Power Mirror Control (W/memory) (Diagnostics & Symptom Tests): Diagnosis Lexus CT I

HOW TO PROCEED WITH TROUBLESHOOTING

HINT

1. Use the following procedure to troubleshoot the power mirror control system.
2. *: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS HINT: In troubleshooting, confirm that the problem symptoms have been accurately identified. Preconceptions should be discarded in order to make an accurate judgment. To clearly understand what the problem symptoms are, it is extremely important to ask the customer about the problem and the conditions at the time the malfunction occurred. Gather as much information as possible for reference. Past problems that seem unrelated may also help in some cases. The following 5 items are important points in the problem analysis: What Vehicle model, system name When Date, time, occurrence frequency Where Road conditions Under what conditions? Running conditions, driving conditions, weather conditions How did it happen? Problem symptoms NEXT: Go to next step
3. INSPECT AUXILIARY BATTERY VOLTAGE Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the auxiliary battery before proceeding to the next step. NEXT: Go to next step
4. CHECK COMMUNICATION FUNCTION OF LIN COMMUNICATION SYSTEM* Use the Techstream to check if the LIN communication system is functioning normally. Result Result Proceed to LIN DTC is not output A LIN DTC is output B B --> Go to LIN COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-568820-S18233360872013072300000) A: Go to next step
5. CHECK COMMUNICATION FUNCTION OF CAN COMMUNICATION SYSTEM* Use the Techstream to check if the CAN communication system is functioning normally. Result Result Proceed to CAN DTC is not output A CAN DTC is output B B --> Go to CAN COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-568746-S16364510032013072300000) A: Go to next step
6. PROBLEM SYMPTOMS TABLE Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE»(ref-568843-S14729116332013072300000) . Result Result Proceed to Fault is not listed in Problem Symptoms Table A Fault is listed in Problem Symptoms Table B B --> Go to step 8 A: Go to next step
7. OVERALL ANALYSIS AND TROUBLESHOOTING* Operation Check. Refer to «OPERATION CHECK»(ref-568843-S24716352082013072300000) Data List / Active Test. Refer to «DATA LIST / ACTIVE TEST»(ref-568843-S02705691702013072300000) Terminals of ECU. Refer to «TERMINALS OF ECU»(ref-568843-S38362539422013072300000) NEXT: Go to next step
8. REPAIR OR REPLACE NEXT: Go to next step
9. CONFIRMATION TEST NEXT --> END

