Multifunction Electronic Modules: Removal & Installation Land Rover Range Rover III facelift

Communication Devices 6 illustrations ~430 words

INSTALLATION

  1. Install the GEM. Connect the electrical connectors.
  2. Connect the battery ground cable. Refer to «SPECIFICATIONS»(ref-522601-S06524472732013011500000) .
  3. Move the passenger seat cushion fully rearwards.
  4. Install the GEM access panel. Install the clips.

Scheme 48

Scheme 48: REMOVAL
Scheme 48: REMOVAL

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52
  1. Disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-522601-S06524472732013011500000) .
  2. Remove the access panel from the loadspace trim panel LH.
  3. Remove the loadspace trim panel, floor stowage compartment LH access cover.
  4. Raise and support the spare tire loadspace trim panel.
  5. Remove the LH finisher trim panel. Remove the luggage tie down ring. Remove the 2 turn fasteners securing the LH finisher trim panel.
  6. Remove the lower turn fastener, securing the front loadspace trim panel LH.
  7. Remove the trim clip securing the front loadspace trim panel LH to the floor stowage compartment.
  8. Remove the LH floor stowage compartment. Remove the 3 nuts.
  9. Remove the information and entertainment module upper bracket. Remove the 2 bolts. Remove the 2 screws.
  10. Release the information and entertainment module from its lower locating bracket.
  11. Remove the information and entertainment module. Disconnect the optical connector. Disconnect the 7 electrical connectors.
  12. Remove the information and entertainment module lower bracket. Remove the 2 screws.
  1. Install the information and entertainment lower bracket. Install the screws.
  2. Install the information and entertainment module. Connect the optical connector. Connect the electrical connectors.
  3. Install the information and entertainment module upper bracket. Tighten the bolts to 10 Nm (7 lb.ft).
  4. Install the LH floor stowage compartment. Install the nuts.
  5. Install the trim clip securing the front loadspace trim panel LH to the floor stowage compartment.
  6. Install the lower turn fastener, securing the front loadspace trim panel to the floor stowage compartment.
  7. Install the LH finisher trim panel. Install the turn fasteners.
  8. Install the luggage tie down ring. Tighten the bolt to 25 Nm (18 lb.ft).
  9. Lower and secure the spare tire loadspace trim panel.
  10. Install the loadspace trim panel, floor stowage compartment LH access cover.
  11. Install the access panel to the loadspace trim panel LH.
  12. Connect the battery ground cable. Refer to «SPECIFICATIONS»(ref-522601-S06524472732013011500000) .
  13. Using the Land Rover approved diagnostic system, follow the on-screen instructions and configure the information and entertainment module.

Scheme 53

Scheme 53: REMOVAL
Scheme 53: REMOVAL
  1. Remove the access panel from the loadspace trim panel LH.
  2. Release the multifunction voice activated module. Remove the 2 nuts.
  3. Remove the multifunction voice activated module. Disconnect the electrical connector.
  1. Install the multifunction voice activated module. Connect the electrical connector.
  2. Secure the multifunction voice activated module. Tighten the bolts to 6 Nm (4 lb.ft).
  3. Install the access panel to the loadspace trim panel LH.
