Interior Trim Components Land Rover Discovery L318

Exterior/interior Trim 52 illustrations ~3992 words

Scheme 1

Scheme 1: Remove
Scheme 1: Remove

Refit

  1. Fit trim casing to speaker assembly and secure with screws.
  2. Fit grille to trim casing and secure with screws.

Scheme 2

Scheme 2: Remove
Scheme 2: Remove

Scheme 3

Scheme 3
Scheme 3
  1. Models with third row seats: Remove third row seat. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/seats/#seats) .
  2. For LH trim casing: Remove accessory socket.
  3. Remove 'D' post trim casing. Refer to «TRIM CASING - 'D' POST»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  4. Remove screw securing trim cap to trim casing.
  5. Release trim cap from trim casing.
  6. Models with ICE headphone control panels: Disconnect multiplug from headphone control panel and remove trim cap.
  7. Partially remove rear door aperture seal.
  8. Remove 2 trim clips securing trim casing to body.
  9. Remove access panel.
  10. Remove trim clip securing trim casing to lower 'D' post.
  11. Models without third row seats: Remove trim clip from bottom rear corner of trim casing.
  12. Release trim casing to gain access to rear seat belt reel.
  13. Remove bolt securing rear seat belt reel to body.
  14. Remove trim casing.
  1. Position trim casing.
  2. Fit rear seat belt reel to body and tighten bolt to 50 Nm (37 lbf.ft).
  3. Models without third row seats: Fit trim clip securing bottom rear corner of trim casing.
  4. Fit trim clip securing trim casing to lower 'D' post.
  5. Fit access panel to trim casing.
  6. Fit trim clips securing trim casing to body.
  7. Fit rear door aperture seal.
  8. Models with ICE headphone control panels: Position trim cap and connect multiplug to headphone control panel.
  9. Fit trim cap to trim casing and secure with screw.
  10. Fit 'D' post trim casing. Refer to «TRIM CASING - 'D' POST»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  11. Fit accessory socket.
  12. Models with third row seats: Fit third row seat. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/seats/#seats) .

Scheme 4

Scheme 4: Remove
Scheme 4: Remove
  1. Release front door aperture seal from 'B' post.
  2. Release rear door aperture seal from 'B' post.
  3. Remove cap from front seat belt lower anchorage bolt.
  4. Remove front seat belt lower anchorage bolt.
  5. Feed seat belt through trim casing.
  6. Remove trim casing.
  7. Remove sound insulation from trim casing.
  1. Fit sound insulation to trim casing.
  2. Feed front seat belt through trim casing.
  3. Fit front seat belt lower anchorage and tighten bolt to 32 Nm (24 lbf.ft).
  4. Fit cap to front seat belt lower anchorage bolt.
  5. Fit trim casing to 'B' post.
  6. Fit front door aperture seal to 'B' post.
  7. Fit rear door aperture seal to 'B' post.

Scheme 5

Scheme 5: Remove
Scheme 5: Remove
  1. Release front door aperture seal from 'B' post.
  2. Release rear door aperture seal from 'B' post.
  3. Move 'B' post upper trim casing aside.
  4. Release 3 clips securing lower trim casing to 'B' post.
  5. Remove lower trim casing.
  1. Fit lower trim casing to 'B' post and secure with clips.
  2. Position 'B' post upper trim casing to 'B' post.
  3. Fit front door aperture seal to 'B' post.
  4. Fit rear door aperture seal to 'B' post.