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

1. CHECK REMOTE CONTROL MIRROR FUNCTION Turn the power switch on (IG). With the mirror select switch set to L, check that the mirror surface moves up, down, left and right normally. With the mirror select switch set to R, check that the mirror surface moves up, down, left and right normally.
2. CHECK MEMORY AND REACTIVATION FUNCTION HINT: The SET, M1, M2 and M3 seat memory switches are shown in the illustration. Turn the power switch on (IG) and push the P position switch (transmission shift main switch). TEXT IN ILLUSTRATION *1 SET Switch *2 M1 Switch *3 M2 Switch *4 M3 Switch Check the M1 switch. Using the mirror adjust switch, turn the mirror surface to the full left position. TEXT IN ILLUSTRATION *a Turn to Left Fully Check that the buzzer sounds for 0.5 seconds and the seat position is memorized when the M1 switch is pressed within 3 seconds of the SET switch is being pressed. NOTE: The mirror surface position will be stored when the M1 switch is pressed after first pressing and holding the SET switch. The mirror surface position will not be stored when the SET switch and M1 switch are pressed simultaneously. The mirror surface position will not be stored when 2 or more of the memory switches are pressed simultaneously (for example, M1 and M2) after first pressing the SET switch. Using the outer mirror switch assembly, turn the mirror surface to the full right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded full left position. Check the M2 switch. Using the mirror adjust switch assembly, turn the mirror surface to the full right position. TEXT IN ILLUSTRATION *a Turn to Right Fully Check that the buzzer sounds for 0.5 seconds and the seat position is memorized when the M2 switch is pressed within 3 seconds of the SET switch is being pressed. NOTE: The mirror surface position will be stored when the M2 switch is pressed after first pressing and holding the SET switch. The mirror surface position will not be stored when the SET switch and M2 switch are pressed simultaneously. The mirror surface position will not be stored when 2 or more of the memory switches are pressed simultaneously (for example, M1 and M2) after first pressing the SET switch. Using the outer mirror switch assembly, turn the mirror surface to the full left position. Press the M2 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded full right position. Check the M3 switch. Using the outer mirror switch assembly, turn the mirror surface to the full upward position. TEXT IN ILLUSTRATION *a Turn Upward Fully Check that the buzzer sounds for 0.5 seconds and the seat position is memorized when the M3 switch is pressed within 3 seconds after the SET switch is being pressed. NOTE: The mirror surface position will be stored when the M3 switch is pressed after first pressing and holding the SET switch. The mirror surface position will not be stored when the SET switch and M3 switch are pressed simultaneously. The mirror surface position will not be stored when 2 or more of the memory switches are pressed simultaneously (for example, M1 and M2) after first pressing the SET switch. Using the outer mirror switch assembly, turn the mirror surface to the full downward position. Press the M3 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded full upward position.
3. CHECK POWER RETRACTABLE MIRROR FUNCTION Turn the power switch on (IG). At each outer rear view mirror assembly position, check the retractable mirror operation when operating the retractable outer mirror switch. Move the mirrors to the driving position. Turn the retractable outer mirror switch to the retract position. Check that the right and left outer rear view mirror assemblies move from the driving position to the retracted position. Move the mirrors to the driving position. Move one of the outer rear view mirror assemblies to the forward position by hand. Turn the retractable outer mirror switch to the retract position. Check that the outer rear view mirror assembly in the forward position moves to the retracted position, and check that the other mirror moves to the retracted position. Move the outer rear view mirror assemblies to the driving position. Move one of the outer rear view mirror assemblies to the retracted position by hand. Turn the retractable outer mirror switch to the retract position. Check that the outer rear view mirror assembly in the driving position moves to the retracted position. Move the mirrors to the retracted position. Turn the retractable outer mirror switch to the driving position. Check that the right and left mirrors move from the retracted position to the driving position. Move the mirrors to the retracted position. Move one of the outer rear view mirror assemblies to the driving position by hand. Turn the retractable outer mirror switch to the driving position. Check that the retracted outer rear view mirror assembly moves to the driving position. Check the operation of the outer rear view mirror assemblies according to retractable outer mirror switch operations and power switch condition. When the outer rear view mirror assembly is operating, turn the power switch off and check that the mirror operation stops immediately. This time, turn the power switch on (ACC) and press the retractable outer mirror switch. Check that the outer rear view mirror assembly operates in the opposite direction. Check the operation of the outer rear view mirror assembly when it is blocked by an obstacle. When the outer rear view mirror assembly is moving to the retracted or driving position, block the outer rear view mirror assembly by hand. Check that the mirror stops moving. With the outer rear view mirror assembly stopped partway, push the retractable outer mirror switch. Check that the outer rear view mirror assembly moves in the opposite direction.
4. CHECK AUTO ELECTRIC RETRACT FUNCTION With the power switch off and the retractable outer mirror switch in the AUTO position, when the doors are unlocked through the entry, wireless or key-linked function, check that the outer rear view mirror assemblies move from the retracted position to the driving position, and stop in the driving position. With the power switch off, and the retractable outer mirror switch in the AUTO position, when the doors are locked through the entry, wireless or key-linked function, check that the outer rear view mirror assemblies move from the driving position to the retracted position, and stop in the retracted position. When the power switch is on (ACC) and then turned off while the retractable outer mirror switch is in AUTO position, check that both outer rear view mirror assemblies automatically move from the driving position to the retracted position. When the power switch is off and then turned on (ACC) while the retractable outer mirror switch is in the AUTO position, check that both outer rear view mirror assemblies automatically move from the retracted position to the driving position.
5. CHECK REVERSE SHIFT-LINKED OPERATION OF MIRRORS Turn the power switch on (IG). Set the mirror select switch to L or R. TEXT IN ILLUSTRATION *1 Mirror Select Switch *a Downward Check that the mirror surface turns downward when the shift lever is moved to R. Check that the mirror surface position returns to the original position when one of the following conditions is met: Shift lever is moved to any position other than R. Mirror select switch is in the neutral position (off). Power switch is turned off.
6. CHECK MEMORY CALL FUNCTION Check automatic memory call function With a transmitter key recognition code registered: Perform a wireless door unlock operation and check that opening the driver side door causes the following: The buzzer sounds for 0.1 seconds. The front seat and outer mirror surface position automatically move to the stored positions. HINT: The registered transmitter key recognition code is recalled automatically. If the automatic memory call function is not operated, the buzzer will not sound. With the power switch off and the driver side door closed, press and hold the M1, M2 or M3 switch while carrying the transmitter key. The main body ECU (multiplex network body ECU) will enter transmitter key recognition code registration mode to allow a key to be linked to mirror surface memory position. HINT: If the memory switch is released before entering registration mode, the memory switch will not enter registration mode. When the manual door lock switch is pressed, check that the buzzer of the position control ECU and switch assembly sounds once (0.5 seconds). With the power switch off and the driver side door closed, press and hold the SET switch while carrying the transmitter key. The main body ECU (multiplex network body ECU) will enter transmitter key recognition code deletion mode. HINT: If the memory switch is released before entering deletion mode, the memory switch will not enter deletion mode. When the manual door lock switch is pressed, check that the buzzer of the position control ECU and switch assembly sounds twice (0.1 seconds each time).
7. EMERGENCY STOP FUNCTION While a memory call function is operating, check that any one of the following actions will stop the memory call operation: 1) pressing the SET, M1, M2 or M3 switch, 2) moving the shift lever to R, 3) moving the mirror surface manually, or 4) moving the mirror surface to the uppermost, lowermost, leftmost or rightmost position.

PROBLEM SYMPTOMS TABLE

HINT

1. Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. Inspect the fuses and relays related to this system before inspecting the suspected areas below.

