Wiring Harnesses & Fuse Box Land Rover Freelander L314

86.70.01 FUSE BOX - PASSENGER COMPARTMENT

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 1

1. Disconnect battery earth lead.
2. Open glove box.
3. Remove hinge pins and lid.
4. Remove fuse box cover.
5. Remove relays from fuse box mounting plate.
6. Remove bolt securing fuse box mounting plate to steering column bracket.
7. Remove 2 bolts securing mounting plate to body.
8. Remove 2 bolts securing fuse box to mounting plate.
9. Disconnect 3 multiplugs from CCU in rear of fuse box.
10. Release fusebox and disconnect 8 multiplugs.
11. Remove fusebox.
12. Remove fuses and relays from fuse box.

REFIT

1. Identify and fit fuses.
2. Fit relays.
3. Fit fuse box.
4. Connect multiplugs to fusebox.
5. Connect multiplugs to CCU.
6. Fit bolts securing fuse box to mounting plate and tighten to 8 Nm (6 lbf.ft).
7. Fit bolts securing fuse box mounting plate to body and tighten to 8 Nm (6 lbf.ft).
8. Fit relays to mounting plate.
9. Fit fuse box cover.
10. Fit glove box lid and hinge pins.
11. Close lid.
12. Connect battery earth lead.

86.70.07 HARNESS - MAIN

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

1. Make the SRS system safe. See SUPPLEMENTARY RESTRAINT SYSTEM PRECAUTIONS in appropriate AIRBAG RESTRAINTS article.
2. Remove carpet.
3. Remove engine acoustic cover. See «COVER -- ENGINE ACOUSTIC»(ref-158807-S41252329712005011200000) .
4. Remove windscreen washer reservoir. See «84.10.01 RESERVOIR - WASHER»(/land-rover/freelander/l314-2003-2006/remont/wiperwasher-systems/#wipers-and-washers__841001-reservoir-washer) .
5. Pull reservoir harness and washer tubes into engine bay.
6. Remove nut and release earth header from RH inner wing.
7. Disconnect multiplug from ABS modulator.
8. Disconnect multiplug from RH ABS speed sensor and release harness from clips.
9. Disconnect 2 multiplugs from RH headlamp and headlamp levelling motor.
10. Disconnect multiplugs from horn, refrigerant pressure sensor and compressor.
11. Remove jack from holder in engine bay.
12. Disconnect multiplug from brake fluid low level indicator switch.
13. Disconnect multiplug from bonnet switch.
14. Remove bolt and 2 nuts securing PAS and coolant reservoir support bracket and position aside.
15. Release 5 harness retaining clips.
16. Release front screen wash tube from harness and position aside.
17. Remove nut securing earth header to bulk head and remove earth header.
18. With assistance feed harness through bulk head into vehicle.
19. Remove battery carrier.
20. Remove 3 cable ties and release bonnet release cable from harness.
21. Disconnect multiplug from cooling fan pack and 2 multiplugs from cooling fans.
22. Release 4 clips securing harness to cooling fans and release harness from cooling fans.
23. Disconnect 2 multiplugs from LH headlamp and headlamp levelling motor.
24. Disconnect multiplug from harness.
25. Remove nut securing LH earth header and release header.
26. Disconnect multiplug from front LH ABS speed sensor.
27. Disconnect Lucar connector from starter motor.
28. Models With Cruise Control: Disconnect multiplug from cruise control vacuum pump.
29. Release 5 harness retaining clips.
30. Disconnect 2 engine harness to main harness multiplugs.
31. Release 5 Allen screws securing 'E' box cover to 'E' box.
32. Remove 'E' box cover
33. Automatic Gearbox Only: Disconnect multiplug from automatic gearbox ECU.
34. Disconnect 2 engine harness to main harness multiplugs.
35. Disconnect 'E' box temperature sensor multiplug.
36. Disconnect 'E' box cooling fan multiplug.
