Intake Air Distribution and Filtering (4.2l) Land Rover Range Rover L322

SPECIFICATIONS

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

AIR INTAKE SYSTEM

The 4.2 Liter V8 supercharger (SC) engine air intake and distribution system comprises

1. Air filter box
2. Air intake
3. Porus duct
4. Air filter and filter box
5. Intake duct
6. Electronic throttle.

AIR FILTER BOX

The air filter box is located in the front of the engine bay on the inside of the right-hand (RH) front wing. Air is drawn from the air intake in the wing through a porous duct and into the air filter box. The filter box contains a paper air filter element.

AIR INTAKE DUCT

The air intake duct runs from the throttle body to the air filter box. The duct comprises 2 separate pieces. One piece runs from the air filter box to the front of the engine and the other from the front of the engine to the rear of the engine locating on the throttle body. The front half is manufactured from plastic and incorporates a number of resonator chambers. The rear part of the duct is manufactured from cast aluminum.

Scheme 1

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Disconnect the air intake resonator. Release the clip.
3. Disconnect the mass air flow (MAF) sensor electrical connector.
4. Remove the air cleaner assembly. Release the breather hose. Release from the 3 grommets.

INSTALLATION

1. To install, reverse the removal procedure.

Scheme 2

1. Disconnect the battery ground cable.
2. Release the air cleaner housing cover. Remove the 6 screws.
3. Remove the air cleaner element.
4. Clean the base of the air cleaner.

1. To install, reverse the removal procedure.

REMOVAL

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Raise and support the vehicle.
3. Remove the coolant manifold. Refer to «coolant manifold»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l) .
4. Remove the throttle body elbow. See «THROTTLE BODY ELBOW»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
5. Position the throttle body intake spigot and wiring harness aside. Remove the bolt.
6. Remove the supercharger. Remove the 3 bolts.

1. Install the supercharger. Clean the component mating faces. Clean the locating dowels. Tighten the bolts to 25 Nm (18 lb.ft).
2. Install the throttle body intake spigot. Tighten the bolt to 25 Nm (18 lb.ft).
3. Install the throttle body elbow. See «THROTTLE BODY ELBOW»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
4. Install the coolant manifold. Refer to «coolant manifold»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l) .
5. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
6. Refill and bleed the cooling system.

Scheme 3

Scheme 4

Scheme 5

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Remove the air intake resonator. See «INTAKE AIR RESONATOR»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
3. Position the wiring harness aside. Remove the 2 bolts.
4. Remove the throttle body intake. Disconnect the breather line. Release the clip. Release the bushing.
5. Remove the supercharger outlet pipe. Remove the 8 bolts. Disconnect the vacuum line. Release the clip. Discard the gasket.
6. Remove the charge air cooler intake ducts. Remove the 4 nuts.

1. Install the charge air cooler intake ducts. Clean the component mating faces. Tighten the nuts to 10 Nm (7 lb.ft).
2. Install the supercharger outlet pipe. Clean the component mating faces. Install a new gasket. Tighten the bolts to 10 Nm (7 lb.ft). Secure the hose with the clip. Connect the vacuum line.
3. Install the throttle body intake. Clean the component mating faces. Align the bushing. Secure the clip. Connect the breather line.
4. Attach the wiring harness. Tighten the bolts to 10 Nm (7 lb.ft).
5. Install the air intake resonator. See «INTAKE AIR RESONATOR»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
6. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Remove the engine cover. Refer to «Engine Cover - 4.2L, Vehicles With: Supercharger»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
3. Remove the air cleaner outlet pipe and intake air resonator. Release the 2 mounting clips.

1. To install, reverse the removal procedure.

Scheme 6

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Raise and support the vehicle.
3. Remove the supercharger. See «SUPERCHARGER»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
4. Disconnect the charge air cooler coolant hoses. Position an absorbent cloth to collect fluid spillage. Release the 2 clips.
5. Remove the charge air cooler. Remove the 8 Torx screws. Discard the gasket.

