Engine Controls - Specifications Lexus ES XV10

Specifications 3 illustrations ~281 words

INTRODUCTION

Use this article to quickly find specifications related to servicing and on-vehicle adjustments. This is a quick-reference article to use when you are familiar with an adjustment procedure and only need a specification.

FLUID CAPACITIES - ES300

ApplicationQuantity
Automatic Transaxle (Dexron-II)
Dry Fill6.8 Qts. (6.5L)
Drain & Refill3.3 Qts. (3.1L)
Automatic Transaxle Differential (Dexron-II)0.8 Qts. (0.8L)
Cooling System (Includes Heater)9.0 Qts. (8.5L)
Crankcase (Includes Filter)4.5 Qts. (4.3L)
Manual Transaxle (SAE 75W-90/API GL-5)4.4 Qts. (4.2L)

FLUID CAPACITIES - ES300

FLUID CAPACITIES - LS400

ApplicationQuantity
Automatic Transmission (T-II ATF)
Dry Fill8.7 Qts. (8.2L)
Drain & Refill2.1 Qts. (2.0L)
Cooling System (Includes Heater)11.2 Qts. (10.6L)
Crankcase (Includes Filter)5.6 Qts. (5.3L)
Differential (SAE 80W-90/API GL-5)1.4 Qts. (1.3L)

FLUID CAPACITIES - LS400

FLUID CAPACITIES - SC300

ApplicationQuantity
Automatic Transmission (T-II ATF)
Dry Fill6.8 Qts. (7.2L)
Drain & Refill1.7 Qts. (1.6L)
Cooling System (Includes Heater)8.9 Qts. (8.4L)
Crankcase (Includes Filter)5.1 Qts. (4.8L)
Differential (SAE 80W-90/API GL-5)1.4 Qts. (1.3L)

FLUID CAPACITIES - SC300

FLUID CAPACITIES - SC400

ApplicationQuantity
Automatic Transmission (T-II ATF)
Dry Fill8.7 Qts. (8.2L)
Drain & Refill2.1 Qts. (2.0L)
Cooling System (Includes Heater)11.4 Qts. (10.8L)
Crankcase (Includes Filter)5.1 Qts. (4.8L)
Differential (SAE 80W-90/API GL-5)1.4 Qts. (1.3L)

FLUID CAPACITIES - SC400

Replacement Intervals

ComponentMiles
Accessory Drive Belts60,000
Air Filter30,000
Coolant45,000
Fuel Filter30,000
Oil & Filter(1) 7500
Spark Plugs60,000
(1) Every 3750 miles for severe service.
(1)Every 3750 miles for severe service.

REPLACEMENT INTERVALS

Drive Belt Adjustment - ES300

Application(1) Lbs. (kg)
Alternator
New180-185 (81-83)
Used (2)95-135 (43-61)
Power Steering
New100-150 (45-68)
Used (2)60-100 (27-45)
(1) Using Borroughs Tension Gauge. (2) For belt used on running engine for 5 minutes or more.
(1)Using Borroughs Tension Gauge.
(2)For belt used on running engine for 5 minutes or more.

BELT ADJUSTMENT - ES300

Drive Belt Adjustment - LS400, SC300 & SC400

ApplicationSpecification
Serpentine Belt(1)
(1) Models are equipped with automatic tensioner.
(1)Models are equipped with automatic tensioner.

BELT ADJUSTMENT - LS400, SC300 & SC400

ENGINE COMPRESSION

To check engine compression, bring engine to normal operating temperature. Disconnect cold start injector (if applicable). Disconnect distributor electrical connector(s). Remove all spark plugs. Remove air intake hose from throttle body, and fully open throttle. Measure at 250 RPM as quickly as possible.

ApplicationSpecification
Compression Ratio
ES3009.5:1
LS400 & SC40010.0:1
SC30010.2:1
Compression Pressure178 psi (12.5 kg/cm 2 )
Minimum Compression Pressure142 psi (10.0 kg/cm 2 )
Maximum Variation Between Cylinders14 psi (1.0 kg/cm 2 )

COMPRESSION SPECIFICATIONS

VALVE CLEARANCE

Application(1) In. (mm)
ES300
Intake.005-.009 (.13-.23)
Exhaust.011-.015 (.28-.38)
LS400, SC300 & SC400
Intake.006-.010 (.15-.26)
Exhaust.010-.014 (.26-.36)
(1) Adjust valves with engine cold.
(1)Adjust valves with engine cold.

VALVE CLEARANCE SPECIFICATIONS

IGNITION COIL

ApplicationPrimarySecondary
ES300.30-.609000-15,000
SC300.20-.306000-11,000
LS400 & SC400.40-.5010,200-13,800

IGNITION COIL RESISTANCE - Ohms @ 68°F (20°C)

DISTRIBUTOR SENSORS

ApplicationIn. (mm)
ES300.008-.020 (.20-.50)
SC300.008-.016 (.20-.40)
(1) Not adjustable. If gap is incorrect, replace distributor housing.
(1)Not adjustable. If gap is incorrect, replace distributor housing.

