Instrument Panel and Console Land Rover Range Rover L322

SPECIFICATIONS

TORQUE SPECIFICATIONS

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
2. Remove the LH front seat. Refer to «Front Seat»(/land-rover/range-rover/l322-2009-2012/remont/seats/#seating) .
3. Remove the LH floor wiring harness trim panel. Remove the 2 clips.
4. Reposition the floor console wiring harness. Disconnect the 4 electrical connectors. Reposition the carpet for access.
5. Remove the selector lever knob. Refer to «Selector Lever Knob»(/land-rover/range-rover/l322-2009-2012/remont/automatic-trans/#automatic-transmissiontransaxle-external-controls-v8-50l-petrolv8-sc-50l-petrol) .
6. Remove the LH floor console extension. See «Floor Console Extension»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
7. Remove the RH floor console extension. Remove the screw. Release the 2 clips.
8. Remove the 2 front bolts from the floor console.
9. Remove the climate controlled seat switch trim panel. Carefully release the 4 clips. Remove the 2 front screws from the floor console upper panel.
10. Remove the rear floor register. Release the 4 clips.
11. Remove the 2 rear bolts from the floor console. Remove the floor console rear LH floor register. Remove the floor console rear LH bolt. Remove the floor console rear RH floor register. Remove the floor console rear RH bolt.
12. Remove the floor console. Reposition the floor console upwards and rearwards.
13. Remove the auxiliary climate control rear register. Refer to «Register»(/land-rover/range-rover/l322-2009-2012/remont/automatic-hvac-system/#auxiliary-climate-control-1-of-2) .
14. Remove the cellular phone cradle assembly lower trim panel. Reposition the cellular phone cradle assembly. Remove the 6 screws.
15. Remove the cellular phone cradle assembly. Disconnect the 2 electrical connectors. Release the 2 electrical connectors from the clips.
16. Remove the floor console stowage compartment. Open the floor console stowage compartment lid. Remove the 2 screws. Carefully release the 2 clips. Disconnect the cigar lighter electrical connector.
17. Remove the center console LH side finisher trim panel. Using a suitable tool, carefully release the 3 clips.
18. Remove the center console RH side finisher trim panel. Using a suitable tool, carefully release the 3 clips.
19. Reposition the floor console upper panel. Remove the 4 screws. Using a suitable tool, carefully release the 4 clips.
20. Disconnect the parking brake switch electrical connector.
21. Remove the floor console upper panel. Release the 3 wiring harness clips. Disconnect the 3 electrical connectors.
22. Disconnect the 6 electrical connectors from the rear passenger entertainment control panel.
23. Remove the floor console rear trim panel. Remove the 4 screws.
24. Remove the rear auxiliary climate control assembly. Remove the 4 screws. Disconnect the 2 electrical connectors.
25. Remove the floor console LH finisher trim panel. Remove the 11 screws.
26. Remove the floor console RH finisher trim panel. Remove the 11 screws.
27. Remove the 14 clips from the floor console.
28. Remove the 2 brackets from the floor console. Remove the 2 screws.