POWER MIRROR CONTROL SYSTEM

*: w/ Retract mirror

Scheme 91

Scheme 92

1. CHECK OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER SIDE) Disconnect the K7 connector. Measure the voltage according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. STANDARD VOLTAGE Tester Connection Wiring Color Terminal Description Condition Specified Condition K7-14 (BDR) - Body ground L - Body ground +B power supply Power Switch off 11 to 14 V K7-6 (CPUB) - Body ground LG - Body ground +B power supply Power Switch off 11 to 14 V K7-5 (SIG) - Body ground Y - Body ground Ignition power supply Power switch off --> on (IG) 0 V --> 11 to 14 V If the result is not as specified, there may be a malfunction on the wire harness side. Measure the resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. STANDARD RESISTANCE Tester Connection Wiring Color Terminal Description Condition Specified Condition K7-7 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the K7 connector. Measure the voltage according to the value(s) in the table below. STANDARD VOLTAGE Tester Connection Wiring Color Terminal Description Condition Specified Condition z6-1 (LMVR) - z6-9 (LMHR) W - R Vertical mirror motor drive voltage LH mirror surface moving upward --> stopped 11 to 14 V --> 0 V z6-10 (LM+R) - z6-1 (LMVR) B - W Vertical mirror motor drive voltage LH mirror surface moving downward --> stopped 11 to 14 V --> 0 V z6-10 (LM+R) - z6-9 (LMHR) B - R Horizontal mirror motor drive voltage LH mirror surface moving right --> stopped 11 to 14 V --> 0 V z6-9 (LMHR) - z6-1 (LMVR) R - W Horizontal mirror motor drive voltage LH mirror surface moving left --> stopped 11 to 14 V --> 0 V z6-4 (HTR+) - z6-12 (HTR-) BR-W - BR Mirror heater relay drive voltage Rear defogger switch on 11 to 14 V z6-5 (LVC) - z6-14 (LE1) SB - GR Mirror position sensor power supply Power switch on (IG) 4.55 to 5.45 V z6-6 (VSSR) - z6-14 (LE1) V - GR Mirror position sensor signal Power switch on (IG) 0.96 to 4.04 V z6-13 (HSSR) - z6-14 (LE1) LG - GR Mirror position sensor signal Power switch on (IG) 0.96 to 4.04 V
2. CHECK OUTER MIRROR CONTROL ECU ASSEMBLY (PASSENGER SIDE) Disconnect the J8 connector. Measure the voltage according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. STANDARD VOLTAGE Tester Connection Wiring Color Terminal Description Condition Specified Condition J8-6 (CPUB) - Body ground LG - Body ground +B power supply Power switch off 11 to 14 V J8-14 (BDR) - Body ground L - Body ground +B power supply Power switch off 11 to 14 V J8-5 (SIG) - Body ground Y - Body ground Ignition power supply Power switch off --> on (IG) 0 V --> 11 to 14 V If the result is not as specified, there may be a malfunction on the wire harness side. Measure the resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. STANDARD RESISTANCE Tester Connection Wiring Color Terminal Description Condition Specified Condition J8-7 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the J8 connector. Measure the voltage according to the value(s) in the table below. STANDARD VOLTAGE Tester Connection Wiring Color Terminal Description Condition Specified Condition z7-1 (RMVR) - z7-9 (RMHR) W - R Vertical mirror motor drive voltage RH mirror surface moving upward --> stopped 11 to 14 V --> 0 V z7-10 (RM+R) - z7-1 (RMVR) B - W Vertical mirror motor drive voltage RH mirror surface moving downward --> stopped 11 to 14 V --> 0 V z7-10 (RM+R) - z7-9 (RMHR) B - R Horizontal mirror motor drive voltage RH mirror surface moving right --> stopped 11 to 14 V --> 0 V z7-9 (RMHR) - z7-1 (RMVR) R - W Horizontal mirror motor drive voltage RH mirror surface moving left --> stopped 11 to 14 V --> 0 V z7-4 (HTR+) - z7-12 (HTR-) BR-W - BR Mirror heater relay drive voltage Rear defogger switch on 11 to 14 V z7-5 (RVC) - z7-14 (RE1) SB - GR Mirror position sensor power supply Power switch on (IG) 4.55 to 5.45 V z7-6 (VSSR) - z7-14 (RE1) V - GR Mirror position sensor signal Power switch on (IG) 0.96 to 4.04 V z7-13 (HSSR) - z7-14 (RE1) LG - GR Mirror position sensor signal Power switch on (IG) 0.96 to 4.04 V

DIAGNOSIS SYSTEM

1. DESCRIPTION Data of the system can be read from the Data Link Connector 3 (DLC3) of the vehicle. Therefore, when the system seems to be malfunctioning, use the Techstream to check for a malfunction and repair it.
2. CHECK DLC3 Check the DLC3. Refer to «GENERAL INFORMATION»(ref-568589-S28103458762013072300000) .