37. Remove fuse box cover.
38. Remove 2 bolts securing battery connections to fuse box and disconnect multiplug from fuse box.
39. Remove 3 nuts securing fuse box to brackets.
40. Disconnect 6 multiplugs from the underside of fusebox.
41. Disconnect multiplug from inertia switch.
42. Release 2 fixings securing harness to LH side of engine bay.
43. Remove air intake plenum. See «80.15.62 PLENUM - AIR INTAKE»(/land-rover/freelander/l314-2003-2006/remont/heater/#heating-and-ventilation__801562-plenum-air-intake) .
44. Disconnect multiplug from wiper motor and pull into engine bay.
45. With assistance pull main harness into vehicle interior.
46. Remove 6 screws securing front mud flaps and remove mud flaps.
47. Release rear edges of front wheel arch liners.
48. Release side repeater lamps, disconnect multiplugs and remove lamps.
49. Remove 3 bolts from passenger compartment fuse box and pull fuse box forward.
50. Release and disconnect multiplug from RH "A" post.
51. Disconnect coaxial cable.
52. Release relays from fuse box bracket.
53. Release fuse box, disconnect 11 multiplugs and remove fuse box.
54. Disconnect multiplug from steering column switch.
55. Release harness clip from steering column.
56. Disconnect multiplug from throttle position sensor.
57. Disconnect multiplugs from brake light switch and brake pedal position switch.
58. Disconnect multiplug from airbag ECU.
59. Remove airbag ECU securing bolt and release earth lead.
60. Remove nut from earth header and release header from floor tunnel.
61. Disconnect heated oxygen sensor multiplug.
62. Automatic Gearbox Only: Disconnect multiplugs from gear selector.
63. Disconnect multiplug from accelerometer.
64. Manual Gearbox Only: Disconnect multiplug from gear lever hill descent switch.
65. Disconnect Lucar from handbrake switch.
66. Release 2 relays from bracket and remove bracket.
67. Release 4 clips securing harness to air ducting.
68. Remove nut from rear heater ducting and remove ducting.
69. Remove 4 nuts securing steering column to bracket and lower column.
70. Remove face level vent ducting to access main harness clips.
71. Disconnect multiplug from window lift ECU.
72. Remove nut securing earth header to RH "A" post and release header.
73. Release multiplugs and earth header from LH lower "A" post.
74. Release all harness clips from interior of vehicle.
75. Release and disconnect multiplugs from base of "B & C" posts.
76. Remove luggage compartment carpet. See «76.49.04 CARPET - LUGGAGE COMPARTMENT»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764904-carpet-luggage-compartment) .
77. Remove 6 screws from fuel pump access cover and remove cover.
78. Disconnect multiplug from fuel pump.
79. Release both rear ABS speed sensor harnesses and disconnect multiplugs.
80. Pull harness into vehicle interior.
81. Release and disconnect rear window lift and wash/wipe relays.
82. Disconnect 3 multiplugs from tail door harness.
83. Disconnect rear screen washer tube.
84. Disconnect multiplug from towing electrics.
85. Remove nut from RH rear earth header and release header.
86. Remove 3 Torx screws securing RH tail lamp to body.
87. Disconnect multiplugs and remove tail lamp.
88. Disconnect multiplugs from LH tail lamp.
89. Remove nut from LH rear earth header and release header.
90. Remove 4 screws from rear bumper lamps, release lamps and disconnect multiplugs.
91. Release harness clips and pull harness into luggage compartment.
92. Release main harness retaining clips and pull harness into vehicle interior.
93. Remove main harness.

