Bumpers Land Rover Range Rover L322

SPECIFICATIONS

TORQUE SPECIFICATIONS

REMOVAL

Note. Removal steps in this procedure may contain installation details.

All vehicles

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Raise and support the vehicle. WARNING: Make sure to support the vehicle with axle stands.
2. See «Front Bumper Cover»(/land-rover/range-rover/l322-2009-2012/remont/exterior-body-panels/#bumpers) .
3. Torque: 5 Nm
4. Torque: 20 Nm
5. Torque: 9 Nm
6. Torque: 2.5 Nm
7. Torque: 45 Nm WARNING: Make sure that new nuts are installed. NOTE: With assistance remove the component.

INSTALLATION

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Note. The ignition must be switched off.

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
2. Refer to «Radiator Grille»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#exterior-trim-and-ornamentation) .
3. Raise and support the vehicle. WARNING: Make sure to support the vehicle with axle stands.
4. Remove both the front wheels and tires.
5. Torque: 1.5 Nm NOTE: The procedure must be carried out on both sides. NOTE: RH graphic shown, LH is similar.
6. Torque: 1.5 Nm NOTE: The procedure must be carried out on both sides. NOTE: RH graphic shown, LH is similar.
7. Torque: 4 Nm
8. Torque: 4 Nm
9. See figure CAUTION: Take extra care not to damage the wiring harnesses.
10. See figure CAUTION: Make sure damage does not occur to bumper cover. Failure to follow this instruction may result in damage to the vehicle. NOTE: With assistance remove the component.
11. See figure CAUTION: Protect the surrounding paintwork to avoid damage. CAUTION: Take extra care not to damage the clips. NOTE: Do not disassemble further if the component is removed for access only. NOTE: The procedure must be carried out on both sides.
12. Torque: 2.5 Nm NOTE: Support as necessary. NOTE: The procedure must be carried out on both sides.
13. See figure NOTE: Support as necessary. NOTE: The procedure must be carried out on both sides.
14. Torque: 1 Nm NOTE: Some variation in the graphics may occur, but the essential information is always correct.
15. Torque: 2.5 Nm NOTE: The procedure must be carried out on both sides.
16. See figure NOTE: The procedure must be carried out on both sides.
17. See figure NOTE: The procedure must be carried out on both sides.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. To install, reverse the removal procedure.

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. Open the tailgate and fold back the loadspace cargo cover.
2. Remove the rear bumper cover assembly. For additional information, refer to «Rear Bumper Cover»(/land-rover/range-rover/l322-2009-2012/remont/exterior-body-panels/#bumpers) .
3. Raise and support the spare tire loadspace trim panel.
4. Remove the access panel from the LH and RH loadspace trim panels.
5. Remove the LH and RH luggage tie down rings.
6. Remove the LH and RH finisher trim panels. Release the 4 turn fasteners.
7. Remove the loadspace trim panel, floor stowage compartment LH and RH access covers.
8. Remove the turn fastener and trim clip securing the LH and RH front loadspace trim panels.
9. Remove the warning triangle.
10. Release the clip and remove the wheel chock and tool roll.
11. Remove the RH floor stowage compartment. Remove the RH floor stowage compartment plastic liner. Release the 2 clips. Remove the 3 nuts.
12. Remove the LH floor stowage compartment. Remove the 3 nuts.
13. Remove the rear bumper. Remove the 8 nuts. NOTE: Do not disassemble further if the component is removed for access only.
14. Release the 8 clips from the rear bumper.

1. Install the 8 clips to the rear bumper.
2. Install the rear bumper. Tighten the nuts to 45 Nm (33 lb.ft).
3. Install the LH floor stowage compartment. Install the nuts.
4. Install the RH floor stowage compartment. Install the nuts. Install the clips. Install the RH floor stowage compartment plastic liner.
5. Install the wheel chock and tool roll. Secure with the clip.
6. Install the warning triangle.
7. Install the turn fastener and trim clip to the LH and RH front loadspace trim panels.
8. Install the loadspace trim panel, floor stowage compartment LH and RH access covers.
9. Install the LH and RH finisher trim panels. Secure the turn fasteners.
10. Install the luggage tie down rings. Tighten the bolts to 25 Nm (18 lb.ft).
11. Install the access panel to the LH and RH loadspace trim panels.
12. Lower and secure the spare tire loadspace trim panel.
13. Install the rear bumper cover assembly. For additional information, refer to «Rear Bumper Cover»(/land-rover/range-rover/l322-2009-2012/remont/exterior-body-panels/#bumpers) .
14. Close the tailgate and liftgate. Return the loadspace cargo cover to the original position.

Scheme 35

Scheme 36

Scheme 37

1. Remove the rear bumper cover trim panel. Release the 7 clips securing the rear edge of the rear bumper cover trim panel. Open the tailgate. Release the 12 clips securing the front edge of the rear bumper cover trim panel. CAUTION: Protect the paintwork during this operation.
2. Release the rear fender splash shield from the rear bumper cover. Remove the 2 clips. Remove the 4 screws.
3. Release the rear bumper cover lower section. Remove the 5 screws.
4. With assistance, remove the rear bumper cover. Remove the 5 screws. Release the 6 clips. Disconnect the 4 electrical connectors to the rear parking aid sensors.

1. With assistance, install the rear bumper cover. Connect the electrical connectors to the rear parking aid sensors. Install the screws.
2. Secure the rear bumper cover lower section. Install the screws.
3. Secure the fender splash shield to the rear bumper cover. Install the screws. Install the clips.
4. Install the rear bumper cover trim panel. Close the tailgate