Scheme 6

Scheme 6: Remove
Scheme 6: Remove

Scheme 7

Scheme 7
Scheme 7
  1. Fold rear seat forward.
  2. Remove tail door aperture upper trim casing.
  3. Release caps from end of grab handle.
  4. Remove 2 bolts securing grab handle to body.
  5. Remove grab handle and collect two spacers.
  6. Remove 8 trim clips securing trim casing to body.
  7. Models with third row seats: Remove third row seat belt escutcheon. Remove cap from lower anchorage of third row seat belt. Remove lower anchorage bolt.
  8. Models with volumetric alarm: Release volumetric sensor from trim casing. Disconnect multiplug from volumetric sensor. Remove volumetric sensor.
  9. Remove rear seat belt blanking plate.
  10. Release 2 clips securing trim casing to body.
  11. Remove trim casing.
  1. Fit trim casing and secure with clips.
  2. Fit rear seat belt blanking plate.
  3. Models with volumetric alarm: Position volumetric sensor to trim casing and connect multiplug. Fit volumetric sensor to trim casing.
  4. Models with third row seats: Fit lower anchorage of third row seat belt and tighten bolt to 32 Nm (24 lbf.ft). Fit cap to lower anchorage bolt. Fit third row seat belt escutcheon to trim casing.
  5. Fit trim clips securing trim casing to body.
  6. Position grab handle and spacers to trim casing.
  7. Fit and tighten bolts securing grab handle to body to 3 Nm (2.2 lbf.ft).
  8. Close caps on ends of grab handle.
  9. Fit tail door aperture upper trim casing.
  10. Reposition rear seat.

Scheme 8

Scheme 8: Remove
Scheme 8: Remove

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
  1. Select position 'D', remove gear selector knob and collect spacer.
  2. Models from 03MY: Remove both center console cup holders.
  3. Release selector panel, disconnect multiplug and remove panel.
  4. Release clips securing transfer box lever gaiter to center console and remove knob and gaiter.
  5. Models with base trim: Remove rubber mat from center console and remove cover plate from switch pack.
  6. Models with base trim: Remove 4 screws securing switch pack to center console, disconnect multiplugs and remove switch pack.
  7. Models with veneer trim: Release veneered console cover and remove cigar lighter element. Disconnect multiplugs from switch pack and remove veneered console cover.
  8. Remove 2 bolts securing forward edge of console to transmission tunnel.
  9. Release handbrake gaiter from console.
  10. Remove clip and clevis pin securing cable to handbrake lever.
  11. Move handbrake to fully upward position.
  12. Release electric seat switches from console.
  13. Disconnect multiplugs from switches and remove.
  14. Remove 2 bolts securing rear of console to transmission tunnel.
  15. Release center console from fascia.
  16. Disconnect multiplug and bulb from cigar lighter.
  17. Remove console. NOTE: Do not carry out further dismantling if component is removed for access only.
  18. Remove 4 screws securing storage bin lid to console and remove lid.
  19. Release cigar lighter body from console and remove.
  1. Fit and secure cigar lighter body to console.
  2. Fit lid to console and secure with screws.
  3. Fit console.
  4. Connect multiplug and bulb to cigar lighter.
  5. Fit center console to fascia.
  6. Fit 2 bolts securing rear of console to transmission tunnel.
  7. Connect multiplugs to seat switches.
  8. Fit switches to console.
  9. Move handbrake to lowered position.
  10. Fit cable to handbrake and secure with clevis pin and clip.
  11. Fit handbrake gaiter to console.
  12. Fit bolts securing forward edge of console to transmission tunnel.
  13. Models with veneer trim: Position veneered console cover and connect multiplugs to switch pack. Fit cigar lighter element and secure veneered console cover to console.
  14. Models with base trim: Connect multiplugs to switch pack, fit switch pack to console and secure with screws.
  15. Models with base trim: Fit cover plate to switch pack, and rubber mat to console.
  16. Fit transfer box gaiter and knob to lever.
  17. Secure transfer box gaiter to console.
  18. Connect multiplug to selector panel, fit and secure panel to center console.
  19. Fit spacer and knob to gear selector lever.
  20. Models from 03MY: Fit both center console cup holders.

