench type seat cushion cover to the seat cushion frame (with pad) with 20 new hog rings. NOTE: Be careful not to damage the cover. When installing the hog rings, avoid wrinkling the cover. Using hog ring pliers, install the rear bench type seat cushion cover to the seat cushion frame (with pad) with 33 new hog rings. NOTE: Be careful not to damage the cover. When installing the hog rings, avoid wrinkling the cover.

Scheme 135

Scheme 136

Scheme 137

Scheme 138

1. INSTALL REAR SEATBACK ASSEMBLY Place the rear seatback assembly in the cabin. NOTE: Be careful not to damage the vehicle body. Install the rear seatback assembly with the 4 bolts. Torque: 18 N*m (184 kgf*cm, 13 ft.*lbf) Install the rear seat shoulder belt guide RH with the 3 screws. Pass the seat belt through and close the caps of the rear seat shoulder belt guide RH. HINT: Use the same procedure for the LH side and RH side. Install the rear seat center shoulder belt guide with the 2 screws. Pass the seat belt through and close the cap of the rear seat center shoulder belt guide.
2. INSTALL REAR SEAT CENTER HEADREST ASSEMBLY
3. INSTALL REAR SEAT HEADREST ASSEMBLY
4. INSTALL REAR SEAT CUSHION ASSEMBLY Attach the 2 rear hooks of the seat cushion to the seatback. Attach the 2 front hooks of the seat cushion to the vehicle body. Confirm that the seat cushion is firmly installed. NOTE: When installing the seat cushion, make sure the seat belt buckle is not under the seat cushion. HINT: After installing the seat cushion, vertically (up and down) rock the area around the rear seat cushion lock hooks. Make sure that there is no abnormal noise. If abnormal noise is heard, replace the rear seat cushion lock hooks with new ones.

Scheme 139

Scheme 140

Scheme 141

1. REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG (See «ON-VEHICLE INSPECTION»(ref-283122-S12886884592008041700000) )
2. REMOVE FRONT DOOR ARMREST BASE PANEL ASSEMBLY (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
3. REMOVE COURTESY LIGHT ASSEMBLY (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
4. REMOVE DOOR ARMREST COVER (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
5. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
6. REMOVE FRONT DOOR INNER GLASS WEATHERSTRIP (See «DISASSEMBLY»(ref-283122-S26637282382008041700000) )
7. REMOVE SEAT MEMORY SWITCH Remove the 2 screws. Disengage the 4 claws of the inside handle. HINT: The inside handle cannot be removed from the trim board sub-assembly. Disengage the 4 claws, and remove the seat memory switch.

1. INSTALL SEAT MEMORY SWITCH Install the seat memory switch to the inside handle. Engage the 4 claws and install the inside handle. Install the 2 screws.
2. INSTALL FRONT DOOR INNER GLASS WEATHERSTRIP (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
3. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
4. INSTALL DOOR ARMREST COVER (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
5. INSTALL COURTESY LIGHT ASSEMBLY (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
6. INSTALL FRONT DOOR ARMREST BASE PANEL ASSEMBLY (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )
7. INSTALL FRONT DOOR INSIDE HANDLE BEZEL PLUG (See «REASSEMBLY»(ref-283122-S14854552522008041700000) )

Scheme 142

REMOVAL

1. REMOVE SEAT BELT ANCHOR COVER CAP (See «REMOVAL»(ref-283085-S02151801352008041700000) )
2. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «REMOVAL»(ref-283085-S02151801352008041700000) )
3. REMOVE FRONT SEAT HEADREST ASSEMBLY
4. REMOVE FRONT SEAT OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
5. REMOVE FRONT SEAT INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
6. REMOVE FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
7. REMOVE FRONT SEAT REAR INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
8. REMOVE FRONT SEAT ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
9. REMOVE RECLINING POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
10. REMOVE SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
11. REMOVE FRONT SEAT CUSHION SHIELD ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
12. REMOVE FRONT POWER SEAT SWITCH (w/ Seat Position Memory System) Disconnect the 2 connectors. Remove the 3 screws and front power seat switch.
13. REMOVE FRONT POWER SEAT SWITCH (w/o Seat Position Memory System) Disconnect the connector. Remove the 3 screws and power seat switch.

