Engine Cooling: Removal & Installation Land Rover Freelander L359

Cooling Fan 19 illustrations ~735 words

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 1

Scheme 1: REMOVAL
Scheme 1: REMOVAL

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3
  1. Raise and support the vehicle.
  2. Remove the intake manifold assembly. Refer to «INTAKE MANIFOLD»(ref-531921-S34523514272013022000000) .
  3. Drain the cooling system. See «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-531918-S31491615612013022000000) .
  4. Torque: 10 Nm
  5. Remove the thermostat.
  6. Remove and discard the gasket.
  7. Remove the ECT sensor.

INSTALLATION

  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to «POWERTRAIN CONTROL MODULE (PCM) LONG DRIVE CYCLE SELF-TEST»(ref-531942-S33376475422013022000000) .

Scheme 4

Scheme 4: REMOVAL
Scheme 4: REMOVAL

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Remove the cover and disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .
  2. Remove the engine cover. Refer to «ENGINE COVER - 3.2L»(ref-531951-S06303498242013022000000) .
  3. Remove the battery tray. Refer to «BATTERY TRAY»(ref-531940-S37654936752013022000000) .
  4. Remove the air cleaner assembly. Refer to «AIR CLEANER»(ref-531922-S17101109672013022000000) .
  5. Drain the coolant. See «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-531918-S31491615612013022000000) .
  6. Remove the A/C compressor, lower support bracket.
  7. Using suitable tools, release the accessory drive belt tension.
  8. Remove the power steering pump support bracket
  9. Release the power steering pump.
  10. Remove the coolant pump.
  1. Install the coolant pump. Torque: 17 Nm
  2. Install the power steering pump. Torque: 25 Nm
  3. Install the power steering pump support bracket. Torque: 25 Nm
  4. Install the accessory drive belt.
  5. Install the A/C compressor, lower support bracket. Torque: 25 Nm
  6. Install the air cleaner assembly. Refer to «AIR CLEANER»(ref-531922-S17101109672013022000000) .
  7. Install the battery tray. Refer to «BATTERY TRAY»(ref-531940-S37654936752013022000000) .
  8. Install the engine cover. Refer to «ENGINE COVER - 3.2L»(ref-531951-S06303498242013022000000) .
  9. Connect the battery ground cable and install the cover. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .
  10. Fill and bleed the cooling system. See «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-531918-S31491615612013022000000) .

Scheme 9

Scheme 9: REMOVAL
Scheme 9: REMOVAL

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
  1. Raise and support the vehicle.
  2. Remove the bumper armature. Refer to «FRONT BUMPER»(ref-531966) .
  3. Drain the cooling system. See «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-531918-S31491615612013022000000) .
  4. Release power steering cooler and secure aside.
  5. Release the A/C condenser and position aside.
  6. Release the automatic transmission fluid cooler and tie aside.
  7. See figure CAUTION: Protect the radiator during this operation.
  8. See figure NOTE: Do not disassemble further if the component is removed for access only.
  1. Install the rubber mounts.
  2. Install the cooling fan assembly.
  3. Carefully install the radiator.
  4. Install the A/C condenser, and tighten the bolt. Torque: 10 Nm
  5. Install the mountings and tighten the bolts. Torque: 6 Nm
  6. Connect and secure the electrical connector.
  7. Install the automatic transmission fluid cooler.
  8. Connect the coolant top hose.
  9. Connect the coolant lower hose.
  10. Install the PAS cooler and tighten the bolts. Torque: 10 Nm
  11. Install the air deflector.
  12. Fill and bleed the cooling system. See «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-531918-S31491615612013022000000) .
  13. Install the bumper. Refer to «FRONT BUMPER»(ref-531966) .

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
  1. Raise and support the vehicle.
  2. Disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .
  3. Remove the intake manifold. Refer to «INTAKE MANIFOLD»(ref-531921-S34523514272013022000000) .
  4. Release the A/C and power steering pipes.
  5. Remove the A/C line support bracket.
  6. Remove the A/C compressor, lower support bracket.
  7. Remove the A/C compressor, upper support bracket.
  8. Using suitable tools, release the accessory drive belt tension.
  9. Release the A/C compressor and position aside.
  10. Disconnect the cooling fan control electrical connector.
  11. Release the cooling fan wiring harness.
  12. Remove the cooling fan assembly.
  1. Install the cooling fan assembly.
  2. Install the A/C compressor. Torque: 25 Nm
  3. Install the A/C compressor, upper support bracket. Torques: M10: 45 Nm M8: 25 Nm M6: 10 Nm
  4. Install the accessory drive belt.
  5. Install the A/C compressor, lower support bracket. Torque: 25 Nm
  6. Install the A/C line support bracket. Torque: 10 Nm
  7. Secure the A/C pipes.
  8. Secure the cooling fan harness.
  9. Connect the cooling fan electrical connector.
  10. Install the intake manifold. Refer to «INTAKE MANIFOLD»(ref-531921-S34523514272013022000000) .
  11. Connect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .

Note. Petrol illustration shown, diesel similar.

  1. Remove the cover and disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .
  2. Remove the cooling fan module. Torque: 6 Nm
  1. To install, reverse the removal procedure.
WARNINGWhen releasing the cooling system pressure, cover the coolant expansion tank cap with a thick cloth.

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Torque: 10 Nm
  2. Clamp the relevant hose, to minimize coolant loss. CAUTION: Be prepared to collect escaping coolant.
  3. See figure NOTE: Do not disassemble further if the component is removed for access only.
  1. To install, reverse the removal procedure.
  2. Top-up the coolant.

Note. Removal steps in this procedure may contain installation details.

Scheme 19

Scheme 19
Scheme 19
  1. Torque: 10 Nm
  1. To install, reverse the removal procedure.