Scheme 14

Scheme 14: Remove
Scheme 14: Remove

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19
  1. Release clips securing gear lever gaiter to center console and remove knob and gaiter.
  2. Models from 03MY: Remove both center console cup holders.
  3. Release clips securing transfer box lever gaiter to center console and remove knob and gaiter.
  4. Models with base trim: Remove rubber mat from console and remove cover plate from switch pack.
  5. Models with base trim: Remove 4 screws securing switch pack to center console, disconnect multiplugs and remove switch pack.
  6. Models with veneer trim: Release veneered console cover from console and remove cigar lighter element. Disconnect multiplugs from switch pack and remove veneered console cover.
  7. Remove 2 bolts securing forward edge of console to transmission tunnel.
  8. Release handbrake gaiter from console.
  9. Remove clip and clevis pin securing cable to handbrake.
  10. Move handbrake to fully upward position.
  11. Release electric seat switches from console.
  12. Disconnect multiplugs from switches and remove.
  13. Remove 2 bolts securing rear of console to transmission tunnel.
  14. Release center console from fascia.
  15. Disconnect multiplug and bulb from cigar lighter.
  16. Remove console. NOTE: Do not carry out further dismantling if component is removed for access only.
  17. Remove 4 screws securing storage bin lid to console and remove lid.
  18. Release cigar lighter body from console and remove.
  1. Fit and secure cigar lighter body to console.
  2. Fit lid to console and secure with screws.
  3. Fit console.
  4. Connect multiplug and bulb to cigar lighter.
  5. Fit center console to fascia.
  6. Fit 2 bolts securing rear of console to transmission tunnel.
  7. Connect multiplugs to seat switches.
  8. Fit switches to console.
  9. Move handbrake to lowered position.
  10. Fit cable to handbrake and secure with clevis pin and clip.
  11. Fit handbrake gaiter to console.
  12. Fit bolts securing forward edge of console to transmission tunnel.
  13. Models with veneer trim: Position veneered console cover and connect multiplugs to switch pack. Fit cigar lighter element and secure veneered console cover to console.
  14. Models with base trim: Connect multiplugs to switch pack, fit switch pack to console and secure with screws.
  15. Models with base trim: Fit cover plate to switch pack, and rubber mat to console.
  16. Fit transfer gearbox gaiter and knob to lever.
  17. Secure gaiter to console.
  18. Fit knob and gaiter to gear lever and secure gear lever gaiter to console with clips.
  19. Models from 03MY: Fit both center console cup holders.

Scheme 20

Scheme 20: Remove
Scheme 20: Remove

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28
  1. Remove the key from the starter switch. Disconnect both battery leads, negative lead first. Wait ten minutes before starting work.
  2. Remove radio cassette player. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/entertainment-systems/#in-car-entertainment-ice) .
  3. Remove steering wheel. Refer to «REMOVAL»(/land-rover/discovery/l318-2002-2004/remont/manual-power-steering/#steering-system) .
  4. Remove steering column nacelle. Refer to «REMOVAL»(/land-rover/discovery/l318-2002-2004/remont/manual-power-steering/#steering-system) .
  5. Remove center console. For models with automatic gearbox: Refer to «CONSOLE - CENTRE - AUTOMATIC MODELS»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) . For models with manual gearbox: Refer to «CONSOLE - CENTRE - MANUAL MODELS»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  6. Remove 'A' post trim panels.
  7. Remove 6 clips securing both lower closing panels to fascia and remove closing panels.
  8. Remove mats from fascia.
  9. Remove 2 screws and release instrument cowl from 2 clips on fascia.
  10. Disconnect multiplugs from switches in instrument cowl and remove cowl.
  11. Remove 4 screws securing instrument pack to fascia.
  12. Disconnect 2 multiplugs from instrument pack and remove pack.
  13. Remove fascia access panel. Refer to «PANEL - FASCIA ACCESS - DRIVER'S SIDE»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  14. Remove 4 nuts securing fascia to steering column bracket.
  15. Disconnect 3 multiplugs connecting main body harness to fascia harness.
  16. Disconnect fascia harness multiplug from fuse box.
  17. Remove 4 bolts securing glove box and remove glove box.
  18. Models with A/C: Disconnect multiplug from heater controls.
  19. Models without A/C: Release temperature and air distribution control outer cables from clips on heater casing and disconnect inner cables from levers.
  20. Separate blue section from ICE multiplug.
  21. Release coaxial cables from fascia panel.
  22. Disconnect multiplug from passenger air bag.
  23. Disconnect multiplug from blower motor.
  24. Working through glove box aperture remove 2 bolts, or 4 bolts if passenger airbag module is fitted, securing fascia to body.
  25. Remove 4 bolts securing lower edge of fascia to mounting brackets on transmission tunnel.
  26. Remove 4 bolts securing lower edge of fascia to brackets on 'A' post.
  27. With assistance carefully remove fascia from vehicle.
  28. If renewing fascia, transfer components to new fascia as necessary.
  1. With assistance carefully fit fascia and tighten bolts securing lower edge of fascia to 26 Nm (19 lbf.ft).
  2. Tighten bolts securing fascia to body to 26 Nm (19 lbf.ft).
  3. Fit nuts securing fascia to steering column bracket to 11 Nm (8 lbf.ft).
  4. Secure coaxial cables to fascia and secure blue multiplug to main ICE multiplug.
  5. Models with A/C: Connect heater control multiplug.
  6. Models without A/C: Connect temperature and air distribution inner cables to heater control levers. Set temperature control knobs to fully hot, distribution knob to de-mist position and, with flap levers fully closed, secure outer cables to clips on heater casing.
  7. Connect multiplugs to blower motor and passenger air bag (where fitted).
  8. Fit glove box and secure with bolts.
  9. Connect fascia harness multiplugs to main harness and fuse box.
  10. Position instrument pack and connect multiplugs.
  11. Fit instrument pack to fascia and secure with screws.
  12. Position instrument cowl and connect multiplugs to switches.
  13. Fit cowl to clips on fascia and secure with screws.
  14. Fit fascia access panel. Refer to «PANEL - FASCIA ACCESS - DRIVER'S SIDE»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  15. Fit fascia lower closing panels and secure with clips.
  16. Fit fascia mats.
  17. Fit 'A' post trim panels.
  18. Fit center console For models with automatic gearbox: Refer to «CONSOLE - CENTRE - AUTOMATIC MODELS»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) . For models with manual gearbox: Refer to «CONSOLE - CENTRE - MANUAL MODELS»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  19. Fit steering column nacelle. Refer to «INSTALLATION»(/land-rover/discovery/l318-2002-2004/remont/manual-power-steering/#steering-system) .
  20. Fit steering wheel. Refer to «INSTALLATION»(/land-rover/discovery/l318-2002-2004/remont/manual-power-steering/#steering-system) .
  21. Fit radio cassette player. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/entertainment-systems/#in-car-entertainment-ice__refit) .
  22. Connect battery.