DATA LIST / ACTIVE TEST

1. USING TECHSTREAM Connect the Techstream to the DLC3. Monitor the ECU data by following the prompts on the Techstream screen. HINT: The Techstream has a "Snapshot" function which records the monitored data. Refer to the Techstream operator's manual for further details.
2. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Mirror L or Mirror R / Data List. Read the Data List according to the display on the Techstream. MIRROR L / MIRROR R Tester Display Measurement Item/Range Normal Condition Diagnostic Note Seat Memory Switch1 Seat memory switch M1 signal / ON or OFF ON: Seat memory switch M1 on OFF: Seat memory switch M1 off - Seat Memory Switch2 Seat memory switch M2 signal / ON or OFF ON: Seat memory switch M2 on OFF: Seat memory switch M2 off - Seat Memory Switch3 Seat memory switch M3 signal / ON or OFF ON: Seat memory switch M3 on OFF: Seat memory switch M3 off - Seat Memory Set SW Seat memory switch SET signal / ON or OFF ON: Seat memory switch SET on OFF: Seat memory switch SET off - Mirror Memory No. 1 Mirror position memorized in memory switch M1 / OFF or ON ON: Memorized OFF: Not memorized - Mirror Memory No. 2 Mirror position memorized in memory switch M2 / OFF or ON ON: Memorized OFF: Not memorized - Mirror Memory No. 3 Mirror position memorized in memory switch M3 / OFF or ON ON: Memorized OFF: Not memorized - Mirror Vertical Sensor Vol Vertical mirror position / MIN: 0, MAX: 4.98 V Within range from 0 to 4.98 V - Mirror Horizontal Sensor Vol Horizontal mirror position / MIN: 0, MAX: 4.98 V Within range from 0 to 4.98 V - +B Voltage Input Value Power supply for outer mirror control ECU assembly / MIN: 0 V, MAX: 19.98 V Within range from 11 to 14 V - # Codes Number of DTC recorded / MIN: 0 V, MAX: 255 Number of DTCs displayed - Enter the following menus: Body Electrical / Master Switch / Data List. Read the Data List according to the display on the Techstream. MASTER SWITCH Tester Display Measurement Item/Range Normal Condition Diagnostic Note Door Lock Switch Status Door lock switch status / ON or OFF ON: Door lock switch on OFF: Door lock switch off - Door Unlock Switch Status Door unlock switch status / ON or OFF ON: Door unlock switch on OFF: Door unlock switch off - Enter the following menus: Body Electrical / Main Body / Data List. Read the Data List according to the display on the Techstream. MAIN BODY Tester Display Measurement Item/Range Normal Condition Diagnostic Note FL Door Courtesy Driver door courtesy switch condition / ON or OFF ON: Door courtesy switch on (driver door open) OFF: Door courtesy switch off (driver door closed) - Mirror Selection SW (R) Mirror select switch signal for RH mirror / ON or OFF ON: Mirror select switch in R position OFF: Mirror select switch off or in L position - Mirror Selection SW (L) Mirror select switch signal for LH mirror / ON or OFF ON: Mirror select switch in L position OFF: Mirror select switch off or in R position - Mirror Position SW (R) Mirror adjust switch signal (Right) / ON or OFF ON: Mirror adjust switch pressed right OFF: Mirror adjust switch not pressed right Check with the mirror select switch in the L or R position Mirror Position SW (L) Mirror adjust switch signal (Left) / ON or OFF ON: Mirror adjust switch pressed left OFF: Mirror adjust switch not pressed left Check with the mirror select switch in the L or R position Mirror Position SW (Up) Mirror adjust switch signal (Up) / ON or OFF ON: Mirror adjust switch pressed up OFF: Mirror adjust switch not pressed up Check with the mirror select switch in the L or R position Mirror Position SW (Dwn) Mirror adjust