Power Steering Land Rover Range Rover L322

SPECIFICATIONS

POWER STEERING FLUID

GENERAL SPECIFICATION

TORQUE SPECIFICATIONS

* New nut(s) must be installed

+ New cage nuts must be installed

** New 'Patchlok' bolt must be installed

++ New sealing washers must be installed

Scheme 1

Note. TDV8 shown, V8 similar

INTRODUCTION

A ZF power steering gear is fitted on the front subframe. The unit is a conventional end take-off rack and pinion power assisted unit with the addition of ZF Servotronic 2 assistance.

Servotronic 2 adds electronic control and speed sensitive steering to the steering gear. The Servotronic 2 feature provides easy and comfortable steering operation when parking, improved 'road feel' at increased road speeds and adds an integrated, positive center feel feature which optimizes steering wheel torque during high speed driving.

The Servotronic 2 system is controlled by software which is incorporated into the generic electronic module (GEM). The software responds to steering torque inputs and road speed signals and controls the assistance via a transducer valve located on the steering gear valve.

Scheme 2

The steering system comprises the mechanical steering gear, the valve and an integrated hydraulic power cylinder.

The steering gear uses a rack with an integrated piston which is guided on plain bearings within the gear housing. The pinion, which is attached to the valve runs in bearings and meshes with the rack teeth. The rack is pressed against the pinion by a spring loaded yoke which ensures that the teeth mesh without any play. The pinion is connected to the valve rotor via a torsion bar.

The rotary motion of the steering wheel is converted into axial movement of the rack by the pinion and is initiated by the valve. This motion is transferred into movement of the wheels by adjustable tie rod arms.

The rotary valve is used to control the pressurized fluid required for power assistance. The valve comprises a valve body, a control bush and a torsion bar. The valve body has eight control grooves in its bore. The control bush also has eight radial grooves which are matched to the valve. The control bush is positively attached to the pinion. The torsion bar is the connecting element between the valve body, the pinion and the control bush.

Torque input from the steering wheel is passed to the valve body and causes a rotary motion of the torsion bar. The valve body changes its relative position to the control bush and subsequently the relative positions of the control grooves is also changed. This allows pressurized fluid to pass via the mismatched grooves to the rack piston and provide the required assistance in the selected direction.

The piston is located at one end of the rack housing. Each side of the piston is connected to fluid pressure or fluid return via a metal external pipe which is connected to the valve housing.

Each end of the rack has a threaded hole which provides for the fitment of an inner tie rod joint. The external ends of the rack are sealed with gaiters which prevent the ingress of dirt and moisture. The inner tie rod joints have a long outer threaded shank which screws into the outer tie rod. The steering toe can be adjusted using the threaded end of the inner tie rod. When the correct toe is achieved, a locknut on the inner tie rod is tightened to prevent further inadvertent movement.

SERVOTRONIC TRANSDUCER VALVE

The Servotronic transducer valve is located in a port on the side of the steering gear valve housing. The valve is sealed in the housing with an O-ring seal and is secured with two long screws into threaded holes in the housing.

The Servotronic valve is a transducer controlled valve which responds to control signals supplied from the generic electronic module (GEM). The generic electronic module (GEM) contains a microprocessor which receives road speed signals from the anti-lock brake system (ABS) module and calculates the correct controlling signal for the Servotronic valve. The Servotronic software within the generic electronic module (GEM) has a diagnostic capability which allows an approved Land Rover diagnostic system to check the tune of the steering.

The Servotronic valve determines the hydraulic reaction at the steering rack rotary valve and controls the input torque required to turn the steering wheel. The Servotronic system allows the steering to be turned with minimum effort when the vehicle is stationary or maneuvered at slow speed. The hydraulic reaction changes proportional to the vehicle speed, with the required steering effort increasing as the vehicle moves faster. At high speeds, the Servotronic system provides the driver with a good feedback through the steering providing precise steering and improved stability.

A major advantage of the Servotronic system is that fluid pressure and flow through the rotary valve remains constant and allows full steering pressure to be available in an emergency where a sudden and unexpected steering correction may be required.

The power steering pumps used are basically the same pump with different connection fitments, therefore they are not interchangeable. The pump is a positive displacement, vane type pump which supplies hydraulic pressure to the steering gear valve unit. The pump is driven by a Poly Vee belt from the crankshaft pulley and output from the pump increases proportionally with engine speed. A self-adjusting tensioner is fitted to maintain the correct tension on the belt.

The pump has an internal pressure relief valve which also incorporates a flow control valve. The pressure relief valve limits the maximum pressure supplied to the steering gear to 114 bar (1653 lbf in 2 ) ± 4 bar (58 lbf in 2 ). The flow control valve limits the maximum flow to 8.8 l/min (1.93 gal/min) ± 0.5 l/min (0.1 gal/min) regardless of engine speed. The pump has a displacement of 9.6 cc/rev (0.58 in 3 /rev).

A shaft runs longitudinally through the pump. One end of the shaft is fitted with a pressed-on drive pulley, the opposite end of the shaft is closed by a cover. The shaft runs in bearings located in the body and oil seals at each end of the shaft prevent leakage of hydraulic fluid.

The pump contains ten vanes which rotate within a cam ring and are driven by the shaft. As the vanes rotate, the cam ring causes the space between the vanes to increase. This causes a depression between the vanes and fluid is drawn from the reservoir via the suction hose into the space between the vanes.

As the shaft rotates, the inlet port is closed to the vanes which have drawn in fluid, trapping the fluid between the vanes. The cam ring causes the space between the vanes to reduce and consequentially compresses and pressurizes the hydraulic fluid trapped between them.

Further rotation of the shaft moves the vanes to the outlet port. As the vanes pass the port plate the pressurized fluid passes from the pump outlet port into the pressure hose to the steering gear.

The pressurized fluid is subject to control by the flow control and pressure relief valve. The flow control valve maintains a constant flow of fluid supplied to the steering gear irrespective of engine speed variations. The pressure relief valve controls the pressure on the output side of the pump. A metering orifice is included in the discharge port of the pump. If the pressure in the orifice reaches a predetermined level, a spring loaded ball in the center of the flow control valve is lifted from its seat and allows pressurized fluid to recirculate within the pump.

The pressure relief valve will operate if the discharge from the pump is restricted, i.e.; steering held on full lock. If the output from the pump is blocked, all output is recirculated through the pump. In this condition, as no fresh fluid is drawn into the pump from the reservoir, the fluid temperature inside the pump will increase rapidly. Consequentially, periods of operation of the steering gear on full lock should be kept to a minimum to prevent overheating of the pump and the fluid within it.

FLUID RESERVOIR

The fluid reservoir is located on the bonnet locking platform, adjacent the radiator. The reservoir comprises a body, cap and filter. The purpose of the reservoir is to contain a surplus of the hydraulic fluid in the system to allow for expansion and contraction of the fluid due to temperature variations. The fluid level ensures that the supply connection on the bottom of the reservoir is covered with fluid at all operating vehicle attitudes. Any air which is present in the system is exhausted from the system in the reservoir.

The body is a plastic moulding with two ports at the bottom which provide for the connection of the suction supply and return hoses. Moulded markings on the side of the reservoir denote the upper and lower fluid levels. A non-serviceable, 100 micron nylon mesh filter is fitted in the body. The filter removes particulate matter from the fluid before it is drawn into the pump supply connection.

The cap is rotated counterclockwise for one quarter turn to release from the body. The cap is fitted with an O-ring to prevent fluid leakage. The cap incorporates a breather hole to allow for changes in fluid level during operation and prevent vacuum or pressurization of the reservoir.

Scheme 3

Note. A = Hardwired connection; B = K Bus; C = Diagnostic DS2 Bus

HYDRAULIC CIRCUIT OPERATION

The following hydraulic circuits show power steering operation and fluid flow for the steering in a straight ahead, neutral position and when turning right. The circuit diagram for turning left is similar to that shown for turning right.

STEERING IN NEUTRAL POSITION

When the engine is started, the power steering pump draws fluid from the reservoir down the low pressure suction line. The fluid passes through the pump and is delivered, via a hose, to the steering rack valve unit.

The pressurized fluid flows through a connecting bore in the valve and, via the feed fluid radial groove and the transverse bores in the valve sleeve, passes to the feed fluid control groove of the valve rotor.

