Speakers Land Rover Range Rover L322

SPECIFICATIONS

TORQUE SPECIFICATIONS

Scheme 67

Scheme 68

The speaker configuration depends on the level of audio unit fitted to the vehicle. Three systems are available; DSP, Logic7 and Logic7 HD Premium. The following details the speaker configuration and control for each system.

Scheme 69

The Digital Sound Processor (DSP) amplifier is located in the rear left-hand (LH) side of the luggage compartment. The DSP amplifier drives 11 speakers; two front door mid-range, four front and rear door bass, four front and rear door tweeters on eight channels and a passive subwoofer. The amplifier produces 320 Watts of digital amplification to power the speakers.

Scheme 70

The Logic7 and Logic7 HD 1200W Premium system amplifiers are located in the rear left-hand (LH) side of the luggage compartment.

Logic7 System

The Logic7 amplifier drives 14 speakers on 5.1 surround channels; two front door mid-range, four front and rear door bass woofers, two front and rear door tweeters on eight channels and a passive subwoofer as on the DSP system, but with two additional surround sound speakers located in the upper tail door and a center surround speaker located in the fascia.

The Logic 7 system amplifier produces 720W of digital amplification to power the speakers.

Logic7 HD 1200W Premium System

The Logic7 HD 1200W Premium system amplifier drives 19 speakers on 5.1 surround channels; two front door mid-range, two front door bass woofers, two front mid range, two front tweeters, two rear door bass woofers, two rear door co-axial mid-high range, a passive subwoofer as on the DSP system, with a co-axial surround sound speaker located in each E pillar and a center co-axial surround speaker located in the instrument panel.

The Logic7 HD 1200W Premium system amplifier produces 1200 Watts of digital amplification to power the speakers.

Scheme 71

Scheme 72

Scheme 73

1. Remove the front door trim panel. Refer to «Front Door Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
2. Remove the front door speaker wiring harness.
3. Remove the front door speaker. Remove the 4 screws. Disconnect the electrical connector.

INSTALLATION

1. Install the front door speaker. Connect the electrical connector. Install the screws.
2. Install the front door speaker wiring harness.
3. Install the front door trim panel. Refer to «Front Door Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.

Scheme 74

1. Remove the rear door trim panel. Refer to «Rear Door Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
2. Remove the speaker. Disconnect the electrical connector. Remove the 4 screws.

1. Install the speaker Tighten the screws. Connect the electrical connector.
2. Install the rear door trim panel. Refer to «Rear Door Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .

Scheme 75

Scheme 76

1. Remove the instrument panel center speaker grille.
2. Remove the instrument panel speaker. Remove the 3 screws. Disconnect the electrical connector.

1. Install the instrument panel speaker. Connect the electrical connector. Tighten the 3 screws.
2. Install the instrument panel center speaker grille.

REMOVAL

Note. The procedure to remove the quarter panel speaker is shown in the D-pillar trim panel procedure.

1. Remove the D-pillar trim panel. Refer to «D-Pillar Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .

1. Install the D-pillar trim panel. Refer to «D-Pillar Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .

Scheme 77

1. Remove the tailgate trim panel. Refer to «Tailgate Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
2. Remove the tailgate speaker assembly. Remove the 10 Torx bolts. Disconnect the 2 electrical connectors.
3. Remove the tailgate speaker. Remove the 6 bolts.

1. Install the tailgate speaker. Tighten the bolts to 10 Nm (7 lb.ft).
2. Install the tailgate speaker assembly. Connect the electrical connectors. Tighten the Torx bolts to 10 Nm (7 lb.ft).
3. Install the tailgate trim panel. Refer to «Tailgate Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

1. Refer to «FRONT DOOR TRIM PANEL - REMOVAL AND INSTALLATION»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation)

Scheme 83

Scheme 84

Scheme 85

Scheme 86

1. See figure.
2. See figure.
3. See figure.
4. See figure.
5. Refer to «FRONT DOOR TRIM PANEL - REMOVAL AND INSTALLATION»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation)
