Safety Belt System Land Rover Range Rover L322

Airbag 15 illustrations ~2816 words

SPECIFICATIONS

DescriptionNm
Safety belt retractor bolt31
Safety belt height adjuster nut31
Front safety belt upper anchor bolt50
Rear safety belt upper anchor bolt31
Safety belt guide bolt6
Front safety belt buckle bolt40
Rear safety belt buckle bolt25

TORQUE SPECIFICATIONS

Scheme 1

Scheme 1: SAFETY BELT SYSTEM
Scheme 1: SAFETY BELT SYSTEM
Item NumberDescription
1Height adjuster
2Buckle
3Anchor point
4Retractor

Scheme 2

Scheme 2
Scheme 2
Item NumberDescription
1Retractor
2Anchor point
3Outer belt buckle
4Outer and center belt buckles

GENERAL

Three point safety belts are installed at all seat positions. The front safety belts incorporate load limiters and have height adjusters on the B/C pillar. The rear outer safety belts have height adjusters on the D pillar.

On NAS vehicles, all passenger safety belts are the ALR (automatic locking retractor) type for use with child restraint systems.

A safety belt warning lamp and associated message are activated on the instrument cluster, by the lighting control module (LCM), at the beginning of each ignition cycle, as a reminder to fasten safety belts.

Child safety seat tether anchors are installed on the back of each rear outer seat.

PRINCIPLE OF OPERATION

For a detailed description of the safety belt system and operation, refer to the relevant description and operation instruction of the workshop information. Refer to Safety Belt System or Safety Belt System information.

SAFETY INFORMATION

WARNINGTo avoid accidental deployment the back-up power supply must be depleted before beginning any work on the SRS system or its components. Failure to follow this instruction may result in personal injury
WARNINGDo not use a multimeter to probe an SRS module. It is possible for the power from the multimeter battery to trigger the activation of the module. Failure to follow this instruction may result in personal injury

Note. Do not to use a cellular phone or to have a cellular phone in close proximity when working on the SRS system or components

Power supply depletion

Before beginning any work on the SRS system or related components

  1. Remove the ignition key
  2. Disconnect the battery leads, ground first
  3. Wait 2 minutes for the power circuit to discharge

There are comprehensive instructions on the correct procedures for SRS system repairs, refer to the relevant instruction of the workshop information

INSPECTION AND VERIFICATION

CAUTIONDiagnosis by substitution from a donor vehicle is NOT acceptable. Substitution of control modules does not guarantee confirmation of a fault and may also cause additional faults in the vehicle being checked and/or the donor vehicle

Note. Check and rectify basic faults before beginning diagnostic routines including pinpoint tests

  1. Verify the customer concern by operating the safety belt
  2. Visually inspect for obvious signs of mechanical or electrical damage VISUAL INSPECTION Mechanical Electrical Check for the installation of non-standard accessories which may affect or obstruct the function of the safety belt system Frayed or damaged webbing Missing or damaged button stop Pretensioner(s) Buckles/Stalks Fuses Wiring harness fault Correct engagement of electrical connectors Loose or corroded connections Warning lamp bulb(s) Impact sensor(s) Buckle sensor(s) Pretensioner(s) Belt tension sensor(s) Restraints control module
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step
  4. If the cause is not visually evident, carry out the test methods described below, alternatively check for diagnostic trouble codes and refer to the relevant diagnostic trouble code index

For a complete list of all diagnostic trouble codes that could be logged on this vehicle, please refer to appropriate instructions. Refer to Diagnostic Trouble Code (DTC) Index - DTC: Restraints Control Module (RCM) information.

