Disc Brakes: Specifications — Lexus ES XV30 (2001-2003)

Disc Brakes: Specifications Lexus ES XV30

DISC BRAKE SPECIFICATIONS

Application				In. (mm)
Brake Pad Thickness
ES 300
Front
Standard (Dual Piston)				.417 (10.6)
Standard (Single Piston)				.472 (12.0)
Minimum				.039 (1.00)
Rear
Standard				.394 (10.0)
Minimum				.039 (1.0)
GS 300, GS 430, IS 300 & SC 430
Front
Standard				.433 (11.0)
Minimum				.039 (1.0)
Rear
Standard				.413 (10.5)
Minimum				.039 (1.0)
LS 430
Front
Standard				.433 (11.0)
Minimum				.039 (1.0)
Rear
Standard				.394 (10.0)
Minimum				.039 (1.0)
LX 470
Front
Standard				.453 (11.5)
Minimum				.039 (1.0)
Rear
Standard				.472 (12.0)
Minimum				.039 (1.0)
RX 300
Front
Standard				.433 (11)
Minimum				.039 (1.0)
Rear
Standard				.394 (10.0)
Minimum				.039 (1.0)
Front Disc
ES 300 & RX 300
Standard Thickness				1.102 (28.0)
Minimum Thickness				1.024 (26.0)
Disc Runout (1)				.002 (.05)
GS 300, GS 430, IS 300 & SC 430
Standard Thickness				1.26 (32.0)
Minimum Thickness				1.181 (30.0)
Disc Runout (1)				.002 (.05)
LS 430
Standard Thickness				1.181 (30.0)
Minimum Thickness				1.102 (28.0)
Disc Runout (1)				.002 (.05)
LX 470
Standard Thickness				1.260 (32.0)
Minimum Thickness				1.181 (30.0)
Disc Runout (1)				.003 (.07)
Rear Disc
ES 300
Standard Thickness				.472 (12.0)
Minimum Thickness				.413 (10.5)
Disc Runout (1)				.0059 (.150)
GS 300, GS 430, IS 300 & SC 430
Standard Thickness				.472 (12)
Minimum Thickness				.413 (10.5)
Disc Runout (1)				.002 (.05)
LS 430
Standard Thickness				.63 (16.0)
Minimum Thickness				.571 (14.5)
Disc Runout (1)				.002 (.05)
LX 470
Standard Thickness				.709 (18.0)
Minimum Thickness				.611 (16.0)
Disc Runout (1)				.004 (0.1)
RX 300
Standard Thickness				.394 (10.0)
Minimum Thickness				.334 (8.5)
Disc Runout (1)				.0059 (.150)
(1) Measured .39" (10.0 mm) from outer edge of rotor.

(1)	Measured .39" (10.0 mm) from outer edge of rotor.

DISC BRAKE SPECIFICATIONS

Scheme 1: SPECIAL TOOLS
