Audio Unit Land Rover Range Rover Sport L320

Entertainment Systems 4 illustrations ~152 words

SPECIFICATIONS

DescriptionNm
Audio amplifier bolts10

TORQUE SPECIFICATIONS

AUDIO SYSTEM

For additional information. Refer to Information and Entertainment System .

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 13

Scheme 13: REMOVAL
Scheme 13: REMOVAL

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
  1. Torque: 2.5 Nm
  2. Torque: 2.5 Nm
  3. Torque: 2.5 Nm
  4. Torque: 2.5 Nm

INSTALLATION

  1. To install, reverse the removal procedure.
  1. Disconnect the battery ground cable. Refer to «SPECIFICATIONS»(/land-rover/range-rover-sport/l320-2009-2013/remont/charging-system/#battery-charging-system-general-information) .
  2. Remove the RH front seat. Refer to «FRONT SEAT»(/land-rover/range-rover-sport/l320-2009-2013/remont/seats/#seating) .
  3. Remove the amplifier. Remove the 4 bolts. Disconnect the 5 electrical connectors.
  1. Install the amplifier. Install the bolts and tighten to 10 Nm (7 lb.ft). Connect and secure the electrical connectors.
  2. Install the front seat. Refer to «FRONT SEAT»(/land-rover/range-rover-sport/l320-2009-2013/remont/seats/#seating) .
  3. Connect the battery ground cable. Refer to «SPECIFICATIONS»(/land-rover/range-rover-sport/l320-2009-2013/remont/charging-system/#battery-charging-system-general-information) .
  4. Using the Land Rover approved diagnostic equipment, follow the on-screen instructions and configure the audio unit amplifier.