Scheme 143

Scheme 144

Scheme 145

Scheme 146

1. INSPECT FRONT POWER SEAT SWITCH LH (w/ Seat Position Memory System) Measure the resistance between the specified terminals when each switch is operated. Standard resistance (Slide switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition U3-5 (+B) - U3-2 (SLD+) FRONT Below 1 ohms U3-1 (GND) - U3-3 (SLD-) FRONT Below 1 ohms U3-5 (+B) - U3-3 (SLD-) FRONT 10 kohms or higher U3-1 (GND) - U3-2 (SLD+) FRONT 10 kohms or higher U3-1 (GND) - U3-2 (SLD+) OFF Below 1 ohms U3-1 (GND) - U3-3 (SLD-) OFF Below 1 ohms U3-5 (+B) - U3-2 (SLD+) OFF 10 kohms or higher U3-5 (+B) - U3-3 (SLD-) OFF 10 kohms or higher U3-5 (+B) - U3-3 (SLD-) REAR Below 1 ohms U3-1 (GND) - U3-2 (SLD+) REAR Below 1 ohms U3-5 (+B) - U3-2 (SLD+) REAR 10 kohms or higher U3-1 (GND) - U3-3 (SLD-) REAR 10 kohms or higher Standard resistance (Front vertical switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition U3-5 (+B) - U3-6 (FRV+) UP Below 1 ohms U3-1 (GND) - U3-4 (FRV-) UP Below 1 ohms U3-5 (+B) - U3-4 (FRV-) UP 10 kohms or higher U3-1 (GND) - U3-6 (FRV+) UP 10 kohms or higher U3-1 (GND) - U3-6 (FRV+) OFF Below 1 ohms U3-1 (GND) - U3-4 (FRV-) OFF Below 1 ohms U3-5 (+B) - U3-6 (FRV+) OFF 10 kohms or higher U3-5 (+B) - U3-4 (FRV-) OFF 10 kohms or higher U3-5 (+B) - U3-4 (FRV-) DOWN Below 1 ohms U3-1 (GND) - U3-6 (FRV+) DOWN Below 1 ohms U3-5 (+B) - U3-6 (FRV+) DOWN 10 kohms or higher U3-1 (GND) - U3-4 (FRV-) DOWN 10 kohms or higher Standard resistance (Lifter switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition U3-5 (+B) - U3-7 (LFT+) UP Below 1 ohms U3-1 (GND) - U3-9 (LFT-) UP Below 1 ohms U3-5 (+B) - U3-9 (LFT-) UP 10 kohms or higher U3-1 (GND) - U3-7 (LFT+) UP 10 kohms or higher U3-1 (GND) - U3-7 (LFT+) OFF Below 1 ohms U3-1 (GND) - U3-9 (LFT-) OFF Below 1 ohms U3-5 (+B) - U3-7 (LFT+) OFF 10 kohms or higher U3-5 (+B) - U3-9 (LFT-) OFF 10 kohms or higher U3-5 (+B) - U3-9 (LFT-) DOWN Below 1 ohms U3-1 (GND) - U3-7 (LFT+) DOWN Below 1 ohms U3-5 (+B) - U3-7 (LFT+) DOWN 10 kohms or higher U3-1 (GND) - U3-9 (LFT-) DOWN 10 kohms or higher Standard resistance (Reclining switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition U3-5 (+B) - U3-8 (RCL+) FRONT Below 1 ohms U3-1 (GND) - U3-10 (RCL-) FRONT Below 1 ohms U3-5 (+B) - U3-10 (RCL-) FRONT 10 kohms or higher U3-1 (GND) - U3-8 (RCL+) FRONT 10 kohms or higher U3-1 (GND) - U3-8 (RCL+) OFF Below 1 ohms U3-1 (GND) - U3-10 (RCL-) OFF Below 1 ohms U3-5 (+B) - U3-8 (RCL+) OFF 10 kohms or higher U3-5 (+B) - U3-10 (RCL-) OFF 10 kohms or higher U3-5 (+B) - U3-10 (RCL-) REAR Below 1 ohms U3-1 (GND) - U3-8 (RCL+) REAR Below 1 ohms U3-5 (+B) - U3-8 (RCL+) REAR 10 kohms or higher U3-1 (GND) - U3-10 (RCL-) REAR 10 kohms or higher If the result is not as specified, replace the front power seat switch LH.
2. INSPECT FRONT POWER SEAT SWITCH LH (w/o Seat Position Memory System) Measure the resistance between the specified terminals when each switch is operated. Standard resistance (Slide switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition U13-1 (B) - U13-9 (SLDF) FRONT Below 1 ohms U13-4 (E) - U13-6 (SLDR) FRONT Below 1 ohms U13-1 (B) - U13-6 (SLDR) FRONT 10 kohms or higher U13-4 (E) - U13-9 (SLDF) FRONT 10 kohms or higher U13-4 (E) - U13-6 (SLDR) OFF Below 1 ohms U13-4 (E) - U13-9 (SLDF) OFF Below 1 ohms U13-1 (B) - U13-6 (SLDR) OFF 10 kohms or higher U13-1 (B) - U13-9 (SLDF) OFF 10 kohms or higher U13-1 (B) - U13-6 (SLDR) REAR Below 1 ohms U13-4 (E) - U13-9 (SLDF) REAR Below 1 ohms U13-1 (B) - U13-9 (SLDF) REAR 10 kohms or higher U13-4 (E) - U13-6 (SLDR) REAR 10 kohms or higher Standard resistance (Front vertical switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition U13-1 (B) - U13-10 (FUP) UP Below 1 ohms U13-4 (E) - U13-5 (FDWN) UP Below 1 ohms U13-1 (B) - U13-5 (FDWN) UP 10 kohms or higher U13-4 (E) - U13-10 (FUP) UP 10 kohms or higher U13-4 (E) - U13-5 (FDWN) OFF Below 1 ohms U13-4 (E) - U13-10 (FUP) OFF Below 1 ohms U13-1 (B) - U13-5 (FDWN) OFF 10 kohms or higher U13-1 (B) - U13-10 (FUP) OFF 10 kohms or higher U13-1 (B) - U13-5 (FDWN) DOWN Below 1 ohms U13-4 (E) - U13-10 (FUP) DOWN Below 1 ohms U13-1 (B) - U13-10 (FUP) DOWN 10 kohms or higher U13-4 (E) - U13-5 (FDWN) DOWN 10 kohms or higher Standard resistance (Lifter switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition U13-1 (B) - U13-7 (RUP) UP Below 1 ohms U13-4 (E) - U13-8 (RDWN) UP Below 1 ohms U13-1 (B) - U13-8 (RDWN) UP 10 kohms or higher U13-4 (E) - U13-7 (RUP) UP 10 kohms or higher U13-4 (E) - U13-7 (RUP) OFF Below 1 ohms U13-4 (E) - U13-8 (RDWN) OFF Below 1 ohms U13-1 (B) - U13-7 (RUP) OFF 10 kohms or higher U13-1 (B) - U13-8 (RDWN) OFF 10 kohms or higher U13-1 (B) - U13-8 (RDWN) DOWN Below 1 ohms U13-4 (E) - U13-7 (RUP) DOWN Below 1 ohms U13-1 (B) - U13-7 (RUP) DOWN 10 kohms or higher U13-4 (E) - U13-8 (RDWN) DOWN 10 kohms or higher Standard resistance (Reclining switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition U13-1 (B) - U13-3 (RCLF) FRONT Below 1 ohms U13-4 (E) - U13-2 (RCLR) FRONT Below 1 ohms U13-1 (B) - U13-2 (RCLR) FRONT 10 kohms or higher U13-4 (E) - U13-3 (RCLF) FRONT 10 kohms or higher U13-4 (E) - U13-2 (RCLR) OFF Below 1 ohms U13-4 (E) - U13-3 (RCLF) OFF Below 1 ohms U13-1 (B) - U13-3 (RCLF) OFF 10 kohms or higher U13-1 (B) - U13-2 (RCLR) OFF 10 kohms or higher U13-1 (B) - U13-2 (RCLR) REAR Below 1 ohms U13-4 (E) - U13-3 (RCLF) REAR Below 1 ohms U13-1 (B) - U13-3 (RCLF) REAR 10 kohms or higher U13-4 (E) - U13-2 (RCLR) REAR 10 kohms or higher If the result is not as specified, replace the front power seat switch LH.
