Engine: Adjustments Land Rover Freelander L359

VALVE CLEARANCE ADJUSTMENT

303-1235 Holder, Camshaft

Scheme 3

Scheme 4

1. Raise and support the vehicle.
2. Remove the cover and disconnect the battery ground cable. Refer to «Specifications»(ref-531959-S27829531522013022000000) .
3. Remove the camshafts. See «Camshafts»(ref-531921-S31010056482013022000000) .
4. Replace the valve shims, with the smallest shim available.
5. Using the special tools, position and secure the exhaust camshaft. Holder, Camshaft (303-1235)
6. Using the original bolt, install the camshaft sprocket and lightley tighten.
7. Using a feeler gauge, measure the clearance between the camshaft and the valve shim.
8. Measure and record the tappet clearances.
9. Remove the camshaft sprocket.
10. Remove the special tool.
11. Remove the exhaust camshaft.
12. Remove the valve tappets, replace with selected tappets.
13. Install the camshafts. See «Camshafts»(ref-531921-S31010056482013022000000) .
14. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-531959-S27829531522013022000000) .