SYMPTOM CHART FOR SAFETY BELT ROWS 1, 2 AND 3

SymptomPossible CausesAction
Safety belt jammed - Webbing tightBacklock effect-in action (webbing retracted quickly and came to sudden stop) Safety belt retractor not installed correctly Rear center belt only. Mini-button (webbing travel limit stop) missing and seat squab has been moved causing tight fit Automatic locking retractor activated (clicking - during retraction only)Refer to Pinpoint Test A . Refer to Pinpoint Test F . Refer to Pinpoint Test H . See the automatic locking retractor description below
Seat squab will not fold/jammedNOTE: Rear center belt only Mini-button (webbing travel limit stop) missing and seat squab has been moved causing excessive tensionRefer to Pinpoint Test H .
Safety belt jammed - Webbing looseSafety belt webbing trapped in seat Safety belt retractor webbing guide loose Twist in webbing Interference in webbing routing D-loop not rotating correctlyRefer to Pinpoint Test B . Refer to Pinpoint Test C . Refer to Pinpoint Test D . Refer to Pinpoint Test E . Refer to Pinpoint Test G .
Safety belt - Intermittent jammingSafety belt retractor not installed correctlyRefer to Pinpoint Test F .
Safety belt - Slow retractionSafety belt retractor webbing guide loose Twist in safety belt webbing Interference in webbing routing Safety belt retractor not installed correctly D-loop not rotating correctly Foreign object/debrisRefer to Pinpoint Test C . Refer to Pinpoint Test D . Refer to Pinpoint Test E . Refer to Pinpoint Test F . Refer to Pinpoint Test G . Refer to Pinpoint Test E .
Safety belt - Not retractingSafety belt retractor webbing guide loose Twist in safety belt webbing D-loop not rotating correctly Interference in webbing routing Foreign object/debrisRefer to Pinpoint Test C . Refer to Pinpoint Test D . Refer to Pinpoint Test G . Refer to Pinpoint Test E . Refer to Pinpoint Test E .
Safety Belt - Not extractingBacklock effect-in action (webbing retracted quickly and came to sudden stop) Safety belt retractor not installed correctly Safety belt retractor webbing guide loose Twist in safety belt webbing D-loop not rotating correctly Interference in webbing routing Foreign object/debris Automatic locking retractor activated (clicking - during retraction only)Refer to Pinpoint Test A . Refer to Pinpoint Test F . Refer to Pinpoint Test C . Refer to Pinpoint Test D . Refer to Pinpoint Test G . Refer to Pinpoint Test E . Refer to Pinpoint Test E . See the automatic locking retractor description below
Safety belt - Noisy during operationAutomatic locking retractor activated (clicking-during retraction only) Interference in webbing routing (rubbing)Refer to Pinpoint Test B . Refer to Pinpoint Test E .
Safety belt buckle - Not latching / jammedForeign object/debrisCAUTION: Do not insert any objects or tools into the buckle head Refer to Pinpoint Test I .
NOTE
Rear center belt only
CAUTION
Do not insert any objects or tools into the buckle head

INERTIA REEL SAFETY BELTS

The vehicle is equipped with (two row one), (three row two), and (two row three (seven seat versions only)) inertia reel safety belts

These safety belts are "dual sensitive" which means that they have

  1. Car sense system - A vehicle motion sensor, which locks the safety belt webbing under braking, cornering, on steep hills and in adverse camber conditions, when parked on a steep incline or driveway or two wheels on a high curb
  2. Webb sense system - A webbing motion sensor, which locks when the safety belt webbing is extracted suddenly

The safety belts in the following positions are equipped with an automatic locking retractor function

CarlineMarketSeat positionAutomatic Locking Retractor InstalledFrom Model Year
Defender (L316)AllAllNo2007
Discovery / Range Rover Sport (L319/L320)AllDriverNo2008
Discovery / Range Rover Sport (L319/L320)USPassengerYes2005
Discovery / Range Rover Sport (L319/L320)AllDriverNo2005
Discovery / Range Rover Sport (L319/L320)ROWPassengerNo2005
Discovery (L319)AllRow 2Yes2005
Discovery (L319)AllRow 3Yes2005
Range Rover Sport (L320)AllRow 2Yes2006
Freelander (L359)AllDriverNo2007
Freelander (L359)ROWPassengerNo2007
Freelander (L359)USPassengerYes2007
Freelander (L359)ROWRow 2No2007
Freelander (L359)USRow 2Yes2007
Range Rover Evoque (L358)AllDriverNo2011
Range Rover Evoque (L358)ROWPassengerNo2011
Range Rover Evoque (L358)USPassengerYes2011
Range Rover Evoque (L358)ROWRow 2No2011
Range Rover Evoque (L358)USRow 2Yes2011
Range Rover (L322)AllDriverNo2003
Range Rover (L322)ROWPassengerNo2003
Range Rover (L322)USPassengerYes2003
Range Rover (L322)ROWRow 2No2003
Range Rover (L322)USRow 2Yes2003

