Audio Unit Land Rover Range Rover L322

SPECIFICATIONS

TORQUE SPECIFICATIONS

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. Disconnect the battery ground cable. For additional information, refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
2. Remove the information and entertainment module. For additional information, refer to «Information and Entertainment Module»(/land-rover/range-rover/l322-2009-2012/remont/communication-devices/#multifunction-electronic-modules) .
3. Release the information and entertainment assembly. Remove the 5 bolts. Remove the 2 nuts.
4. Reposition the information and entertainment assembly for access. Disconnect the 2 coaxial cable connectors. Disconnect the 3 electrical connectors. Disconnect the 3 optical connectors. CAUTION: Cover fiber optic cable connectors to minimize dust ingress and avoid bending the cables in a radius of less than 30 mm.
5. Remove the information and entertainment assembly.
6. Remove the satellite radio tuner (NAS variants only). Disconnect the optical connector. Disconnect the electrical connector. Remove the bolt. CAUTION: Cover fiber optic cable connectors to minimize dust ingress and avoid bending the cables in a radius of less than 30 mm.
7. Release the audio unit amplifier and television (TV) receiver assembly. Remove the 2 bolts and 4 nuts securing the audio unit amplifier and TV receiver mounting bracket.
8. Disconnect the TV receiver connections. Disconnect the optical connector. Disconnect the 3 electrical connectors. CAUTION: Cover fiber optic cable connectors to minimize dust ingress and avoid bending the cables in a radius of less than 30 mm.
9. Disconnect the audio unit amplifier connections. Disconnect the audio unit amplifier 2 optical connectors. Disconnect the 3 electrical connectors. Release the wiring harness clip. CAUTION: Cover fiber optic cable connectors to minimize dust ingress and avoid bending the cables in a radius of less than 30 mm.
10. Remove the audio unit amplifier and TV receiver assembly.
11. Remove the audio unit amplifier. Remove the 4 bolts.

INSTALLATION

1. Install the audio unit amplifier to the mounting bracket. Tighten the bolts to 10 Nm (7 lb.ft).
2. Install the audio unit amplifier and TV receiver assembly. Connect the electrical connectors. Connect the optical connectors. Secure the wiring harness clip.
3. Secure the audio unit amplifier and TV receiver assembly. Tighten the nuts and bolts to 10 Nm (7 lb.ft).
4. Install the satellite radio tuner (NAS variants only). Tighten the bolt to 10 Nm (7 lb.ft). Connect the electrical connector. Connect the optical connector.
5. Install the information and entertainment assembly. Connect the coaxial cable connectors. Connect the electrical connectors. Connect the optical connector. Tighten the bolts to 10 Nm (7 lb.ft).
6. Install the information and entertainment module. For additional information, refer to «Information and Entertainment Module»(/land-rover/range-rover/l322-2009-2012/remont/communication-devices/#multifunction-electronic-modules) .
7. Connect the battery ground cable. For additional information, refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
8. Using the Land Rover approved diagnostic equipment, follow the on-screen instructions and configure the audio unit amplifier.

REMOVAL

Scheme 5

Scheme 6

1. Make the air bag supplemental restraint system (SRS) safe. For additional information, refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2009-2012/remont/dtc-index/#dtc-index-general-information) .
2. Disconnect the battery ground cable. For additional information, refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
3. Remove the upper glove compartment. For additional information, refer to «Upper Glove Compartment»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
4. Remove the compact disc (CD) changer. Remove the 3 screws.
5. Remove the bracket from the CD changer. Remove the 5 screws. NOTE: Do not disassemble further if the component is removed for access only. NOTE: Right-hand shown, left-hand similar.

1. Install the CD changer bracket. Install the 5 screws.
2. Install the CD changer. Install the 3 screws.
3. Install the upper glove compartment. For additional information, refer to «Upper Glove Compartment»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
4. Connect the battery ground cable. For additional information, refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .

Note. Some variation in the graphics may occur, but the essential information is always correct.

Scheme 7

Scheme 8

1. Make the air bag supplemental restraint system (SRS) safe. For additional information, refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2009-2012/remont/dtc-index/#dtc-index-general-information) .
2. Disconnect the battery ground cable. For additional information, refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
3. Remove the instrument panel upper section. For additional information, refer to «Instrument Panel Upper Section»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
4. Remove the 4 screws securing the integrated control panel (ICP) bracket to the instrument panel.
5. Remove the ICP assembly. Disconnect the electrical connectors. Disconnect the co-axial cables.
6. Remove the ICP from the ICP bracket. Remove the 4 screws. NOTE: Do not disassemble further if the component is removed for access only.

1. Install the ICP to the ICP bracket. Install the 4 screws.
2. Install the ICP assembly. Connect the electrical connectors. Connect the co-axial cables.
3. Install the screws securing the ICP to the instrument panel.
4. Install the instrument panel upper section. For additional information, refer to «Instrument Panel Upper Section»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
5. Connect the battery ground cable. For additional information, refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .

Note. Removal steps in this procedure may contain installation details.

Scheme 9

Scheme 10

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
2. Refer to «Bluetooth Module»(/land-rover/range-rover/l322-2009-2012/remont/communication-devices/#cellular-phone) .
3. Torque: 8 Nm

1. To install, reverse the removal procedure.
2. Using the diagnostic tool, follow the on-screen instructions and configure the satellite radio.

Scheme 11

1. Make the air bag supplemental restraint system (SRS) safe. For additional information, refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2009-2012/remont/dtc-index/#dtc-index-general-information) .
2. Disconnect the battery ground cable. For additional information, refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
3. Remove the driver air bag module. For additional information, refer to «Driver Air Bag Module»(/land-rover/range-rover/l322-2009-2012/remont/airbag/#supplemental-restraint-system) .
4. Remove the steering wheel audio controls. Disconnect the electrical connectors. Remove the 2 screws.

1. Install the steering wheel audio controls. Connect the electrical connectors. Install the 2 screws and tighten to 3 Nm (2 lb.ft).
2. Install the driver air bag module. For additional information, refer to «Driver Air Bag Module»(/land-rover/range-rover/l322-2009-2012/remont/airbag/#supplemental-restraint-system) .
3. Connect the battery ground cable. For additional information, refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
2. Refer to «Rear Quarter Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
3. Torque: 10 Nm
4. Torque: 10 Nm
5. Torque: 10 Nm
6. Torque: 10 Nm
7. Torque: 10 Nm CAUTION: Make sure that excessive force is not used. Failure to follow this instruction may result in damage to the vehicle. CAUTION: Take extra care not to damage the wiring harnesses.
8. Torque: 10 Nm

1. To install, reverse the removal procedure.