In the neutral (straight ahead) position, the fluid passes over the open feed fluid control edges to all valve sleeve axial grooves. The fluid then passes through the open return fluid control edges and the return fluid control grooves of the valve rotor. The fluid then passes via connecting bores to the return fluid chamber and to the reservoir via an external hose.

Simultaneously, the radial grooves of the valve body and their associated pipes provide a connection between the left and right power assist cylinders.

Scheme 4

When the steering wheel is turned to the right, the steering rack and piston moves to the left in the piston bore. The valve rotor is rotated to the right (clockwise) and pressurized fluid is directed over the further opened feed fluid control edges and to the associated axial grooves, the radial groove and via an external pipe to the left power assist cylinder chamber. The pressure applied to the piston from the left power assist cylinder chamber provides the hydraulic assistance.

An adaptable pressure build-up is achieved by the partially or fully closed feed fluid control edges restricting or preventing a connection between the fluid pressure inlet and the other axial grooves connected to the radial groove.

Simultaneously, the fluid pressure outlet to the pressurized axial grooves are restricted or partially restricted by the closing return fluid control edges. The fluid displaced by the piston from the right power assist cylinder chamber, flows through an external pipe to the radial grooves. From there the fluid passes to the associated axial grooves and on to the return fluid control grooves, via the further opened return fluid control edges. The return flow of fluid to the reservoir passes via interconnecting bores which lead to the return fluid chamber.

When the steering wheel is turned to the left the operating sequence is as above but the pressure is applied to the opposite side of the piston.

SERVOTRONIC OPERATION

When the vehicle is maneuvered into and out of a parking space (or other similar maneuver), the Servotronic function of the generic electronic module (GEM) uses road speed data from the anti-lock brake system (ABS) module to determine the vehicle speed, which in this case will be slow or stationary. The generic electronic module (GEM) microprocessor analyses the signals and outputs an appropriate control current to the Servotronic transducer valve. The Servotronic valve closes and prevents fluid flowing from the feed fluid radial groove to the reaction chamber. An orifice also ensures that there is return pressure in the reaction chamber. This condition eliminates any 'reaction' ensuring that the steering is very light to operate, reducing the effort required to turn the steering wheel.

As the vehicle is driven and the road speed increases, the generic electronic module (GEM) microprocessor analyses the road speed signals from the anti-lock brake system (ABS) module and reduces the amount of control current supplied to the Servotronic valve. The Servotronic valve reacts to the control current and opens the valve by an amount appropriate to the road speed. This allows a controlled fluid supply from the feed fluid radial groove to the reaction chamber. The orifice prevents the loss of large amounts of fluid to the return fluid chamber. The higher fluid pressure acting on the reaction piston causes compression of the balls which are located between the reaction piston and the centering piece which in turn is securely connected to the valve sleeve. When driving in a straight line, this has a positive effect on the exact centralizing of the steering valve. When the steering valve is actuated, the balls, with a higher load on them, provide additional torsional resistance to rotation of the valve rotor. This mode of Servotronic assistance requires an established higher steering wheel torque until the hydraulic assistance required in the left or right power assist cylinder is determined.

At high driving speeds, i.e. on a motorway, the Servotronic valve is fully open due to a very low or nonexistent control current supplied from the generic electronic module (GEM). This enables maximum pressure supply from the feed fluid radial groove to the reaction piston. When the steering wheel is turned, the reaction pressure increases appropriate to the existing operating pressure and pressurizes the piston in the reaction chamber. As soon as the reaction pressure reaches its upper limit, the fluid is discharged to the return fluid chamber via the cut-off valve and prevents further increases in reaction pressure. This maintains the input torque applied through the steering wheel and provides the driver with an improved 'road feel' allowing precise steering and directional stability.

SPECIAL TOOLS Tool Illustration Tool Name Tool Number Adapter - power steering pressure test 211-011-13 Hose - power steering pressure test 211-011-11 Valve block power steering test 211-011-01(LRT-57-001) Hose and gauge - power steering pressure test 211-287(LRT-57-005)

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Remove the air cleaner assembly. Refer to «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) or «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-44l) .
3. Remove the fluid from the power steering reservoir. Remove the power steering fluid reservoir cap.
4. Disconnect the power steering high-pressure pipe union. Remove the bolt. Remove and discard the 2 sealing washers Position a container to collect the fluid.
5. Install the special tools to the power steering high-pressure port. Install the sealing washers. Tighten the bolt to 28 Nm (18 lb.ft).
6. Raise and support the vehicle.
7. Remove the engine undershield. For additional information, refer to: «Engine Undershield - Removal and Installation»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels)
8. Remove the front undershield. For additional information, refer to: «Radiator Splash Shield - Removal and Installation»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels)
9. Release and reposition the power steering high-pressure pipe. Remove the nut.
10. Disconnect the power steering fluid line from the steering gear. Remove the bolt. Remove and discard the 2 sealing washers. Position a container to collect the fluid.
11. Install the special tool to the steering gear. Install the sealing washers. Tighten the bolt to 28 Nm (18 lb.ft).
12. Install the special tool valve block assembly, to the steering gear and pump special tools. Connect the special tool lines, to the special tool valve block assembly. Tighten the union nuts to 25 Nm (18 lb.ft).
13. Connect the pressure gauge to the special tool valve block. Tighten the union to 25 Nm (18 lb.ft). Tie aside under the vehicle.
14. Lower the vehicle on the lift.
15. Fill the power steering reservoir.
16. Install the air cleaner assembly. For additional information, refer to: «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) or «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-44l) .
17. Connect the battery ground cable. For additional information, refer to: «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications)
18. With the test valve open start the engine. Start the engine and turn steering fully lock to lock, stop the engine. Top-up the power steering fluid reservoir. Install the reservoir filler cap.
19. For correct power steering pressures, refer to the steering specification section. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover/l322-2005-2009/remont/manual-power-steering/#power-steering__specifications)
20. With the engine at idle, slowly turn the steering wheel and hold on full lock. With assistance record the pressure reading.
21. Repeat the above procedure for the other side. Record the pressure reading.
22. With the engine at idle, release the steering wheel. The pressure should be, at or below, the pressure specified.
23. Pressure outside this tolerance, indicates a fault.
24. To determine if the fault is in the steering pump or the steering rack, close the test valve for a maximum of 5 seconds.
25. If the pressures recorded fall outside the given values, replace the power steering pump.
26. If the maximum pump pressure is correct, then replace the power steering gear.
27. On completion of the test stop the engine.
28. Disconnect the battery ground cable. For additional information, refer to: «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications)
29. Remove the air cleaner assembly. For additional information, refer to: «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) or Refer to «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-44l) .
30. Remove the fluid from the power steering reservoir.
31. Remove the special tools.
32. Connect the high-pressure line to the power steering pump. Clean the component mating faces. Install 2 new sealing washers. Tighten the bolt to 28 Nm (18 lb.ft).
33. Install the air cleaner assembly. For additional information, refer to: «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) or «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-44l) .
34. Connect the battery ground cable. For additional information, refer to: «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications)
35. Raise and support the vehicle.
36. Connect the high-pressure line to the power steering gear. Clean the component mating faces. Install 2 new sealing washers. Tighten the bolt to 28 Nm (18 lb.ft).
37. Install the front undershield. For additional information, refer to: «Engine Undershield - Removal and Installation»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels)
38. Install the engine undershield. For additional information, refer to: «Radiator Splash Shield - Removal and Installation»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels)
39. Fill and bleed the power steering system. For additional information, refer to: «Power Steering System Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/steering/#steering-system-general-information__power-steering-system-filling-and-bleeding)

REMOVAL

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Raise the vehicle on the lift.
3. Remove the front wheel and tire.
4. Remove the power steering control valve actuator. Disconnect the electrical connector. Position a container to collect the fluid spillage. Remove and discard the 2 Torx screws. Remove and discard the 2 O-ring seals. Remove and discard the filter.

INSTALLATION

1. Clean the component mating faces.
2. Install a new filter to the steering gear.
3. Install new seals to the actuator.
4. Install the actuator. Tighten the new Torx screws, evenly and progressively, to 3 Nm (2.2 lb.ft). Connect the electrical connector.
5. Install the wheel and tire. Tighten the wheel nuts to 140 Nm (103 lb.ft).
6. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
7. Refill and bleed the power steering. Refer to «Power Steering System Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/steering/#steering-system-general-information__power-steering-system-filling-and-bleeding) .

