PRECAUTION
Note. Some systems need to be initialized after reconnecting the negative (-) battery terminal (See INITIALIZATION ).
Scheme 174
Scheme 175
Scheme 176
Scheme 177
Scheme 178
Communication table
| Sender | Receiver | Signal | Line |
|---|---|---|---|
| ECM | Front Power Seat Switch LH (Position Control ECU) | Shift position signal (P, R, N, D, S) | CAN |
| ECM | Front Power Seat Switch RH (Position Control ECU) | Shift position signal (P, R, N, D, S) | CAN |
| Outer Mirror Control ECU | Front Power Seat Switch LH (Position Control ECU) | Driver's seat memory switch M1 signal Driver's seat memory switch M2 signal Driver's seat memory switch SET signal | CAN |
| Outer Mirror Control ECU | Front Power Seat Switch RH (Position Control ECU) | Front passenger seat memory switch M1 signal Front passenger seat memory switch M2 signal Front passenger seat memory switch SET signal | CAN |
| Main Body ECU | Front Power Seat Switch LH (Position Control ECU) | Engine switch signal Key switch signal Driver's door courtesy light switch signal Parking brake switch signal Door lock output factor | CAN |
| Main Body ECU | Front Power Seat Switch RH (Position Control ECU) | Engine switch signal Front passenger door courtesy light switch signal Parking brake switch signal | CAN |
| Certification ECU | Front Power Seat Switch LH (Position Control ECU) | Smart memory call replay request | CAN |
| Multiplex Tilt and Telescopic ECU | Front Power Seat Switch LH (Position Control ECU) | Tilt and Telescopic execution signal Tilt and Telescopic completion signal | CAN |
| Front Power Seat Switch LH (Position Control ECU) | Multiplex Tilt and Telescopic ECU | Memory command of Memory 1 for driver's seat Memory command of Memory 2 for driver's seat Play command of Memory 1 for driver's seat Play command of Memory 2 for driver's seat Start signal to play tilt and telescopic steering Stop signal to play tilt and telescopic steering | CAN |
| Front Power Seat Switch LH (Position Control ECU) | Outer Mirror Control ECU | Memory command of Memory 1 for driver's seat Memory command of Memory 2 for driver's seat Play command of Memory 1 for driver's seat Play command of Memory 2 for driver's seat | CAN |
| Combination meter ECU | Front Power Seat Switch LH (Position Control ECU) | Vehicle speed signal (meter to other) | CAN |
| Combination meter ECU | Front Power Seat Switch RH (Position Control ECU) | Vehicle speed signal (meter to other) | CAN |
COMMUNICATION CHART
Note. Some systems need to be initialized after reconnecting the negative (-) battery terminal (See INITIALIZATION ).
Scheme 179
Scheme 180
Scheme 181
Scheme 182
Scheme 183
Scheme 184
- CHECK POWER SEAT FUNCTION Check the basic functions. Operate the power seat switches and check to make sure each seat function works: Sliding Front vertical Lifter Reclining Lumbar support
Note. Some systems need to be initialized after reconnecting the negative (-) battery terminal (See INITIALIZATION ).
Scheme 185
Scheme 186
Note. Some systems need to be initialized after reconnecting the negative (-) battery terminal (See INITIALIZATION ).
