SPECIFICATIONS
| Item | Specification |
|---|
| Type | Cable operated from shift mechanism to bellcrank on side of gearbox with manual release from Park 'P' position in the event of electrical failure |
| Description | Nm |
|---|
| Selector lever locknut | 14 |
| Transmission heat shield bolts | 10 |
| Transmission undershield bolts | 10 |
| Transmission selector nuts | 8* |
*Before VIN257100, discard old fixings and tighten new fixings to the torque value given.
Scheme 87
Scheme 87: GEAR SELECTOR LEVER ASSEMBLY COMPONENT LOCATION
| Item Number | Description |
|---|
| 1 | Selector cable |
| 2 | Shift interlock solenoid |
| 3 | Selector lever |
| 4 | Manual +/- CommandShift switch |
| 5 | Selector lever and shroud |
| 6 | Park/Reverse release button |
| 7 | Selector lever cover |
| 8 | High/Low range selector switch |
| 9 | Selector position LED display |
| 10 | Hill Descent Control (HDC) switch |
| 11 | Key interlock cable |
| 12 | Key interlock mechanism |
| 13 | Selector lever position switch |
| 14 | Manual/Sport switch |
| 15 | Mounting plate |
