Audio Unit: Specifications Land Rover Range Rover III facelift 2

Entertainment Systems 4 illustrations ~284 words

SPECIFICATIONS

DescriptionNm
Audio unit to audio unit bracket screws1
Compact disc (CD) changer1
Amplifier mounting bracket side bolts9
Amplifier mounting bracket bottom bolts5
Amplifier bolts5
Antenna nuts6

TORQUE SPECIFICATIONS

Scheme 1

Scheme 1: REMOVAL
Scheme 1: REMOVAL

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4
  1. Disconnect the battery ground cable. For additional information, refer to «Specifications»(ref-514850).
  2. Remove the information and entertainment module. For additional information, refer to «Information and Entertainment Module»(ref-514946-S30524041022012112600000).
  3. Release the information and entertainment assembly. Remove the 5 bolts. Remove the 2 nuts.
  4. Reposition the information and entertainment assembly for access. Disconnect the 2 coaxial cable connectors. Disconnect the 3 electrical connectors. Disconnect the 3 optical connectors. CAUTION: Cover fiber optic cable connectors to minimize dust ingress and avoid bending the cables in a radius of less than 30 mm.
  5. Remove the information and entertainment assembly.
  6. Remove the satellite radio tuner (NAS variants only). Disconnect the optical connector. Disconnect the electrical connector. Remove the bolt. CAUTION: Cover fiber optic cable connectors to minimize dust ingress and avoid bending the cables in a radius of less than 30 mm.
  7. Release the audio unit amplifier and television (TV) receiver assembly. Remove the 2 bolts and 4 nuts securing the audio unit amplifier and TV receiver mounting bracket.
  8. Disconnect the TV receiver connections. Disconnect the optical connector. Disconnect the 3 electrical connectors. CAUTION: Cover fiber optic cable connectors to minimize dust ingress and avoid bending the cables in a radius of less than 30 mm.
  9. Disconnect the audio unit amplifier connections. Disconnect the audio unit amplifier 2 optical connectors. Disconnect the 3 electrical connectors. Release the wiring harness clip. CAUTION: Cover fiber optic cable connectors to minimize dust ingress and avoid bending the cables in a radius of less than 30 mm.
  10. Remove the audio unit amplifier and TV receiver assembly.
  11. Remove the audio unit amplifier. Remove the 4 bolts.