Scheme 13

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Raise and support the vehicle.
3. Remove the radiator assembly. Refer to «Radiator»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l) .
4. Disconnect the 2 power steering fluid cooler hoses. Remove the 2 clips.
5. Remove the power steering fluid cooler.

1. Install the power steering fluid cooler.
2. Connect the power steering fluid cooler hoses. Secure with the clips.
3. Install the radiator assembly. Refer to «Radiator»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l) .
4. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
5. Top-up the power steering fluid reservoir. Refer to «Power Steering System Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/steering/#steering-system-general-information__power-steering-system-filling-and-bleeding) .

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Raise and support the vehicle.
3. Remove the radiator assembly. Refer to «Radiator»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-44l) .
4. Disconnect the 2 power steering fluid cooler hoses. Remove the 2 clips.
5. Remove the power steering fluid cooler.

1. Install the power steering fluid cooler.
2. Connect the power steering fluid cooler hoses. Secure with the clips.
3. Install the radiator assembly. Refer to «Radiator»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-44l) .
4. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
5. Top-up the power steering fluid reservoir. Refer to «Power Steering System Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/steering/#steering-system-general-information__power-steering-system-filling-and-bleeding) .

Scheme 14

Scheme 15

Scheme 16

Scheme 17

1. Disconnect the battery ground cable. For additional information, refer to: «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications)
2. Raise and support the vehicle.
3. Remove the hood latch panel. For additional information, refer to: «Hood Latch Panel»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-sheet-metal-repairs)
4. Remove the front bumper assembly. For additional information, refer to: «Front Bumper»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#bumpers)
5. Remove the air ducting. Release the wiring harness grommet. Release the cable. Remove the 3 clips.
6. Disconnect the cooling fan electrical connector.
7. Remove the condenser cooling fan. Carefully release the 2 clips
8. Remove the power steering fluid cooler. Disconnect the 2 fluid lines. Remove the power steering fluid cooler line bracket.

1. Install the power steering fluid cooler. Install the hoses into the locating clips. Install the power steering line support bracket. Tighten the bolt to 3 Nm. Install the power steering fluid lines.
2. Install the condenser cooling fan. Secure in the clips.
3. Connect the cooling fan electrical connector.
4. Install the air ducting. Secure with the 3 clips. Install the bonnet release cable. Secure the wiring harness grommet.
5. Install the front bumper assembly. For additional information, refer to: «Front Bumper»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#bumpers)
6. Install the hood latch panel. For additional information, refer to: «Hood Latch Panel»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-sheet-metal-repairs)
7. Connect the battery ground cable. For additional information, refer to: «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications)
8. Fill and bleed the power steering system. For additional information, refer to: «Power Steering System Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/steering/#steering-system-general-information__power-steering-system-filling-and-bleeding)

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 18

1. Disconnect the battery ground cable. For additional information, refer to: «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications)
2. Flush the power steering system. For additional information, refer to: «Power Steering System Flushing»(/land-rover/range-rover/l322-2005-2009/remont/steering/#steering-system-general-information__power-steering-system-flushing)
3. Remove the air cleaner. For additional information, refer to: «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l)
4. Remove the power steering fluid reservoir.

1. To install, reverse the removal procedure.

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Raise and support the vehicle.
3. Remove the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
4. Remove the radiator splash shield. Refer to «Radiator Splash Shield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
5. Release the accessory drive belt. Rotate the tensioner assembly counter-clockwise. Release the accessory drive belt from the power steering pump pulley.
6. Disconnect the power steering pump supply hose. Position a container to collect the fluid spillage. Release the clip.
7. Disconnect the power steering pump high-pressure line. Remove and discard the 2 sealing washers.
8. LH front: Release the height sensor link.
9. LH front: Remove the suspension height sensor. Remove and discard the tie-strap. Disconnect the electrical connector. Remove the 2 bolts.
10. Remove the power steering pump. Remove the 4 bolts.

1. Install the power steering pump. Tighten the bolts to 25 Nm (18 lb.ft).
2. LH front: Install the suspension height sensor. Tighten the bolts to 3 Nm (2.2 lb.ft). Connect the electrical connector. Using a suitable tie strap, secure the harness.
3. LH front: Connect the height sensor link.
4. Connect the power steering pump high-pressure line. Clean the component mating faces. Install new sealing washers. Tighten the union to 25 Nm (18 lb.ft).
5. Connect the power steering pump supply hose. Clean the component mating faces. Secure with the clip. Remove the container.
6. Secure the accessory drive belt. Rotate the tensioner assembly counter-clockwise.
7. Install the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
8. Install the radiator splash shield. Refer to «Radiator Splash Shield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
9. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
10. Fill and bleed the power steering system. Refer to «Power Steering System Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/steering/#steering-system-general-information__power-steering-system-filling-and-bleeding) .

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Raise and support the vehicle.
3. Remove the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
4. Remove the radiator splash shield. Refer to «Radiator Splash Shield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
5. Release the accessory drive belt. Rotate the tensioner assembly counter-clockwise. Release the accessory drive belt from the power steering pump pulley.
6. Disconnect the power steering pump supply hose. Position a container to collect the fluid spillage. Release the clip.
7. Disconnect the power steering pump high-pressure line. Remove and discard the 2 sealing washers.
8. Remove the power steering pump. Remove the 4 bolts.

1. Install the power steering pump. Tighten the bolts to 25 Nm (18 lb.ft).
2. Connect the power steering pump high-pressure line. Clean the component mating faces. Install new sealing washers. Tighten the union to 25 Nm (18 lb.ft).
3. Connect the power steering pump supply hose. Clean the component mating faces. Secure with the clip. Remove the container.
4. Secure the accessory drive belt. Rotate the tensioner assembly counter-clockwise.
5. Install the radiator splash shield. Refer to «Radiator Splash Shield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
6. Install the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
7. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
8. Fill and bleed the power steering system. Refer to «Power Steering System Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/steering/#steering-system-general-information__power-steering-system-filling-and-bleeding) .

Scheme 24

Scheme 25

Scheme 26

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Raise and support the vehicle.
3. Remove the accessory drive belt. Refer to «Accessory Drive Belt»(/land-rover/range-rover/l322-2005-2009/remont/accessory-drive-belts/#accessory-drive-42l) or «Accessory Drive Belt»(/land-rover/range-rover/l322-2005-2009/remont/accessory-drive-belts/#accessory-drive-44l) .
4. Disconnect the power steering fluid cooler hose. Release the clip. Allow the fluid to drain into a container.
5. Remove the air cleaner. Refer to «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) or «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-44l) .
6. Disconnect the power steering pump to steering gear pressure line. Remove the banjo bolt. Remove and discard the 2 sealing washers.
7. Release the power steering pump and mounting bracket. Release the wiring harness. Remove the 3 bolts.
8. Remove the power steering pump and mounting bracket. Disconnect the power steering pump supply hose. Release the clip.

1. Install the power steering pump and mounting bracket. Connect the power steering pump supply hose. Secure with the clip.
2. Attach the power steering pump and mounting bracket. Tighten the 2 front bolts to 10 Nm (7 lb.ft) Loosen the 2 front bolts by a quarter of a turn. Tighten the rear bolt to 23 Nm (17 lb.ft). Tighten the 2 front bolts to 23 Nm (17 lb.ft). Secure the wiring harness.
3. Connect the power steering pump to steering gear pressure line. Install new sealing washers. Tighten the banjo bolt to 25 Nm (18 lb.ft).
4. Install the air cleaner. Refer to «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) or «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-44l) .
5. Connect the power steering fluid cooler hose. Secure with the clip. Remove the container.
6. Install the accessory drive belt. Refer to «Accessory Drive Belt»(/land-rover/range-rover/l322-2005-2009/remont/accessory-drive-belts/#accessory-drive-42l) or «Accessory Drive Belt»(/land-rover/range-rover/l322-2005-2009/remont/accessory-drive-belts/#accessory-drive-44l) .
7. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
8. Fill and bleed the power steering system. Refer to «Power Steering System Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/steering/#steering-system-general-information__power-steering-system-filling-and-bleeding) .

1. Make the SRS system safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2005-2009/remont/oem-general-information/#general-information) .
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
3. Remove the steering column. Refer to «Steering Column»(/land-rover/range-rover/l322-2005-2009/remont/steering-column/#steering-column) .
4. Remove the steering angle sensor. Remove the 3 screws.

1. Install the steering angle sensor. Tighten the screws to 3 Nm (2 lb.ft).
2. Install the steering column. Refer to «Steering Column»(/land-rover/range-rover/l322-2005-2009/remont/steering-column/#steering-column) .
3. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
4. Using the Land Rover approved diagnostic system, calibrate the steering angle sensor.

