GENERATOR SPECIFICATIONS
| Application | Specification | ||
|---|---|---|---|
| Brush Length | |||
| Discovery | |||
| Standard | 0.67" (17.0 mm) | ||
| Limit | 0.20" (5.0 mm) | ||
| Discovery Series II & Range Rover | — | ||
| Generator Speed | |||
| Discovery | 6000 RPM | ||
| Discovery Series II & Range Rover | — | ||
| Maximum Output | |||
| Discovery | 100 Amps | ||
| Discovery Series II | 130 Amps | ||
| Range Rover | 150 Amps | ||
| Regulator Voltage | |||
| Discovery | 13.6-14.4 Volts | ||
| Discovery Series II & Range Rover | — | ||
GENERATOR SPECIFICATIONS
TORQUE SPECIFICATIONS
| Applications | Ft. Lbs. (N.m) | |
|---|---|---|
| Drive Belt Tensioner Bolt | 37 (50) | |
| Generator Leads | ||
| B+ nut | 13 (18) | |
| Generator Mounting Bolts | ||
| Discovery Series II | 33 (45) | |
| Range Rover | 18 (24) | |
| Generator Pulley Nut | ||
| Discovery Series II | 59 (80) | |
| Range Rover | 30 (41) | |
| INCH Lbs. (N.m) | ||
| Generator Leads | ||
| D+ nut | 44 (5) | |
TORQUE SPECIFICATIONS