3. INSPECT FRONT POWER SEAT SWITCH RH (w/ Seat Position Memory System) Measure the resistance between the specified terminals when each switch is operated. Standard resistance (Slide switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition T6-5 (+B) - T6-2 (SLD+) FRONT Below 1 ohms T6-1 (GND) - T6-3 (SLD-) FRONT Below 1 ohms T6-5 (+B) - T6-3 (SLD-) FRONT 10 kohms or higher T6-1 (GND) - T6-2 (SLD+) FRONT 10 kohms or higher T6-1 (GND) - T6-2 (SLD+) OFF Below 1 ohms T6-1 (GND) - T6-3 (SLD-) OFF Below 1 ohms T6-5 (+B) - T6-2 (SLD+) OFF 10 kohms or higher T6-5 (+B) - T6-3 (SLD-) OFF 10 kohms or higher T6-5 (+B) - T6-3 (SLD-) REAR Below 1 ohms T6-1 (GND) - T6-2 (SLD+) REAR Below 1 ohms T6-5 (+B) - T6-2 (SLD+) REAR 10 kohms or higher T6-1 (GND) - T6-3 (SLD-) REAR 10 kohms or higher Standard resistance (Front vertical switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition T6-5 (+B) - T6-6 (FRV+) UP Below 1 ohms T6-1 (GND) - T6-4 (FRV-) UP Below 1 ohms T6-5 (+B) - T6-4 (FRV-) UP 10 kohms or higher T6-1 (GND) - T6-6 (FRV+) UP 10 kohms or higher T6-1 (GND) - T6-6 (FRV+) OFF Below 1 ohms T6-1 (GND) - T6-4 (FRV-) OFF Below 1 ohms T6-5 (+B) - T6-6 (FRV+) OFF 10 kohms or higher T6-5 (+B) - T6-4 (FRV-) OFF 10 kohms or higher T6-5 (+B) - T6-4 (FRV-) DOWN Below 1 ohms T6-1 (GND) - T6-6 (FRV+) DOWN Below 1 ohms T6-5 (+B) - T6-6 (FRV+) DOWN 10 kohms or higher T6-1 (GND) - T6-4 (FRV-) DOWN 10 kohms or higher Standard resistance (Lifter switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition T6-5 (+B) - T6-7 (LFT+) UP Below 1 ohms T6-1 (GND) - T6-9 (LFT-) UP Below 1 ohms T6-5 (+B) - T6-9 (LFT-) UP 10 kohms or higher T6-1 (GND) - T6-7 (LFT+) UP 10 kohms or higher T6-1 (GND) - T6-7 (LFT+) OFF Below 1 ohms T6-1 (GND) - T6-9 (LFT-) OFF Below 1 ohms T6-5 (+B) - T6-7 (LFT+) OFF 10 kohms or higher T6-5 (+B) - T6-9 (LFT-) OFF 10 kohms or higher T6-5 (+B) - T6-9 (LFT-) DOWN Below 1 ohms T6-1 (GND) - T6-7 (LFT+) DOWN Below 1 ohms T6-5 (+B) - T6-7 (LFT+) DOWN 10 kohms or higher T6-1 (GND) - T6-9 (LFT-) DOWN 10 kohms or higher Standard resistance (Reclining switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition T6-5 (+B) - T6-8 (RCL+) FRONT Below 1 ohms T6-1 (GND) - T6-10 (RCL-) FRONT Below 1 ohms T6-5 (+B) - T6-10 (RCL-) FRONT 10 kohms or higher T6-1 (GND) - T6-8 (RCL+) FRONT 10 kohms or higher T6-1 (GND) - T6-8 (RCL+) OFF Below 1 ohms T6-1 (GND) - T6-10 (RCL-) OFF Below 1 ohms T6-5 (+B) - T6-8 (RCL+) OFF 10 kohms or higher T6-5 (+B) - T6-10 (RCL-) OFF 10 kohms or higher T6-5 (+B) - T6-10 (RCL-) REAR Below 1 ohms T6-1 (GND) - T6-8 (RCL+) REAR Below 1 ohms T6-5 (+B) - T6-8 (RCL+) REAR 10 kohms or higher T6-1 (GND) - T6-10 (RCL-) REAR 10 kohms or higher If the result is not as specified, replace the front power seat switch RH.
4. INSPECT FRONT POWER SEAT SWITCH RH (w/o Seat Position Memory System) Measure the resistance between the specified terminals when each switch is operated. Standard resistance (Slide switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition T14-1 (B) - T14-9 (SLDF) FRONT Below 1 ohms T14-4 (E) - T14-6 (SLDR) FRONT Below 1 ohms T14-1 (B) - T14-6 (SLDR) FRONT 10 kohms or higher T14-4 (E) - T14-9 (SLDF) FRONT 10 kohms or higher T14-4 (E) - T14-6 (SLDR) OFF Below 1 ohms T14-4 (E) - T14-9 (SLDF) OFF Below 1 ohms T14-1 (B) - T14-6 (SLDR) OFF 10 kohms or higher T14-1 (B) - T14-9 (SLDF) OFF 10 kohms or higher T14-1 (B) - T14-6 (SLDR) REAR Below 1 ohms T14-4 (E) - T14-9 (SLDF) REAR Below 1 ohms T14-1 (B) - T14-9 (SLDF) REAR 10 kohms or higher T14-4 (E) - T14-6 (SLDR) REAR 10 kohms or higher Standard resistance (Front vertical switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition T14-1 (B) - T14-5 (FUP) UP Below 1 ohms T14-4 (E) - T14-10 (FDWN) UP Below 1 ohms T14-1 (B) - T14-10 (FDWN) UP 10 kohms or higher T14-4 (E) - T14-5 (FUP) UP 10 kohms or higher T14-4 (E) - T14-10 (FDWN) OFF Below 1 ohms T14-4 (E) - T14-5 (FUP) OFF Below 1 ohms T14-1 (B) - T14-10 (FDWN) OFF 10 kohms or higher T14-1 (B) - T14-5 (FUP) OFF 10 kohms or higher T14-1 (B) - T14-10 (FDWN) DOWN Below 1 ohms T14-4 (E) - T14-5 (FUP) DOWN Below 1 ohms T14-1 (B) - T14-5 (FUP) DOWN 10 kohms or higher T14-4 (E) - T14-10 (FDWN) DOWN 10 kohms or higher Standard resistance (Lifter switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition T14-1 (B) - T14-8 (RUP) UP Below 1 ohms T14-4 (E) - T14-7 (RDWN) UP Below 1 ohms T14-1 (B) - T14-7 (RDWN) UP 10 kohms or higher T14-4 (E) - T14-8 (RUP) UP 10 kohms or higher T14-4 (E) - T14-8 (RUP) OFF Below 1 ohms T14-4 (E) - T14-7 (RDWN) OFF Below 1 ohms T14-1 (B) - T14-8 (RUP) OFF 10 kohms or higher T14-1 (B) - T14-7 (RDWN) OFF 10 kohms or higher T14-1 (B) - T14-7 (RDWN) DOWN Below 1 ohms T14-4 (E) - T14-8 (RUP) DOWN Below 1 ohms T14-1 (B) - T14-8 (RUP) DOWN 10 kohms or higher T14-4 (E) - T14-7 (RDWN) DOWN 10 kohms or higher Standard resistance (Reclining switch) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition T14-1 (B) - T14-3 (RCLF) FRONT Below 1 ohms T14-4 (E) - T14-2 (RCLR) FRONT Below 1 ohms T14-1 (B) - T14-2 (RCLR) FRONT 10 kohms or higher T14-4 (E) - T14-3 (RCLF) FRONT 10 kohms or higher T14-4 (E) - T14-2 (RCLR) OFF Below 1 ohms T14-4 (E) - T14-3 (RCLF) OFF Below 1 ohms T14-1 (B) - T14-3 (RCLF) OFF 10 kohms or higher T14-1 (B) - T14-2 (RCLR) OFF 10 kohms or higher T14-1 (B) - T14-2 (RCLR) REAR Below 1 ohms T14-4 (E) - T14-3 (RCLF) REAR Below 1 ohms T14-1 (B) - T14-3 (RCLF) REAR 10 kohms or higher T14-4 (E) - T14-2 (RCLR) REAR 10 kohms or higher If the result is not as specified, replace the front power seat switch RH.