Scheme 29

Scheme 29: Remove
Scheme 29: Remove
  1. Carefully remove electric exterior mirror switch from auxiliary switch panel and disconnect multiplug.
  2. Models with headlamp levelling: Release knob and remove nut securing headlamp levelling switch to auxiliary switch panel.
  3. Release 2 fasteners and open fascia access panel.
  4. Models with headlamp levelling: Remove headlamp levelling switch from auxiliary switch panel and disconnect multiplug.
  5. Models with A/C: Remove 2 screws securing in-car temperature sensor to auxiliary switch panel.
  6. Models with A/C: Disconnect multiplug from in-car temperature sensor and remove from auxiliary switch panel.
  7. Release 2 clips securing auxiliary switch panel to fascia and remove panel.
  1. Position auxiliary switch panel to fascia and clip into position.
  2. Models with A/C: Connect multiplug to in-car temperature sensor.
  3. Models with A/C: Position in-car temperature sensor to auxiliary switch panel and secure with screws.
  4. Models with headlamp levelling: Position headlamp levelling switch to auxiliary switch panel and secure with nut.
  5. Models with headlamp levelling: Replace cap and connect multiplug to headlamp levelling switch.
  6. Connect multiplug to exterior mirror switch and fit switch to auxiliary switch panel.

Scheme 30

Scheme 30: 76.46.40 Panel - fascia access - driver's side
Scheme 30: 76.46.40 Panel - fascia access - driver's side

Remove

  1. Remove 4 bolts securing fascia access panel to fascia.
  2. Release 2 quarter turn screws securing fascia access panel to fascia.
  3. Remove fascia access panel.
  1. Position fascia access panel to fascia and secure with quarter turn screws.
  2. Position base of fascia access panel to fascia and secure with bolts.

Scheme 31

Scheme 31: Remove
Scheme 31: Remove
  1. Remove coin tray and ash tray.
  2. Remove 6 screws securing drink tray assembly to fascia.
  3. Remove drink tray.
  1. Position drink tray assembly to fascia and secure with screws.
  2. Fit ash tray and coin tray to drink tray assembly.