The automatic locking retractor function is a feature to secure a child seat or heavy load to the seat

ActivationDeactivation
NOTE: When automatic locking retractor is activated, no further webbing can be drawn from the safety belt retractor, prior to disengagement of the automatic locking. This can be mistaken as a jammed safety belt retractor Activated by total extraction of the webbingAutomatic locking retractor is deactivated by allowing the webbing to retract until the clicking stops (close to park position)
When activated the automatic locking retractor is identified by a clicking noise during webbing retractionWhen deactivated the automatic locking retractor safety belt changes state, from a static safety belt to an automatic safety belt
NOTE
When automatic locking retractor is activated, no further webbing can be drawn from the safety belt retractor, prior to disengagement of the automatic locking. This can be mistaken as a jammed safety belt retractor

SAFETY BELT LOCKING TEST

With the vehicle stationary and on level ground take firm hold of the safety belt webbing (on the tongue side of the upper safety belt anchor) and withdraw sharply, the retractor should lock . Preventing further webbing release (repeat this test 3 times) . Any safety belt retractor which fails to lock must not be used and a new safety belt must be installed .

DTC INDEX

For a list of diagnostic trouble codes that could be logged on this vehicle, please refer to appropriate removal and installation/description and operation.

Pinpoint Test A: Backlock

Pinpoint Test A

A1 Backlock
  1. Visually inspect the condition of the suspect safety belt
  2. Draw a maximum of 20 mm of the webbing from the safety belt retractor with moderate force. Then release the webbing
  3. Check for correct operation twice
Does the webbing move freely then retract correctly?
YES No further action required
NO For first row safety belt Refer to «Pinpoint Test C»(ref-514900-S29947608192012112600000) . For second and third row safety belts Refer to «Pinpoint Test B»(ref-514900-S24325758392012112600000) .

Pinpoint Test B: Webbing-Trapped In Seat

Pinpoint Test B

B1 Webbing-Trapped In Seat
  1. Visually inspect the condition of the suspect safety belt
  2. Lift the seat base or release the seat backrest as required
  3. Check for correct operation twice
Does the webbing move freely then retract correctly?
YES No further action required
NO Refer to «Pinpoint Test C»(ref-514900-S29947608192012112600000) .

Pinpoint Test C: Safety Belt Retractor-Webbing Guide Loose

Pinpoint Test C

C1 Safety Belt Retractor-Webbing Guide Loose
  1. Refer to appropriate removal and installation instructions of the workshop information, remove any trim panels required to expose the D loop (anchor point) and safety belt retractor.
  2. Check the webbing is not trapped or twisted and is centrally located on the safety belt retractor spindle.
  3. To release the automatic locking retractor, manually wind the webbing onto the spindle until the automatic locking retractor deactivates (clicking stops)
  4. Fully extract webbing
  5. Confirm webbing guide location is correct, confirm the fixing lugs are correctly located in the retractor frame
  6. Allow webbing to retract
  7. Check for correct operation twice
Does the webbing move freely then retract correctly?
YES Refer to the appropriate removal and installation instructions of the workshop information, reinstall any trim panels, ensure there are no obstructions and the webbing does not catch or rub. No further action required
NO Refer to «Pinpoint Test D»(ref-514900-S30235309072012112600000) .

