CAN Communication: Overview Lexus ES XV40

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. STEERING SYSTEM HANDLING PRECAUTIONS Care must be taken when replacing parts. Incorrect replacement could affect the performance of the steering system and result in hazardous driving.
2. SRS AIRBAG SYSTEM HANDLING PRECAUTIONS This vehicle is equipped with an SRS (Supplemental Restraint System) which includes components such as the driver airbag and front passenger airbag. Failure to carry out service operations in the correct sequence could cause unexpected SRS deployment during servicing and may lead to a serious accident. Before servicing (including removal or installation of parts, inspection or replacement), be sure to read the precautionary notice for the Supplemental Restraint System (See «AIRBAG SYSTEM»(/lexus/es/xv40-2006-2009/remont/airbag/#supplemental-restraint-system) ).
3. BUS WIRE REPAIR After repairing the bus wire with solder, wrap the repaired part with electrical tape. NOTE: The CANL bus wire and CANH bus wire must be installed together all the times. When installing, make sure to twist them. CAN bus wires are likely to be influenced by electrical noise if they are not twisted. The difference in length between the CANL bus wire and CANH bus wire should be 100 mm (3.937 in.) or less. Leave approximately 80 mm (3.150 in.) loose in the twisted wires around the connector. Do not use bypass wiring between the connectors. NOTE: The ability of the twisted bus wires to resist interference will be lost if bypass wiring is used.
4. CONNECTOR HANDLING When checking resistance with a tester, insert the tester probes from the backside (harness side) of the connector. Use a service wire to check the connector if it is impossible to check continuity from the rear of the connector.
5. PRECAUTION FOR DISCONNECTING THE BATTERY CABLE NOTE: Some systems need to be initialized after reconnecting the negative (-) battery terminal (See «INITIALIZATION»(ref-283083-S29543038892008041700000) ).

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

HINT

1. The skid control ECU detects and stores steering angle sensor and yaw rate sensor DTCs and performs DTC communication by receiving information from the steering angle sensor and yaw rate sensor.
2. The ECM uses the CAN communication system to perform DTC communication instead of the conventional line (SIL).