switch signal (Down) / ON or OFF ON: Mirror adjust switch pressed down OFF: Mirror adjust switch not pressed down Check with the mirror select switch in the L or R position Outer Mirror Fold SW Retractable outer mirror switch signal / ON or OFF ON: Retractable outer mirror switch in retract position OFF: Retractable outer mirror switch in driving position - Auto Mirror SW Retractable outer mirror switch signal / ON or OFF ON: Retractable outer mirror switch in AUTO position OFF: Retractable outer mirror switch in except AUTO position - Mem SW No. w/KeyID1 Switch linked with key ID1 / NONE, MEM SW1, MEM SW2, or MEM SW3 NONE: No switches linked with key ID1 MEM SW1: M1 linked with key ID1 MEM SW2: M2 linked with key ID1 MEM SW3: M3 linked with key ID1 - Mem SW No. w/KeyID2 Switch linked with key ID2 / NONE, MEM SW1, MEM SW2, or MEM SW3 NONE: No switches linked with key ID2 MEM SW1: M1 linked with key ID2 MEM SW2: M2 linked with key ID2 MEM SW3: M3 linked with key ID2 - Mem SW No. w/KeyID3 Switch linked with key ID3 / NONE, MEM SW1, MEM SW2, or MEM SW3 NONE: No switches linked with key ID3 MEM SW1: M1 linked with key ID3 MEM SW2: M2 linked with key ID3 MEM SW3: M3 linked with key ID3 - Mem SW No. w/KeyID4 Switch linked with key ID4 / NONE, MEM SW1, MEM SW2, or MEM SW3 NONE: No switches linked with key ID4 MEM SW1: M1 linked with key ID4 MEM SW2: M2 linked with key ID4 MEM SW3: M3 linked with key ID4 - Mem SW No. w/KeyID5 Switch linked with key ID5 / NONE, MEM SW1, MEM SW2, or MEM SW3 NONE: No switches linked with key ID5 MEM SW1: M1 linked with key ID5 MEM SW2: M2 linked with key ID5 MEM SW3: M3 linked with key ID5 - Mem SW No. w/KeyID6 Switch linked with key ID6 / NONE, MEM SW1, MEM SW2, or MEM SW3 NONE: No switches linked with key ID6 MEM SW1: M1 linked with key ID6 MEM SW2: M2 linked with key ID6 MEM SW3: M3 linked with key ID6 - Mem SW No. w/KeyID7 Switch linked with key ID7 / NONE, MEM SW1, MEM SW2, or MEM SW3 NONE: No switches linked with key ID7 MEM SW1: M1 linked with key ID7 MEM SW2: M2 linked with key ID7 MEM SW3: M3 linked with key ID7
3. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Mirror L or Mirror R / Active Test. Perform the Active Test according to the display on the Techstream. MIRROR L / MIRROR R Tester Display Test Part Control Range Diagnostic Note Mirror Up/Down Mirror vertical operation Up / Down Operate with power switch on (IG) and the vehicle stopped. This test activates the mirror up or down. This operation can be confirmed by watching the mirror move in the desired direction. Mirror Right/Left Mirror horizontal operation Right / Left Operate with power switch on (IG) and the vehicle stopped. This test tilts the mirror right or left. This operation can be confirmed by watching the mirror move in the desired direction. Mirror Fold/Return mirror retract operation Fold / Return Operate with power switch on (IG) and the vehicle stopped. This test activates the Fold / Return. This operation can be confirmed by watching the mirror move in the desired direction. Mirror Heater Mirror heater operation ON / OFF Operate with power switch on (IG) and the vehicle stopped. This test activates the mirror heater on or off. Mirror heater operation can be confirmed by touch. Enter the following menus: Body Electrical / Driver Seat / Active Test. Perform the Active Test according to the display on the Techstream. DRIVER SEAT Tester Display Test Part Control Range Diagnostic Note Buzzer Buzzer built into the front power seat switch LH ON or OFF This test causes vehicle parts to move. Please watch your hands and feet. Confirm that the vehicle is stopped.