INSTALLATION

1. Install the 2 brackets to the floor console. Install the 2 screws.
2. Install the 14 clips to the floor console.
3. Install the floor console LH finisher trim panel. Install the 10 screws.
4. Install the floor console RH finisher trim panel. Install the 10 screws.
5. Install the rear auxiliary climate control assembly. Connect the 2 electrical connectors. Install the 4 screws.
6. Install the floor console rear trim panel. Install the 4 screws.
7. Connect the 6 electrical connectors to the rear passenger entertainment control panel.
8. Install the floor console upper panel. Connect the 3 electrical connectors. Attach the 3 wiring harness clips.
9. Connect the parking brake switch electrical connector.
10. Reposition the floor console upper panel. Secure the 4 clips. Install the 4 screws.
11. Install the center console LH side finisher trim panel. Secure the 3 clips.
12. Install the center console RH side finisher trim panel. Secure the 3 clips.
13. Install the floor console stowage compartment. Connect the cigar lighter electrical connector. Secure the 2 clips. Install the 2 screws. Close the floor console stowage compartment lid.
14. Install the cellular phone cradle assembly. Attach the 2 electrical connectors to the clips. Connect the 2 electrical connectors.
15. Install the cellular phone cradle assembly lower trim panel. Install the six screws. Reposition the cellular phone cradle assembly.
16. Install the auxiliary climate control rear register. Refer to «Register»(/land-rover/range-rover/l322-2009-2012/remont/automatic-hvac-system/#auxiliary-climate-control-1-of-2) .
17. Install the floor console. Reposition the floor console to its original position.
18. Install the 2 rear bolts to the floor console. Install the floor console rear RH bolt. Install the floor console rear RH floor register. Install the floor console rear LH bolt. Install the floor console rear LH floor register.
19. Install the rear floor register. Secure the 4 clips.
20. Install the climate controlled seat switch trim panel. Install the 2 front screws to the floor console upper panel. Secure the 4 clips.
21. Install the 2 front bolts to the floor console. Install the floor console front RH bolt. Install the floor console front LH bolt.
22. Install the LH floor console extension. See «Floor Console Extension»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
23. Install the RH floor console extension. Install the screw. Secure the 2 clips.
24. Install the selector lever knob. Refer to «Selector Lever Knob»(/land-rover/range-rover/l322-2009-2012/remont/automatic-trans/#automatic-transmissiontransaxle-external-controls-v8-50l-petrolv8-sc-50l-petrol) .
25. Reposition the floor console wiring harness. Reposition the carpet for access. Connect the 4 electrical connectors.
26. Install the LH floor wiring harness trim panel. Install the 2 clips.
27. Install the LH front seat. Refer to «Front Seat»(/land-rover/range-rover/l322-2009-2012/remont/seats/#seating) .
28. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .

Scheme 17

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
2. Remove the floor console upper panel. See «Floor Console Upper Panel»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
3. Remove the floor console cup holder. Remove the 6 screws.

1. Install the floor console cup holder. Install the 6 screws.
2. Install the floor console upper panel. See «Floor Console Upper Panel»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
3. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .

Scheme 18

Scheme 19

1. Remove the LH floor console extension. Remove the screw. Release the 2 clips.
2. Remove the floor console extension trim panel. NOTE: Do not disassemble further if the component is removed for access only. Remove the rubber isolator. Remove the 6 screws. Remove the 2 clips.

1. Install the floor console extension trim panel. Install the rubber isolator. Install the 6 screws. Install the 2 clips.
2. Install the LH floor console extension. Secure the 2 clips. Tighten the screw.

REMOVAL

1. Remove the floor console stowage compartment. Open the floor console stowage compartment lid. Remove the 2 screws. Using a suitable tool, carefully release the 2 clips. Disconnect the cigar lighter electrical connector.
2. Remove the cigar lighter assembly. Remove the cigar lighter. With extreme care release the 2 clips and remove the cigar lighter inner housing. Remove the cigar lighter housing.

1. Install the cigar lighter assembly.
2. Install the floor console stowage compartment. Connect the cigar lighter electrical connector. Secure the 2 clips. Install the 2 screws. Close the floor console stowage compartment lid.

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

1. Position the front seats fully forward. Reposition both of the front seat backrests for access.
2. Remove the floor console stowage compartment lid LH hinge trim. Remove the floor console stowage compartment lid hinge pin LH bolt.
3. Remove the floor console stowage compartment lid hinge pin. Using a suitable tool, remove the floor console stowage compartment lid hinge pin.
4. Remove the floor console stowage compartment lid RH hinge trim.
5. Release the cellular phone handset holder lid damper. Remove the cellular phone handset holder lid damper clevis pin clip. Remove the cellular phone handset holder lid damper clevis pin.
6. Release the floor console stowage compartment lid damper. Release the cellular phone handset holder from the floor console stowage compartment lid. Remove the floor console stowage compartment lid damper screw.
7. Remove the floor console stowage compartment lid. Remove the tool. Release the floor console stowage compartment lid hinge pin RH sleeve clips. Remove the floor console stowage compartment lid hinge pin RH sleeve.

1. Install the floor console stowage compartment lid. Install the floor console stowage compartment lid hinge pin RH sleeve. Secure the floor console stowage compartment lid hinge pin RH sleeve clips. Using a suitable tool, align the floor console stowage compartment lid.
2. Secure the floor console stowage compartment lid damper. Install the floor console stowage compartment lid damper screw. Secure the cellular phone handset holder to the floor console stowage compartment lid.
3. Secure the cellular phone handset holder lid damper. Install the cellular phone handset holder lid damper clevis pin. Install the cellular phone handset holder lid damper clevis pin clip.
4. Install the floor console stowage compartment lid RH hinge trim.
5. Install the floor console stowage compartment lid hinge pin. Remove the tool.
6. Install the floor console stowage compartment lid LH hinge trim. Install the floor console stowage compartment lid hinge pin LH bolt.
7. Reposition the front seats to their original position.