Pinpoint Test D: Twist In Webbing

Pinpoint Test D

D1 Twist In Webbing
  1. Refer to appropriate removal and installation instruction of the workshop information, remove any trim panels required to expose the D loop (anchor point)
  2. Twist the webbing back the correct way in the loop
  3. Pass the twist through the pillar loop or escutcheon as required
  4. Check for correct operation twice
Does the webbing move freely then retract correctly?
YES Refer to the appropriate removal and installation instructions of the workshop information, reinstall any trim panels, ensure there are no obstructions and the webbing does not catch or rub. No further action required
NO Refer to «Pinpoint Test E»(ref-514900-S20281577352012112600000) .

Pinpoint Test E: Interference-Webbing Routing

Pinpoint Test E

E1 Interference-Webbing Routing
  1. Refer to the appropriate removal and installation instruction of the workshop information, remove any trim panels required to expose the D loop (anchor point)
  2. Remove obstructions and foreign objects ensure the webbing does not catch or rub
  3. Confirm the safety belt does not contact the wiring harness
  4. Check for correct operation twice
Does the webbing move freely then retract correctly?
YES Refer to the appropriate removal and installation instructions of the workshop information, reinstall any trim panels, ensure there are no obstructions and the webbing does not catch or rub. No further action required
NO Refer to «Pinpoint Test F»(ref-514900-S38607011722012112600000) .

Pinpoint Test F: Safety Belt Retractor-Incorrect Installation

Pinpoint Test F

F1 Safety Belt Retractor-Incorrect Installation
  1. Refer to the appropriate removal and installation instructions of the workshop information, remove any trim panels required to expose the D loop (anchor point) and the safety belt retractor
  2. Refer to the appropriate removal and installation instructions of the workshop information, correctly reinstall the safety belt retractor ensure that the locating "T bar" and "anti rotation pins" are correctly located
  3. Check for correct operation twice
Does the webbing move freely then retract correctly?
YES Refer to the appropriate removal and installation instructions of the workshop information, reinstall any trim panels, ensure there are no obstructions and the webbing does not catch or rub. No further action required
NO Replace as required. Refer to the warranty policy and procedures information, or determine if any prior approval program is in operation, prior to the installation of a new module/component

Pinpoint Test G: D-loop Not Rotating Correctly

Pinpoint Test G

G1 D-loop Not Rotating Correctly
  1. Refer to the appropriate removal and installation instruction of the workshop information, remove any trim panels required to expose the D loop (anchor point) and the safety belt retractor
  2. Ensure there are no obstructions and the webbing does not catch or rub, the D loop (anchor point) rotates correctly and if installed the confirm the height adjuster operates correctly
  3. Check for correct operation twice
Does the webbing move freely then retract correctly?
YES Refer to the appropriate removal and installation instruction of the workshop information, reinstall any trim panels, ensure there are no obstructions and the webbing does not catch or rub. No further action required
NO Replace as required. Refer to the warranty policy and procedures information, or determine if any prior approval program is in operation, prior to the installation of a new module/component

Pinpoint Test H: Mini Button-Missing/Damaged

Pinpoint Test H

H1 Mini Button-Missing/Damaged
  1. NOTE: This test applies to the rear center safety belt retractor installed in the seat back
  2. Refer to the appropriate removal and installation instruction of the workshop information, remove the seat cushion and the plastic escutcheon at the top of the seat back (where the webbing exits to expose the lower anchor fixing point of the center safety belt)
  3. Remove the lower anchorage of the safety belt
  4. With the seat back correctly latched, allow up to 20 mm webbing to retract, then extract the webbing
Is the mini-button (webbing travel limit stop) correctly installed to the webbing and in good condition?
YES Feed the mini-button back through the plastic escutcheon if required. Correctly reinstall the escutcheon to the seat back, extract the webbing then allow to retract, ensure the mini-button comes to rest outside the escutcheon stop
NO Replace as required. Refer to the warranty policy and procedures information, or determine if any prior approval program is in operation, prior to the installation of a new module/component