INSPECTION PROCEDURE

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Scheme 93

Scheme 94

Scheme 95

1. CHECK CAN COMMUNICATION SYSTEM Check for CAN communication system DTCs. Refer to «DIAGNOSIS SYSTEM»(ref-568746-S10222482722013072300000) . OK CAN communication DTC is not output. NG --> See step 7 OK: Go to next step
2. READ VALUE USING TECHSTREAM (OUTER MIRROR SWITCH ASSEMBLY) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Main Body / Data List. Read the Data List according to the display on the Techstream. MAIN BODY Tester Display Measurement Item/Range Normal Condition Diagnostic Note Mirror Selection SW (L) Mirror select switch signal for LH mirror / ON or OFF ON: Mirror select switch in L position OFF: Mirror select switch off or in R position - Mirror Position SW (R) Mirror adjust switch signal (Right) / ON or OFF ON: Mirror adjust switch pressed right OFF: Mirror adjust switch not pressed right Check with the mirror select switch in the L position. Mirror Position SW (L) Mirror adjust switch signal (Left) / ON or OFF ON: Mirror adjust switch pressed left OFF: Mirror adjust switch not pressed left Check with the mirror select switch in the L position. Mirror Position SW (Up) Mirror adjust switch signal (Up) / ON or OFF ON: Mirror adjust switch pressed up OFF: Mirror adjust switch not pressed up Check with the mirror select switch in the L position. Mirror Position SW (Dwn) Mirror adjust switch signal (Down) / ON or OFF ON: Mirror adjust switch pressed down OFF: Mirror adjust switch not pressed down Check with the mirror select switch in the L position. OK On the Techstream screen, ON or OFF is displayed for each item according to the table above. NG --> See step 5 OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (POWER MIRROR CONTROL FUNCTION) Enter the following menus: Body Electrical / Mirror L / Active Test. Perform the Active Test according to the display on the Techstream. MIRROR L Tester Display Test Part Control Range Diagnostic Note Mirror Up/Down Mirror vertical operation Up / Down Operate with power switch on (IG) and the vehicle stopped. This test tilts the mirror up or down. This operation can be confirmed by watching the mirror move in the desired direction. Mirror Right/Left Mirror horizontal operation Right / Left Operate with power switch on (IG) and the vehicle stopped. This test tilts the mirror right or left This operation can be confirmed by watching the mirror move in the desired direction. OK Power mirror operation is normal. NG --> See step 4 OK --> See step 8
4. INSPECT OUTER MIRROR ACTUATOR ASSEMBLY LH Remove the outer rear view mirror assembly LH. Refer to «REMOVAL»(ref-568827-S23458436912013072300000) . Apply auxiliary battery voltage and check the operation of the outer rear view mirror assembly LH. OK Measurement Condition Specified Condition Auxiliary battery positive (+) --> Terminal z6-1 (LMVR) Auxiliary battery negative (-) --> Terminal z6-10 (LM+R) Turns upward Auxiliary battery negative (-) --> Terminal z6-1 (LMVR) Auxiliary battery positive (+) --> Terminal z6-10 (LM+R) Turns downward Auxiliary battery positive (+) --> Terminal z6-9 (LMHR) Auxiliary battery negative (-) --> Terminal z6-10 (LM+R) Turns left Auxiliary battery negative (-) --> Terminal z6-9 (LMHR) Auxiliary battery positive (+) --> Terminal z6-10 (LM+R) Turns right TEXT IN ILLUSTRATION *a Component without harness connected (Outer Mirror Actuator Assembly LH) NG --> See step 10 OK --> See step 9
5. INSPECT OUTER MIRROR SWITCH ASSEMBLY w/ Retract mirror: Remove the outer mirror switch assembly. Refer to «REMOVAL»(ref-568827-S31229128902013072300000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition H136-8 (M+) - H136-6 (E) Mirror adjust switch pressed up 90 to 110 ohms Mirror adjust switch pressed down 437 to 503 ohms Mirror adjust switch pressed left 744 to 856 ohms Mirror adjust switch pressed right 225 to 275 ohms H136-3 (MSW) - H136-6 (E) Mirror select switch L 90 to 110 ohms Mirror select switch off 10 kohms or higher TEXT IN ILLUSTRATION *1 Mirror Adjust Switch *2 Mirror Select Switch *a Component without harness connected (Outer Mirror Switch Assembly) w/o Retract mirror: Remove the outer mirror switch assembly. Refer to «REMOVAL»(ref-568827-S31229128902013072300000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition H37-16 (M+) - H37-14 (E) Mirror adjust switch pressed up 90 to 110 ohms Mirror adjust switch pressed down 437 to 503 ohms Mirror adjust switch pressed left 744 to 856 ohms Mirror adjust switch pressed right 225 to 275 ohms H37-13 (MSW) - H37-14 (E) Mirror select switch L 90 to 110 ohms Mirror select switch off 10 kohms or higher TEXT IN ILLUSTRATION *1 Mirror Select Switch *2 Mirror Adjust Switch *a Component without harness connected (Outer Mirror Switch Assembly) NG --> See step 11 OK: Go to next step
6. CHECK HARNESS AND CONNECTOR (OUTER MIRROR SWITCH - MAIN BODY ECU) w/ Retract mirror: Disconnect the H136 connector from the outer mirror switch assembly. Disconnect the H17 connector from the main body ECU (multiplex network body ECU). Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition H136-6 (E) - H17-15 (MIRE) Always Below 1 ohms H136-8 (M+) - H17-13 (MIRB) Always Below 1 ohms H136-3 (MSW) - H17-14 (MIRS) Always Below 1 ohms H136-6 (E) - Body ground Always 10 kohms or higher H136-8 (M+) - Body ground Always 10 kohms or higher H136-3 (MSW) - Body ground Always 10 kohms or higher w/o Retract mirror: Disconnect the H37 connector from the outer mirror switch assembly. Disconnect the H17 connector from the main body ECU (multiplex network body ECU). Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition H37-14 (E) - H17-15 (MIRE) Always Below 1 ohms H37-16 (M+) - H17-13 (MIRB) Always Below 1 ohms H37-13 (MSW) - H17-14 (MIRS) Always Below 1 ohms H37-14 (E) - Body ground Always 10 kohms or higher H37-16 (M+) - Body ground Always 10 kohms or higher H37-13 (MSW) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (OUTER MIRROR SWITCH - MAIN BODY ECU) OK --> See step 12
7. GO TO CAN COMMUNICATION SYSTEM (DIAGNOSTIC TROUBLE CODE CHART). Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-568746-S16364510032013072300000)
8. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER SIDE). Refer to «REMOVAL»(ref-568827-S38819182732013072300000)
9. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER SIDE). Refer to «REMOVAL»(ref-568827-S38819182732013072300000)
10. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY LH. Refer to «DISASSEMBLY»(ref-568827-S22141404002013072300000)
11. REPLACE OUTER MIRROR SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-568827-S31229128902013072300000)
12. REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU). Refer to «REMOVAL»(ref-568756-S16773882952013072300000)