SYSTEM DESCRIPTION

1. BRIEF DESCRIPTION The CAN (Control Area Network) is a serial data communication system for real time application. It is a vehicle multiplex communication system which has a high communication speed and the ability to detect malfunctions. Two different types of CAN buses are used. The CAN buses are classified into two types based on typical communication speed. The HS-CAN bus is a high speed communication bus that is used for powertrain, chassis, and some body electrical communication. The HS-CAN bus is referred to as "CAN No. 1 bus" and "CAN No. 2 bus". It operates at speeds of approximately 500 kbps. Terminating resistors for the CAN No. 1 bus are located in the combination meter and ECM. Terminating resistors for the CAN No. 2 bus are located in the gateway ECU and the CAN No. 4 J/C. The resistance of the CAN No. 2 bus cannot be measured from the DLC3 connector. The MS-CAN bus is a medium speed communication bus that is used for body electrical communication. The MS-CAN bus is referred to as "MS bus" and it operates at speeds of approximately 250 kbps. Terminating resistors for the MS-CAN bus are located in the main body ECU and the certification ECU. The resistance of the MS CAN bus cannot be measured from the DLC3 connector. Communication between these networks is handled via the main body ECU (for the CAN MS bus) or the gateway ECU (for the CAN No. 2 bus), which acts as a gateway. By pairing the CANH and CANL bus wires, the CAN performs communication based on differential voltage. Many ECUs (sensors) installed on the vehicle operate by sharing information and communicating with each other. The CAN has two resistors of 120 ohms which are necessary to communicate with the main bus wire.
2. DEFINITION OF TERMS Main bus wire The main bus wire is a wire harness between the two terminating resistors on the bus (communication wire). This is the main bus in the CAN communication system. Branch wire The branch wire is a wire harness which diverges from the main bus wire to an ECU or sensor. Terminating resistors Two resistors of 120 ohms are installed in parallel across the ends of the CAN main bus wire. They are called terminating resistors. These resistors allow the changes of the voltage differential between the CAN bus wires to be accurately judged. To allow proper function of CAN communication, it is necessary to have both terminating resistors installed. Since the two resistors are installed in parallel, a measurement of resistance between the two CAN bus wires should produce a reading of approximately 60 ohms.
3. ECUS OR SENSORS WHICH COMMUNICATE THROUGH CAN COMMUNICATION SYSTEM Skid control ECU Yaw rate sensor Steering angle sensor Main body ECU Multi-display (*1) Center airbag sensor ECM Gateway ECU (*7) Certification ECU Outer mirror control ECU Active control engine mount ECU Air conditioning amplifier Combination meter Clearance warning ECU (*2) Seat position control ECU (Front LH seat) (*3) Seat position control ECU (Front RH seat) (*3) AFS ECU (*4) Multiplex tilt and telescopic ECU Seat belt control ECU (*5) Distance control ECU (*6) HINT: (*1): with Navigation system (*2): with Intuitive parking assist system (*3): with Seat position memory system (*4): with AFS (Adaptive Front-lighting System) (*5): with Pre-collision system (*6): with Dynamic radar cruise control system (*7): with AFS, Dynamic radar cruise control system or Pre-collision system
4. DIAGNOSTIC CODE FOR CAN COMMUNICATION SYSTEM DTCs for the CAN communication system are as follows: U0073, U0100, U0122, U0123, U0124, U0126, U0129,-U1101, U0151, B2427, B2621, U1002, U0182, U1102, U1100, B1207, B1297, B1276, B1272, B1289, B1213, and B2326.
5. TROUBLESHOOTING REMARKS DTCs for the CAN communication system can be checked using the intelligent tester via the CAN VIM. The DLC3 is connected to the CAN communication system, but no DTCs exist regarding problems in the DLC3 or the DLC3 branch wires. If there is trouble in the DLC3 or the DLC3 branch wires, ECUs on the CAN network cannot output codes to the intelligent tester via the CAN VIM. Trouble in the CAN buses (communication wires) can be checked by measuring the resistance between terminals of the DLC3. However, an open circuit in a branch wire other than the DLC3 branch wires cannot be checked from the DLC3. NOTE: Do not insert the tester probes directly into the DLC3. Be sure to use service wires.
6. HOW TO DISTINGUISH THE CAN J/C CONNECTOR In the CAN communication system, the shape of all connectors connected to the CAN J/C is the same. The connectors connected to the CAN J/C can be distinguished by the colors of the bus wire and the connecting side of the junction connector. HINT: See " «TERMINALS OF ECU»(ref-283107-S31400636542008041700000) " for bus wire color or the type of connecting surface.

DESCRIPTION

The main body ECU will store this DTC when no signals can be received from the certification ECU while the CAN MS main bus is normal.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 11

The main body ECU will store this DTC when no signals can be received from the tilt and telescopic ECU while the CAN MS main bus is normal.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 12

The main body ECU will store this DTC when no signals can be received from the seat position control ECU (front LH side) while the CAN MS main bus is normal.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 13

The main body ECU will store this DTC when no signals can be received from the outer mirror control ECU while the CAN MS main bus is normal.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 14

The main body ECU will store this DTC when no signals can be received from the seat position control ECU (front RH side) while the CAN MS main bus is normal.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 15

The main body ECU will store this DTC when no signals can be received from the clearance warning ECU while the CAN MS main bus is normal.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 16

1. The main body ECU will store this DTC when no signals can be received from the ECUs that have been memorized as those that are connected to the CAN MS bus.
2. When the main body ECU receives response signals from the ECUs connected to the CAN MS bus, the main body ECU recognizes and memorizes that the ECUs are connected to the CAN MS bus. Based on this memorized data, the main body ECU monitors for malfunctions in the ECUs connected to the CAN MS bus when communicating with those ECUs. If the main body ECU cannot receive response signals from the ECUs that have been memorized as those connected to the CAN MS bus, the main body ECU determines that a malfunction exists.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 17

The gateway ECU will store this DTC when no signals can be received from the AFS ECU while the CAN No. 2 main bus is normal.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 18