Scheme 32

Scheme 32: Remove
Scheme 32: Remove

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38
  1. Remove radio cassette player from fascia. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/entertainment-systems/#in-car-entertainment-ice) .
  2. Carefully release and remove radio DIN socket from louvre panel.
  3. Remove screw cover from radio aperture.
  4. Remove drink tray assembly. Refer to «DRINK TRAY ASSEMBLY - CENTRE FASCIA»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  5. Carefully release clock assembly from louvre panel.
  6. Disconnect multiplugs from clock and door locking switch. Remove clock assembly.
  7. Carefully release switch pack from louvre panel.
  8. Disconnect multiplugs from switches and remove switch pack.
  9. Models without A/C: Carefully remove blower speed and heater control knobs.
  10. Models without A/C: Remove 2 screws securing heater control panel graphic plate and remove graphic plate.
  11. Models without A/C: Remove 4 screws securing heater control panel to louvre panel.
  12. Models with A/C: Carefully release ATC ECU from louvre panel, disconnect multiplugs and remove ATC ECU.
  13. Loosen 2 upper screws and remove 4 remaining screws securing louvre panel to fascia.
  14. Remove louvre panel assembly.
  15. Remove seals from face level vents.
  1. Fit seals to face level vents on new louvre panel.
  2. Fit louvre panel to fascia and secure with screws.
  3. Models with A/C: Connect multiplugs to ATC ECU and fit ATC ECU to fascia.
  4. Models without A/C: Fit screws securing heater control panel to louvre panel.
  5. Models without A/C: Fit heater control panel graphic plate and secure with screws.
  6. Models without A/C: Fit blower speed and heater control knobs.
  7. Position switch pack, connect multiplugs to switches and fit switch pack to louvre panel.
  8. Position clock assembly, connect multiplug to clock and door locking switch and fit clock assembly to louvre panel.
  9. Fit drinks tray. Refer to «DRINK TRAY ASSEMBLY - CENTRE FASCIA»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  10. Fit and secure radio DIN socket.
  11. Fit screw cover to radio aperture.
  12. Fit radio cassette player. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/entertainment-systems/#in-car-entertainment-ice__refit) .

Scheme 39

Scheme 39: Remove
Scheme 39: Remove

Scheme 40

Scheme 40
Scheme 40
  1. Models with premium ICE: Remove power amplifier. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/entertainment-systems/#in-car-entertainment-ice) .
  2. Models with premium ICE: Remove CD autochanger. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/entertainment-systems/#in-car-entertainment-ice) .
  3. Remove center console. For models with manual gearbox: Refer to «CONSOLE - CENTRE - MANUAL MODELS»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) . For models with automatic gearbox: Refer to «CONSOLE - CENTRE - AUTOMATIC MODELS»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  4. Remove both lower 'A' post trim panels.
  5. Remove finisher from both front carpet retainers.
  6. Remove 8 screws securing front carpet retainers to floor.
  7. Remove front carpet retainers.
  8. Remove 2 nuts securing main body harness to transmission tunnel.
  9. With assistance release and remove carpet.
  1. With assistance position carpet.
  2. Secure main body harness to transmission tunnel with nuts.
  3. Position front carpet retainers and secure to floor with screws.
  4. Fit finishers to front carpet retainers
  5. Fit both lower 'A' post trim panels.
  6. Fit center console. For models with manual gearbox: Refer to «CONSOLE - CENTRE - MANUAL MODELS»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) . For models with automatic gearbox: Refer to «CONSOLE - CENTRE - AUTOMATIC MODELS»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  7. Models with premium ICE: Fit CD autochanger. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/entertainment-systems/#in-car-entertainment-ice) .
  8. Models with premium ICE: Fit power amplifier. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/entertainment-systems/#in-car-entertainment-ice) .