DISTRIBUTOR PICK-UP COIL AIR GAP - ES300 & SC300 (1)

ApplicationOhms
ES300 & SC300
Pick-Up Coils
Between Terminals G1 & "G"125-190
Between Terminals G2 & "G"125-190
Between Terminals NE & "G"155-240
SC400
Cam Sensor835-1350
Engine Speed Sensor835-1350
LS400
No. 1 & 2 Cam Sensors950-1250
Engine Speed Sensor950-1250

DISTRIBUTOR SENSOR RESISTANCE

HIGH TENSION WIRE RESISTANCE

ApplicationOhms
All Models25,000 Maximum

HIGH TENSION WIRE RESISTANCE

SPARK PLUGS

ApplicationNGK No.
ES300BCPR6EP-11
LS400 & SC400BKR6EP-11
SC300BKR5EP-11

SPARK PLUG TYPE

ApplicationGap In. (mm)Torque Ft. Lbs. (N.m)
Maximum Wear (1).051 (1.30)13 (17)
New Plug.043 (1.10)13 (17)
(1) Replace spark plug when worn past this dimension.
(1)Replace spark plug when worn past this dimension.

SPARK PLUG SPECIFICATIONS

FIRING ORDER & TIMING MARKS

Note. For firing order and timing marks (Scheme 1)to 3.

Firing Order & Timing Marks (ES300). Scheme 1

Scheme 1: Firing Order & Timing Marks (ES300)
Scheme 1: Firing Order & Timing Marks (ES300)

Firing Order & Timing Marks (SC300). Scheme 2

Scheme 2: Firing Order & Timing Marks (SC300)
Scheme 2: Firing Order & Timing Marks (SC300)

Firing Order & Timing Marks (LS400 & SC400). Scheme 3

Scheme 3: Firing Order & Timing Marks (LS400 & SC400)
Scheme 3: Firing Order & Timing Marks (LS400 & SC400)

IGNITION TIMING

ApplicationAuto. Trans.Man. Trans.
ES300 & SC300(1) 10 @ 650-750(1) 10 @ 650-750
LS400 & SC400(1) 10 @ 600-700N/A
(1) Jumper wire installed between TE1 and E1 timing check terminals.
(1)Jumper wire installed between TE1 and E1 timing check terminals.

IGNITION TIMING (Degrees BTDC @ RPM)

FUEL PUMP

Note. Fuel pump performance measures fuel pressure and volume availability, not regulated fuel pressure.

ApplicationPressure psi (kg/cm 2 )Min. Vol. In 30 Sec. Pts. (L)
All Models38-44 (2.7-3.1)(1)
(1) Information is not available from manufacturer.
(1)Information is not available from manufacturer.

FUEL PUMP PERFORMANCE

ApplicationAt Idle W/Vacuum psi (kg/cm 2 )At Idle W/O Vacuum psi (kg/cm 2 )
ES30033-37 (2.3-2.6)38-44 (2.7-3.1)
All Others28-34 (2.0-2.4)38-44 (2.7-3.1)

REGULATED FUEL PRESSURE

INJECTOR RESISTANCE

ApplicationOhms
Cold Start Injector2.0-4.0
Fuel Injector13.4-14.2
(1) Ohms @ 68°F (20°C).
(1)Ohms @ 68°F (20°C).

INJECTOR RESISTANCE SPECIFICATIONS (1)

DASHPOT SPECIFICATION

Application(1) RPM
ES300(2) 2000
LS4001500
SC300
A/T1700
M/T2600
SC400700
(1) With dashpot cap and filter removed and dashpot vacuum port plugged (upper hole behind dashpot filter) on all except SC300. On SC300 specification is with dashpot rod pushed all the way with screwdriver. (2) With cooling fan not running.
(1)With dashpot cap and filter removed and dashpot vacuum port plugged (upper hole behind dashpot filter) on all except SC300. On SC300 specification is with dashpot rod pushed all the way with screwdriver.
(2)With cooling fan not running.

DASHPOT SET SPEED SPECIFICATIONS

THROTTLE POSITION SENSOR

Clearance Between Lever & Stop ScrewOhmmeter Reading at Terminals IDL & E2
ES300
.014" (.35 mm)Continuity
.028" (.70 mm)No Continuity
LS400
.016" (.40 mm)Continuity
.034" (.85 mm)No Continuity
SC300
.014" (.35 mm)Continuity
.020" (.50 mm)No Continuity
SC400
.016" (.40 mm)Continuity
.026" (.65 mm)No Continuity

THROTTLE POSITION SENSOR ADJUSTMENT
