TIMING BELT

1. Check the belt for oil or dust deposits. Replace, if necessary. Small deposits should be wiped away with a dry cloth or paper. Do not clean with solvent.
2. When the engine is overhauled or belt tension adjusted, check the carefully. If any damage is found, replace the belt. NOTE: Do not bend, twist or turn the timing belt inside out. Do not allow timing belt to come into contact with oil, water and steam.

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

1. Install the camshaft sprocket and tighten the bolt to the specified torque. Temporarily install the camshaft sprocket bolt (C). Hold the portion (A) of the camshaft with a hexagonal wrench, and tighten the bolt (C) with a wrench (B). Tightening torque: 98.1 - 117.7 N.m (10 - 12 kgf.m, 72.3 - 86.8 lb-ft)
2. Install the cylinder head cover. Install the cylinder head cover (A) and bolts (B). Tightening torque: 7.8 - 9.8 N.m (0.8 - 1.0 kgf.m, 5.8 - 7.2 lb-ft) Install the PCV (Positive Crankcase Ventilation) hose (A) and breather hose (B) to the cylinder head cover. Install the accelerator cable (A) to the cylinder head cover. Install the spark plug cables.
3. Install the crankshaft sprocket (A).
4. Align the timing marks of the camshaft sprocket (A) and crankshaft sprocket (B) with the No. 1 piston placed at top dead center and its compression stroke.
5. Install the idler pulley (A) and tighten the bolt (B) to the specified torque. Tightening torque: 42.2 - 53.9 N.m (4.3 - 5.5 kgf.m, 31.1 - 39.8 lb-ft)
6. Install the timing belt tensioner loosely enough for the adjuster to rotate. Make sure that the stopper of base is leaning against the lowering sealing cap on the cylinder head.
7. Belt so as not give slack at each center of shaft. Do as following procedures when installing timing belt. Crankshaft sprocket (A) --> Idler pulley (B) --> Camshaft sprocket (C) --> timing belt tensioner (D). (The tensioner can be installed after the timing belt.)
8. Check the alignment of the timing marks on each sprocket.
9. Remove the pin fixing the tensioner arm.
10. Using a hex wrench, turn the adjuster counterclockwise to make the indicator of the arm(A) located at the center of the base notch.
11. Tightening tensioner bolt with fixing the indicator not to move. Tightening torque Tensioner bolt : 22.6 ~ 28.4Nm (2.3 ~ 2.9kgf.m, 16.6 ~ 21.0lb-ft)
12. Turn the crankshaft two turns in the operating direction (Clockwise) and realign crankshaft sprocket and camshaft sprocket timing mark.
13. If the indicator is not located at the center of base, slacken the bolt and repeat the abore procedure.
14. Install the timing belt lower cover (A) with 5 bolts (B). Tightening torque: 7.8 - 9.8 N.m (0.8 - 1.0k gf.m, 5.8 - 7.2 lb-ft)
15. Install the flange and crankshaft pulley (A), and then tighten crankshaft pulley bolt (B). Make sure that the crankshaft sprocket pin fits into the small hole in the pulley. Tightening torque: 166.7 - 176.5 N.m (17 - 18 kgf.m, 123.0 - 130.2 lb-ft)
16. Install the timing belt upper cover (A) with bolts (B). Tightening torque: 7.8 - 9.8 N.m (0.8 - 1.0 kgf.m, 5.8 - 7.2 lb-ft)
17. Install the water pump pulley and 4 bolts.
18. Install the power steering pump drive belt. ( «CHECKING POWER STEERING BELT TENSION»(ref-355472-S09851128832010012500000) )
19. Install the air conditioner compressor drive belt. (See «HEATING, VENTILATION & AIR CONDITIONING»(ref-355471) )
20. Install the alternator drive belt. (See «CHARGING SYSTEM»(ref-355470) )
21. Tighten the bolts of water pump pulley.
22. Install the engine mounting support bracket. Install the engine mounting support bracket stay plate (A) with bolt (B). Tightening torque: 42.2 - 53.9 N.m (4.3 - 5.5 kgf.m, 31.1 - 39.8 lb-ft) Install the engine mounting support bracket (A) with nuts (C, D) and bolt (B). Tightening torque: Nut (D): 58.8 - 78.5 N.m (6.0 - 8.0 kgf.m, 43.4 - 57.9 lb-ft) Nut (C) and bolt (B): 49.0 - 63.7 N.m (5.0 - 6. 5kgf.m, 36.2 - 47.0 lb-ft)
23. Install the RH side cover (A) with 2 bolts (B).
24. Install the RH front wheel. Tightening torque: 88.3 - 98.1 N.m (9.0 - 10.0 kgf.m, 65.1 - 72.3 lb-ft)
25. Install the engine cover with bolts. Tightening torque: 3.9 - 5.9 N.m (0.4 - 0.6 kgf.m, 2.9 - 4.3 lb-ft)