Scheme 41

Scheme 41: Remove
Scheme 41: Remove

Scheme 42

Scheme 42
Scheme 42
  1. Models with premium ICE: Remove power amplifier. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/entertainment-systems/#in-car-entertainment-ice) .
  2. Remove RH front seat. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/seats/#seats__remove) .
  3. Remove both 'B' post lower trim panels. Refer to «TRIM CASING - LOWER - 'B' POST»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  4. Remove finishers from front and rear carpet retainers.
  5. Remove 12 screws securing front and rear carpet retainers to floor.
  6. Remove front and rear carpet retainers.
  7. Remove 4 screws securing trim panel to rear of center console.
  8. Remove trim panel.
  9. Position harnesses clear of rear carpet.
  10. Remove rear carpet.
  1. Position new rear carpet.
  2. Fit front and rear carpet retainers to floor and secure with screws.
  3. Fit finishers to front and rear carpet retainers
  4. Position trim panel to rear of center console and secure with screws.
  5. Fit lower 'B' post trim panels. Refer to «TRIM CASING - LOWER - 'B' POST»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  6. Fit RH front seat to floor. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/seats/#seats__refit) .
  7. Models with premium ICE: Fit power amplifier. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/entertainment-systems/#in-car-entertainment-ice) .

Scheme 43

Scheme 43: Remove
Scheme 43: Remove
  1. Remove both rear seat belt lower fixings.
  2. Models with third row seats: Remove both third row seats. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/seats/#seats) .
  3. Remove both loadspace side trim casings. Refer to «TRIM CASING - SIDE - LOADSPACE»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  4. Models with third row seats: Remove 4 screws and remove both seat lower mounting escutcheons.
  5. Recline rear seats fully forward.
  6. Remove finisher from loadspace carpet retainer.
  7. Remove 6 screws securing loadspace carpet retainer to floor and remove retainer.
  8. Remove loadspace carpet.
  1. Position loadspace carpet to floor.
  2. Position loadspace carpet retainer to floor and secure with screws.
  3. Fit finisher to loadspace carpet retainer
  4. Return rear seats to their normal position.
  5. Models with third row seats: Position both third row seats lower mounting escutcheons to floor and secure with screws.
  6. Fit both loadspace side trim casings. Refer to «TRIM CASING - SIDE - LOADSPACE»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  7. Models with third row seats: Fit both third row seats. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/seats/#seats) .
  8. Position both rear seat belt lower mountings and secure with bolts tightened to 32 Nm (24 lbf.ft).

