TROUBLE SHOOTING
Note. See STARTER - GENERAL TROUBLE SHOOTING article in GENERAL INFORMATION.
STARTER RELAY TEST
Remove starter relay. See COMPONENT LOCATIONS. Check for continuity between starter relay terminals No. 1 and 2. (Scheme 1) Continuity should exist. If continuity does not exist, replace relay. Check for continuity between starter relay terminals No. 3 and 5. Continuity should not exist. If continuity exists, replace relay. Apply battery voltage across starter relay terminals No. 1 and 2. Check for continuity between starter relay terminals No. 3 and 5. Continuity should exist. If continuity does not exist, replace relay.
Scheme 1
BENCH TESTING
| CAUTION | DO NOT operate starter for more than 3-5 seconds. |
ARMATURE TEST
- Using ohmmeter, check for continuity between all segments of commutator. If continuity does not exist, replace armature. Using ohmmeter, check for continuity between commutator and armature coil core. If continuity exists, replace armature.
- Inspect commutator for dirty or burnt surfaces. Repair as necessary using No. 400 sandpaper or a lathe. Place commutator on "V" blocks. Using a dial gauge, measure circle runout. See «STARTER SPECIFICATIONS»(ref-168554-S09523666032004111000000) . Repair as necessary using a lathe.
- Using a vernier caliper, measure commutator diameter. See «STARTER SPECIFICATIONS»(ref-168554-S09523666032004111000000) . If commutator diameter is less than minimum specification, replace armature.
- Ensure commutator mica undercut depth is clean and free of foreign materials. Smooth out edge. Measure commutator mica undercut depth. See «STARTER SPECIFICATIONS»(ref-168554-S09523666032004111000000) . If undercut depth is less than minimum specification, correct depth by using a hacksaw blade to remove mica from between segments.