1. INSTALL FRONT POWER SEAT SWITCH (w/ Seat Position Memory System) Install the power seat switch with the 3 screws. Connect the 2 connectors.
2. INSTALL FRONT POWER SEAT SWITCH (w/o Seat Position Memory System) Install the power seat switch with the 3 screws. Connect the connector.
3. INSTALL FRONT SEAT CUSHION SHIELD ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
4. INSTALL SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
5. INSTALL RECLINING POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
6. INSTALL FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
7. INSTALL FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
8. INSTALL FRONT SEAT REAR INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
9. INSTALL FRONT SEAT OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
10. INSTALL FRONT SEAT INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
11. INSTALL FRONT SEAT HEADREST ASSEMBLY
12. CONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
13. INSTALL SEAT BELT ANCHOR COVER CAP (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
14. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the negative battery cable (See «INITIALIZATION»(ref-283083-S29543038892008041700000) )
15. INSPECT FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
16. INSPECT SRS WARNING LIGHT Check the SRS warning light. (See «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) )

Scheme 147

1. REMOVE SEAT BELT ANCHOR COVER CAP (See «REMOVAL»(ref-283085-S02151801352008041700000) )
2. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «REMOVAL»(ref-283085-S02151801352008041700000) )
3. REMOVE FRONT SEAT HEADREST ASSEMBLY
4. REMOVE FRONT SEAT OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
5. REMOVE FRONT SEAT INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
6. REMOVE FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
7. REMOVE FRONT SEAT REAR INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
8. REMOVE FRONT SEAT ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
9. REMOVE RECLINING POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
10. REMOVE SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
11. REMOVE FRONT SEAT CUSHION SHIELD ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
12. REMOVE FRONT POWER SEAT LUMBAR SWITCH Remove the 2 screws and front power seat lumbar switch.

Scheme 148

Scheme 149

1. INSPECT FRONT POWER SEAT LUMBAR SWITCH LH Measure the resistance between the terminals when the switch is operated. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition U12-4 (E2) - U12-3 (R) HOLD Below 1 ohms U12-2 (B) - U12-5 (H) HOLD Below 1 ohms U12-4 (E2) - U12-5 (H) HOLD 10 ohms or higher U12-2 (B) - U12-3 (R) HOLD 10 ohms or higher U12-4 (E2) - U12-3 (R) OFF Below 1 ohms U12-5 (H) - U12-1 (E) OFF Below 1 ohms U12-4 (E2) - U12-1 (E) OFF 10 ohms or higher U12-5 (H) - U12-3 (R) OFF 10 ohms or higher U12-2 (B) - U12-3 (R) RELEASE Below 1 ohms U12-5 (H) - U12-1 (E) RELEASE Below 1 ohms U12-2 (B) - U12-1 (E) RELEASE 10 ohms or higher U12-5 (H) - U12-3 (R) RELEASE 10 ohms or higher If the result is not as specified, replace the switch.
2. INSPECT FRONT POWER SEAT LUMBAR SWITCH RH Measure the resistance between the terminals when the switch is operated. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition T13-1 (GND) - T13-5 (R) HOLD Below 1 ohms T13-2 (B) - T13-3 (H) HOLD Below 1 ohms T13-1 (GND) - T13-3 (H) HOLD 10 ohms or higher T13-2 (B) - T13-5 (R) HOLD 10 ohms or higher T13-1 (GND) - T13-5 (R) OFF Below 1 ohms T13-3 (H) - T13-4 (E) OFF Below 1 ohms T13-1 (GND) - T13-4 (E) OFF 10 ohms or higher T13-3 (H) - T13-5 (R) OFF 10 ohms or higher T13-2 (B) - T13-5 (R) RELEASE Below 1 ohms T13-3 (H) - T13-4 (E) RELEASE Below 1 ohms T13-2 (B) - T13-4 (E) RELEASE 10 ohms or higher T13-3 (H) - T13-5 (R) RELEASE 10 ohms or higher If the result is not as specified, replace the switch.

1. INSTALL FRONT POWER SEAT LUMBAR SWITCH Install the front power seat lumbar switch with the 2 screws.
2. INSTALL FRONT SEAT CUSHION SHIELD ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
3. INSTALL SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
4. INSTALL RECLINING POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
5. INSTALL FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
6. INSTALL FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
7. INSTALL FRONT SEAT REAR INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
8. INSTALL FRONT SEAT OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
9. INSTALL FRONT SEAT INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
10. INSTALL FRONT SEAT HEADREST ASSEMBLY
11. CONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
12. INSTALL SEAT BELT ANCHOR COVER CAP (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
13. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the negative battery cable (See «INITIALIZATION»(ref-283083-S29543038892008041700000) )
14. INSTALL FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
15. INSPECT SRS WARNING LIGHT Check the SRS warning light. (See «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) )

