| Ride height | |
| Off road | 55 mm (2.1 in) above standard |
| Access - reselectable while vehicle is moving | 40 mm (1.6 in) below standard |
| High speed mode - non-selectable | 20 mm (0.8 in) below standard |
| Trim height | Configured using the Land Rover approved diagnostic system |
| Height sensors | |
| Location | Mounted to front and rear subframes with mechanical linkage to suspension lower arms |
| Height sensor arm color coding | |
| Left hand side, front and rear | WHITE |
| Right hand side, front and rear | BLACK |
| Height sensor operating voltages | |
| Supply voltage | 5 volts - supplied by air suspension control module |
| Output voltage | Left-hand and right-hand rear: Voltage decreases with compression and increases with rebound Left-hand and right-hand front: Voltage increases with compression and decreases with rebound |
| Spring/damper module types | |
| Front | Unguided air spring surrounding twin tube damper |
| Rear | Unguided air spring, separate mono-tube damper |
| Pressures | |
| Normal - Front | 800 to 1000 kPa (8.0 to 10.0 bar) (116.0 to 145.0 lbf/in 2 ) |
| Normal - Rear | 500 to 800 kPa (5.0 to 8.0 bar) (72.5 to 116.0 lbf/in 2 ) |
| Air supply unit | Comprises a piston compressor, 12 volt electric motor, solenoid operated exhaust pilot valve, pressure relief valve, air dryer unit and two silencers |
| Controlled by | Air suspension control module |
| Working pressure | 1450 kPa (14.5 bar) (210.3 lbf/in 2 ) |
| Maximum pressure | 2700 kPa (27 bar) (391.6 lbf/in 2 ) |
| Air reservoir | |
| Volume | 10.2 liters (622 cu.in) |
| Nominal working pressure | 1440-1550 kPa (14.4-15.5 bar) (208.85-224.8 lbf/in 2 ) |
| Maximum operating pressure | 2200 kPa (22 bar) (319 lbf/in 2 ) |
| Reservoir valve block | Incorporates pressure sensor to monitor spring and air reservoir pressures |
| Valve blocks | |
| Front | 2 corner valves, 1 cross link valve - all mounted at rear of right-hand front wheel arch behind liner |
| Rear | 2 corner valves, 1 cross link valve - all mounted at right-hand rear wheel arch behind liner, adjacent to the fuel filler pipe |