Scheme 26

Scheme 27

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
2. Remove the floor console stowage compartment. Open the floor console stowage compartment lid. Remove the 2 screws. Carefully release the 2 clips. Disconnect the cigar lighter electrical connector.
3. Remove the center console LH side finisher trim panel. Using a suitable tool, carefully release the 3 clips.
4. Remove the center console RH side finisher trim panel. Using a suitable tool, carefully release the 3 clips.
5. Remove the selector lever knob. Refer to «Selector Lever Knob»(/land-rover/range-rover/l322-2009-2012/remont/automatic-trans/#automatic-transmissiontransaxle-external-controls-v8-50l-petrolv8-sc-50l-petrol) .
6. Remove the climate controlled seat switch trim panel. Carefully release the 4 clips. Remove the 2 front screws from the floor console upper panel.
7. Reposition the floor console upper panel. Using a suitable tool, carefully release the 4 clips. Remove the 4 screws.
8. Disconnect the parking brake switch electrical connector.
9. Remove the floor console upper panel. Release the 3 wiring harness clips. Disconnect the 3 electrical connectors.
10. Remove the floor console cup holder. Remove the 6 screws.
11. Remove the parking brake switch. Remove the parking brake switch trim panel. Remove the 2 screws.
12. Remove the upper floor console stowage compartment. Remove the 4 screws.
13. Remove the ride and handling optimization switch assembly. Remove the 6 screws.

1. Install the ride and handling optimization switch assembly. Install the 6 screws.
2. Install the upper floor console stowage compartment. Install the 4 screws.
3. Install the parking brake switch. Install the 2 screws. Install the parking brake switch trim panel.
4. Install the floor console cup holder. Install the 6 screws.
5. Install the floor console upper panel. Connect the 3 electrical connectors. Attach the 3 wiring harness clips.
6. Connect the parking brake switch electrical connector.
7. Reposition the floor console upper panel. Secure the 4 clips. Install the 4 screws.
8. Install the climate controlled seat switch trim panel. Install the 2 front screws to the floor console upper panel. Secure the 4 clips.
9. Install the selector lever knob. Refer to «Selector Lever Knob»(/land-rover/range-rover/l322-2009-2012/remont/automatic-trans/#automatic-transmissiontransaxle-external-controls-v8-50l-petrolv8-sc-50l-petrol) .
10. Install the center console LH side finisher trim panel. Secure the 3 clips.
11. Install the center console RH side finisher trim panel. Secure the 3 clips.
12. Install the floor console stowage compartment. Connect the cigar lighter electrical connector. Secure the 2 clips. Install the 2 screws. Close the floor console stowage compartment lid.
13. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

1. Cooling System Draining, Filling and Bleeding - Vehicles With: Supercharger, refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/cooling-fan/#engine-cooling-v8-50l-petrolv8-sc-50l-petrol__specifications)
2. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(/land-rover/range-rover/l322-2009-2012/remont/ac-compressor/#climate-control-system-general-information) .
3. Refer to «Plenum Chamber»(/land-rover/range-rover/l322-2009-2012/remont/automatic-hvac-system/#air-distribution-and-filtering) .
4. Refer to «Windshield Wiper Motor»(/land-rover/range-rover/l322-2009-2012/remont/wiperwasher-systems/#wipers-and-washers) .
5. See «Instrument Panel Reinforcement»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
6. Refer to «Steering Column»(/land-rover/range-rover/l322-2009-2012/remont/steering-column/#steering-column) .
7. Using 3 suitable pipe clamps, clamp the 3 heater core coolant hoses. Position a container to collect the fluid spillage.
8. Torque: 25 Nm
9. Torque: 10 Nm
10. Torque: 25 Nm
11. Torque: 6 Nm
12. Torque: 8 Nm
13. Torque: 6 Nm
14. Torque: 6 Nm
15. Torque: 25 Nm
16. Torque: 6 Nm
17. Torque: 8 Nm
18. Torque: 6 Nm
19. Torque: 6 Nm