Pinpoint Test I: Safety Belt Buckle-Not Latching/Jammed

Pinpoint Test I

I1 Safety Belt Buckle-Not Latching/Jammed
  1. CAUTION: Do not insert any objects or tools into the buckle head
  2. Visually inspect the buckle head for evidence of damage. If damaged replace as required
  3. Depress the buckle release (red button) and (Using a torch) carry out visual inspection for any evidence of debris/material or foreign objects in the buckle head
  4. If required remove the pretensioner from the vehicle. Remove the seat. Remove the pretensioner from the seat frame
  5. Do not insert any objects or tools buckle head With the buckle removed invert and attempt to shake out any debris
  6. Attempt to latch the tongue in the buckle
  7. Does the seat belt buckle operate correctly
YES Reinstall any components, no further action required
NO Replace the pretensioner, Refer to appropriate instructions.

REMOVAL

WARNINGPersons working on the supplemental restraint system (SRS) must be fully trained and have been issued with the safety guidelines.
WARNINGAllow a period of 10 minutes to elapse after disconnecting the battery before undertaking any work on the SRS.
WARNINGThe SRS electrical connectors are unique. DO NOT force, or attempt to connect electrical connectors to the wrong sockets.
WARNINGThe correct procedures must always be used when working on SRS components.
WARNINGIt is imperative that before any work is undertaken on the SRS system, the appropriate information is read thoroughly.
WARNINGAlways disconnect both battery cables before beginning work on the SRS system. Disconnect the ground cable first. Never reverse connect the battery.
WARNINGTake extra care when handling SRS components.

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) information.
  2. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2009-2012/remont/dtc-index/#dtc-index-general-information) information.
  3. Remove the front seat. Refer to «Front Seat»(/land-rover/range-rover/l322-2009-2012/remont/seats/#seating) information.
  4. Release the 2 lower tension straps from the front seat base. Reposition the front seat backrest cover for access.
  5. Remove the front seat side trim panel support. Release the 2 clips.
  6. Remove the front seat backrest hinge cover. Remove the 2 screws. Release the clip.
  7. Disconnect the front safety belt buckle electrical connector. Release the wiring harness clip.
  8. Remove the front safety belt buckle. Remove and discard the bolt.

Scheme 7

Scheme 7: INSTALLATION
Scheme 7: INSTALLATION
  1. Install the front safety belt buckle. Install a new bolt and tighten to 40 Nm (30 lb.ft).
  2. Connect the front safety belt buckle electrical connector. Secure the wiring harness clip.
  3. Reposition the front safety belt buckle wiring harness.
  4. Install the front seat backrest hinge cover. Secure the clip. Install the 2 screws.
  5. Install the front seat side trim panel support. Secure the 2 clips.
  6. Secure the 2 lower tension straps to the front seat base. Reposition the front seat backrest cover.
  7. Install the front seat. Refer to «Front Seat»(/land-rover/range-rover/l322-2009-2012/remont/seats/#seating) information.
  8. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) information.

Scheme 8

Scheme 8: REMOVAL
Scheme 8: REMOVAL
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) information.
  2. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2009-2012/remont/dtc-index/#dtc-index-general-information) information.
  3. Remove the B-pillar trim panel. Refer to «B-Pillar Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) information.
  4. Remove the safety belt guide. Remove the 2 bolts.
  5. Release the safety belt from the safety belt shoulder height adjuster. Remove and discard the nut.
  6. Remove the front safety belt. Release the front safety belt retractor. Remove and discard the bolt.

INSTALLATION

  1. Install the front safety belt. Secure the front safety belt retractor. Install the new bolt and tighten to 31 Nm (23 lb.ft).
  2. Secure the safety belt to the safety belt shoulder height adjuster. Install the new nut and tighten to 31 Nm (23 lb.ft.).
  3. Install the safety belt guide. Tighten the bolts to 6 Nm (4.4 lb.ft).
  4. Install the B-pillar trim panel. Refer to «B-Pillar Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) information.
  5. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) information.