Scheme 150

1. REMOVE SEAT BELT ANCHOR COVER CAP (See «REMOVAL»(ref-283085-S02151801352008041700000) )
2. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «REMOVAL»(ref-283085-S02151801352008041700000) )
3. REMOVE FRONT SEAT HEADREST ASSEMBLY
4. REMOVE FRONT SEAT OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
5. REMOVE FRONT SEAT INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
6. REMOVE FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
7. REMOVE FRONT SEAT REAR INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
8. REMOVE FRONT SEAT ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
9. REMOVE FRONT SEAT INNER BELT ASSEMBLY (See «REMOVAL»(ref-283085-S02151801352008041700000) )
10. REMOVE RECLINING POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
11. REMOVE SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
12. REMOVE FRONT SEAT CUSHION SHIELD ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
13. REMOVE FRONT SEAT INNER CUSHION SHIELD (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
14. REMOVE FRONT SEATBACK BOARD SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
15. REMOVE FRONT SEATBACK BOARD COVER SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
16. REMOVE FRONT SEAT HEADREST SUPPORT (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
17. REMOVE FRONT SEAT HEADREST SUPPORT
18. REMOVE FRONT SEPARATE TYPE SEATBACK COVER WITH PAD (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
19. REMOVE LUMBAR SUPPORT ADJUSTER ASSEMBLY Disconnect the connector. Remove the 2 screws and lumbar support adjuster assembly.

Scheme 151

Scheme 152

1. INSPECT LUMBAR SUPPORT ADJUSTER ASSEMBLY LH Check operation of the lumbar support adjuster. Check if the lumbar support adjuster moves smoothly when the battery is connected to the lumbar support adjuster motor connector terminals. OK MEASUREMENT CONDITION CHART Measurement Condition Operation Direction Battery positive (+) --> U8-2 Battery negative (-) --> U8-1 Clockwise Battery positive (+) --> U8-1 Battery negative (-) --> U8-2 Counterclockwise If the result is not as specified, replace the lumbar support adjuster LH.
2. INSPECT LUMBAR SUPPORT ADJUSTER ASSEMBLY RH Check operation of the lumbar support adjuster. Check if the lumbar support adjuster moves smoothly when the battery is connected to the lumbar support adjuster motor connector terminals. OK MEASUREMENT CONDITION CHART Measurement Condition Operation Direction Battery positive (+) --> T10-1 Battery negative (-) --> T10-2 Clockwise Battery positive (+) --> T10-2 Battery negative (-) --> T10-1 Counterclockwise If the result is not as specified, replace the lumbar support adjuster RH.

1. INSTALL LUMBAR SUPPORT ADJUSTER ASSEMBLY Install the lumber support adjuster assembly with the 2 screws. Connect the connector.
2. INSTALL FRONT SEPARATE TYPE SEATBACK COVER WITH PAD (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
3. INSTALL FRONT SEAT HEADREST SUPPORT (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
4. INSTALL FRONT SEAT HEADREST SUPPORT
5. INSTALL FRONT SEATBACK BOARD COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
6. INSTALL FRONT SEATBACK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
7. INSTALL FRONT SEAT INNER CUSHION SHIELD (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
8. INSTALL FRONT SEAT CUSHION SHIELD ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
9. INSTALL SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
10. INSTALL RECLINING POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
11. INSTALL FRONT SEAT INNER BELT ASSEMBLY (See «INSTALLATION»(ref-283085-S41824513002008041700000) )
12. INSTALL FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
13. INSTALL FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
14. INSTALL FRONT SEAT REAR INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
15. INSTALL FRONT SEAT OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
16. INSTALL FRONT SEAT INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
17. INSTALL FRONT SEAT HEADREST ASSEMBLY
18. CONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
19. INSTALL SEAT BELT ANCHOR COVER CAP (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
20. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the negative battery cable (See «INITIALIZATION»(ref-283083-S29543038892008041700000) )
21. INSPECT FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
22. INSPECT SRS WARNING LIGHT Check the SRS warning light. (See «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) )

Scheme 153

1. REMOVE SEAT BELT ANCHOR COVER CAP (See «REMOVAL»(ref-283085-S02151801352008041700000) )
2. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «REMOVAL»(ref-283085-S02151801352008041700000) )
3. REMOVE FRONT SEAT HEADREST ASSEMBLY
4. REMOVE FRONT SEAT OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
5. REMOVE FRONT SEAT INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
6. REMOVE FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
7. REMOVE FRONT SEAT REAR INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
8. REMOVE FRONT SEAT ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
9. REMOVE RECLINING POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
10. REMOVE SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
11. REMOVE FRONT SEAT CUSHION SHIELD ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
12. REMOVE SEAT VARIABLE CUSHION SWITCH Remove the 2 screws and seat variable cushion switch.

Scheme 154

1. INSPECT SEAT VARIABLE CUSHION SWITCH (w/ Seat Position Memory System) Inspect the seat variable cushion switch. Measure the resistance between the terminals when the switch is operated. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition U11-4 (E2) - U11-5 (CSNF) FRONT Below 1 ohms U11-2 (B) - U11-3 (CSNR) FRONT Below 1 ohms U11-4 (E2) - U11-3 (CSNR) FRONT 10 kohms or higher U11-2 (B) - U11-5 (CSNF) FRONT 10 kohms or higher U11-4 (E2) - U11-5 (CSNF) OFF Below 1 ohms U11-1 (E1) - U11-3 (CSNR) OFF Below 1 ohms U11-4 (E2) - U11-3 (CSNR) OFF 10 kohms or higher U11-1 (E1) - U11-5 (CSNF) OFF 10 kohms or higher U11-1 (E1) - U11-3 (CSNR) REAR Below 1 ohms U11-2 (B) - U11-5 (CSNF) REAR Below 1 ohms U11-1 (E1) - U11-5 (CSNF) REAR 10 kohms or higher U11-2 (B) - U11-3 (CSNR) REAR 10 kohms or higher If the result is not as specified, replace the seat variable cushion switch.