1. Lay main harness in vehicle.
2. Locate rear section and secure in retaining clips.
3. Feed harness to rear bumper lamps, secure in clips and grommets.
4. Connect multiplugs to rear bumper lamps, fit rear lamps and secure with screws.
5. Fit LH rear earth header and secure with nut.
6. Connect multiplugs to LH tail lamp.
7. Position RH tail lamp and connect multiplugs.
8. Fit RH tail lamp and secure with Torx screws.
9. Fit RH rear earth header and secure with nut.
10. Connect multiplug to towing electrics.
11. Connect rear screen washer tube.
12. Connect tail door harness multiplugs.
13. Connect and fit rear window lift and wash/wipe relays.
14. Position harness into luggage compartment.
15. Connect both rear ABS speed sensor multiplugs and secure harness grommets.
16. Connect multiplug to fuel pump.
17. Fit fuel pump access cover and secure with screws.
18. Fit luggage compartment carpet. See «76.49.04 CARPET - LUGGAGE COMPARTMENT»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764904-carpet-luggage-compartment) .
19. Connect multiplugs at the base of "B & C" Posts.
20. Fit all harness clips to interior of vehicle.
21. Fit multiplugs and earth header to LH lower "A" post.
22. Fit earth header to RH lower "A" post.
23. Connect multiplug to window lift ECU.
24. Fit face level vent ducting.
25. Fit steering column to bracket and secure with nuts.
26. Fit rear heater ducting and secure with nut.
27. Secure harness to rear heater ducting with clips.
28. Position mounting bracket and secure relays.
29. Connect Lucar to handbrake switch.
30. Manual Gearbox Only: Connect multiplug to gear lever hill descent switch.
31. Connect multiplug to accelerometer.
32. Automatic Gearbox Only: Connect multiplugs to gear selector.
33. Connect heated oxygen sensor multiplug.
34. Fit earth header to floor tunnel and secure with nut.
35. Fit earth lead to airbag ECU and secure with bolt.
36. Connect multiplug to airbag ECU.
37. Connect multiplugs to brake light switch and brake pedal position switch.
38. Connect multiplug to throttle position sensor.
39. Fit harness clip to steering column.
40. Connect multiplug to steering column switch.
41. Position fuse box to body and connect multiplugs.
42. Fit relays to fuse box bracket.
43. Connect coaxial cable.
44. Fit and connect multiplug to RH "A" post.
45. Fit passenger compartment fuse box and secure with bolts.
46. Position side repeater lamps, connect multiplugs and fit to wings.
47. Secure rear edge of front wheel arch liners.
48. Fit front mud flaps and secure with screws.
49. With assistance feed harness through bulk head into engine bay.
50. Position harness to wiper motor and connect multiplug.
51. Fit air intake plenum. See «80.15.62 PLENUM - AIR INTAKE»(/land-rover/freelander/l314-2003-2006/remont/heater/#heating-and-ventilation__801562-plenum-air-intake) .
52. Secure harness to LH side of engine bay and secure fixings.
53. Connect multiplug to inertia switch.
54. Connect multiplugs to underside of fuse box.
55. Fit nuts securing fuse box to brackets.
56. Fit battery connections and multiplug to fuse box.
57. Fit fuse box cover.
58. Connect 'E' box cooling fan multiplug.
59. Connect 'E' box temperature sensor multiplug.
60. Connect engine harness multiplugs to main harness.
61. Automatic Gearbox Only: Connect multiplug to gearbox ECU.
62. Fit 'E' box cover and secure with Allen screws.
63. Connect engine harness multiplugs to main harness.
64. Fit harness retaining clips.
65. Models With Cruise Control: Connect multiplug to vacuum pump.
66. Connect Lucar connector to starter motor.
67. Connect multiplug to LH ABS speed sensor.
68. Fit LH earth header and secure with nut.
69. Connect multiplug to harness.
70. Connect multiplugs to LH headlamp and headlamp levelling motor.
71. Secure harness to cooling fan clips.
72. Connect multiplugs to cooling fan pack and cooling fans.
73. Position bonnet release cable to harness and secure with cable ties.
74. Fit battery carrier.
75. With assistance feed harness through bulk head into engine bay.
76. Fit earth header to bulk head and secure with nut.
77. Fit front screen washer tube to harness.
78. Fit harness retaining clips.
79. Fit PAS and coolant reservoir support bracket and secure with bolt and nuts.
80. Connect multiplug to bonnet switch.
81. Connect multiplug to brake fluid low level indicator switch.
82. Fit jack to holder in engine bay.
83. Connect multiplugs to horn, refrigerant pressure sensor and compressor.
84. Connect multiplugs to RH headlamp and headlamp levelling motor.
85. Connect multiplug to RH ABS speed sensor and secure to clips.
86. Connect multiplug to ABS modulator.
87. Fit earth header to RH inner wing and secure with nut.
88. Position harness to windscreen washer reservoir.
89. Fit windscreen washer reservoir. See «84.10.01 RESERVOIR - WASHER»(/land-rover/freelander/l314-2003-2006/remont/wiperwasher-systems/#wipers-and-washers__841001-reservoir-washer) .
90. Fit engine acoustic cover. See «COVER -- ENGINE ACOUSTIC»(ref-158807-S41252329712005011200000) .
91. Fit carpet.