Scheme 44

Scheme 44: Remove
Scheme 44: Remove

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50
  1. Remove both 'D' post trim casings. Refer to «TRIM CASING - 'D' POST»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  2. Remove both 'B' post upper trim casings. Refer to «TRIM CASING - UPPER - 'B' POST»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  3. Release clips securing both 'A' post trim casings.
  4. Models with premium ICE: Disconnect multiplugs from 'A' post speakers.
  5. Remove both 'A' post trim casings.
  6. Remove 3 screws securing sun visor to headlining.
  7. Release sun visor from clip.
  8. Disconnect multiplug from sun visor.
  9. Remove sun visor.
  10. Repeat process for second sun visor.
  11. Remove access panel from front edge of front stowage pocket.
  12. Remove screw securing front stowage pocket to headlining.
  13. Remove lens from front interior lamp.
  14. Remove 2 nuts securing front interior lamp to headlining.
  15. Disconnect multiplug from front interior lamp.
  16. Remove front interior lamp.
  17. Remove 10 screws securing front stowage pocket to headlining.
  18. Disconnect 3 multiplugs from sunroof switches.
  19. Remove front stowage pocket.
  20. Remove caps from sun visor clips.
  21. Remove screws and release both sun visor clips.
  22. Remove tail door aperture upper trim casing.
  23. Remove rear sunroof aperture trim.
  24. Remove front sunroof aperture trim.
  25. Release end caps from all grab handles.
  26. Remove 2 bolts securing each grab handle to roof.
  27. Remove all 4 grab handles.
  28. Models with volumetric alarm: Release front volumetric sensor from headlining and disconnect multiplug.
  29. Models with rear A/C: Release rear A/C control panel from headlining. Disconnect 2 multiplugs and 2 Lucar connectors from rear A/C control panel. Remove rear A/C control panel.
  30. Release rear interior lamp from headlining and disconnect multiplug.
  31. Remove rear interior lamp.
  32. Remove 2 clips securing rear of headlining to roof.
  33. Release rear sunroof switch from headlining.
  34. Disconnect multiplug and remove rear sunroof switch.
  35. Remove screw securing headlining to roof.
  36. With assistance, remove headlining.
  37. Models with rear A/C: Remove foam pads from air vents. Release 2 rear air vents from headlining. Release 3 central air vents from headlining.
  38. Remove 7 nuts securing each stowage pocket to headlining and collect mounting plates.
  39. Remove both pockets from headlining.
  40. Remove 8 screws securing rear console to headlining and collect 3 mounting plates.
  41. Remove rear console from headlining.
  1. Fit rear console and mounting plates to headlining.
  2. Fit and tighten nuts securing rear console to headlining.
  3. Fit both stowage pockets and mounting plates to headlining.
  4. Fit and tighten nuts securing stowage pockets to headlining.
  5. Models with rear A/C: Fit 3 central air vents to headlining. Fit 2 rear air vents to headlining. Fit foam pads to air vents.
  6. With assistance, position headlining in vehicle.
  7. Fit and tighten screw securing center of headlining to roof.
  8. Connect multiplug to rear sunroof switch.
  9. Fit rear sunroof switch to rear console.
  10. Fit clips securing rear edge of headlining to sunroof.
  11. Position rear interior lamp to headlining and connect multiplug.
  12. Fit rear interior lamp to headlining.
  13. Models with rear A/C: Position rear A/C control panel to headlining and connect multiplugs and Lucar connectors. Fit rear A/C control panel to headlining.
  14. Models with volumetric alarm: Connect multiplug to front volumetric sensor and fit sensor to headlining.
  15. Fit grab handles to headlining and secure with bolts.
  16. Fit end caps to grab handles.
  17. Fit front sunroof aperture trim.
  18. Fit rear sunroof aperture trim.
  19. Fit tail door aperture upper trim casing.
  20. Fit sun visor clips to headlining and secure with screws.
  21. Fit caps to sun visor clips.
  22. Position front stowage pocket to headlining and connect multiplugs to sunroof switches.
  23. Fit and tighten 10 screws securing front stowage pocket to headlining.
  24. Connect multiplug to front interior lamp.
  25. Fit front interior lamp to headlining and secure with nuts.
  26. Fit lens to front interior lamp.
  27. Fit and tighten screw securing front stowage pocket to headlining.
  28. Fit access panel to front edge of front stowage pocket.
  29. Position sun visor to headlining and secure to clip.
  30. Connect multiplug to sun visor.
  31. Fit and tighten screws securing sun visor to headlining.
  32. Repeat process for second sun visor.
  33. Models with premium ICE: Position both 'A' post trim casings and connect multiplugs to speakers.
  34. Fit both trim casings to 'A' posts and secure with clips.
  35. Fit both 'B' post upper trim casings. Refer to «TRIM CASING - UPPER - 'B' POST»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
  36. Fit both 'D' post trim casings. Refer to «TRIM CASING - 'D' POST»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .

Scheme 51

Scheme 51: Remove
Scheme 51: Remove

Scheme 52

Scheme 52
Scheme 52
  1. Remove access panel from front edge of front stowage pocket.
  2. Remove screw securing front stowage pocket to headlining.
  3. Remove lens from front interior lamp.
  4. Remove 2 nuts securing front interior lamp to headlining.
  5. Disconnect multiplug from front interior lamp.
  6. Remove front interior lamp.
  7. Remove 10 screws securing front stowage pocket to headlining.
  8. Disconnect 3 multiplugs from sunroof switches.
  9. Remove front stowage pocket.
  10. Release clips securing sunroof switch pack.
  11. Remove switch pack.
  1. Fit sunroof switch pack to front stowage pocket and secure with clips.
  2. Position front stowage pocket to headlining and connect multiplugs to sunroof switches.
  3. Fit and tighten 10 screws securing front stowage pocket to headlining.
  4. Connect multiplug to front interior lamp.
  5. Fit front interior lamp to headlining and secure with nuts.
  6. Fit lens to front interior lamp.
  7. Fit and tighten screw securing front of front stowage pocket to headlining.
  8. Fit access panel to front stowage pocket.

See also:
• REMOVE
• REMOVE
• REMOVAL
• REFIT
• REMOVE
• REFIT
• TRIM CASING - 'D' POST