1. Install the charge air cooler. Clean the component mating faces. Install a new gasket. Tighten the Torx screws to 10 Nm (7 lb.ft).
2. Connect the charge air cooler coolant hoses. Secure with the clips.
3. Install the supercharger. See «SUPERCHARGER»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
4. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 7

Scheme 8

Scheme 9

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Raise and support the vehicle.
3. Remove the supercharger. See «SUPERCHARGER»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
4. Release the coolant hose support bracket. Remove the Torx screw.
5. Disconnect the charge air cooler coolant hoses. Position an absorbent cloth to collect fluid spillage. Release the 2 clips.
6. Disconnect the intake air temperature (IAT) sensor electrical connector.
7. Remove the charge air cooler. Remove the 8 Torx screws. Discard the gasket.
8. Remove the intake air temperature (IAT) sensor. Remove the 2 Torx screws. Remove and discard the O-ring seal.

1. Install the IAT sensor. Clean the components. Install a new O-ring seal. Tighten the Torx screws to 6 Nm (4 lb.ft).
2. Install the charge air cooler. Clean the component mating faces. Install a new gasket. Tighten the Torx bolts to 10 Nm (7 lb.ft).
3. Connect the IAT sensor electrical connector.
4. Connect the charge air cooler coolant hoses. Secure with the clips.
5. Attach the coolant hose support bracket. Tighten the Torx screw to 10 Nm (7 lb.ft).
6. Install the supercharger. See «SUPERCHARGER»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
7. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 10

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Partially drain the cooling system. Refer to «Supercharger Cooling System Draining, Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/blowers-superchargers-turbochargers/#supercharger-cooling) .
3. Remove the supercharger outlet pipe. See «SUPERCHARGER OUTLET PIPE»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
4. Disconnect the throttle position (TP) sensor electrical connector.
5. Disconnect the coolant hoses from the throttle body. Clamp the throttle body coolant hoses to minimize coolant loss. Release the 2 clips.
6. Remove the throttle body. Remove the 4 bolts. Remove and discard the gasket.
7. Disconnect the brake booster vacuum hose quick release connector.
8. Disconnect the supercharger fuel tank purge line quick release connector. Release the dust seal.
9. Disconnect the supercharger engine breather line. With assistance release the clip.
10. Disconnect the manifold absolute pressure (MAP) sensor electrical connector.
11. Remove the throttle body elbow. Remove the 6 bolts. Remove and discard the O-ring seals. Discard the gasket.
12. Remove the MAP sensor. Remove the Allen screw. Discard the O-ring seal.
13. Remove the supercharger pressure relief actuator. Remove the bolt. Disconnect the actuator link. Remove the vacuum line.

1. Install the supercharger pressure relief actuator. Clean the component mating faces. Connect the actuator link. Tighten the bolt to 10 Nm (7 lb.ft). Connect the vacuum line.
2. Install the MAP sensor. Clean the component mating faces. Install a new O-ring seal. Tighten the Allen screw to 3 Nm (2 lb.ft).
3. Install the throttle body elbow. Clean the component mating faces. Install a new gasket. Install new O-ring seals. Tighten the bolts to 25 Nm (18 lb.ft).
4. Connect the MAP sensor electrical connector.
5. Connect the supercharger engine breather line. Clean the component mating faces.
6. Connect the supercharger fuel tank purge line. Clean the component mating faces. Replace the dust seal.
7. Connect the brake booster vacuum hose.
8. Install the throttle body. Clean the components. Install a new gasket. Tighten the bolts to 10 Nm (7 lb.ft).
9. Connect the coolant hoses to the throttle body. Secure with the clips. Remove the hose clamps.
10. Connect the TP sensor electrical connector.
11. Install the supercharger outlet pipe. See «SUPERCHARGER OUTLET PIPE»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
12. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
13. Refill and bleed the cooling system. Refer to «Supercharger Cooling System Draining, Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/blowers-superchargers-turbochargers/#supercharger-cooling) .