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Scheme 96

Scheme 97

Scheme 98

1. CHECK CAN COMMUNICATION SYSTEM Use the Techstream to check if the CAN communication system is functioning normally. Refer to «DIAGNOSIS SYSTEM»(ref-568746-S10222482722013072300000) . OK CAN communication DTC is not output. NG --> See step 8 OK: Go to next step
2. READ VALUE USING TECHSTREAM (OUTER MIRROR SWITCH ASSEMBLY) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Main Body / Data List. Read the Data List according to the display on the Techstream. MAIN BODY Tester Display Measurement Item/Range Normal Condition Diagnostic Note Mirror Selection SW (R) Mirror select switch signal for RH mirror / ON or OFF ON: Mirror select switch in R position OFF: Mirror select switch off or in L position - Mirror Position SW (R) Mirror adjust switch signal (Right) / ON or OFF ON: Mirror adjust switch pressed right OFF: Mirror adjust switch not pressed right Check with the mirror select switch in the R position Mirror Position SW (L) Mirror adjust switch signal (Left) / ON or OFF ON: Mirror adjust switch pressed left OFF: Mirror adjust switch not pressed left Check with the mirror select switch in the R position Mirror Position SW (Up) Mirror adjust switch signal (Up) / ON or OFF ON: Mirror adjust switch pressed up OFF: Mirror adjust switch not pressed up Check with the mirror select switch in the R position Mirror Position SW (Dwn) Mirror adjust switch signal (Down) / ON or OFF ON: Mirror adjust switch pressed down OFF: Mirror adjust switch not pressed down Check with the mirror select switch in the R position OK On the Techstream screen, ON or OFF is displayed for each item according to the table above. NG --> See step 5 OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (POWER MIRROR CONTROL FUNCTION) Enter the following menus: Body Electrical / Mirror R / Active Test. Perform the Active Test according to the display on the Techstream. MIRROR R Tester Display Test Part Control Range Diagnostic Note Mirror Up/Down Mirror vertical operation Up / Down Operate with power switch on (IG) and the vehicle stopped. This test activates the mirror up or down. This operation can be confirmed by watching the mirror move in the desired direction. Mirror Right/Left Mirror horizontal operation Right / Left Operate with power switch on (IG) and the vehicle stopped. This test activates the mirror right or left. This operation can be confirmed by watching the mirror move in the desired direction. OK Power mirror operation is normal. NG --> See step 4 OK --> See step 9
4. INSPECT OUTER MIRROR ACTUATOR ASSEMBLY RH Remove the outer rear view mirror assembly RH. Refer to «REMOVAL»(ref-568827-S23458436912013072300000) . Apply auxiliary battery voltage and check the operation of the outer rear view mirror assembly RH. OK Measurement Condition Specified Condition Auxiliary battery positive (+) --> Terminal z7-1 (RMVR) Auxiliary battery negative (-) --> Terminal z7-10 (RM+R) Turns upward Auxiliary battery negative (-) --> Terminal z7-1 (RMVR) Auxiliary battery positive (+) --> Terminal z7-10 (RM+R) Turns downward Auxiliary battery positive (+) --> Terminal z7-9 (RMHR) Auxiliary battery negative (-) --> Terminal z7-10 (RM+R) Turns left Auxiliary battery negative (-) --> Terminal z7-9 (RMHR) Auxiliary battery positive (+) --> Terminal z7-10 (RM+R) Turns right TEXT IN ILLUSTRATION *a Component without harness connected (Outer Mirror Actuator Assembly RH) NG --> See step 10 OK --> See step 7
5. INSPECT OUTER MIRROR SWITCH ASSEMBLY w/ Retract mirror: Remove the outer mirror switch assembly. Refer to «REMOVAL»(ref-568827-S31229128902013072300000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition H136-8 (M+) - H136-6 (E) Mirror adjust switch pressed up 90 to 110 ohms Mirror adjust switch pressed down 437 to 503 ohms Mirror adjust switch pressed left 744 to 856 ohms Mirror adjust switch pressed right 225 to 275 ohms H136-3 (MSW) - H136-6 (E) Mirror select switch R Below 10 ohms Mirror select switch off 10 kohms or higher TEXT IN ILLUSTRATION *1 Mirror Adjust Switch *2 Mirror Select Switch *a Component without harness connected (Outer Mirror Switch Assembly) w/o Retract mirror: Remove the outer mirror switch assembly. Refer to «REMOVAL»(ref-568827-S31229128902013072300000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition H37-16 (M+) - H37-14 (E) Mirror adjust switch pressed up 90 to 110 ohms Mirror adjust switch pressed down 437 to 503 ohms Mirror adjust switch pressed left 744 to 856 ohms Mirror adjust switch pressed right 225 to 275 ohms H37-13 (MSW) - H37-14 (E) Mirror select switch R Below 10 ohms Mirror select switch off 10 kohms or higher TEXT IN ILLUSTRATION *1 Mirror Select Switch *2 Mirror Adjust Switch *a Component without harness connected (Outer Mirror Switch Assembly) NG --> See step 11 OK: Go to next step
6. CHECK HARNESS AND CONNECTOR (OUTER MIRROR SWITCH - MAIN BODY ECU) w/ Retract mirror: Disconnect the H136 connector from the outer mirror switch assembly. Disconnect the H17 connector from the main body ECU (multiplex network body ECU). Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition H136-6 (E) - H17-15 (MIRE) Always Below 1 ohms H136-8 (M+) - H17-13 (MIRB) Always Below 1 ohms H136-3 (MSW) - H17-14 (MIRS) Always Below 1 ohms H136-6 (E) - Body ground Always 10 kohms or higher H136-8 (M+) - Body ground Always 10 kohms or higher H136-3 (MSW) - Body ground Always 10 kohms or higher w/o Retract mirror: Disconnect the H37 connector from the outer mirror switch assembly. Disconnect the H17 connector from the main body ECU (multiplex network body ECU). Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition H37-14 (E) - H17-15 (MIRE) Always Below 1 ohms H37-16 (M+) - H17-13 (MIRB) Always Below 1 ohms H37-13 (MSW) - H17-14 (MIRS) Always Below 1 ohms H37-14 (E) - Body ground Always 10 kohms or higher H37-16 (M+) - Body ground Always 10 kohms or higher H37-13 (MSW) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (OUTER MIRROR SWITCH - MAIN BODY ECU) OK --> See step 12
7. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (FRONT PASSENGER SIDE). Refer to «REMOVAL»(ref-568827-S38819182732013072300000)
8. GO TO CAN COMMUNICATION SYSTEM (DIAGNOSTIC TROUBLE CODE CHART). Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-568746-S16364510032013072300000)
9. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (FRONT PASSENGER SIDE). Refer to «REMOVAL»(ref-568827-S38819182732013072300000)
10. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY RH. Refer to «DISASSEMBLY»(ref-568827-S22141404002013072300000)
11. REPLACE OUTER MIRROR SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-568827-S31229128902013072300000)
12. REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU). Refer to «REMOVAL»(ref-568756-S16773882952013072300000)

Note. The power mirror control system is a part of the CAN communication system. This system features shared communication wiring that reduces the wiring complexity of the communication lines. The first step in any repair is to confirm the proper operation of the communication system. Proceed with troubleshooting after the communication has been verified (See CAN Communication System. Refer to DIAGNOSIS SYSTEM ). The mirror heater operation is linked with the defogger system or wiper and washer system. Confirm that these systems are operating normally before starting the inspection.