1. The gateway ECU will store this DTC when no signals can be received from the ECUs that have been memorized as those that are connected to the CAN No. 2 bus.
2. When the gateway ECU receives response signals from the ECUs connected to the CAN No. 2 bus, the gateway ECU recognizes and memorizes that the ECUs are connected to the CAN No. 2 bus. Based on this memorized data, the gateway ECU monitors for malfunctions in the ECUs connected to the CAN No. 2 bus when communicating with those ECUs. If the gateway ECU cannot receive response signals from the ECUs that have been memorized as those connected to the CAN No. 2 bus, the gateway ECU determines that a malfunction exists.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 19

The gateway ECU will store this DTC when no signals can be received from the seat belt control ECU while the CAN No. 2 main bus is normal.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 20

The gateway ECU will store this DTC when no signals can be received from the distance control ECU while the CAN No. 2 main bus is normal.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 21

PROBLEM SYMPTOMS CHART

HINT

"ABS/VSC/TRAC" refers to the circuit that includes the skid control ECU.

Scheme 22

PROBLEM SYMPTOMS CHART

HINT

"A/C" refers to the circuit that includes the air conditioning amplifier.

Scheme 23

PROBLEM SYMPTOMS CHART

HINT

"GATEWAY" refers to the circuit that includes the gateway ECU.

Scheme 24

PROBLEM SYMPTOMS CHART

HINT

"STEERING SENSOR" refers to the circuit that includes the steering angle sensor.

Scheme 25

PROBLEM SYMPTOMS CHART

HINT

"YAW/DECELERAT" refers to the circuit that includes the yaw rate sensor.

Scheme 26

PROBLEM SYMPTOMS CHART

HINT

"ENGINE" and "ECT" refer to the circuit that includes the ECM.

Scheme 27

PROBLEM SYMPTOMS CHART

HINT

"MAIN BODY" refers to the circuit that includes the main body ECU.

Scheme 28

PROBLEM SYMPTOMS CHART

HINT

"METER" refers to the circuit that includes the combination meter.

Scheme 29

PROBLEM SYMPTOMS CHART

HINT

"SRS AIRBAG" refers to the circuit that includes the center airbag sensor.

Scheme 30

PROBLEM SYMPTOMS CHART

HINT

"AVN" refers to the circuit that includes the multi-display.

Scheme 31

PROBLEM SYMPTOMS CHART

HINT

"E-ACM" refers to the circuit that includes the active control engine mount ECU.

Scheme 32

When all DTCs and sensors connected to the CAN communication system are not displayed on the intelligent tester's "BUS CHECK" screen via CAN VIM, first measure the resistance between the terminals of the DLC3 to specify the trouble area.

There may be an open circuit in the CAN No. 1 main bus wire and/or the DLC3 branch wire when the resistance between terminals 6 (CANH) and 14 (CANL) of the DLC3 is 69 ohms or more.

DIAGNOSTIC CHART

Scheme 33

The CAN bus wires are considered to be shorted when the resistance between terminals 6 (CANH) and 14 (CANL) of the DLC3 is below 54 ohms

DIAGNOSTIC CHART

Scheme 34

Scheme 35

A short to B+ is suspected in the CAN bus wire when the resistance between terminals 6 (CANH) and 16 (BAT), or terminals 14 (CANL) and 16 (BAT) of the DLC3 is below 6 kohms.

DIAGNOSTIC CHART

Scheme 36

Scheme 37

A short to GND is suspected in the CAN bus wire when the resistance between terminals 4 (CG) and 6 (CANH), or terminals 4 (CG) and 14 (CANL) of the DLC3 is below 200 ohms

DIAGNOSTIC CHART

If some ECUs and sensors are not displayed on the "BUS CHECK" screen of the intelligent tester and some ECUs and sensors repeatedly appear and disappear from the screen when the CAN main bus wires are normal (there is no open, short, short to B+, or short to GND in the main bus wires), there may be an open circuit in either of the CAN branch wires.

HINT

If some ECUs and sensors repeatedly appear and disappear from the "BUS CHECK" screen, communication between the normal ECUs (sensors) and intelligent tester may be affected by the incomplete signals that are output from the ECU that has an open circuit in either of its CAN branch wires. In this case, the CAN branch wires for the ECUs and sensors that repeatedly appear and disappear from the screen are normal and the ECU that is not displayed on the screen may be the main cause of the problem (this ECU may have an open circuit in either of its CAN branch wires).

DIAGNOSTIC CHART