STEERING GEAR V8 S/C 4.2L PETROL, LHD AWD

SPECIAL TOOLS Tool Illustration Tool Name Tool Number Remover halfshaft inboard joint (LRT-54-026) 205-735 Installer halfshaft oil seal 308-626/1 Installer/Guide halfshaft oil seal 308-626/2 Impulse extractor (LRT-99-004) 100-012 Ball joint separator (LRT-54-027) 205-754

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Align the steering wheel to straight ahead. Remove the ignition key.
3. Raise and support the vehicle.
4. Remove the air intake resonator. Refer to «Intake Air Resonator»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
5. Remove the coolant expansion tank. Refer to «Coolant Expansion Tank»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l) or «Coolant Expansion Tank»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-44l) .
6. Using the special tools, release the cooling fan.
7. Remove the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
8. Drain the differential fluid. Refer to «Differential Draining and Filling»(/land-rover/range-rover/l322-2005-2009/remont/differentials-drive-axles/#front-drive-axledifferential__differential-draining-and-filling) .
9. Remove the front wheels and tires.
10. RH front: Disconnect the steering gear tie rod end ball joint. Use the special tool. Loosen the tie-rod end ball joint retaining nut. Discard the nut.
11. RH front: Disconnect the stabilizer bar link. Remove the nut. Remove the flat washer.
12. LH front: Release the air suspension spring. Loosen the 3 nuts.
13. LH front: Disconnect the suspension height sensor link arm. Remove the nut.
14. LH front: Remove the suspension height sensor. Remove the clip. Disconnect the electrical connector. Remove the 2 bolts.
15. LH front: Disconnect the steering gear tie rod end ball joint. Use the special tool. Loosen the tie-rod end ball joint retaining nut. Discard the nut.
16. LH front: Disconnect the stabilizer bar link. Remove the nut. Remove the flat washer.
17. LH front: Disconnect the lower arm. Remove the bolt and discard the nut.
18. LH front: Disconnect the tie rod. Remove the bolt and discard the nut.
19. LH front: Using the special tool, disconnect the halfshaft from the differential. Remove and discard the retaining clip.
20. LH front: Remove and discard the halfshaft oil seal.
21. Disconnect the lower steering column from the steering gear. Note the fitted position. Align the steering wheel to straight ahead. Remove and discard the Torx bolt.
22. Disconnect the steering gear electrical connector.
23. Disconnect the power steering feed and return fluid lines from the steering gear. Note the fitted position. Remove the 2 unions. Remove and discard the 4 sealing washers.
24. Remove the LH engine mount heat shield. Remove the 2 screws.
25. Release the RH engine mount. Support the engine. Remove the nut.
26. Release the LH engine mount. Remove the bolt.
27. Release the steering gear. Remove and discard the 2 nuts and Torx bolts.
28. Remove the steering gear. Raise the engine. With assistance, carefully rotate and release the steering gear.
29. Remove the tie-rod end. Note the fitted position. Loosen the locknut. Remove and discard the locking ring. Remove and discard the locknut. Repeat the above procedure for the other side.

Scheme 44

Scheme 45

1. Install the tie-rod end. Clean the components. Install a new locknut. Install a new locking ring. Tighten the new nut to 80 Nm (59 lb.ft).
2. Install the steering gear. With assistance, carefully rotate and align the steering gear. Tighten the new nuts and Torx bolts to 100 Nm (74 lb.ft), then tighten a further 90 degrees.
3. Lower the engine onto its mounts. Tighten the bolt to 100 Nm (74 lb.ft). Tighten the nut to 100 Nm (74 lb.ft).
4. Install the LH engine mount heat shield. Tighten the screws.
5. Connect the power steering feed and return fluid lines. Clean the components. Install new sealing washers. Up to 07 MY : Tighten the M16 union to 40 Nm (30 lb.ft). Up to 07 MY : Tighten the M14 union to 36 Nm (26 lb.ft). 07 MY on : Tighten the M14 union and the M16 union to 28 Nm (21 lb.ft).
6. Connect the steering gear electrical connector.
7. Lower the engine onto its mounts. Tighten the bolt to 100 Nm (74 lb.ft). Tighten the nut to 100 Nm (74 lb.ft).
8. Attach the lower steering column. Make sure that the steering gear tag is aligned correctly, as shown. Install a new Torx bolt and tighten to 24 Nm (18 lb.ft).
9. LH front: Using the special tools, install a new halfshaft oil seal. Clean the component mating faces.
10. LH front: Fully install the halfshaft. Clean the component. Install a new retaining clip. Open the halfshaft oil seal protector. Lubricate the seal with clean differential fluid. Remove and discard the halfshaft oil seal protector.
11. LH front: Connect the tie rod. Install the bolt with a new nut.
12. LH front: Connect the lower arm. Install the bolt with a new nut.
13. LH front: Connect the steering gear tie rod end ball joint. Clean the component mating faces. Tighten the new nut to 70 Nm (52 lb.ft).
14. LH front: Connect the stabilizer bar link. Install the washer. Tighten the nut to 100 Nm (74 lb.ft).
15. LH front: Install the suspension height sensor. Tighten the bolts to 3.5 Nm (2.5 lb.ft). Connect the electrical connector. Install the clip.
16. LH front: Connect the suspension height sensor link arm. Tighten the nut to 8 Nm (6 lb.ft).
17. RH front: Connect the stabilizer bar link. Install the washer. Tighten the nut to 100 Nm (74 lb.ft).
18. RH front: Connect the steering gear tie rod end ball joint. Clean the component mating faces. Tighten the new nut to 70 Nm (52 lb.ft).
19. Install the front wheels and tires. Tighten the wheel nuts to 140 Nm (103 lb.ft).
20. Tighten the front lower arm nuts and bolts to 165 Nm (122 lb.ft), then tighten a further 90 degrees.
21. Tighten the rear lower arm nuts and bolts to 165 Nm (122 lb.ft), then tighten a further 90 degrees.
22. Secure the air suspension spring. Tighten the nuts securing the air springs to 56 Nm (41 lb.ft).
23. Fill the front differential case with the correct amount of fluid. Refer to «Differential Draining and Filling»(/land-rover/range-rover/l322-2005-2009/remont/differentials-drive-axles/#front-drive-axledifferential__differential-draining-and-filling) .
24. Install the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
25. Install the cooling fan. Tighten the cooling fan to 65 Nm (48 lb.ft).
26. Install the air intake resonator. Refer to «Intake Air Resonator»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
27. Install the coolant expansion tank. Refer to «Coolant Expansion Tank»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l) or «Coolant Expansion Tank»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-44l) .
28. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
29. Fill and bleed the power steering system. Refer to «Power Steering System Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/steering/#steering-system-general-information__power-steering-system-filling-and-bleeding) .
30. Carry out a complete vehicle geometry check and adjustment.

STEERING GEAR V8 S/C 4.2L PETROL, RHD AWD

SPECIAL TOOLS Tool Illustration Tool Name Tool Number Remover halfshaft inboard joint (LRT-54-026) 205-735 Installer halfshaft oil seal 308-626/1 Installer/Guide halfshaft oil seal 308-626/2 Impulse extractor (LRT-99-004) 100-012 Ball joint separator (LRT-54-027) 205-754