1. INSTALL SEAT VARIABLE CUSHION SWITCH Install the seat variable cushion switch with the 2 screws.
2. INSTALL FRONT SEAT CUSHION SHIELD ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
3. INSTALL SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
4. INSTALL RECLINING POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
5. INSTALL FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
6. INSTALL FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
7. INSTALL FRONT SEAT REAR INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
8. INSTALL FRONT SEAT OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
9. INSTALL FRONT SEAT INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
10. INSTALL FRONT SEAT HEADREST ASSEMBLY
11. CONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
12. INSTALL SEAT BELT ANCHOR COVER CAP (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
13. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the negative battery cable (See «INITIALIZATION»(ref-283083-S29543038892008041700000) )
14. INSPECT FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
15. INSPECT SRS WARNING LIGHT Check the SRS warning light. (See «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) )

Scheme 155

1. REMOVE SEAT BELT ANCHOR COVER CAP (See «REMOVAL»(ref-283085-S02151801352008041700000) )
2. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «REMOVAL»(ref-283085-S02151801352008041700000) )
3. REMOVE FRONT SEAT HEADREST ASSEMBLY
4. REMOVE FRONT SEAT OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
5. REMOVE FRONT SEAT INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
6. REMOVE FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
7. REMOVE FRONT SEAT REAR INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
8. REMOVE FRONT SEAT ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
9. REMOVE FRONT SEAT INNER BELT ASSEMBLY (See «REMOVAL»(ref-283085-S02151801352008041700000) )
10. REMOVE RECLINING POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
11. REMOVE SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
12. REMOVE FRONT SEAT CUSHION SHIELD ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
13. REMOVE FRONT SEAT INNER CUSHION SHIELD (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
14. REMOVE FRONT SEATBACK BOARD SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
15. REMOVE FRONT SEATBACK BOARD COVER SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
16. REMOVE FRONT SEAT HEADREST SUPPORT (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
17. REMOVE FRONT SEAT HEADREST SUPPORT
18. REMOVE FRONT SEPARATE TYPE SEATBACK COVER WITH PAD (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
19. REMOVE SEATBACK CLIMATE CONTROL BLOWER Disconnect the connector and detach the 4 clamps. Using a T30 "TORX" socket, remove the 6 "TORX" bolts and remove the seatback climate control blower.

Scheme 156

Scheme 157

1. INSPECT SEAT CLIMATE CONTROL BLOWER LH (FRONT SEATBACK BLOWER LH) Connect the battery positive (+) lead to terminal U14-2 (IG), and the negative (-) lead to terminal U14-1 (GND). Check that the blower fan motor operates smoothly. If the result is not as specified, replace the blower.
2. INSPECT SEAT CLIMATE CONTROL BLOWER RH (FRONT SEATBACK BLOWER RH) Connect the battery positive (+) lead to terminal T16-2 (IG), and the negative (-) lead to terminal T16-1 (GND). Check that the blower fan motor operates smoothly. If the result is not as specified, replace the blower.

1. INSTALL SEATBACK CLIMATE CONTROL BLOWER Using T30 "TORX" socket, install the seatback climate control blower with the 6 "TORX" bolts. Connect the 4 clamps and connector.
2. INSTALL FRONT SEPARATE TYPE SEATBACK COVER WITH PAD (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
3. INSTALL FRONT SEAT HEADREST SUPPORT (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
4. INSTALL FRONT SEAT HEADREST SUPPORT
5. INSTALL FRONT SEATBACK BOARD COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
6. INSTALL FRONT SEATBACK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
7. INSTALL FRONT SEAT INNER CUSHION SHIELD (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
8. INSTALL FRONT SEAT CUSHION SHIELD ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
9. INSTALL SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
10. INSTALL RECLINING POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
11. INSTALL FRONT SEAT INNER BELT ASSEMBLY (See «INSTALLATION»(ref-283085-S41824513002008041700000) )
12. INSTALL FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
13. INSTALL FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
14. INSTALL FRONT SEAT REAR INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
15. INSTALL FRONT SEAT OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
16. INSTALL FRONT SEAT INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
17. INSTALL FRONT SEAT HEADREST ASSEMBLY
18. CONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
19. INSTALL SEAT BELT ANCHOR COVER CAP (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
20. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the negative battery cable (See «INITIALIZATION»(ref-283083-S29543038892008041700000) )
21. INSPECT FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
22. INSPECT SRS WARNING LIGHT Check the SRS warning light. (See «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) )

Scheme 158

Scheme 159

1. REMOVE SEAT BELT ANCHOR COVER CAP (See «REMOVAL»(ref-283085-S02151801352008041700000) )
2. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «REMOVAL»(ref-283085-S02151801352008041700000) )
3. REMOVE FRONT SEAT HEADREST ASSEMBLY
4. REMOVE FRONT SEAT OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
5. REMOVE FRONT SEAT INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
6. REMOVE FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
7. REMOVE FRONT SEAT REAR INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
8. REMOVE FRONT SEAT ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
9. REMOVE FRONT SEAT INNER BELT ASSEMBLY (See «REMOVAL»(ref-283085-S02151801352008041700000) )
10. REMOVE RECLINING POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
11. REMOVE SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
12. REMOVE FRONT SEAT CUSHION SHIELD ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
13. REMOVE FRONT SEAT INNER CUSHION SHIELD (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
14. REMOVE FRONT SEPARATE TYPE SEAT CUSHION COVER WITH PAD (w/o Variable Cushion) (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
15. REMOVE FRONT SEPARATE TYPE SEAT CUSHION COVER WITH PAD (w/ Variable Cushion) (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
16. REMOVE SEAT CUSHION CLIMATE CONTROL DUCT (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
17. REMOVE SEAT CUSHION CLIMATE CONTROL BLOWER Disconnect the connector. Remove the screw, detach the claw and remove the seat cushion climate control blower.
18. REMOVE SEAT CLIMATE CONTROL BLOWER Remove the 3 bolts, 3 nuts, bracket, and seat climate control blower.

Scheme 160

Scheme 161

1. INSPECT SEAT CLIMATE CONTROL BLOWER LH (FRONT SEAT CUSHION BLOWER LH) Connect the battery positive (+) lead to terminal U15-1 (IG), and the negative (-) lead to terminal U15-4 (GND). Check that the blower fan motor operates smoothly. If the result is not as specified, replace the blower.
2. INSPECT SEAT CLIMATE CONTROL BLOWER RH (FRONT SEAT CUSHION BLOWER RH) Connect the battery positive (+) lead to terminal T17-1 (IG), and the negative (-) lead to terminal T17-4 (GND). Check that the blower fan motor operates smoothly. If the result is not as specified, replace the blower.

