Climate Control System - General Information Land Rover Range Rover L322

A/c Compressor 1 illustration ~482 words

SPECIFICATIONS

DescriptionSpecification
Air conditioning (A/C) refrigerantHFC 134a
A/C compressor oilND-OIL8 or Sanden SP10

LUBRICANTS, FLUIDS, SEALERS AND ADHESIVES

DescriptionGrammes
A/C refrigerant - vehicles fitted with 2 zone - vehicles with 3.6 diesel700
A/C refrigerant - vehicles fitted with 2 zone - vehicles with 5.0L750
A/C refrigerant - vehicles fitted with 4 zone - vehicles with 3.6 diesel880
A/C refrigerant - vehicles fitted with 4 zone - vehicles with 5.0L930

CAPACITIES

Note. Rotate the A/C compressor shaft at least 6 to 8 turns when draining the refrigerant oil.

ItemMilliliters
A/C condenser coreAdd 33
A/C evaporatorAdd 46
A/C compressor1. Drain old A/C compressor. With drain plug removed and ports uncapped, rotate shaft to remove A/C compressor oil and measure the amount of oil captured. 2. Drain new A/C compressor into a clean vessel. With drain plug removed and ports uncapped, rotate shaft to remove oil. Then add back a quantity of the new oil that is identical to the quantity of oil removed from the old A/C compressor. However, if this quantity is less than 30ml, then make it up to 30ml.
A/C lines - if air conditioning has been operational.Add 10 per A/C line
A/C system after flushing - with compressor included - vehicles fitted with 2 zone - vehicles with 3.6 dieselAdd 120
A/C system after flushing - with compressor included - vehicles fitted with 2 zone - vehicles with 5.0LAdd 110
A/C system after flushing - with compressor included - vehicles fitted with 4 zone - vehicles with 3.6 dieselAdd 170
A/C system after flushing - with compressor included - vehicles fitted with 4 zone - vehicles with 5.0LAdd 200
A/C system after flushing - without a new compressor installed - remaining A/C compressor oil is to be drained - vehicles fitted with 2 zone - vehicles with 3.6 dieselAdd 120
A/C system after flushing - without a new compressor installed - remaining A/C compressor oil is to be drained - vehicles fitted with 2 zone - vehicles with 5.0LAdd 110
A/C system after flushing - without a new compressor installed - remaining A/C compressor oil is to be drained - vehicles fitted with 4 zone - vehicles with 3.6 dieselAdd 170
A/C system after flushing - without a new compressor installed - remaining A/C compressor oil is to be drained - vehicles fitted with 4 zone - vehicles with 5.0LAdd 200
A/C system after flushing - vehicles fitted with 2 zone - with a new compressor installed - A/C compressor supplied with 120ml
A/C system after flushing - vehicles fitted with 2 zone - with a new compressor installed - A/C compressor supplied with 110ml
A/C system after flushing - vehicles fitted with 4 zone - with a new compressor installed - A/C compressor supplied with 120mlAdd 50
A/C system after flushing - vehicles fitted with 4 zone - with a new compressor installed - A/C compressor supplied with 110mlAdd 90

REFRIGERANT OIL ADDING CAPACITIES

PRINCIPLES OF OPERATION

For a detailed description of the Climate Control System and operation, refer to the relevant Description and Operation instructions. Refer to Air Distribution and Filtering or Refer to Air Distribution and Filtering . Refer to Heating and Ventilation . Refer to Auxiliary Heater and Refer to Air Conditioning . Refer to Auxiliary Climate Control and Refer to Control Components .

INSPECTION AND VERIFICATION

CAUTIONDiagnosis by substitution from a donor vehicle is NOT acceptable. Substitution of control modules does not guarantee confirmation of a fault, and may also cause additional faults in the vehicle being tested and/or the donor vehicle.
  1. Verify the customer concern.
  2. Visually inspect for obvious signs of mechanical or electrical damage. VISUAL INSPECTION Mechanical Electrical Coolant level Air vents (contaminated/blocked) Auxiliary drive belt condition and tension Air conditioning compressor Fuses Harnesses Electrical connector(s) Relays Control module(s) Control panel(s) Air conditioning compressor
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. If the cause is not visually evident, check for Diagnostic Trouble Codes (DTCs) and refer to the DTC Index.

DTC INDEX

For a list of Diagnostic Trouble Codes (DTCs) that could be logged on this vehicle, please refer to Diagnostic Trouble Code (DTC) Index - DTC: Module Name: Climate Control Module and Diagnostic Trouble Code (DTC) Index - DTC: Module Name: Rear Climate Control Module .

Scheme 1

Scheme 1: AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING (5.0L NA V8 - AJ133/5.0L SC V8 - AJ1
  1. Refrigerant recovery.
  2. See figure NOTE: Some variation in the illustrations may occur, but the essential information is always correct. Remove the dust covers from the high and low pressure connections.
  3. Connect the high and low pressure lines to the appropriate connections.
  4. Following the manufacturer's instructions, recover the refrigerant from the A/C system. Measure and record the quantity of refrigerant oil recovered from the system.
  5. Disconnect the high and low pressure connections.
  6. Evacuation.
  7. Connect the high and low pressure lines to the appropriate connections.
  8. Following the manufacturer's instructions, evacuate the A/C system.
  9. Refer to «Receiver Drier - 5.0L NA V8 - AJ133»(/land-rover/range-rover/l322-2009-2012/remont/automatic-hvac-system/#air-conditioning) and «Receiver Drier - 5.0L SC V8 - AJ133»(/land-rover/range-rover/l322-2009-2012/remont/automatic-hvac-system/#air-conditioning) .
  10. Recharging
  11. Ensure the correct amount of oil is added to the A/C system before or during recharging.
  12. Recharge the A/C system to the correct specification. See «Specifications - 3.6L V8 - TdV8/5.0L NA V8 - AJ133/5.0L SC V8 - AJ133»(/land-rover/range-rover/l322-2009-2012/remont/ac-compressor/#climate-control-system-general-information__specifications) .
  13. Disconnect the high and low pressure connections.
  14. See figure NOTE: Some variation in the illustrations may occur, but the essential information is always correct. Install and firmly tighten the caps that cover the high and low pressure connections.
