Multifunction Electronic Modules Land Rover Range Rover L322

Communication Devices 5 illustrations ~504 words

DESCRIPTION AND OPERATION

For a detailed description of the Driver/Passenger Door modules and operation, refer to the relevant Description and Operation instructions. Refer to Module Controlled Functions . .

INSPECTION AND VERIFICATION

  1. Verify the customer concern.
  2. Visually inspect for obvious signs of electrical damage. Visual Inspection Electrical Fuse(s) Electrical connector(s) Wiring Harness
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. If the cause is not visually evident, check for DTCs and refer to the DTC Index.

DTC INDEX

For a list of Diagnostic Trouble Codes (DTCs) that could be logged on this vehicle, please refer to Diagnostic Trouble Code (DTC) Index - DTC: Module Name: Driver/Passenger Door Module .

Scheme 6

Scheme 6: REMOVAL
Scheme 6: REMOVAL

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10
  1. Disconnect the battery ground cable. For additional information, refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
  2. Remove the access panel from the loadspace trim panel LH.
  3. Remove the loadspace trim panel, floor stowage compartment LH access cover.
  4. Raise and support the spare tire loadspace trim panel.
  5. Remove the LH finisher trim panel. Remove the luggage tie down ring. Remove the 2 turn fasteners securing the LH finisher trim panel.
  6. Remove the lower turn fastener, securing the front loadspace trim panel LH.
  7. Remove the trim clip securing the front loadspace trim panel LH to the floor stowage compartment.
  8. Remove the LH floor stowage compartment. Remove the 3 nuts.
  9. Remove the information and entertainment module upper bracket. Remove the 2 bolts. Remove the 2 screws.
  10. Release the information and entertainment module from its lower locating bracket.
  11. Remove the information and entertainment module. Disconnect the optical connector. Disconnect the 7 electrical connectors. CAUTION: Cover fiber optic cable connectors to minimize dust ingress and avoid bending the cables in a radius of less than 30 mm.
  12. Remove the information and entertainment module lower bracket. Remove the 2 screws.

INSTALLATION

  1. Install the information and entertainment lower bracket. Install the screws.
  2. Install the information and entertainment module. Connect the optical connector. Connect the electrical connectors.
  3. Install the information and entertainment module upper bracket. Tighten the bolts to 10 Nm (7 lb.ft).
  4. Install the LH floor stowage compartment. Install the nuts.
  5. Install the trim clip securing the front loadspace trim panel LH to the floor stowage compartment.
  6. Install the lower turn fastener, securing the front loadspace trim panel to the floor stowage compartment.
  7. Install the LH finisher trim panel. Install the turn fasteners.
  8. Install the luggage tie down ring. Tighten the bolt to 25 Nm (18 lb.ft).
  9. Lower and secure the spare tire loadspace trim panel.
  10. Install the loadspace trim panel, floor stowage compartment LH access cover.
  11. Install the access panel to the loadspace trim panel LH.
  12. Connect the battery ground cable. For additional information, refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
  13. Using the Land Rover approved diagnostic system, follow the on-screen instructions and configure the information and entertainment module.