Scheme 46

Scheme 47

Scheme 48

Scheme 49

1. Align the steering wheel to straight ahead. Remove the ignition key.
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
3. Remove the cooling fan and shroud. Refer to «Cooling Fan»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l__cooling-fan) .
4. Drain the differential fluid. Refer to «Differential Draining and Filling»(/land-rover/range-rover/l322-2005-2009/remont/differentials-drive-axles/#front-drive-axledifferential__differential-draining-and-filling) .
5. Raise and support the vehicle.
6. Remove the front wheels and tires.
7. RH front: Disconnect the steering gear tie rod end ball joint. Use the special tools. Loosen the tie-rod end ball joint retaining nut. Discard the nut.
8. RH front: Release the air suspension spring. Loosen the 3 nuts.
9. RH front: Disconnect the suspension height sensor link arm. Remove the nut.
10. RH front: Remove the suspension height sensor. Remove the clip. Disconnect the electrical connector. Remove the 2 bolts.
11. RH front: Disconnect the stabilizer bar link. Remove the nut. Remove the flat washer.
12. RH front: Disconnect the lower arm. Remove the bolt and discard the nut.
13. RH front: Disconnect the tie rod. Remove the bolt and discard the nut.
14. RH front: Using the special tool, disconnect the halfshaft from the differential. Remove and discard the retaining clip.
15. RH front: Remove and discard the halfshaft oil seal.
16. Remove the halfshaft support bearing housing. Remove the 4 bolts. Remove and discard the O-ring seal.
17. LH front: Disconnect the steering gear tie rod end ball joint. Use the special tools. Loosen the tie-rod end ball joint retaining nut. Discard the nut.
18. LH front: Release the air suspension spring. Loosen the 3 nuts.
19. LH front: Disconnect the suspension height sensor link arm. Remove the nut.
20. LH front: Remove the suspension height sensor. Remove the clip. Disconnect the electrical connector. Remove the 2 bolts.
21. LH front: Disconnect the stabilizer bar link. Remove the nut. Remove the flat washer.
22. LH front: Disconnect the lower arm. Remove the bolt and discard the nut.
23. LH front: Disconnect the tie rod. Remove the bolt and discard the nut.
24. LH front: Using the special tool, disconnect the halfshaft from the differential. Remove and discard the retaining clip.
25. LH front: Remove and discard the halfshaft oil seal.
26. Disconnect the lower steering column from the steering gear. Note the fitted position. Align the steering wheel to straight ahead. Remove and discard the Torx bolt.
27. Disconnect the steering gear electrical connector.
28. Disconnect the power steering feed and return fluid lines from the steering gear. Note the fitted position. Remove the 2 unions. Remove and discard the 4 sealing washers.
29. Release the RH engine mount. Support the engine. Remove the nut.
30. Remove the LH engine mount heat shield. Remove the 2 screws.
31. Release the LH engine mount. Remove the bolt.
32. Release the accessory drive belt. Rotate the tensioner assembly counter-clockwise. Release the power steering pump pulley.
33. Disconnect the power steering pump high-pressure line. Remove and discard both O-ring seals.
34. Release the power steering pump and tie aside Remove the 4 bolts.
35. Release the engine wiring harness from the oil pan. Remove the 2 bolts.
36. Release the steering gear. Raise the engine. Remove and discard the 2 nuts and Torx bolts.
37. Remove the engine RH mount. Remove the 2 bolts.
38. Remove the RH engine mount bracket. Remove the 4 bolts.
39. Remove the steering gear. With assistance, carefully rotate and release the steering gear.
40. Remove the tie-rod end. Note the fitted position. Loosen the locknut. Remove and discard the locking ring. Remove and discard the locknut. Repeat the above procedure for the other side.

1. Install the tie-rod end. Clean the components. Install a new locknut. Install a new locking ring. Tighten the new nut to 80 Nm (59 lb.ft).
2. Install the steering gear. With assistance, carefully rotate and align the steering gear. Tighten the new nuts and Torx bolts to 100 Nm (74 lb.ft), then tighten a further 90 degrees.
3. Install the engine mount. Clean the component mating faces. Tighten the bolts to 56 Nm (41 lb.ft).
4. Install the RH engine mount bracket. Clean the component mating faces. Tighten the engine mount bracket to engine bolts to 45 Nm (33 lb.ft), then a further 60 degrees.
5. Lower the engine onto its mounts. Tighten the bolt to 100 Nm (74 lb.ft). Tighten the nut to 100 Nm (74 lb.ft).
6. Install the LH engine mount heat shield. Tighten the screws.
7. Install the power steering pump. Tighten the bolts to 25 Nm (18 lb.ft).
8. Connect the power steering pump high-pressure line. Clean the component mating faces. Install the new O-ring seals. Tighten the union to 25 Nm (18 lb.ft).
9. Install the accessory drive belt. Rotate the tensioner assembly counter-clockwise. Install to the power steering pump pulley.
10. Attach the engine wiring harness to the oil pan. Tighten the bolts to 6 Nm (4 lb.ft).
11. Connect the power steering feed and return fluid lines. Clean the components. Install new sealing washers. Up to 07 MY :Tighten the M16 union to 40 Nm (30 lb.ft). Up to 07 MY :Tighten the M14 union to 36 Nm (26 lb.ft). 07 MY on : Tighten the M14 union and the M16 union to 28 Nm (21 lb.ft).
12. Connect the steering gear electrical connector.
13. Lower the engine onto its mounts. Tighten the bolt to 100 Nm (74 lb.ft). Tighten the nut to 100 Nm (74 lb.ft).
14. Attach the lower steering column. Make sure that the steering gear tag is aligned correctly, as shown. Install a new Torx bolt and tighten to 24 Nm (18 lb.ft).
15. LH front: Using the special tools, install a new halfshaft oil seal. Clean the component mating faces.
16. LH front: Fully install the halfshaft. Clean the component. Install a new retaining clip. Open the halfshaft oil seal protector. Lubricate the seal with clean differential fluid. Remove and discard the halfshaft oil seal protector.
17. LH front: Connect the tie rod. Install the bolt with a new nut.
18. LH front: Connect the lower arm. Install the bolt with a new nut.
19. LH front: Connect the steering gear tie rod end ball joint. Clean the component mating faces. Tighten the new nut to 70 Nm (52 lb.ft).
20. LH front: Connect the stabilizer bar link. Install the washer. Tighten the nut to 100 Nm (74 lb.ft).
21. LH front: Install the suspension height sensor. Tighten the bolts to 3.5 Nm (2.5 lb.ft). Connect the electrical connector. Install the clip.
22. LH front: Connect the suspension height sensor link arm. Tighten the nut to 8 Nm (6 lb.ft).
23. Install the halfshaft support bearing housing. Install a new O-ring seal. Lubricate the O-ring seal with petroleum jelly. Tighten the bolts evenly to 25 Nm (18 lb.ft).
24. RH front: Using the special tools, install a new halfshaft oil seal. Clean the component mating faces.
25. RH front: Fully install the halfshaft. Clean the component. Install a new retaining clip. Open the halfshaft oil seal protector. Lubricate the seal with clean differential fluid. Remove and discard the halfshaft oil seal protector.
26. RH front: Connect the tie rod. Install the bolt with a new nut.
27. RH front: Connect the lower arm. Install the bolt with a new nut.
28. RH front: Connect the steering gear tie rod end ball joint. Clean the component mating faces. Tighten the new nut to 70 Nm (52 lb.ft).
29. RH front: Connect the stabilizer bar link. Install the washer. Tighten the nut to 100 Nm (74 lb.ft).
30. RH front: Install the suspension height sensor. Tighten the bolts to 3.5 Nm (2.5 lb.ft). Connect the electrical connector. Install the clip.
31. RH front: Connect the suspension height sensor link arm. Tighten the nut to 8 Nm (6 lb.ft).
32. Install the front wheels and tires. Tighten the wheel nuts to 140 Nm (103 lb.ft).
33. Tighten the front lower arm nuts and bolts to 165 Nm (122 lb.ft), then tighten a further 90 degrees.
34. Tighten the rear lower arm nuts and bolts to 165 Nm (122 lb.ft), then tighten a further 90 degrees.
35. Secure the air suspension springs. Tighten the nuts securing the air springs to 56 Nm (41 lb.ft).
36. Fill the front differential case with the correct amount of fluid. Refer to «Differential Draining and Filling»(/land-rover/range-rover/l322-2005-2009/remont/differentials-drive-axles/#front-drive-axledifferential__differential-draining-and-filling) .
37. Install the cooling fan and shroud. Refer to «Cooling Fan»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l__cooling-fan) .
38. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
39. Carry out a complete vehicle geometry check and adjustment.