1. INSTALL SEAT CLIMATE CONTROL BLOWER Install the seat climate control blower and bracket with the 3 bolts and 3 nuts.
2. INSTALL SEAT CUSHION CLIMATE CONTROL BLOWER Engage the 2 claws to install the seat cushion climate control blower. Install the seat cushion climate control blower with the screw. Torque: 2.6 N*m (27 kgf*cm, 23 in.*lbf) Connect the connector.
3. INSTALL SEAT CUSHION CLIMATE CONTROL DUCT (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
4. INSTALL FRONT SEPARATE TYPE SEAT CUSHION COVER WITH PAD (w/o Variable Cushion) (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
5. INSTALL FRONT SEPARATE TYPE SEAT CUSHION COVER WITH PAD (w/ Variable Cushion) (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
6. INSTALL FRONT SEAT INNER CUSHION SHIELD (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
7. INSTALL FRONT SEAT CUSHION SHIELD ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
8. INSTALL SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
9. INSTALL RECLINING POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
10. INSTALL FRONT SEAT INNER BELT ASSEMBLY (See «INSTALLATION»(ref-283085-S41824513002008041700000) )
11. INSTALL FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
12. INSTALL FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
13. INSTALL FRONT SEAT REAR INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
14. INSTALL FRONT SEAT OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
15. INSTALL FRONT SEAT INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
16. INSTALL FRONT SEAT HEADREST ASSEMBLY
17. CONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
18. INSTALL SEAT BELT ANCHOR COVER CAP (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
19. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the negative battery cable (See «INITIALIZATION»(ref-283083-S29543038892008041700000) )
20. INSPECT FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
21. INSPECT SRS WARNING LIGHT Check the SRS warning light. (See «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) )

Scheme 162

Scheme 163

1. REMOVE HEATER SEAT SWITCH CONSOLE BASE (See «REMOVAL»(ref-283109-S39106719462008041700000) )
2. REMOVE SEAT HEATER SWITCH Disengage the 4 claws and remove the seat heater switch.

Scheme 164

1. INSPECT SEAT HEATER SWITCH Inspect seat heater switch operation. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Position Specified Condition F3-1 (RV) - F3-6 (SW) OFF: Front RH Vol: 0 Below 2.5 kohms OFF: Front RH Vol: 3 Below 376 ohms F3-2 (REL1) - F3-11 (SW) OFF: Front LH Vol: 0 Below 2.5 kohms OFF: Front LH Vol: 3 Below 376 ohms F3-7 (BLLH) - F3-10 (SVSG) OFF: Front RH Vol: 0 Below 1.1 kohms OFF: Front RH Vol: 3 Below 111 ohms F3-8 (SVS5) - F3-10 (SVSG) Always Below 770 ohms to 1.43 kohms F3-9 (BLRH) - F3-10 (SVSG) OFF: Front LH Vol:0 Below 1.1 kohms OFF: Front LH Vol: 3 Below 111 ohms Inspect seat heater switch indicator operation. Apply battery voltage and check operation of the switch, as shown in the table below. OK MEASUREMENT CONDITION CHART Measurement Condition Condition Specified Condition Battery positive (+) --> Terminal F3-5 (IG) Battery negative (-) --> Terminal F3-12 (E) Seat heater switch ON Indicator comes on Inspect seat heater switch illumination. Apply battery voltage and check operation of the switch, as shown in the table below. OK MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal F3-4 (ILL+) Battery negative (-) --> Terminal F3-3 (ILL-) Illumination comes on

1. INSTALL SEAT HEATER SWITCH Engage the 4 claws and install the seat heater switch.
2. INSTALL HEATER SEAT SWITCH CONSOLE BASE (See «INSTALLATION»(ref-283109-S06931105292008041700000) )

Scheme 165

1. REMOVE SEAT BELT ANCHOR COVER CAP (See «REMOVAL»(ref-283085-S02151801352008041700000) )
2. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «REMOVAL»(ref-283085-S02151801352008041700000) )
3. REMOVE FRONT SEAT HEADREST ASSEMBLY
4. REMOVE FRONT SEAT OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
5. REMOVE FRONT SEAT INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
6. REMOVE FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
7. REMOVE FRONT SEAT REAR INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
8. REMOVE FRONT SEAT ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
9. REMOVE FRONT SEAT INNER BELT ASSEMBLY (See «REMOVAL»(ref-283085-S02151801352008041700000) )
10. REMOVE RECLINING POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
11. REMOVE SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
12. REMOVE FRONT SEAT CUSHION SHIELD ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
13. REMOVE FRONT SEAT INNER CUSHION SHIELD (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
14. REMOVE FRONT SEATBACK BOARD SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
15. REMOVE FRONT SEATBACK BOARD COVER SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
16. REMOVE FRONT SEAT HEADREST SUPPORT (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
17. REMOVE FRONT SEAT HEADREST SUPPORT
18. REMOVE FRONT SEPARATE TYPE SEATBACK COVER WITH PAD (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
19. REMOVE FRONT SEPARATE TYPE SEATBACK COVER (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
20. REMOVE FRONT SEATBACK HEATER Cut off the tack pins that fasten the seat heater, and then remove the front seatback heater from the front separate type seatback cover.

Scheme 166

1. INSPECT FRONT SEATBACK HEATER Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition 1 - 2 Always Below 1 ohms

1. INSTALL FRONT SEATBACK HEATER Using a tacker, install the front seatback heater to the end of the seat cover with the 11 new tack pins.
2. INSTALL FRONT SEPARATE TYPE SEATBACK COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
3. INSTALL FRONT SEPARATE TYPE SEATBACK COVER WITH PAD (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
4. INSTALL FRONT SEAT HEADREST SUPPORT (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
5. INSTALL FRONT SEAT HEADREST SUPPORT
6. INSTALL FRONT SEATBACK BOARD COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
7. INSTALL FRONT SEATBACK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
8. INSTALL FRONT SEAT INNER CUSHION SHIELD (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
9. INSTALL FRONT SEAT CUSHION SHIELD ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
10. INSTALL SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
11. INSTALL RECLINING POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
12. INSTALL FRONT SEAT INNER BELT ASSEMBLY (See «INSTALLATION»(ref-283085-S41824513002008041700000) )
13. INSTALL FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
14. INSTALL FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
15. INSTALL FRONT SEAT REAR INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
16. INSTALL FRONT SEAT OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
17. INSTALL FRONT SEAT INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
18. INSTALL FRONT SEAT HEADREST ASSEMBLY
19. CONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
20. INSTALL SEAT BELT ANCHOR COVER CAP (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
21. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the negative battery cable (See «INITIALIZATION»(ref-283083-S29543038892008041700000) )
22. INSPECT FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
23. INSPECT SRS WARNING LIGHT Check the SRS warning light. (See «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) )