Scheme 99

Scheme 100

1. CHECK WINDOW DEFOGGER SYSTEM Check window defogger system operation. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-568849-S23907873022013072300000) . OK Window defogger system is normal. NG --> See step 7 OK: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical /Mirror L or Mirror R / Active Test. Perform an Active Test according to the display on the Techstream. MIRROR L / MIRROR R Tester Display Test Part Control Range Diagnostic Note Mirror Heater Mirror heater operation ON / OFF Operate with power switch on (IG) and the vehicle stopped. This test activates the mirror heater on or off. Mirror heater operation can be confirmed by touch. Result Result Proceed to Mirror heater operation on both mirrors are not normal A Mirror heater operation on RH side mirror is not normal B Mirror heater operation on LH side mirror is not normal C B --> See step 3 C --> See step 5 A --> See step 8
3. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY RH Remove the outer rear view mirror assembly RH. Refer to «REMOVAL»(ref-568827-S23458436912013072300000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition z7-4 (HTR+) - z7-12 (HTR-) 25°C (77°F) 2.4 to 4.4 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Outer Rear View Mirror Assembly RH) NG --> See step 4 OK --> See step 10
4. INSPECT OUTER MIRROR RH Remove the outer mirror RH. Refer to «DISASSEMBLY»(ref-568827-S22141404002013072300000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 at 25°C (77°F) 2.4 to 4.4 ohms NG --> See step 13 OK --> See step 9
5. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY LH Remove the outer mirror LH. Refer to «REMOVAL»(ref-568827-S23458436912013072300000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition z6-4 (HTR+) - z6-12 (HTR-) 25°C (77°F) 2.4 to 4.4 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Outer Rear View Mirror Assembly LH) NG --> See step 6 OK --> See step 12
6. INSPECT OUTER MIRROR LH Remove the outer rear view mirror glass LH. Refer to «DISASSEMBLY»(ref-568827-S22141404002013072300000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 at 25°C (77°F) 2.4 to 4.4 ohms NG --> See step 14 OK --> See step 11
7. GO TO WINDOW DEFOGGER SYSTEM. Refer to «PROBLEM SYMPTOMS TABLE»(ref-568849-S01409872302013072300000)
8. REPLACE AIR CONDITIONING AMPLIFIER ASSEMBLY. Refer to «REMOVAL»(ref-568733-S07880864152013072300000)
9. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY RH. Refer to «REMOVAL»(ref-568827-S23458436912013072300000)
10. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (FRONT PASSENGER SIDE). Refer to «REMOVAL»(ref-568827-S38819182732013072300000)
11. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY LH. Refer to «DISASSEMBLY»(ref-568827-S22141404002013072300000)
12. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER SIDE). Refer to «REMOVAL»(ref-568827-S38819182732013072300000)
13. REPLACE OUTER MIRROR RH. Refer to «DISASSEMBLY»(ref-568827-S22141404002013072300000)
14. OUTER MIRROR LH. Refer to «DISASSEMBLY»(ref-568827-S22141404002013072300000)

HINT

The reverse shift-linked function will not activate when the mirror select switch is in the neutral position (off).

Scheme 101

1. CHECK MEMORY AND REACTIVATION FUNCTION Turn the power switch on (IG). Using the outer mirror switch assembly, turn the mirror surface to the fully left position. TEXT IN ILLUSTRATION *a Turn to Left Fully Press the M1 switch while the SET switch is being pressed. Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized. Using the outer mirror switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded fully left position. Result Result Proceed to Memory and reactivation functions are normal. A Memory function is not normal. B Reactivation function is not normal. C B --> See step 6 C --> See step 7 A: Go to next step
2. CHECK CAN COMMUNICATION SYSTEM Use the Techstream to check if the CAN communication system is functioning normally. Refer to «DIAGNOSIS SYSTEM»(ref-568746-S10222482722013072300000) . OK CAN communication DTC is not output. NG --> See step 8 OK: Go to next step
3. CHECK FOR DTC Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Hybrid Control / Trouble Codes. Check if hybrid control system DTCs are output. OK Hybrid control system DTCs are not output. NG --> See step 9 OK: Go to next step
4. CHECK COMBINATION METER ASSEMBLY Check if the shift position indicator light in the combination meter assembly operates normally. OK The shift position indicator light indicates the actual shift position correctly. NG --> See step 10 OK: Go to next step
5. CHECK REVERSE SHIFT-LINKED FUNCTION Turn the power switch on (IG). Set the mirror select switch to L or R. Check that the mirror surface turns downward when the shift lever is moved to R. Result Result Proceed to Reverse shift-linked functions on both mirrors are not normal A Reverse shift-linked function on RH side is not normal B Reverse shift-linked function on LH side is not normal C B --> See step 11 C --> See step 12 A --> See step 13
6. GO TO OTHER FLOW CHART (Power Mirror Surface Position is not Memorized). Refer to «Power Mirror Surface Position is not Memorized»(ref-568843-S23008922582013072300000)
7. GO TO OTHER FLOW CHART (Power Mirrors do not Return to Memorized Position). Refer to «Power Mirrors do not Return to Memorized Position»(ref-568843-S32263080792013072300000)
8. GO TO CAN COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-568746-S16364510032013072300000)
9. GO TO HYBRID CONTROL SYSTEM (DIAGNOSTIC TROUBLE CODE CHART). Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-568739-S34469312312013072300000)
10. GO TO METER / GAUGE SYSTEM (PROBLEM SYMPTOMS TABLE). Refer to «PROBLEM SYMPTOMS TABLE»(ref-568601-S21933555562013072300000)
11. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (FRONT PASSENGER SIDE). Refer to «REMOVAL»(ref-568827-S38819182732013072300000)
12. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER SIDE). Refer to «REMOVAL»(ref-568827-S38819182732013072300000)
13. REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU). Refer to «REMOVAL»(ref-568756-S16773882952013072300000)
