Horn Land Rover Range Rover L322

Horns 2 illustrations ~199 words

SPECIFICATION

No data available

Scheme 1

Scheme 1: REMOVAL
Scheme 1: REMOVAL

Scheme 2

Scheme 2
Scheme 2
  1. Raise and support the vehicle.
  2. Remove the horn access panel. Remove the 5 clips. Remove the 3 screws.
  3. Remove the horn assembly. Remove the bolt. Disconnect the 2 electrical connectors.
  4. Remove the 2 horns from the mounting bracket. Remove the 2 nuts.

INSTALLATION

  1. Install the 2 horns to the mounting bracket. Tighten the 2 nuts to 10 Nm (7 lb.ft).
  2. Install the horn assembly. Connect the 2 electrical connectors. Install the bolt and tighten to 10 Nm (7 lb.ft).
  3. Install the horn access panel.

REMOVAL

WARNINGPersons working on the supplemental restraint system (SRS) must be fully trained and have been issued with the safety guidelines.
WARNINGAllow a period of 10 minutes to elapse after disconnecting the battery before undertaking any work on the SRS.
WARNINGThe SRS electrical connectors are unique. DO NOT force, or attempt to connect electrical connectors to the wrong sockets.
WARNINGThe correct procedures must always be used when working on SRS components.
WARNINGIt is imperative that before any work is undertaken on the SRS system, the appropriate information is read thoroughly.
WARNINGAlways disconnect both battery cables before beginning work on the SRS system. Disconnect the ground cable first. Never reverse connect the battery.
WARNINGTake extra care when handling SRS components.
  1. Make the air bag supplemental restraint system (SRS) safe. Refer to «STANDARD WORKSHOP PRACTICES»(/land-rover/range-rover/l322-2005-2009/remont/oem-general-information/#general-information) .
  2. Disconnect the battery ground cable. Refer to «SPECIFICATIONS»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  3. Remove the driver air bag module. Refer to «DRIVER AIR BAG MODULE»(/land-rover/range-rover/l322-2005-2009/remont/airbag/#supplemental-restraint-system) .
  4. Remove the horn switch. Disconnect the 3 electrical connectors. Remove the 2 screws.
  1. Install the horn switch. Connect the 3 electrical connectors. Install the 2 screws and tighten to 3 Nm (2 lb.ft).
  2. Install the driver air bag module. Refer to «DRIVER AIR BAG MODULE»(/land-rover/range-rover/l322-2005-2009/remont/airbag/#supplemental-restraint-system) .
  3. Connect the battery ground cable. Refer to «SPECIFICATIONS»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
