Scheme 2
ENGINE TEMPERATURE GAUGE
Indicates engine coolant temperature. Needle should remain below Red zone while vehicle is driven. If needle rises into Red zone or higher and remains there, stop vehicle immediately and let engine cool. Check coolant level.
| CAUTION | DO NOT continue to operate vehicle when engine is overheating. Severe damage can result. |
OIL PRESSURE WARNING LIGHT
If this light flickers or comes on while driving, oil pressure is probably low. Stop vehicle immediately, and check oil level. If oil level is okay and light remains on, service system as soon as possible.
CHARGING SYSTEM WARNING LIGHT
Light indicates battery is not charging properly. Service system as soon as possible.
BRAKE SYSTEM WARNING LIGHT
This light indicates either parking brake is on or brake fluid level is low.
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG WARNING LIGHT
This light should come on for about 6 seconds after ignition switch is turned to ON position. If light does not come on, stays on after 6 seconds or comes on while vehicle is driven, service system as soon as possible.
ANTI-LOCK BRAKE SYSTEM (ABS) WARNING LIGHT
Light indicates a problem with anti-lock brake system. Brakes will still operate normally, but without anti-lock feature. If light comes on and remains on, service system as soon as possible.
COOLANT LEVEL WARNING LIGHT
This light indicates engine coolant level is low. Add coolant as soon as possible.
| CAUTION | Continued operation with a low coolant level may result in overheating of engine. |
TRACTION CONTROL INDICATOR (IF EQUIPPED)
Light should come on when ignition switch is turned to ON position and should go out after about 3 seconds. If traction control system comes on while vehicle is driven, light will blink. If light comes on and remains on, service system as soon as possible.
TRACTION CONTROL OFF INDICATOR (IF EQUIPPED)
Light should comes on when ignition is turned to ON position and go out after about three seconds. This means system is operating properly. If light remains on when switch is turned to ON position, a malfunction exists in anti-lock brake system or engine system. Service vehicle as soon as possible.
ENGINE SYSTEM WARNING LIGHT
If this light comes on while driving, it indicates a problem with engine electrical system. On California vehicles, it also indicates a malfunction in emission control system and may be used to access fault codes. Have system serviced as soon as possible.
LOW ENGINE OIL LEVEL WARNING LIGHT
If this light comes on while driving, the oil level is low. Add oil as soon as possible.