STEERING GEAR V8 4.4L PETROL, LHD AWD

SPECIAL TOOLS Tool Illustration Tool Name Tool Number Remover halfshaft inboard joint (LRT-54-026) 205-735 Installer halfshaft oil seal 308-626/1 Installer/Guide halfshaft oil seal 308-626/2 Impulse extractor (LRT-99-004) 100-012 Ball joint separator (LRT-54-027) 205-754

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Align the steering wheel to straight ahead. Remove the ignition key.
3. Raise and support the vehicle.
4. Remove the air intake resonator. Refer to «Intake Air Resonator»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-44l) .
5. Remove the coolant expansion tank. Refer to «Coolant Expansion Tank»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l) or «Coolant Expansion Tank»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-44l) .
6. Using the special tools, release the cooling fan.
7. Remove the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
8. Drain the differential fluid. Refer to «Differential Draining and Filling»(/land-rover/range-rover/l322-2005-2009/remont/differentials-drive-axles/#front-drive-axledifferential__differential-draining-and-filling) .
9. Remove the front wheels and tires.
10. RH front: Disconnect the steering gear tie rod end ball joint. Use the special tool. Loosen the tie-rod end ball joint retaining nut. Discard the nut.
11. RH front: Disconnect the stabilizer bar link. Remove the nut. Remove the flat washer.
12. LH front: Release the air suspension spring. Loosen the 3 nuts.
13. LH front: Disconnect the suspension height sensor link arm. Remove the nut.
14. LH front: Remove the suspension height sensor. Remove the clip. Disconnect the electrical connector. Remove the 2 bolts.
15. LH front: Disconnect the steering gear tie rod end ball joint. Use the special tool. Loosen the tie-rod end ball joint retaining nut. Discard the nut.
16. LH front: Disconnect the stabilizer bar link. Remove the nut. Remove the flat washer.
17. LH front: Disconnect the lower arm. Remove the bolt and discard the nut.
18. LH front: Disconnect the tie rod. Remove the bolt and discard the nut.
19. LH front: Using the special tool, disconnect the halfshaft from the differential. Remove and discard the retaining clip.
20. LH front: Remove and discard the halfshaft oil seal.
21. Disconnect the lower steering column from the steering gear. Note the fitted position. Align the steering wheel to straight ahead. Remove and discard the Torx bolt.
22. Disconnect the steering gear electrical connector.
23. Disconnect the power steering feed and return fluid lines from the steering gear. Note the fitted position. Remove the 2 unions. Remove and discard the 4 sealing washers.
24. Release the engine wiring harness from the oil pan. Remove the 2 bolts.
25. Remove the LH engine mount heat shield. Remove the 2 screws.
26. Release the RH engine mount. Support the engine. Remove the nut.
27. Release the LH engine mount. Remove the bolt.
28. Release the steering gear. Remove and discard the 2 nuts and Torx bolts.
29. Remove the steering gear. Raise the engine. With assistance, carefully rotate and release the steering gear.
30. Remove the tie-rod end. Note the fitted position. Loosen the locknut. Remove and discard the locking ring. Remove and discard the locknut. Repeat the above procedure for the other side.

1. Install the tie-rod end. Clean the components. Install a new locknut. Install a new locking ring. Tighten the new nut to 80 Nm (59 lb.ft).
2. Install the steering gear. With assistance, carefully rotate and align the steering gear. Tighten the new nuts and Torx bolts to 100 Nm (74 lb.ft), then tighten a further 90 degrees.
3. Lower the engine onto its mounts. Tighten the bolt to 100 Nm (74 lb.ft). Tighten the nut to 100 Nm (74 lb.ft).
4. Install the LH engine mount heat shield. Tighten the screws.
5. Attach the engine wiring harness to the oil pan. Tighten the bolts to 6 Nm (4 lb.ft).
6. Connect the power steering feed and return fluid lines. Clean the components. Install new sealing washers. Up to 07 MY : Tighten the M16 union to 40 Nm (30 lb.ft). Up to 07 MY : Tighten the M14 union to 36 Nm (26 lb.ft). 07 MY on : Tighten the M14 union and the M16 union to 28 Nm (21 lb.ft).
7. Connect the steering gear electrical connector.
8. Lower the engine onto its mounts. Tighten the bolt to 100 Nm (74 lb.ft). Tighten the nut to 100 Nm (74 lb.ft).
9. Attach the lower steering column. Make sure that the steering gear tag is aligned correctly, as shown. Install a new Torx bolt and tighten to 24 Nm (18 lb.ft).
10. LH front: Using the special tools, install a new halfshaft oil seal. Clean the component mating faces.
11. LH front: Fully install the halfshaft. Clean the component. Install a new retaining clip. Open the halfshaft oil seal protector. Lubricate the seal with clean differential fluid. Remove and discard the halfshaft oil seal protector.
12. LH front: Connect the tie rod. Install the bolt with a new nut.
13. LH front: Connect the lower arm. Install the bolt with a new nut.
14. LH front: Connect the steering gear tie rod end ball joint. Clean the component mating faces. Tighten the new nut to 70 Nm (52 lb.ft).
15. LH front: Connect the stabilizer bar link. Install the washer. Tighten the nut to 100 Nm (74 lb.ft).
16. LH front: Install the suspension height sensor. Tighten the bolts to 3.5 Nm (2.5 lb.ft). Connect the electrical connector. Install the clip.
17. LH front: Connect the suspension height sensor link arm. Tighten the nut to 8 Nm (6 lb.ft).
18. RH front: Connect the stabilizer bar link. Install the washer. Tighten the nut to 100 Nm (74 lb.ft).
19. RH front: Connect the steering gear tie rod end ball joint. Clean the component mating faces. Tighten the new nut to 70 Nm (52 lb.ft).
20. Install the front wheels and tires. Tighten the wheel nuts to 140 Nm (103 lb.ft).
21. Tighten the front lower arm nuts and bolts to 165 Nm (122 lb.ft), then tighten a further 90 degrees.
22. Tighten the rear lower arm nuts and bolts to 165 Nm (122 lb.ft), then tighten a further 90 degrees.
23. Secure the air suspension spring. Tighten the nuts securing the air springs to 56 Nm (41 lb.ft).
24. Fill the front differential case with the correct amount of fluid. Refer to «Differential Draining and Filling»(/land-rover/range-rover/l322-2005-2009/remont/differentials-drive-axles/#front-drive-axledifferential__differential-draining-and-filling) .
25. Install the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
26. Install the cooling fan. Tighten the cooling fan to 65 Nm (48 lb.ft).
27. Install the air intake resonator. Refer to «Intake Air Resonator»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-44l) .
28. Install the coolant expansion tank. Refer to «Coolant Expansion Tank»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l) .
29. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
30. Fill and bleed the power steering Refer to «Power Steering System Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/steering/#steering-system-general-information__power-steering-system-filling-and-bleeding) .
31. Carry out a complete vehicle geometry check and adjustment.

STEERING GEAR V8 4.4L PETROL, RHD AWD

SPECIAL TOOLS Tool Illustration Tool Name Tool Number Remover halfshaft inboard joint (LRT-54-026) 205-735 Installer halfshaft oil seal 308-626/1 Installer/Guide halfshaft oil seal 308-626/2 Impulse extractor (LRT-99-004) 100-012 Ball joint separator (LRT-54-027) 205-754

1. Align the steering wheel to straight ahead. Remove the ignition key.
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
3. Remove the cooling fan and shroud. Refer to «Cooling Fan»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-44l__cooling-fan) .
4. Drain the differential fluid. Refer to «Differential Draining and Filling»(/land-rover/range-rover/l322-2005-2009/remont/differentials-drive-axles/#front-drive-axledifferential__differential-draining-and-filling) .
5. Raise and support the vehicle.
6. Remove the front wheels and tires.
7. RH front: Disconnect the steering gear tie rod end ball joint. Use the special tools. Loosen the tie-rod end ball joint retaining nut. Discard the nut.
8. RH front: Release the air suspension spring. Loosen the 3 nuts.
9. RH front: Disconnect the suspension height sensor link arm. Remove the nut.
10. RH front: Remove the suspension height sensor. Remove the clip. Disconnect the electrical connector. Remove the 2 bolts.
11. RH front: Disconnect the stabilizer bar link. Remove the nut. Remove the flat washer.
12. RH front: Disconnect the lower arm. Remove the bolt and discard the nut.
13. RH front: Disconnect the tie rod. Remove the bolt and discard the nut.
14. RH front: Using the special tool, disconnect the halfshaft from the differential. Remove and discard the retaining clip.
15. RH front: Remove and discard the halfshaft oil seal.
16. Remove the halfshaft support bearing housing. Remove the 4 bolts. Remove and discard the O-ring seal.
17. LH front: Disconnect the steering gear tie rod end ball joint. Use the special tools. Loosen the tie-rod end ball joint retaining nut. Discard the nut.
18. LH front: Release the air suspension spring. Loosen the 3 nuts.
19. LH front: Disconnect the suspension height sensor link arm. Remove the nut.
20. LH front: Remove the suspension height sensor. Remove the clip. Disconnect the electrical connector. Remove the 2 bolts.
21. LH front: Disconnect the stabilizer bar link. Remove the nut. Remove the flat washer.
22. LH front: Disconnect the lower arm. Remove the bolt and discard the nut.
23. LH front: Disconnect the tie rod. Remove the bolt and discard the nut.
24. LH front: Using the special tool, disconnect the halfshaft from the differential. Remove and discard the retaining clip.
25. LH front: Remove and discard the halfshaft oil seal.
26. Disconnect the lower steering column from the steering gear. Note the fitted position. Align the steering wheel to straight ahead. Remove and discard the Torx bolt.
27. Disconnect the steering gear electrical connector.
28. Disconnect the power steering feed and return fluid lines from the steering gear. Note the fitted position. Remove the 2 unions. Remove and discard the 4 sealing washers.
29. Release the RH engine mount. Support the engine. Remove the nut.
30. Remove the LH engine mount heat shield. Remove the 2 screws.
31. Release the LH engine mount. Remove the bolt.
32. Release the accessory drive belt. Rotate the tensioner assembly counter-clockwise. Release the power steering pump pulley.
33. Disconnect the power steering pump high-pressure line. Remove and discard both O-ring seals.
34. Release the power steering pump and tie aside Remove the 4 bolts.
35. Release the engine wiring harness from the oil pan. Remove the 2 bolts.
36. Release the steering gear. Raise the engine. Remove and discard the 2 nuts and Torx bolts.
37. Remove the engine RH mount. Remove the 2 bolts.
38. Remove the RH engine mount bracket. Remove the 4 bolts.
39. Remove the steering gear. With assistance, carefully rotate and release the steering gear.
40. Remove the tie-rod end. Note the fitted position. Loosen the locknut. Remove and discard the locking ring. Remove and discard the locknut. Repeat the above procedure for the other side.

