SPECIFICATIONS
| WARNING | Vehicle is equipped with Supplemental Inflatable Restraint (SIR) system. When servicing vehicle, use care to avoid accidental air bag deployment. SIR system-related components are located in various locations throughout interior and exterior of vehicle, depending on application. Do not use electrical test equipment on or near these circuits. If necessary, deactivate SIR system before servicing components. See appropriate AIR BAG RESTRAINT SYSTEMS article in RESTRAINTS. |
| CAUTION | When battery is disconnected, radio will go into anti-theft protection mode. Obtain radio anti-theft protection code from owner prior to servicing vehicle. |
| Application | Specifications |
|---|
| Compressor Type | Nippondenso 10PA20 10-Cyl. |
| Compressor Belt Tension (1) |
| New | 139-191 lbs. (63-87 kg) |
| Used | 66-110 lbs. (20-50 kg) |
| Compressor Oil Capacity | (2) 4.8 ozs. |
| Refrigerant (R-134a) Capacity | 28.2-31.7 ozs. |
| System Operating Pressures (3) |
| High Side | 199-228 psi (14-16 kg/cm 2 ) |
| Low Side | 21-36 psi (1.5-2.5 kg/cm 2 ) |
| (1) Measure belt tension with tension gauge. (2) Use Denso/ND-OIL 8 refrigerant oil. (3) At 86-95°F (30-35°C) and engine speed at 1500 RPM. |
| (1) | Measure belt tension with tension gauge. |
| (2) | Use Denso/ND-OIL 8 refrigerant oil. |
| (3) | At 86-95°F (30-35°C) and engine speed at 1500 RPM. |
A/C SYSTEM SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor Bolts | 18 (25) |
| INCH Lbs. (N.m) |
| Compressor Hoses | 88 (10) |
| Condenser Lines | 88 (10) |
| Receiver-Drier Lines | 52 (6) |
Automatic A/C-Heater System Wiring Diagram (1 Of 2). Scheme 1
Scheme 1: Automatic A/C-Heater System Wiring Diagram (1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2 Of 2). Scheme 2