1. To install, reverse the removal procedure.

1. Cooling System Draining, Filling and Bleeding - Vehicles Without: Supercharger, refer to «Engine Cooling (V8 5.0L Petrol/V8 S/C 5.0L Petrol)»(/land-rover/range-rover/l322-2009-2012/remont/cooling-fan/#engine-cooling-v8-50l-petrolv8-sc-50l-petrol)
2. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(/land-rover/range-rover/l322-2009-2012/remont/ac-compressor/#climate-control-system-general-information) .
3. Refer to «Plenum Chamber»(/land-rover/range-rover/l322-2009-2012/remont/automatic-hvac-system/#air-distribution-and-filtering) .
4. Refer to «Windshield Wiper Motor»(/land-rover/range-rover/l322-2009-2012/remont/wiperwasher-systems/#wipers-and-washers) .
5. See «Instrument Panel Reinforcement»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
6. Refer to «Steering Column»(/land-rover/range-rover/l322-2009-2012/remont/steering-column/#steering-column) .
7. Using 3 suitable pipe clamps, clamp the 3 heater core coolant hoses. Position a container to collect the fluid spillage.
8. Torque: 25 Nm
9. Torque: 10 Nm
10. Torque: 25 Nm
11. Torque: 6 Nm
12. Torque: 8 Nm
13. Torque: 6 Nm
14. Torque: 6 Nm
15. Torque: 25 Nm
16. Torque: 6 Nm
17. Torque: 8 Nm
18. Torque: 6 Nm
19. Torque: 6 Nm

1. To install, reverse the removal procedure.

Scheme 49

Scheme 50

Scheme 51

Scheme 52

1. Remove the floor console. See «Floor Console»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
2. Torque: 2 Nm
3. Torque: 3 Nm

1. To install, reverse the removal procedure.

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2009-2012/remont/dtc-index/#dtc-index-general-information) .
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
3. Remove the instrument cluster. Refer to «Instrument Cluster»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-cluster) .
4. Remove the driver side floor console extension. Remove the screw. Release the 2 clips.
5. Release the driver side closing trim panel. Remove the 4 screws. Remove the clip.
6. Remove the driver side closing trim panel. Disconnect the 2 electrical connectors. Release the vehicle diagnostic socket.
7. Remove the 6 lower screws from the instrument panel lower section.
8. Remove the instrument cluster finish panel. Remove the 2 screws.
9. Release the instrument panel lower section. Remove the 2 upper screws.
10. Remove the instrument panel lower section. Release the driver lower air bag module harness. Disconnect the driver lower air bag module electrical connector. Disconnect the footwell lamp electrical connector.
11. Remove the footwell lamp assembly. Release the 2 clips.
12. Remove the driver lower air bag module. Remove the 10 nuts.

1. Install the driver lower air bag module. Tighten the nuts to 8 Nm (6 lb.ft).
2. Install the footwell lamp assembly. Secure with the 2 clips.
3. Install the instrument panel lower section. Connect the footwell lamp electrical connector. Connect the driver lower air bag module electrical connector. Secure the driver lower air bag module harness.
4. Secure the instrument panel lower section. Install the 2 upper screws.
5. Install the instrument cluster finish panel. Install the 2 screws.
6. Install the 6 lower screws to the instrument panel lower section.
7. Install the driver side closing trim panel. Attach the vehicle diagnostic socket. Connect the 2 electrical connectors.
8. Secure the driver side closing trim panel. Install the 4 screws. Install the clip.
9. Install the driver side floor console extension. Secure the 2 clips. Install the screw.
10. Install the instrument cluster. Refer to «Instrument Cluster»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-cluster) .
11. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2009-2012/remont/dtc-index/#dtc-index-general-information) .
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
3. Refer to «Clockspring»(/land-rover/range-rover/l322-2009-2012/remont/airbag/#supplemental-restraint-system) .
4. See «Lower Center Registers Panel Assembly»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
5. Torque: 2 Nm
6. Torque: 3 Nm
7. Torque: 3 Nm
8. Torque: 3 Nm
9. Torque: 3 Nm
10. Torque: 3 Nm
11. Torque: 3 Nm
12. Torque: 3 Nm

1. To install, reverse the removal procedure.

Note. The passenger air bag is installed to the underside of the instrument panel upper section.