1. Install the tie-rod end. Clean the components. Install a new locknut. Install a new locking ring. Tighten the new nut to 80 Nm (59 lb.ft).
2. Install the steering gear. With assistance, carefully rotate and align the steering gear. Tighten the new nuts and Torx bolts to 100 Nm (74 lb.ft), and then tighten a further 90 degrees.
3. Install the engine mount. Clean the component mating faces. Tighten the bolts to 56 Nm (41 lb.ft).
4. Install the RH engine mount bracket. Clean the component mating faces. Tighten the engine mount bracket to engine bolts to 45 Nm (33 lb.ft), then a further 60 degrees.
5. Lower the engine onto its mounts. Tighten the bolt to 100 Nm (74 lb.ft). Tighten the nut to 100 Nm (74 lb.ft).
6. Install the LH engine mount heat shield. Tighten the screws.
7. Install the power steering pump. Tighten the bolts to 25 Nm (18 lb.ft).
8. Connect the power steering pump high-pressure line. Clean the component mating faces. Install the new O-ring seals. Tighten the union to 25 Nm (18 lb.ft).
9. Install the accessory drive belt. Rotate the tensioner assembly counter-clockwise. Install to the power steering pump pulley.
10. Attach the engine wiring harness to the oil pan. Tighten the bolts to 6 Nm (4 lb.ft).
11. Connect the power steering feed and return fluid lines. Clean the components. Install new sealing washers. Up to 07 MY : Tighten the M16 union to 40 Nm (30 lb.ft). Up to 07 MY : Tighten the M14 union to 36 Nm (26 lb.ft). 07 MY on : Tighten the M14 union and the M16 union to 28 Nm (21 lb.ft).
12. Connect the steering gear electrical connector.
13. Lower the engine onto its mounts. Tighten the bolt to 100 Nm (74 lb.ft). Tighten the nut to 100 Nm (74 lb.ft).
14. Attach the lower steering column. Make sure that the steering gear tag is aligned correctly, as shown. Install a new Torx bolt and tighten to 24 Nm (18 lb.ft).
15. LH front: Using the special tools, install a new halfshaft oil seal. Clean the component mating faces.
16. LH front: Fully install the halfshaft. Clean the component. Install a new retaining clip. Open the halfshaft oil seal protector. Lubricate the seal with clean differential fluid. Remove and discard the halfshaft oil seal protector.
17. LH front: Connect the tie rod. Install the bolt with a new nut.
18. LH front: Connect the lower arm. Install the bolt with a new nut.
19. LH front: Connect the steering gear tie rod end ball joint. Clean the component mating faces. Tighten the new nut to 70 Nm (52 lb.ft).
20. LH front: Connect the stabilizer bar link. Install the washer. Tighten the nut to 100 Nm (74 lb.ft).
21. LH front: Install the suspension height sensor. Tighten the bolts to 3.5 Nm (2.5 lb.ft). Connect the electrical connector. Install the clip.
22. LH front: Connect the suspension height sensor link arm. Tighten the nut to 8 Nm (6 lb.ft).
23. Install the halfshaft support bearing housing. Install a new O-ring seal. Lubricate the O-ring seal with petroleum jelly. Tighten the bolts evenly to 25 Nm (18 lb.ft).
24. RH front: Using the special tools, install a new halfshaft oil seal. Clean the component mating faces.
25. RH front: Fully install the halfshaft. Clean the component. Install a new retaining clip. Open the halfshaft oil seal protector. Lubricate the seal with clean differential fluid. Remove and discard the halfshaft oil seal protector.
26. RH front: Connect the tie rod. Install the bolt with a new nut.
27. RH front: Connect the lower arm. Install the bolt with a new nut.
28. RH front: Connect the steering gear tie rod end ball joint. Clean the component mating faces. Tighten the new nut to 70 Nm (52 lb.ft).
29. RH front: Connect the stabilizer bar link. Install the washer. Tighten the nut to 100 Nm (74 lb.ft).
30. RH front: Install the suspension height sensor. Tighten the bolts to 3.5 Nm (2.5 lb.ft). Connect the electrical connector. Install the clip.
31. RH front: Connect the suspension height sensor link arm. Tighten the nut to 8 Nm (6 lb.ft).
32. Install the front wheels and tires. Tighten the wheel nuts to 140 Nm (103 lb.ft).
33. Tighten the front lower arm nuts and bolts to 165 Nm (122 lb.ft), then tighten a further 90 degrees.
34. Tighten the rear lower arm nuts and bolts to 165 Nm (122 lb.ft), then tighten a further 90 degrees.
35. Secure the air suspension springs. Tighten the nuts securing the air springs to 56 Nm (41 lb.ft).
36. Fill the front differential case with the correct amount of fluid. Refer to «Differential Draining and Filling»(/land-rover/range-rover/l322-2005-2009/remont/differentials-drive-axles/#front-drive-axledifferential__differential-draining-and-filling) .
37. Install the cooling fan and shroud. Refer to «Cooling Fan»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-44l__cooling-fan) .
38. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
39. Carry out a complete vehicle geometry check and adjustment.

STEERING GEAR (3.6L (TDV8) DIESEL LHD)

SPECIAL TOOLS Tool Illustration Tool Name Tool Number Installer halfshaft oil seal 308-626/1 Installer/Guide halfshaft oil seal 308-626/2 Impulse extractor 100-012(LRT-99-004) Ball joint separator 205-754(LRT-54-027)

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

1. Raise and support the vehicle.
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
3. Center the steering wheel. Remove the ignition key.
4. Remove the front wheels and tires.
5. Remove the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
6. Remove the radiator splash shield. Refer to «Radiator Splash Shield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
7. Disconnect the height sensor link.
8. LH front: Remove the suspension height sensor. Remove and discard the tie-strap. Disconnect the electrical connector. Remove the 2 bolts.
9. Using the special tool release both tie rod ends. Remove and discard the 2 nuts. Using the special tool, release both tie rod end ball joints.
10. Release the front lower arm. Remove the bolt. Remove and discard the nut.
11. Release the rear lower arm. Remove the bolt. Remove and discard the nut.
12. Release the halfshaft from the differential. Remove and discard the snap ring.
13. Using a suitable tie strap, secure the halfshaft and both lower arms.
14. Release the LH stabilizer bar link. Remove and discard the nut.
15. Release the RH stabilizer bar link. Remove and discard the nut.
16. Using the special tools, remove and discard the halfshaft seal.
17. Disconnect the lower steering column from the steering gear. Remove and discard the bolt.
18. Disconnect the steering gear control valve actuator electrical connector.
19. Disconnect the steering gear return line. Position a container to collect the fluid spillage. Release the clip. Release the steering gear return line.
20. Release the steering gear pressure line. Remove the nut.
21. Release the steering gear. Remove and discard the 2 nuts. Remove the 2 bolts.
22. Using a suitable tie strap, secure the stabilizer bar to the RH front lower arm.
23. Reposition the steering gear.
24. Disconnect the steering gear pressure line. Remove the bolt. Remove and discard the 2 sealing washers.
25. Remove the steering gear.
26. Remove both tie rod ends. Loosen the locknut. Remove and discard the locking ring. Remove and discard the locknut.
27. Remove the steering gear return line. Remove the bolt. Remove and discard the 2 sealing washers.