Scheme 9

Scheme 9: REMOVAL
Scheme 9: REMOVAL

Scheme 10

Scheme 10
Scheme 10
  1. Fold the rear seat fully forwards. Release the rear seat backrest catch.
  2. Remove the rear seat backrest inner hinge cover. Remove the 3 screws.
  3. Remove the rear seat backrest inner hinge. Remove the 4 bolts. Discard the 2 lower bolts.
  4. Remove the rear safety belt buckle. Remove and discard the bolt.
  1. Install the rear safety belt buckle. Install the new bolt and tighten to 25 Nm (18 lb.ft).
  2. Install the rear seat backrest inner hinge. Install the 2 upper bolts. Install the 2 new lower bolts. Tighten the bolts to 25 Nm (18 lb.ft).
  3. Install the rear seat backrest inner hinge cover. Install the 3 screws.
  4. Fold the rear seat fully rearwards. Secure the rear seat backrest catch.

Scheme 11

Scheme 11: REMOVAL
Scheme 11: REMOVAL
  1. Remove the rear seat. Refer to «Rear Seat»(/land-rover/range-rover/l322-2009-2012/remont/seats/#seating) information.
  2. Remove the rear seat backrest cover. Refer to «Rear Seat Backrest Cover»(/land-rover/range-rover/l322-2009-2012/remont/seats/#seating) information.
  3. Remove the rear center safety belt retractor. Remove and discard the bolt.
  1. Install the rear center safety belt retractor. Install the new bolt and tighten to 25 Nm (18 lb.ft).
  2. Install the rear seat backrest cover. Refer to «Rear Seat Backrest Cover»(/land-rover/range-rover/l322-2009-2012/remont/seats/#seating) information.
  3. Install the rear seat. Refer to «Rear Seat»(/land-rover/range-rover/l322-2009-2012/remont/seats/#seating) information.

Scheme 12

Scheme 12: REMOVAL
Scheme 12: REMOVAL

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14
  1. Remove the rear seat. Refer to «Rear Seat»(/land-rover/range-rover/l322-2009-2012/remont/seats/#seating) information.
  2. Remove the rear seat backrest inner hinge cover. Remove the 3 screws.
  3. Remove the rear seat backrest outer hinge cover. Remove the 2 screws.
  4. Remove the rear seat base lower trim panel. Remove the 6 clips. Reposition the rear seat hinge plates for access.
  5. Release the rear seat cushion cover from the rear seat base.
  6. Reposition the rear seat cushion and seat cushion cover for access.
  7. Remove the LH rear safety belt buckle. Remove and discard the bolt.
  1. Install the LH rear safety belt buckle. Install the new bolt and tighten to 25 Nm (18 lb.ft).
  2. Reposition the rear seat cushion and seat cushion cover for access.
  3. Secure the rear seat cushion cover to the rear seat base.
  4. Install the rear seat base lower trim panel. Install the 6 clips. Reposition the rear seat hinge plates for access.
  5. Install the rear seat backrest outer hinge cover. Remove the 2 screws. Install the 2 screws.
  6. Install the rear seat backrest inner hinge cover. Install the 3 screws.
  7. Install the rear seat. Refer to «Rear Seat»(/land-rover/range-rover/l322-2009-2012/remont/seats/#seating) information.

Scheme 15

Scheme 15: REMOVAL
Scheme 15: REMOVAL
  1. Remove the C-pillar trim panel. Refer to «C-Pillar Upper Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) information.
  2. Release the safety belt upper anchor. Remove and discard the bolt.
  3. Remove the rear safety belt. Remove and discard the bolt. Release the rear safety belt retractor.
  1. Install the rear safety belt. Secure the safety belt retractor. Install the new bolt and tighten to 31 Nm (23 lb.ft).
  2. Secure the safety belt upper anchor. Install the new bolt and tighten to 31 Nm (23 lb.ft).
  3. Install the C-Pillar trim panel. Refer to «C-Pillar Upper Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) information.

More articles — Restraints