Scheme 73

Scheme 74

Scheme 75

Scheme 76

1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2009-2012/remont/dtc-index/#dtc-index-general-information) .
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
3. Remove the upper glove compartment. See «Upper Glove Compartment»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
4. Disconnect the passenger air bag module electrical connector. Release the passenger air bag module harness.
5. Remove the 2 bolts securing the passenger air bag module to the in-vehicle crossbeam.
6. Remove the driver side register trim panel. Refer to «Driver Side Register Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/automatic-hvac-system/#air-distribution-and-filtering) .
7. Remove the upper center registers. Refer to «Upper Center Registers»(/land-rover/range-rover/l322-2009-2012/remont/automatic-hvac-system/#air-distribution-and-filtering) .
8. Remove the instrument panel center speaker grille.
9. With assistance, remove the instrument panel upper section. Remove the 10 screws. Slide the instrument panel upper section away from the windshield and disconnect the instrument panel center speaker electrical connector.
10. Remove the instrument cluster finish panel. Remove the 4 screws.
11. Remove the instrument panel center speaker. Remove the 4 screws.
12. Remove the passenger air bag module. Remove the 8 nuts.

1. Install the passenger air bag module. Tighten the nuts to 8 Nm (6 lb.ft).
2. Install the instrument panel center speaker. Install the 4 screws.
3. Install the instrument cluster finish panel. Install the 4 screws.
4. With assistance, install the instrument panel upper section. Connect the instrument panel center speaker electrical connector. Install the 10 screws.
5. Install the instrument panel center speaker grille.
6. Install the upper center registers. Refer to «Upper Center Registers»(/land-rover/range-rover/l322-2009-2012/remont/automatic-hvac-system/#air-distribution-and-filtering) .
7. Install the driver side register trim panel. Refer to «Driver Side Register Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/automatic-hvac-system/#air-distribution-and-filtering) .
8. Install the 2 bolts securing the passenger air bag module to the in-vehicle crossbeam.
9. Connect the passenger air bag module electrical connector. Secure the passenger air bag module harness.
10. Install the upper glove compartment. See «Upper Glove Compartment»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
11. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2009-2012/remont/dtc-index/#dtc-index-general-information) .
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
3. See «Instrument Panel Lower Section»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .

1. To install, reverse the removal procedure.

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2009-2012/remont/dtc-index/#dtc-index-general-information) .
2. Open the lower glove compartment.
3. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
4. Remove the cowl side trim panel. Refer to «Cowl Side Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
5. Remove the floor console extension trim panel. See «Floor Console Extension»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
6. Remove the passenger side closing trim panel. Remove the 3 screws. Disconnect the footwell lamp electrical connector.
7. Remove the passenger side register trim panel. Refer to «Passenger Side Register Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/automatic-hvac-system/#air-distribution-and-filtering) .
8. Release the lower glove compartment. Remove the retaining screw.
9. Open the lower glove compartment to the service position.
10. Remove the 8 screws from the lower glove compartment.
11. Remove the lower glove compartment. Disconnect the electrical connector from the footwell lamp. Disconnect the electrical connector from the lower glove compartment lamp. Disconnect the electrical connector from the lower glove compartment latch.
12. Remove the lower glove compartment lamp.
13. Remove the lower glove compartment latch. Remove the 3 screws.
14. Remove the lower glove compartment lid.

1. Install the lower glove compartment lid. Position the lower glove compartment striker. Install the 6 screws to the lower glove compartment lid.
2. Install the lower glove compartment latch. Install the 3 screws.
3. Install the lower glove compartment lamp.
4. Install the lower glove compartment. Connect the lower glove compartment latch electrical connector. Connect the lower glove compartment lamp electrical connector. Connect the footwell lamp electrical connector. Align the lower glove compartment.
5. Secure the lower glove compartment. Install the 8 screws.
6. Close the lower glove compartment.
7. Attach the lower glove compartment. Install the retaining screw.
8. Install the passenger side register trim panel. Refer to «Passenger Side Register Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/automatic-hvac-system/#air-distribution-and-filtering) .
9. Install the passenger side closing trim panel. Connect the footwell lamp electrical connector. Install the 3 screws.
10. Install the floor console extension trim panel. See «Floor Console Extension»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
11. Install the cowl side trim panel. Refer to «Cowl Side Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
12. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .

Scheme 89

1. Open the lower glove compartment.
2. Remove the lower glove compartment lid. Remove the 6 screws from the lower glove compartment lid. Collect the lower glove compartment striker. Disconnect the footwell lamp electrical connector.
3. Remove the footwell lamp assembly. Release the 2 clips.

1. Install the footwell lamp assembly.
2. Install the lower glove compartment lid. Connect the footwell lamp electrical connector. Position the lower glove compartment striker. Install the 6 screws.
3. Close the lower glove compartment.

Scheme 90

Scheme 91

Scheme 92

1. Release the overhead console. Open the sunglasses compartment. Remove the 2 screws. Release the 6 clips.
2. Remove the overhead console. Disconnect the 4 electrical connectors.
3. Remove the front interior lamp. Release the 2 clips.
4. Remove the roof opening panel switch. Carefully release the 2 clips.
5. Remove the overhead console blanking trim. Release the 4 clips.
6. Release the tire pressure monitoring system receiver.
7. Remove the cellular phone microphone. Release the 3 clips.
8. Remove the 4 clips from the overhead console.

1. Install the 4 clips to the overhead console.
2. Install the cellular phone microphone. Secure the 3 clips.
3. Secure the tire pressure monitoring system receiver.
4. Install the overhead console blanking trim. Secure the 4 clips.
5. Install the roof opening panel switch. Secure in the 2 clips.
6. Install the front interior lamp. Secure the 2 clips.
7. Install the overhead console. Connect the 4 electrical connectors.
8. Secure the overhead console. Secure the 6 clips. Install the 2 screws. Close the sunglasses compartment.

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2009-2012/remont/dtc-index/#dtc-index-general-information) .
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
3. Remove the lower glove compartment. See «Lower Glove Compartment»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
4. Remove the 2 screws from the compact disc (CD) changer bracket.
5. Open the upper glove compartment.
6. Remove the upper glove compartment finisher trim panel. Remove the screw. Release the 3 clips.
7. Remove the 3 screws from the upper glove compartment.
8. Remove the upper glove compartment. Disconnect the upper glove compartment latch electrical connector. If installed, disconnect the electrical connector from the portable camera docking station. Disconnect the coaxial cable from the portable camera docking station. Disconnect the CD changer electrical connector.
9. Remove the CD changer. Remove the 3 screws securing the CD changer bracket to the upper glove compartment.
10. Remove the upper glove compartment latch. Remove the 3 screws.
11. Release and remove the portable camera from the portable camera docking station.
12. Remove the portable camera docking station. Remove the 2 screws.
13. Remove the upper glove compartment lid. Remove the 6 screws from the upper glove compartment lid. Collect the upper glove compartment striker.

1. Install the upper glove compartment lid. Position the upper glove compartment striker. Install the 6 screws to the upper glove compartment lid.
2. Install the portable camera docking station. Install the 2 screws.
3. Install the portable camera to the portable camera docking station.
4. Install the upper glove compartment latch. Install the 3 screws.
5. Install the CD changer. Install the 3 screws securing the CD changer bracket to the upper glove compartment.
6. Install the upper glove compartment. Connect the CD changer electrical connector. Connect the portable camera docking station coaxial cable. Connect the portable camera docking station electrical connector. Connect the upper glove compartment latch electrical connector.
7. Install the 3 screws to the upper glove compartment.
8. Install the upper glove compartment finisher trim panel. Secure the 3 clips. Install the screw.
9. Close the upper glove compartment.
10. Install the 2 screws to the CD changer bracket.
11. Install the lower glove compartment. See «Lower Glove Compartment»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
12. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .

Scheme 101

1. Open the upper glove compartment.
2. Remove the upper glove compartment lid. Remove the 6 screws from the upper glove compartment lid. Collect the upper glove compartment striker.

1. Install the upper glove compartment lid. Position the upper glove compartment striker. Install the 6 screws.
2. Close the upper glove compartment.

See also:
• Specifications
• Front Seat
• Selector Lever Knob
• Register
• Specifications
• Air Conditioning (A/C) System Recovery, Evacuation and Charging
• Plenum Chamber
• Windshield Wiper Motor
• Steering Column
• Engine Cooling (V8 5.0L Petrol/V8 S/C 5.0L Petrol)
• Standard Workshop Practices
• Instrument Cluster
• Clockspring
• Cowl Side Trim Panel
• Floor Console Extension