86.70.19 HARNESS - TAILGATE

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. Remove RH rear quarter lower trim casing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .
2. Remove tail door plastic sheet. See «76.34.25 PLASTIC SHEET - TAIL DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#doors-door-trim__763425-plastic-sheet-tail-door) .
3. Remove 3 nuts and remove spare wheel.
4. Remove 3 screws securing CHMSL, disconnect multiplug and remove CHMSL.
5. Release 2 harness clips.
6. Disconnect rear washer tube from behind the spare wheel carrier.
7. Remove 3 nuts from number plate lamp housing and release housing.
8. Disconnect 2 Lucars and multiplug from housing.
9. Collect 2 spacers and housing seal.
10. Remove housing.
11. Disconnect 2 Lucars from rear screen element.
12. Remove 4 screws from door latch, release door latch to access multiplugs and harness clips.
13. Disconnect 2 multiplugs from door lock.
14. Disconnect multiplug from rear wiper motor.
15. Disconnect multiplug from rear window motor.
16. Release and disconnect 3 multiplugs and washer tube from main harness at 'E' post.
17. Release tail door harness from 13 retaining clips.
18. Release harness sheath from tail door and 'E' post.
19. Remove harness from vehicle.

1. Position harness to vehicle and secure in retaining clips.
2. Secure harness sheath to tail door and 'E' post.
3. Connect multiplugs and washer tube to main harness, secure multiplugs to body.
4. Connect multiplugs to window motor, wiper motor and door lock.
5. Position door latch, fit and tighten screws.
6. Connect Lucars to heated rear screen.
7. Position number plate lamp housing, locate seal and fit spacers.
8. Connect multiplug and Lucars to housing.
9. Fit housing and secure with nuts.
10. Connect washer tube behind spare wheel carrier.
11. Secure harness clips to spare wheel carrier, connect multiplug to CHMSL, fit CHMSL and secure with screws.
12. Fit spare wheel and secure with nuts.
13. Fit tail door plastic sheet. See «76.34.25 PLASTIC SHEET - TAIL DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#doors-door-trim__763425-plastic-sheet-tail-door) .
14. Fit rear lower trim casing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .

86.70.44 HARNESS - INTERIOR LIGHTS - 5 DOOR

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 41

1. Remove fascia. See «76.46.23 FASCIA - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764623-fascia-up-to-04my) or «76.46.23 FASCIA - FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764623-fascia-from-04my) .
2. Remove headlining. See «76.64.15 HEADLINING - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__766415-headlining-5-door) .
3. Disconnect aerial connection and interior light harness from main harness.
4. Disconnect multiplug from volumetric sensor.
5. Release 10 harness clips.
6. Remove harness.

1. Position harness and secure harness clips.
2. Connect multiplug to volumetric sensor.
3. Connect multiplug and aerial connection to main harness.
4. Fit headlining. See «76.64.15 HEADLINING - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__766415-headlining-5-door) .
5. Fit fascia. See «76.46.23 FASCIA - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764623-fascia-up-to-04my) or «76.46.23 FASCIA - FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764623-fascia-from-04my) .

86.70.65 HARNESS - FRONT DOOR - 5 DOOR

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 42

1. Remove front door plastic sheet. See «76.34.26 PLASTIC SHEET - FRONT DOOR - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#doors-door-trim__763426-plastic-sheet-front-door) .
2. Disconnect multiplugs from door lock, door mirror and window motor.
3. Release 8 clips securing door harness to door.
4. Release 2 multiplugs from location at base of 'A' post and disconnect multiplugs.
5. Release sheath from front edge of door, and pull harness from door.
6. Release sheath from 'A' post and pull harness from 'A' post.
7. Remove door harness.

1. Position harness to 'A' post and feed harness partly into 'A' post.
2. Feed sheath onto harness and locate sheath to 'A' post.
3. Feed harness through front edge of door and secure sheath to door.
4. Connect and secure multiplugs at base of 'A' post.
5. Position harness to door and secure with clips.
6. Connect multiplugs to door mirror, door lock and window motor.
7. Fit front door plastic sheet. See «76.34.26 PLASTIC SHEET - FRONT DOOR - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#doors-door-trim__763426-plastic-sheet-front-door) .

86.70.66 HARNESS - REAR DOOR

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 43

Scheme 44

Scheme 45

1. Remove rear door plastic sheet. See «76.34.28 PLASTIC SHEET - REAR DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#doors-door-trim__763428-plastic-sheet-rear-door) .
2. Disconnect multiplugs from door latch and window lift motor.
3. Release 7 clips securing door harness to door.
4. Release 'B/C' post upper finisher from 6 clips and position aside.
5. Release multiplug from location at base of 'B/C' post and disconnect multiplug.
6. Release harness sheath from 'B/C' post and pull door harness through 'B/C' post.
7. Release sheath from front edge of door and pull harness into door.
8. Remove door harness.

1. Position harness to door and secure with clips.
2. Connect multiplugs to door latch and window lift motor.
3. Feed harness through front edge of door and secure sheath to door.
4. Feed harness into 'B/C' post and secure sheath to 'B/C' post.
5. Connect and secure multiplug at base of 'B/C' post.
6. Position 'B/C' post upper finisher and secure with clips.
7. Fit rear door plastic sheet. See «76.34.28 PLASTIC SHEET - REAR DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#doors-door-trim__763428-plastic-sheet-rear-door) .

See also:
• 84.10.01 RESERVOIR - WASHER
• 80.15.62 PLENUM - AIR INTAKE
• 76.49.04 CARPET - LUGGAGE COMPARTMENT
• 76.13.12 TRIM CASING - REAR QUARTER - LOWER
• 76.34.25 PLASTIC SHEET - TAIL DOOR
• 76.46.23 FASCIA - UP TO 04MY
• 76.46.23 FASCIA - FROM 04MY
• 76.64.15 HEADLINING - 5 DOOR
• 76.34.26 PLASTIC SHEET - FRONT DOOR - 5 DOOR
• 76.34.28 PLASTIC SHEET - REAR DOOR
