SPECIFICATIONS
| Description | Nm |
|---|---|
| Tailgate speaker to casing bolts | 10 |
| Tailgate speaker to tailgate Torx screws | 10 |
TORQUE SPECIFICATIONS
Scheme 67
| Item Number | Description |
|---|---|
| 1 | Left-hand (LH) front door tweeter |
| 2 | Right-hand (RH) front door tweeter |
| 3 | RH front door mid-range |
| 4 | Center fill speaker - Logic7 only |
| 5 | RH front door woofer |
| 6 | RH rear door mid-high range |
| 7 | Audio amplifier rear door mid-woofer |
| 8 | Subwoofer |
| 9 | LH rear door mid-high range |
| 10 | LH rear door mid-woofer |
| 11 | LH front door mid-range |
| 12 | LH front door woofer |
Scheme 68
| Item Number | Description |
|---|---|
| 1 | LH front door tweeter |
| 2 | Center fill speaker (co-axial speaker on 1200W Premium system) |
| 3 | RH front door tweeter |
| 4 | RH front door mid-range |
| 5 | RH front door woofer |
| 6 | RH rear door mid-high range (co-axial speaker on 1200W Premium system) |
| 7 | RH rear door mid-woofer |
| 8 | E pillar surround (2 off) (co-axial speaker on 1200W Premium system) |
| 9 | Audio amplifier |
| 10 | Subwoofer |
| 11 | LH rear door mid-high range (co-axial speaker on 1200W Premium system) |
| 12 | LH rear door mid-woofer |
| 13 | LH front door mid-range |
| 14 | LH front door woofer |
The speaker configuration depends on the level of audio unit fitted to the vehicle. Three systems are available; DSP, Logic7 and Logic7 HD Premium. The following details the speaker configuration and control for each system.
Scheme 69
The Digital Sound Processor (DSP) amplifier is located in the rear left-hand (LH) side of the luggage compartment. The DSP amplifier drives 11 speakers; two front door mid-range, four front and rear door bass, four front and rear door tweeters on eight channels and a passive subwoofer. The amplifier produces 320 Watts of digital amplification to power the speakers.
Scheme 70
The Logic7 and Logic7 HD 1200W Premium system amplifiers are located in the rear left-hand (LH) side of the luggage compartment.
