Full Frame and Body Mounting Land Rover Range Rover L322

Frames, Subframes & Crossmembers 6 illustrations ~505 words

SPECIFICATIONS

DescriptionNm
Transmission support crossmember damper90
Transmission support crossmember to chassis bolts68
Transmission support insulator through-bolt115
Exhaust hanger bolt45

TORQUE SPECIFICATIONS

Scheme 1

Scheme 1: REMOVAL
Scheme 1: REMOVAL

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
  2. Raise and support the vehicle.
  3. Remove the exhaust system. Refer to «Exhaust System»(/land-rover/range-rover/l322-2005-2009/remont/exhaust/#exhaust-system-44l) .
  4. Remove the RH heat shield. Remove the 7 nuts.
  5. Remove the LH heat shield. Remove the 5 nuts.
  6. Remove the LH exhaust hanger. Remove the nut.
  7. Remove the transmission support insulator nut, bolt and damper. Support the transmission.
  8. Release the catalyst monitor sensor wiring harness. Release the 4 clips.
  9. With assistance, remove the transmission support crossmember. Remove the 4 bolts and washers. Noting fitted position, remove the 4 spacers. Noting fitted position, remove the 2 transmission support insulator buffers.
  10. Remove the transmission support crossmember damper. Remove the nut and bolt.

INSTALLATION

  1. Install the transmission support crossmember damper. Tighten the nut and bolt to 90 Nm (66 lb.ft).
  2. With assistance, install the transmission support crossmember. Install the transmission support insulator buffers. Install the spacers. Tighten the bolts to 68 Nm (50 lb.ft).
  3. Attach the catalyst monitor sensor wiring harness. Secure the clips.
  4. Install the transmission support insulator nut, bolt and damper. Lower the transmission. Tighten the bolt to 115 Nm (85 lb.ft).
  5. Install the exhaust hanger. Tighten the nut to 45 Nm (33 lb.ft).
  6. Install the heat shields. Tighten the nuts.
  7. Install the exhaust system. Refer to «Exhaust System»(/land-rover/range-rover/l322-2005-2009/remont/exhaust/#exhaust-system-44l) .
  8. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .

REMOVAL

  1. Disconnect the battery ground cable.
  2. Raise and support the vehicle.
  3. Remove the exhaust system. Refer to «Exhaust System - Vehicles Without: Diesel Particulate Filter (DPF)»(/land-rover/range-rover/l322-2005-2009/remont/exhaust/#exhaust-system-42l) or «Exhaust System - Vehicles Without: Diesel Particulate Filter (DPF)»(/land-rover/range-rover/l322-2005-2009/remont/exhaust/#exhaust-system-44l) .
  4. Remove the RH heat shield. Remove the 7 nuts.
  5. Remove the LH heat shield. Remove the 5 nuts.
  6. Remove the LH exhaust hanger. Remove the nut.
  7. Remove the transmission support insulator nut, bolt and damper. Support the transmission.
  8. Release the catalyst monitor/temperature sensor wiring harness. Release the 4 clips.
  9. With assistance, remove the transmission support crossmember. Remove the 4 bolts and washers. Noting fitted position, remove the 4 spacers. Noting fitted position, remove the 2 transmission support insulator buffers.
  10. Remove the transmission support crossmember damper. Remove the nut and bolt.
  1. Install the transmission support crossmember damper. Tighten the nut and bolt to 90 Nm (66 lb.ft).
  2. With assistance, install the transmission support crossmember. Install the transmission support insulator buffers. Install the spacers. Tighten the bolts to 68 Nm (50 lb.ft).
  3. Attach the catalyst monitor/temperature sensor wiring harness. Secure the clips.
  4. Install the transmission support insulator nut, bolt and damper. Lower the transmission. Tighten the bolt to 115 Nm (85 lb.ft).
  5. Install the exhaust hanger. Tighten the nut to 45 Nm (33 lb.ft).
  6. Install the heat shields. Tighten the nuts.
  7. Install the exhaust system. Refer to «Exhaust System - Vehicles Without: Diesel Particulate Filter (DPF)»(/land-rover/range-rover/l322-2005-2009/remont/exhaust/#exhaust-system-42l) or «Exhaust System - Vehicles Without: Diesel Particulate Filter (DPF)»(/land-rover/range-rover/l322-2005-2009/remont/exhaust/#exhaust-system-44l) .
  8. Connect the battery ground cable.