1. Install the steering gear return line. Install new sealing washers. Up to 07 MY : Tighten the bolt to 40 Nm (30 lb.ft). 07 MY on : Tighten the bolt to 28 Nm (21 lb.ft).
2. Install both tie rod ends. Install a new locking ring. Tighten the new nut to 70 Nm (52 lb.ft).
3. Install the steering gear.
4. Connect the steering gear pressure line. Install new sealing washers. Up to 07 MY : Tighten the bolt to 36 Nm (26 lb.ft). 07 MY on : Tighten the bolt to 28 Nm (21 lb.ft).
5. Reposition the steering gear.
6. Release the stabilizer bar. Remove and discard the tie-strap.
7. Secure the steering gear. Install the bolts. Tighten the new nuts to 100 Nm (74 lb.ft), and then tighten a further 90 degrees.
8. Secure the steering gear high pressure line.
9. Connect the steering gear return line. Secure with the clip. Secure the steering gear return line.
10. Connect the steering gear control valve actuator electrical connector.
11. Connect the lower steering column shaft to the steering gear. Tighten the new bolt to 22 Nm (16 lb.ft).
12. Secure the LH stabilizer bar link. Install a new nut. Tighten the nut to 100 Nm (74 lb.ft).
13. Secure the RH stabilizer bar link. Install a new nut. Tighten the nut to 100 Nm (74 lb.ft).
14. Using the special tools, install a new halfshaft seal. The halfshaft seal protector must be left in place, until the halfshaft is fully installed.
15. Release the halfshaft and both lower arms. Remove and discard the tie strap.
16. Secure the halfshaft to the differential. Install a new snap ring.
17. Secure the rear lower arm. Install the bolt. Install a new nut. Tighten the new nut and bolt to 165 Nm (122 lb.ft), and then tighten a further 90 degrees.
18. Secure the front lower arm. Install the bolt. Install a new nut. Tighten the new nut and bolt to 165 Nm (122 lb.ft), and then tighten a further 90 degrees.
19. Secure both tie rod ends. Install new nuts. Tighten the nuts to 70 Nm (52 lb.ft).
20. LH front: Install the suspension height sensor. Tighten the bolts to 2.5 Nm (1.7 lb.ft). Connect the electrical connector. Secure with a tie strap.
21. Connect the height sensor link.
22. Install the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
23. Install the radiator splash shield. Refer to «Radiator Splash Shield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
24. Install the front wheels and tires. Tighten the wheel nuts to 140 Nm (103 lb.ft).
25. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
26. Fill and bleed the power steering system. Refer to «Power Steering System Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/steering/#steering-system-general-information__power-steering-system-filling-and-bleeding) .
27. Adjust the front wheel alignment.

STEERING GEAR (3.6L (TDV8) DIESEL RHD)

SPECIAL TOOLS Tool Illustration Tool Name Tool Number Ball joint separator 205-754(LRT-54-027) Impulse extractor 100-012(LRT-99-004) Installer halfshaft oil seal 308-626/1 Installer/Guide halfshaft oil seal 308-626/2

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

1. Raise and support the vehicle.
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
3. Center the steering wheel. Remove the ignition key.
4. Remove the front wheels and tires.
5. Remove the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
6. Remove the radiator splash shield. Refer to «Radiator Splash Shield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
7. Release the RH front brake caliper. Remove and discard the 2 bolts. Tie the brake caliper aside.
8. Remove the front axle. Refer to «Axle Assembly - 3.6L (TdV8) Diesel RHD»(/land-rover/range-rover/l322-2005-2009/remont/differentials-drive-axles/#front-drive-axledifferential__axle-assembly-36l-tdv8-diesel-rhd) .
9. Using the special tool release both tie rod ends. Remove and discard the 2 nuts. Using the special tool, release both tie rod end ball joints.
10. Release the RH front anti-lock brake system (ABS) sensor. Remove the bolt. Release the wiring harness.
11. RH front: With assistance, remove the halfshaft and wheel knuckle assembly. Remove and discard the 2 nuts and bolts.
12. RH front: Remove and discard the halfshaft seal.
13. Remove the halfshaft support bearing housing. Remove the 4 bolts. Remove and discard the O-ring seal.
14. Disconnect the lower steering column from the steering gear. Remove and discard the bolt.
15. Disconnect the steering gear control valve actuator electrical connector.
16. Release the steering gear high pressure line. Remove the nut.
17. Disconnect the power steering high pressure line and return line from the steering gear. Remove the 2 bolts. Remove and discard the 4 sealing washers.
18. Release the steering gear. Remove and discard the 2 nuts. Remove the 2 bolts.
19. Reposition the steering gear.
20. Release both the steering gear high pressure pipes. Remove the 2 bolts. Remove and discard the O-ring seals.
21. Remove both the steering gear high pressure pipes. Remove the 2 bolts. Remove and discard the O-ring seals.
22. Remove the steering gear.
23. Remove both tie rod ends. Remove and discard the locking ring. Remove and discard the locknut.

1. Install both tie rod ends. Install a new locking ring. Tighten the new nut to 70 Nm (52 lb.ft).
2. Install the steering gear.
3. Install both the steering gear high pressure pipes. Install new O-ring seals. Tighten the bolts.
4. Reposition the steering gear.
5. Secure the steering gear. Install the bolts. Tighten the new nuts to 100 Nm (74 lb.ft), and then tighten a further 90 degrees.
6. Connect the steering gear high pressure line. Install new sealing washers. Up to 07 MY : Tighten the bolt to 36 Nm (26 lb.ft). 07 MY on : Tighten the bolt to 28 Nm (21 lb.ft).
7. Connect the steering gear return line. Install new sealing washers. Up to 07 MY : Tighten the bolt to 40 Nm (30 lb.ft). 07 MY on : Tighten the bolt to 28 Nm (21 lb.ft).
8. Secure the steering gear high pressure line.
9. Connect the steering gear control valve actuator electrical connector.
10. Connect the lower steering column shaft to the steering gear. Tighten the new bolt to 24 Nm (18 lb.ft).
11. Install the halfshaft support bearing housing. Install a new O-ring seal. Tighten the 4 bolts to 22 Nm (16 lb.ft).
12. Using the special tool, install a new halfshaft seal. Clean the component mating face. Lubricate the seal with clean differential fluid.
13. RH front: With assistance, install the halfshaft and wheel knuckle assembly. Tighten the nuts and bolts to 250 Nm (184 lb.ft).
14. Secure the RH front ABS sensor. Apply anti-seize compound to the ABS sensor. Tighten the bolt to 8 Nm (6 lb.ft) Secure the wiring harness.
15. Secure both tie rod ends. Install new nuts. Tighten the nuts to 70 Nm (52 lb.ft).
16. Secure the RH front brake caliper. Clean the component mating faces. Tighten the new bolts to 65 Nm (48 lb.ft), then a further 90 degrees.
17. Install the front axle. Refer to «Axle Assembly - 3.6L (TdV8) Diesel RHD»(/land-rover/range-rover/l322-2005-2009/remont/differentials-drive-axles/#front-drive-axledifferential__axle-assembly-36l-tdv8-diesel-rhd) .
18. Install the radiator splash shield. Refer to «Radiator Splash Shield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
19. Install the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
20. Install the front wheels and tires. Tighten the wheel nuts to 140 Nm (103 lb.ft).
21. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

See also:
• Specifications
• Air Cleaner
• Air Cleaner
• Engine Undershield - Removal and Installation
• Power Steering System Filling and Bleeding
• Radiator
• Radiator
• Hood Latch Panel
• Front Bumper
• Power Steering System Flushing
• Accessory Drive Belt
• Accessory Drive Belt
• Standard Workshop Practices
• Steering Column
• Differential Draining and Filling
• Specifications
• Cooling Fan
• Cooling Fan
• Axle Assembly - 3.6L (TdV8) Diesel RHD
• SPECIFICATIONS