Scheme 167

1. REMOVE SEAT BELT ANCHOR COVER CAP (See «REMOVAL»(ref-283085-S02151801352008041700000) )
2. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «REMOVAL»(ref-283085-S02151801352008041700000) )
3. REMOVE FRONT SEAT HEADREST ASSEMBLY
4. REMOVE FRONT SEAT OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
5. REMOVE FRONT SEAT INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
6. REMOVE FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
7. REMOVE FRONT SEAT REAR INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
8. REMOVE FRONT SEAT ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
9. REMOVE FRONT SEAT INNER BELT ASSEMBLY (See «REMOVAL»(ref-283085-S02151801352008041700000) )
10. REMOVE RECLINING POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
11. REMOVE SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «REMOVAL»(ref-283115-S37038451012008041700000) )
12. REMOVE FRONT SEAT CUSHION SHIELD ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
13. REMOVE FRONT SEAT INNER CUSHION SHIELD (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
14. REMOVE FRONT SEPARATE TYPE SEAT CUSHION COVER WITH PAD (w/o Variable Cushion) (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
15. REMOVE FRONT SEPARATE TYPE SEAT CUSHION COVER WITH PAD (w/ Variable Cushion) (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
16. REMOVE FRONT SEPARATE TYPE SEAT CUSHION COVER (W/o variable cushion) (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
17. REMOVE FRONT SEPARATE TYPE SEAT CUSHION COVER (W/ variable cushion) (See «DISASSEMBLY»(ref-283115-S04154550432008041700000) )
18. REMOVE FRONT SEAT CUSHION HEATER Cut off the tack pins that fasten the seat heater, and then remove the front seat cushion heater assembly from the separate type front seat cushion cover.

Scheme 168

1. INSPECT FRONT SEAT CUSHION HEATER Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition A-1 - B-1 Below 25°C (77°F) 3.05 to 3.65 ohms A-4 - B-2 A-1 - A-4 B-1 - B-2 A-2 - A-3 35°C (95°F) 8 to 12 kohms

1. INSTALL FRONT SEAT CUSHION HEATER Using a tacker, install the front seat cushion heater to the end of the seat cover with the tack pins.
2. INSTALL FRONT SEPARATE TYPE SEAT CUSHION COVER (w/o variable cushion) (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
3. REMOVE FRONT SEPARATE TYPE SEAT CUSHION COVER (w/ variable cushion) (See «REASSEMBLY»(ref-283115-S14727516362008041700000) )
4. INSTALL FRONT SEPARATE TYPE SEAT CUSHION COVER WITH PAD (w/o Variable Cushion) (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
5. INSTALL FRONT SEPARATE TYPE SEAT CUSHION COVER WITH PAD (w/ Variable Cushion) (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
6. INSTALL FRONT SEAT INNER CUSHION SHIELD (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
7. INSTALL FRONT SEAT CUSHION SHIELD ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
8. INSTALL SLIDE AND VERTICAL POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
9. INSTALL RECLINING POWER SEAT SWITCH KNOB (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
10. INSTALL FRONT SEAT INNER BELT ASSEMBLY (See «INSTALLATION»(ref-283085-S41824513002008041700000) )
11. INSTALL FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
12. INSTALL FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
13. INSTALL FRONT SEAT REAR INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
14. INSTALL FRONT SEAT OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
15. INSTALL FRONT SEAT INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
16. INSTALL FRONT SEAT HEADREST ASSEMBLY
17. CONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
18. INSTALL SEAT BELT ANCHOR COVER CAP (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
19. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the negative battery cable (See «INITIALIZATION»(ref-283083-S29543038892008041700000) )
20. INSPECT AND ADJUST FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
21. INSPECT SRS WARNING LIGHT Check the SRS warning light. (See «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) )

Scheme 169

Scheme 170

1. REMOVE SEAT BELT ANCHOR COVER CAP (See «REMOVAL»(ref-283085-S02151801352008041700000) )
2. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «REMOVAL»(ref-283085-S02151801352008041700000) )
3. REMOVE FRONT SEAT HEADREST ASSEMBLY
4. REMOVE FRONT SEAT OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
5. REMOVE FRONT SEAT INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
6. REMOVE FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
7. REMOVE FRONT SEAT REAR INNER TRACK BRACKET COVER (See «REMOVAL»(ref-283115-S37038451012008041700000) )
8. REMOVE FRONT SEAT ASSEMBLY (See «REMOVAL»(ref-283115-S37038451012008041700000) )
9. REMOVE SEAT HEATER CONTROL Disconnect the 2 connectors. Disconnect the clamp and claw, and remove the seat heater control sub-assembly.

Scheme 171

Scheme 172

1. INSPECT FRONT SEAT HEATER CONTROL LH Disconnect the seat heater control LH connector. Measure the voltage and resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition U16-6 (E) - Body ground Always Below 1 ohms Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition U16-1 (SWL) - U16-6 (E) Engine switch on (IG), seat heater switch OFF --> ON 0 V --> 10 to 14 V U16-4 (B) - U16-6 (E) Engine switch off --> on (IG) 0 V --> 10 to 14 V Reconnect the seat heater control LH connector. Measure the voltage according to the value(s) in the table below. Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition U16-5 (THL) - U16-6 (E) Engine switch on (IG), seat heater switch volume 1 --> 3 Gradual increase 0 V --> 10 to 14 V
2. INSPECT FRONT SEAT HEATER CONTROL RH Disconnect the seat heater control RH connector. Measure the voltage and resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition T18-6 (E) - Body ground Always Below 1 ohms Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition T18-1 (SWR) - T18-6 (E) Engine switch on (IG), seat heater switch OFF --> ON 0 V --> 10 to 14 V T18-4 (B1) - T18-6 (E) Engine switch off --> on (IG) 0 V --> 10 to 14 V Reconnect the seat heater control RH connector. Measure the voltage according to the value(s) in the table below. Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition T18-5 (THR) - T18-6 (E) Engine switch on (IG), seat heater switch volume 1 --> 3 Gradual increase 0 V --> 10 to 14 V

Scheme 173

1. INSTALL SEAT HEATER CONTROL Install the seat heater control with the clamp and claw. Connect the 2 connectors.
2. INSTALL FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
3. INSTALL FRONT SEAT REAR OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
4. INSTALL FRONT SEAT REAR INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
5. INSTALL FRONT SEAT OUTER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
6. INSTALL FRONT SEAT INNER TRACK BRACKET COVER (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
7. INSTALL FRONT SEAT HEADREST ASSEMBLY
8. CONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
9. INSTALL SEAT BELT ANCHOR COVER CAP (See «INSTALLATION»(ref-283085-S02015809652008041700000) )
10. REMOVE PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the negative battery cable (See «INITIALIZATION»(ref-283083-S29543038892008041700000) )
11. INSPECT FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-283115-S30488853982008041700000) )
12. INSPECT SRS WARNING LIGHT Check the SRS warning light. (See «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) )
